BODY CONTROL MODULE (BCM) CONFIGURATION

Note. Use the IDS (laptop PC) because the PDS (Pocket PC) does not support the BCM CONFIGURATION.

Scheme 68

1. Connect the M-MDS to DLC-2. (Scheme 68): Identifying DLC-2
2. After the vehicle is identified, select the following items from the initial screen of the M-MDS. When using the IDS (laptop PC) Select "Module Programming".
3. Then, select items from the screen menu in the following order. Select "Programmable Module Installation". Select "BCM/GEM".
4. Perform the configuration according to the directions on the screen.
5. Retrieve DTCs by the M-MDS, then verify that there is no DTC present. If a DTC(s) is detected, perform the applicable DTC inspection. (See «DTC TABLE [BCM]»(ref-581631-S36729145862013101400000).)

CONTROL SYSTEM PERSONALIZATION FEATURES SETTING PROCEDURE

Note. Use the IDS (laptop PC) because the PDS (Pocket PC) does not support the PERSONALIZATION FEATURES SETTING PROCEDURE.

Scheme 69

1. Connect the M-MDS to the DLC-2. (Scheme 69): Identifying DLC-2
2. After the vehicle is identified, select the following items from the initial screen of the M-MDS. When using the IDS (laptop PC) Select the "Module Programming". Select menu in the "BCM/GEM".
3. Select an item name, and then select option. M-MDS display Function Initial setting Setting content Control unit Smart turn The 'turn light system' function can be set. Disabled Disabled / Enabled BCM 2 stage door unlocking (with AKE) 2-step unlocking system can be set. Enabled Disabled / Enabled BCM Auto room lamp (when doors unlocked) The automatic illumination function of the interior light when the doors are locked can be canceled. Enabled Disabled / Enabled BCM Auto relock timer (without AKE) Auto re-lock operation timing can be changed. 30sec Disabled, 30sec, 60sec, 90sec BCM Auto room lamp (when IG-Off) The automatic illumination function of the interior light after the ignition is switched off can be canceled. Enabled Disabled / Enabled BCM Answer Back Buzzer Answer back buzzer can be set to inoperable. Enabled Disabled / Enabled BCM Window closing/opening with advanced-key/transmitter Exterior open/close function can be set to inoperable. Enabled Disabled / Enabled BCM Room lamp timer The elapsed time between the doors closing and the interior light turning off can be adjusted. 15sec 15sec, 7.5sec, 30sec, 60sec BCM Room Lamp Battery Saver Timer The elapsed time for the interior light to automatically turn off when a door is ajar can be adjusted. 30min 30min / 10min BCM Window closing with key Exterior close function can be set to inoperable. Enabled Disabled / Enabled BCM Window opening with key Exterior open function can be set to inoperable. Enabled Disabled / Enabled BCM
