Inspection Procedure
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | INSPECT POWER SUPPLY CIRCUIT OF DISCHARGE HEADLIGHT CONTROL MODULE Disconnect the discharge headlight control module connector. Turn the light switch to the HEAD (LO) position. Measure the voltage at discharge headlight control module connector (harness-side) terminal A. Is the voltage approx. 12 V ? | Yes | Go to Step 6. |
| No | Go to the next step. | ||
| 2 | INSPECT FUSE Turn the light switch to the OFF position. Remove the HEAD LO 10 A fuse or HEAD LO LH 10 A fuse. Inspect the fuses. Are the fuses normal? | Yes | Go to the next step. |
| No | Replace the fuse. | ||
| 3 | INSPECT HEADLIGHT RELAY Remove the headlight relay. (See RELAY LOCATION .) Inspect the headlight relay. (See RELAY INSPECTION .) Is the headlight low relay normal? | Yes | Go to the next step. |
| No | Replace the headlight relay. (See RELAY LOCATION .) | ||
| 4 | INSPECT LIGHT SWITCH Inspect the light switch. (See LIGHT SWITCH INSPECTION .) Is the light switch normal? | Yes | Go to the next step. |
| No | Replace the light switch. (See LIGHT SWITCH REMOVAL/INSTALLATION .) | ||
| 5 | INSPECT WIRING HARNESS BETWEEN BATTERY AND DISCHARGE HEADLIGHT CONTROL MODULE Disconnect the negative battery cable. Inspect for continuity between the following terminals: Positive battery-headlight relay terminal D HEAD LO RH 10 A fuse-discharge headlight control module terminal A HEAD LO LH 10 A fuse-discharge headlight control module terminal A Are the wiring harnesses normal? | Yes | Go to the next step. |
| No | Replace the related wiring harness. | ||
| 6 | INSPECT WIRING HARNESS BETWEEN DISCHARGE HEADLIGHT CONTROL MODULE AND GROUND Inspect wiring harness between discharge headlight control module terminal B and ground for following: Short to power supply Open circuit Is the wiring harness normal? | Yes | Go to the next step. |
| No | Replace the related wiring harness. | ||
| 7 | VERIFY WHETHER MALFUNCTION IS IN DISCHARGE HEADLIGHT OR DISCHARGE HEADLIGHT CONTROL MODULE Install any other discharge headlight. (See HEADLIGHT BULB REMOVAL/INSTALLATION .) Connect the discharge headlight control module connector. Turn the light switch to the HEAD (LO) position. Does the headlight (low-beam) illuminate? | Yes | Replace the discharge headlight. (See HEADLIGHT BULB REMOVAL/INSTALLATION .) |
| No | Replace the discharge headlight control module. (See DISCHARGE HEADLIGHT CONTROL MODULE REMOVAL/INSTALLATION .) | ||
AUTO LIGHT-OFF CONTROL MODULE INSPECTION
- Measure the voltage at the auto light-off control module terminals as indicated below.
Identifying Auto Light-Off Control Module Connector Terminals. Scheme 3
| Terminal | Signal | Connection | Test condition | Voltage (V) | Action | |
|---|---|---|---|---|---|---|
| 1A (1) | Headlight high (RH) operation | Headlight high (RH) | Switch the ignition to ON | Light switch at HEAD position and dimmer switch at the HI position | B+ | RH headlight Related wiring harnesses |
| Light switch at HEAD position and dimmer switch at the LO position | 1.0 or less | |||||
| DRL mode | Approx 6.0 | |||||
| 1B (1) | Headlight high (LH) operation | Headlight high (LH) | Switch the ignition to ON | Light switch at HEAD position and dimmer switch at the HI position | B+ | LH headlight Related wiring harnesses |
| Light switch at HEAD position and dimmer switch at the LO position | 1.0 or less | |||||
| DRL mode | Approx 6.0 | |||||
| 1C | ||||||
| 1D | ||||||
| 1E | ||||||
| 1F | ||||||
| 1G (1) | GND | GND | Under any condition | 1.0 or less | Related wiring harnesses | |
| 1H | ||||||
| 1I (1) | Power supply | DRL 20 A fuse | Under any condition | B+ | DRL 20 A fuse Related wiring harnesses | |
| 1J | ||||||
| 1K (1) | Headlight high operation | Headlight high | Switch the ignition to ON | DRL mode | B+ | LH headlight Related wiring harnesses |
| Other | 1.0 or less | |||||
| 1L | Headlight high on/off | Light switch | Switch the ignition to ON | Light switch at HEAD position and dimmer switch at the HI position | 1.0 or less | Light switch (See LIGHT SWITCH INSPECTION .) Related wiring harnesses |
| Light switch at HEAD position and dimmer switch at the LO position | B+ | |||||
| 2A | ||||||
| 2B | Sensitivity adjustment volume | Windshield wiper and washer switch | Switch the ignition to ON | Sensitivity adjustment volume turned from + position to - position | 0 --> 0.8 --> 1.4 --> 1.8 --> 2.2 | Windshield wiper and washer switch (See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION .) Related wiring harnesses |
| 2C | IG1 | METER IG 15 A fuse | Switch the ignition to ON | B+ | METER IG 15 A fuse Related wiring harnesses | |
| Switch the ignition from off or ACC. | 1.0 or less | |||||
| 2D | Power supply | ROOM 15 A fuse | Under any condition | B+ | ROOM 15 A fuse Related wiring harnesses | |
| 2E | ||||||
| 2F | DLC-2 power supply | DLC-2 | Under any condition | B+ | Related wiring harnesses | |
| 2G | TNS relay operation | TNS relay | Light switch at TNS or HEAD position | 1.0 or less | TNS relay (See RELAY INSPECTION .) Related wiring harnesses | |
| Light switch at OFF | B+ | |||||
| 2H | ||||||
| 2I | Front fog light relay operation | Front fog light relay | Light switch at the headlight position and dimmer switch at LO | Front fog light switch at ON position | 1.0 or less | Front fog light relay (See RELAY INSPECTION .) Related wiring harnesses |
| Front fog light switch at OFF position | B+ | |||||
| 2J | Front fog switch on/off | Front fog Light switch | Light switch at the headlight position and dimmer switch at LO | Front fog light switch at ON position | 1.0 or less | Light switch (See FRONT FOG LIGHT SWITCH INSPECTION .) Related wiring harnesses |
| Front fog light switch at OFF position | B+ | |||||
| 2K | Headlight relay operation | Headlight relay | Light switch at HEAD position | 1.0 or less | Headlight relay (See RELAY INSPECTION .) Related wiring harnesses | |
| Light switch at OFF or TNS position | B+ | |||||
| 2L | ||||||
| 2M | TNS switch on/off | Light switch | Switch the ignition to ON | Light switch at TNS or HEAD position | 1.0 or less | Light switch (See LIGHT SWITCH INSPECTION .) Related wiring harnesses |
| Light switch at OFF position | B+ | |||||
| 2N | Light switch on/off | Light switch | Switch the ignition to ON | Light switch at HEAD position | 1.0 or less | Light switch (See LIGHT SWITCH INSPECTION .) Related wiring harnesses |
| Light switch at OFF or TNS position | B+ | |||||
| 2O | GND | GND | Under any condition | 1.0 or less | Related wiring harnesses | |
| 2P (1) | Parking brake switch on/off | BCM Parking brake switch | Switch the ignition to ON | Parking brake switch on | 1.0 or less | BCM (See BODY CONTROL MODULE (BCM) INSPECTION .) Parking brake switch Related wiring harnesses |
| Parking brake switch OFF | B+ | |||||
| (1) With DRL only. | ||||||
| (1) | With DRL only. |
DRL And Auto Light System Wiring Diagram. Scheme 4
AUTO LIGHT/WIPER CONTROL MODULE INSPECTION
- Measure the voltage at the auto light/wiper control module terminals as indicated below.
Identifying Auto Light/Wiper Control Module Connector Terminals. Scheme 5
| Terminal | Signal | Connection | Test condition | Voltage (V) | Action | |
|---|---|---|---|---|---|---|
| 1A (1) | Headlight high (RH) operation | Headlight high (RH) | Switch the ignition to ON | Light switch at HEAD position and dimmer switch at the HI position | B+ | RH headlight Related wiring harnesses |
| Light switch at HEAD position and dimmer switch at the LO position | 1.0 or less | |||||
| DRL mode | Approx 6.0 | |||||
| 1B (1) | Headlight high (LH) operation | Headlight high (LH) | Switch the ignition to ON | Light switch at HEAD position and dimmer switch at the HI position | B+ | LH headlight Related wiring harnesses |
| Light switch at HEAD position and dimmer switch at the LO position | 1.0 or less | |||||
| DRL mode | Approx 6.0 | |||||
| 1C | Autostop switch signal | Autostop switch | Switch the ignition to ON | Windshield wiper switch at LO position | Alternates between 1.0 or less and B+ | Autostop switch (Windshield wiper motor) (See WINDSHIELD WIPER MOTOR INSPECTION .) Related wiring harnesses |
| Windshield wiper switch at OFF position | 1.0 or less | |||||
| 1D | Windshield wiper switch signal (OFF) | Windshield wiper and washer switch | Switch the ignition to ON | Windshield wiper switch at LO position | Alternates between 1.0 or less and B+ | Windshield wiper and washer switch (See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION .) Related wiring harnesses |
| Windshield wiper switch at OFF position | 1.0 or less | |||||
| 1E | IG2 | WIPER 25 A fuse | Switch the ignition to ON | B+ | WIPER 25 A fuse Related wiring harnesses | |
| Switch the ignition from off or ACC. | 1.0 or less | |||||
| 1F | Windshield wiper switch signal (HI) | Windshield wiper and washer switch | Switch the ignition to ON | Windshield wiper switch at HI position | B+ | Windshield wiper and washer switch (See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION .) Related wiring harnesses |
| Windshield wiper switch at OFF position | 1.0 or less | |||||
| 1G (1) | GND | GND | Under any condition | 1.0 or less | Related wiring harnesses | |
| 1H | Windshield wiper switch signal (AUTO) | Windshield wiper and washer switch | Switch the ignition to ON | Windshield wiper switch at AUTO position | B+ | Windshield wiper and washer switch (See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION .) Related wiring harnesses |
| Windshield wiper switch at OFF position | 1.0 or less | |||||
| 1I (1) | Power supply | DRL 20 A fuse | Under any condition | B+ | DRL 20 A fuse Related wiring harnesses | |
| 1J | Washer switch signal | Windshield wiper and washer switch | Switch the ignition to ON | Washer switch at ON position | B+ | Windshield wiper and washer switch (See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION .) Related wiring harnesses |
| Washer switch at OFF position | 1.0 or less | |||||
| 1K (1) | Headlight high operation | Headlight high | Switch the ignition to ON | DRL mode | B+ | LH headlight Related wiring harnesses |
| Other | 1.0 or less | |||||
| 1L | Headlight high on/off | Light switch | Switch the ignition to ON | Light switch at HEAD position and dimmer switch at the HI position | 1.0 or less | Light switch (See LIGHT SWITCH INSPECTION .) Related wiring harnesses |
| Light switch at HEAD position and dimmer switch at the LO position | B+ | |||||
| 2A | Vehicle speed signal input | Instrument cluster | Because this terminal is for communication, good/no good judgment by terminal voltage is not possible. | Instrument cluster (See INSTRUMENT CLUSTER INSPECTION .) Related wiring harnesses | ||
| 2B | Sensitivity adjustment volume | Windshield wiper and washer switch | Switch the ignition to ON | Sensitivity adjustment volume turned from + position to - position | 0 --> 0.8 --> 1.4 --> 1.8 --> 2.2 | Windshield wiper and washer switch (See WINDSHIELD WIPER AND WASHER SWITCH INSPECTION .) Related wiring harnesses |
| 2C | IG1 | METER IG 15 A fuse | Switch the ignition to ON | B+ | METER IG 15 A fuse Related wiring harnesses | |
| Switch the ignition from off or ACC. | 1.0 or less | |||||
| 2D | Power supply | ROOM 15 A fuse | Under any condition | B+ | ROOM 15 A fuse Related wiring harnesses | |
| 2E | Wiper or headlight operation request | Rain sensor | Because this terminal is for communication, good/no good judgment by terminal voltage is not possible. | Rain sensor Related wiring harnesses | ||
| 2F | DLC-2 power supply | DLC-2 | Under any condition | B+ | Related wiring harnesses | |
| 2G | TNS relay operation | TNS relay | Light switch at TNS or HEAD position | 1.0 or less | TNS relay (See RELAY INSPECTION .) Related wiring harnesses | |
| Light switch at OFF | B+ | |||||
| 2H | ||||||
| 2I | Front fog light relay operation | Front fog light relay | Light switch at the headlight position and dimmer switch at LO | Front fog light switch at ON position | 1.0 or less | Front fog light relay (See RELAY INSPECTION .) Related wiring harnesses |
| Front fog light switch at OFF position | B+ | |||||
| 2J | Front fog switch on/off | Front fog Light switch | Light switch at the headlight position and dimmer switch at LO | Front fog light switch at ON position | 1.0 or less | Light switch (See FRONT FOG LIGHT SWITCH INSPECTION .) Related wiring harnesses |
| Front fog light switch at OFF position | B+ | |||||
| 2K | Headlight relay operation | Headlight relay | Light switch at HEAD position | 1.0 or less | Headlight relay (See RELAY INSPECTION .) Related wiring harnesses | |
| Light switch at OFF or TNS position | B+ | |||||
| 2L | Light switch signal | Light switch | Switch the ignition to ON | Light switch at AUTO position | 1.0 or less | Light switch (See LIGHT SWITCH INSPECTION .) Related wiring harnesses |
| Other | B+ | |||||
| 2M | TNS switch on/off | Light switch | Switch the ignition to ON | Light switch at TNS or HEAD position | 1.0 or less | Light switch (See LIGHT SWITCH INSPECTION .) Related wiring harnesses |
| Light switch at OFF position | B+ | |||||
| 2N | Light switch on/off | Light switch | Switch the ignition to ON | Light switch at HEAD position | 1.0 or less | Light switch (See LIGHT SWITCH INSPECTION .) Related wiring harnesses |
| Light switch at OFF or TNS position | B+ | |||||
| 2O | GND | GND | Under any condition | 1.0 or less | Related wiring harnesses | |
| 2P (1) | Parking brake switch on/off | BCM Parking brake switch | Switch the ignition to ON | Parking brake switch on | 1.0 or less | BCM (See BODY CONTROL MODULE (BCM) INSPECTION .) Parking brake switch Related wiring harnesses |
| Parking brake switch OFF | B+ | |||||
| (1) With DRL only. | ||||||
| (1) | With DRL only. |
Scheme 6
- Connect the M-MDS (IDS) to the DLC-2. (Scheme 6): Identifying DLC-2
- After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Module Programming".
- Then, select items from the screen menu in the following order. Select "Programmable Module Installation". Select "LCM".
- Perform the configuration according to the directions on the screen.
- Retrieve DTCs by the M-MDS, then verify that there is no DTC present. If a DTC (s) is detected, perform the applicable DTC inspection. (See «DTC INSPECTION [AUTO LIGHT/WIPER CONTROL MODULE]»(ref-581704-S20555176972013101400000).)
Scheme 7
- Connect the M-MDS (IDS) to DLC-2. (Scheme 7): Identifying DLC-2
- After the vehicle is identified, select the following items from the initial screen of the IDS. Select the "Module Programming". Select the "LCM".
- Select an item name, and then select option.
| M-MDS display | Function | Initial setting | Setting content | Control unit |
|---|---|---|---|---|
| Autolamp On Setting | The auto light system sensitivity can be adjusted. | Standard (Except Japan) | Extra Low (Except Japan)/Low (Except Japan)/Standard (Except Japan)/High (Except Japan)/Extra High (Except Japan) | Auto light/wiper control module |
| Headlamp auto-on timer | The elapsed time between the detection of darkness and the headlights turning on can be adjusted. | 15s | 0s, 5s, 10s, 15s, 20s | Auto light/wiper control module |
| Headlamp auto-off timer | The elapsed time between the ignition being switched off and the headlights turning off can be adjusted. | 30s | 0s, 30s, 60s, 120s | Auto light/wiper control module |
| Auto Wiper and Auto Light request | The auto light/wiper system function can be set. | Auto Light Enable/Auto Wiper Enable | "Auto Light Disable/Auto Wiper Disable" / "Auto Light Disable/Auto Wiper Enable" / "Auto Light Enable/Auto Wiper Disable" / "Auto Light Enable/Auto Wiper Enable" | Auto light/wiper control module |
Note. Other than the above conditions, an "Japan Only" command is also displayed, however, do not select the command because it is for use other than in Japan. If the mode is set to "Extra High (Except Japan)" and "High (Except Japan)", the illumination level for illuminating the TNS and headlight increases. Therefore, the TNS and headlights illuminate when the ambient light is brighter than when the level is set to "Standard (Except Japan)". In addition, if the mode is set to "Low (Except Japan)" and "Extra Low (Except Japan)", the illumination level for illuminating the TNS and headlights decreases. Therefore, the TNS and headlights illuminate when the ambient light is lower than when the level is set to "Standard (Except Japan)".
