On-Board Diagnostic [Bcm]: Overview Mazda 6 GJ

Communication Devices 5 illustrations ~180 words

On-Board Diagnostic Wiring Diagram [BCM] (1 Of 4). Scheme 26

Scheme 26: On-Board Diagnostic Wiring Diagram [BCM] (1 Of 4)

On-Board Diagnostic Wiring Diagram [BCM] (2 Of 4). Scheme 27

Scheme 27: On-Board Diagnostic Wiring Diagram [BCM] (2 Of 4)

On-Board Diagnostic Wiring Diagram [BCM] (3 Of 4). Scheme 28

Scheme 28: On-Board Diagnostic Wiring Diagram [BCM] (3 Of 4)

On-Board Diagnostic Wiring Diagram [BCM] (4 Of 4). Scheme 29

Scheme 29: On-Board Diagnostic Wiring Diagram [BCM] (4 Of 4)

Scheme 30

Scheme 30: DTC INSPECTION [BCM]
  1. Connect the M-MDS (IDS) to the DLC-2. (Scheme 30): Identifying DLC-2 Location
  2. Verify the following vehicle conditions: All the switches are turned off (except the ignition switch). All the doors, hood, and liftgate are closed. All the doors, and liftgate are unlocked. All the seat belts are unbuckled. Parking brake lever is pulled.
  3. After the vehicle is identified, select the following items from the initial screen of the IDS. Select "Self Test". Select "Modules". Select "BCM".
  4. Verify the DTC according to the directions on the screen. If any DTCs are displayed, perform troubleshooting according to the corresponding DTC inspection.
  5. After completion of repairs, clear all DTCs stored in the BCM. (See «CLEARING DTC [BCM]»(ref-581631-S31827721662013101400000).)
