Lighting Systems: Removal & Installation Mazda 6 GH рестайлинг

FRONT COMBINATION LIGHT REMOVAL/INSTALLATION

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-448631-S32376246232012012000000) .)
3. Remove the bolt shown in the illustration.
4. Remove the bolt and fastener shown in the illustration.
5. Remove the bolts shown in the illustration.
6. Disconnect the connectors shown in the illustration.
7. Pull the front combination light in the direction of the arrow shown in the illustration and remove the pin from the body.
8. Remove the front combination light.
9. Remove the bolts shown in the illustration.
10. Remove the tabs and pin shown in the illustration.
11. Remove the cover from the combination light.
12. Install in the reverse order of removal.
13. Adjust the headlight aiming. (See «HEADLIGHT AIMING»(ref-448651-S18930774982012012000000) .)

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Disconnect the negative battery cable.
2. Remove the fasteners and slightly bend back the mudguard.
3. Remove the cover.
4. Pull the connectors in the direction of the arrow shown in the illustration and disconnect them.
5. Move the bulb retaining wire in the direction of the arrow (1) to release the lock, then open the bulb retaining wire in the direction of the arrow (2).
6. Remove the headlight bulb. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
7. Install in the reverse order of removal.

Discharge connector removal note

1. Rotate the connector in the direction of the arrow shown in the illustration to remove it.

Scheme 24

Discharge headlight removal note

1. Press sections A to release the bulb retaining wire and remove the discharge headlight.

Scheme 25

Scheme 26

Scheme 27

1. Disconnect the negative battery cable.
2. Disconnect the connector.
3. Rotate the headlight bulb in the direction of the arrow shown in the illustration.
4. Remove the headlight bulb. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
5. Install in the reverse order of removal.

DISCHARGE HEADLIGHT CONTROL MODULE REMOVAL/INSTALLATION

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-448631-S32376246232012012000000) .)
3. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-448651-S14785826912012012000000) .)
4. Remove the screws A.
5. Disconnect the connector A.
6. Remove the screws B.
7. Disconnect the connector B.
8. Remove the discharge headlight control module.
9. Remove the cover.
10. Rotate the connector in the direction of the arrow shown in the illustration to remove it.
11. Remove the short cord.
12. Install in the reverse order of removal.

Scheme 32

PARKING/FRONT TURN LIGHT BULB REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Slightly bend back the mudguard. (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-448621-S29524228602012012000000) .)
3. Rotate the parking/front turn light socket in the direction of the arrow (1) shown in the illustration.
4. Pull the parking/front turn light socket in the direction of the arrow (2) shown in the illustration and remove it.
5. Remove the parking/front turn light bulb.
6. Install in the reverse order of removal.

Scheme 33

Scheme 34

Scheme 35

1. Disconnect the negative battery cable.
2. Slightly bend back the mudguard. (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-448621-S29524228602012012000000) .)
3. Disconnect the front side marker light connector.
4. Remove tab A by pressing it in the direction of the arrow shown in the illustration.
5. Remove the front side marker light by pulling it in the direction of the arrow shown in the illustration. CAUTION: When remove the front side marker light, be careful not to damage the pin.
6. Install in the reverse order of removal.

FRONT SIDE MARKER LIGHT BULB REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Slightly bend back the mudguard. (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-448621-S29524228602012012000000) .)
3. Rotate the front side marker light socket in the direction of the arrow shown in the illustration and remove it.
4. Remove the front side marker light bulb.
5. Install in the reverse order of removal.

Scheme 36

Scheme 37

Scheme 38

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-448631-S32376246232012012000000) .)
3. Remove the screws A.
4. Remove the front fog light component.
5. Remove the screw B.
6. Remove the adjustment bolt.
7. Pull the front fog light in the direction of the arrow shown in the illustration and remove it from the front fog light bracket.
8. Install in the reverse order of removal.
9. Adjust the front fog light aiming. (See «FRONT FOG LIGHT AIMING»(ref-448651-S35172100312012012000000) .)

Scheme 39

Scheme 40

1. Disconnect the negative battery cable.
2. Slightly bend back the mudguard. (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-448621-S29524228602012012000000) .)
3. Disconnect the connector.
4. Rotate the front fog light bulb in the direction of the arrow shown in the illustration. CAUTION: A halogen bulb generates extremely high heat when it is used. If the surface of the bulb is soiled, excessive heat will build up and the light's life will be shortened. When replacing the bulb, hold the metal flange, not the glass.
5. Remove the front fog light bulb.
6. Install in the reverse order of removal.

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. Make a screen as shown in the illustration using double-weight, white paper.
2. Adjust the tire pressure to the specification.
3. Position the unloaded vehicle on a flat, level surface.
4. Seat one person in the driver's seat.
5. Line up the vehicle with the wall so that the center of the front fog light is 3 in {9.8 ft} away from the wait.
6. Measure the height at the center of the front fog light. NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the front fog light using the actual vehicle.
7. Align the center of the front fog light with the center of the screen.
8. Block the light of the other front fog light using a partition.
9. Start the engine so that the battery remains charged.
10. Turn the front fog lights on.
11. Verify that the brightness border line of the front fog light is at the position indicated on the adjustment screen.

1. If the brightness border line is not at the position indicated on the adjustment screen, perform the following adjustment.

1. Remove the adjustment bolt and cut the front fog light hole cover at the position shown in the illustration.
2. Loosen the screw.
3. Move the front fog light in the direction of the arrow shown in the illustration to adjust the brightness border line to the position indicated on the adjustment screen.
4. Install the adjusting bolt and tighten the screw.

Scheme 46

Scheme 47

1. Disconnect the negative battery cable.
2. Remove the outer mirror glass. (See «OUTER MIRROR GLASS REMOVAL»(ref-448571-S05828933712012012000000) .) (See «OUTER MIRROR GLASS INSTALLATION»(ref-448571-S05509705632012012000000) .)
3. Remove the outer mirror garnish. (See «OUTER MIRROR GARNISH REMOVAL/INSTALLATION»(ref-448571-S28366635672012012000000) .)
4. Remove the screw.
5. Disconnect the connector.
6. Remove the side turn light.
7. Install in the reverse order of removal.

Scheme 48

LICENSE PLATE LIGHT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Recess (See «RECESS REMOVAL/INSTALLATION»(ref-448656-S23387134952012012000000) .) Trunk rid trim (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-448656-S28823214402012012000000) .) Rear finisher (See «REAR FINISHER REMOVAL/INSTALLATION»(ref-448621-S30655826072012012000000) .) License plate light bulb (See «LICENSE PLATE LIGHT BULB REMOVAL/INSTALLATION»(ref-448651-S05623043862012012000000) .)
3. Press tab A in the direction; of the arrow (1) shown in the illustration, press the license plate light in the direction of the arrow (2), and detach tab B.
4. Remove the license plate light.
5. install in the reverse order of removal.

Scheme 49

Scheme 50

1. Disconnect the negative battery cable.
2. Partially peel back the trunk rid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-448656-S28823214402012012000000) .)
3. Disconnect the license plate light connector.
4. Rotate the socket in the direction of the arrow shown in the illustration to remove it.
5. Remove the license plate light bulb.
6. Install in the reverse order of removal.

Scheme 51

COMBINATION SWITCH REMOVAL/INSTALLATION

Scheme 52

1. Disconnect the negative battery cable and wait 1 min or more .
2. Remove the following parts: Driver-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-448570-S05866549032012012000000) .) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S01292366382012012000000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S18771656912012012000000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-448656-S12743804542012012000000) .) Clock spring (See «CLOCK SPRING REMOVAL/INSTALLATION»(ref-448570-S13234663042012012000000) .)
3. Disconnect the connectors.
4. Remove the screws.
5. Remove the combination switch.
6. Install in the reverse order of removal.

Scheme 53

LIGHT SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-448656-S12743804542012012000000) .)
3. Disconnect the connector.
4. Remove the screws shown in the illustration, then remove the light switch by pulling it in the direction of the arrow.
5. Install in the reverse order of removal.

Scheme 54

HAZARD WARNING SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the center panel upper. (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-448656-S12464949122012012000000) .)
3. Squeeze the tabs of hazard warning switch and putt it outward to remove it.
4. Install in the reverse order of removal.

Scheme 55

Scheme 56

Scheme 57

1. Disconnect the negative battery cable.
2. Remove the center panel upper. (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-448656-S12464949122012012000000) .)
3. Remove the hazard warning switch. (See «HAZARD WARNING SWITCH REMOVAL/INSTALLATION»(ref-448651-S42527809492012012000000) .)
4. Verify that the continuity between the hazard switch terminals is as indicated in the table. If not as indicated in the table, replace the hazard warning switch.
5. Apply battery voltage to hazard switch terminal D, and connect terminal C to ground.
6. Verify that the LED illuminates.

1. If there is any malfunction, replace the hazard warning switch.

HEADLIGHT LEVELING SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (driver-side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Front side trim (driver-side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-448656-S24645152862012012000000) .) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Decoration panel (driver-side) (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-448614-S41008846102012012000000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-448656-S09959257172012012000000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-448656-S04202039792012012000000) .)
3. Remove the tabs.
4. Remove the headlight leveling switch.
5. Install in the reverse order of removal.

Scheme 58

Scheme 59

Scheme 60

1. Remove the following parts: Front scuff plate (driver-side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Front side trim (driver-side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-448656-S24645152862012012000000) .) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Decoration panel (driver-side) (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-448614-S41008846102012012000000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-448656-S09959257172012012000000) .) Lower panel (driver-side) (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-448656-S04202039792012012000000) .) Headlight leveling switch (See «HEADLIGHT LEVELING SWITCH REMOVAL/INSTALLATION»(ref-448651-S20286079402012012000000) .)
2. Verify that the resistance between the headlight leveling switch terminals is as indicated in the table. If not as indicated in the table, or if the resistance is not within the specification, replace the headlight leveling switch.
3. Apply battery voltage to headlight leveling switch terminal E, and connect terminal A to ground.
4. Verify that the LED illuminates.

1. If there is any malfunction, replace the headlight leveling switch.

Scheme 61

AUTO LIGHT-OFF CONTROL MODULE REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the dashboard under cover (Driver side). (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-448656-S15925168382012012000000) .)
3. Removal the nut.
4. Disconnect the connectors.
5. Remove the auto light-off control module.
6. Install in the reverse order of removal.

Scheme 62

AUTO LIGHT/WIPER CONTROL MODULE REMOVAL/INSTALLATION

Note. Auto light-off system are integrated with the auto light/wiper control module.

1. Disconnect the negative battery cable.
2. Remove the dashboard under cover (Driver side). (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-448656-S15925168382012012000000) .)
3. Remove the nut.
4. Disconnect the connectors.
5. Remove the auto light/wiper control module.
6. Install in the reverse order of removal.
7. Perform the auto light/wiper control module configuration when replacing it. (See «AUTO LIGHT/WIPER CONTROL MODULE CONFIGURATION»(ref-448651-S29862211142012012000000) .)

Scheme 63

MAP LIGHT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Open the overhead console.
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Lens (See «LENS REMOVAL NOTE»(ref-448651-S03788070042012012000000) .) 2 Screw 3 Map light bulb 4 Map light 5 Connector
4. Install in the reverse order of removal.

Scheme 64

Lens Removal Note

1. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.

Scheme 65

Scheme 66

Scheme 67

1. Disconnect the negative battery cable.
2. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-448651-S38096746852012012000000) .)
3. Verify that the continuity between the map light terminals is as indicated in the table. If not as indicated in the table, replace the map light.
4. Apply battery positive voltage to map light terminal C, and connect terminal F to ground.
5. Switch the room light switch to the DOOR position and verify that the map light illuminates.

1. If the light does not illuminate, replace the map light.

INTERIOR LIGHT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
4. Disconnect the rain sensor connector. (Vehicles auto light/wiper system)
5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S22638988852012012000000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S10692943582012012000000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-448656-S35625955382012012000000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-448671-S24354888492012012000000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-448656-S29824177632012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .)
6. Disconnect the auto-dimming mirror connector, (vehicles with auto-dimming mirror)
7. Remove the sunvisor. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-448656-S17577240092012012000000) .)
8. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-448651-S38096746852012012000000) .)
9. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-448656-S04086798262012012000000) .)
10. Remove the headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-448656-S29577759512012012000000) .)
11. Disconnect the interior light connector.
12. Detach the tab and remove the interior light.
13. Install in the reverse order of removal.

Scheme 68

Scheme 69

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.
3. Remove the interior light bulb.
4. Install in the reverse order of removal.

Scheme 70

TRUNK COMPARTMENT LIGHT BULB REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Disengage the tabs by pressing both ends of the lens in the directions indicated by the arrows and remove the lens.
3. Install in the reverse order of removal.

Scheme 71

COURTESY LIGHT BULB REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Lens (See «LENS REMOVAL NOTE»(ref-448651-S03054961472012012000000) .) 2 Courtesy light bulb
3. Install in the reverse order of removal.

Scheme 72

1. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.

Scheme 73

IGNITION KEY ILLUMINATION REMOVAL/INSTALLATION

Note. The ignition key illumination is integrated with the coil antenna. (See COIL ANTENNA REMOVAL/INSTALLATION [KEYLESS ENTRY SYSTEM] .) (See COIL ANTENNA REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .)

GLOVE COMPARTMENT LIGHT BULB REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-448656-S36262450112012012000000) .)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Socket 2 Glove compartment light bulb
4. Install in the reverse order of removal.

Scheme 74

INDIRECT ILLUMINATION REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-448651-S38096746852012012000000) .)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Connector 2 Console indirect illumination
4. Install in the reverse order of removal.

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped fastener remover into the service hole indicated in the illustration.
3. White pressing tab in the direction of the arrow (1), pull the ground illumination light in the direction of the arrow (2).
4. Remove the ground illumination tight by putting it in the direction of the arrow (3).
5. Disconnect the socket in the direction of the arrow shown in the illustration.
6. Remove the ground illumination light bulb as shown in the illustration.
7. install in the reverse order of removal.

Scheme 79
