ENGINE DISMOUNTING
- Dismount in the reverse order of mounting.
Scheme 118
- Disassemble in the order indicated in the figure.
Scheme 119
- Remove the cylinder head cover bolts in the order indicated in the figure.
Scheme 120
- Rotate the belt tensioner counterclockwise to release the drive belt tension and remove the belt.
Scheme 121
Scheme 122
- Replace part A of the SST [303-009 (49 UN30 3009)] with the SST [303-457 (49 UN30 3457)].
- Remove the water pump pulley using the SSTs .
Scheme 123
- Remove the oil seal using a screwdriver.
Scheme 124
- Remove the oil pan bolts and studs in the order indicated in the figure.
Scheme 125
Scheme 126
- Hold the flywheel (MTX) or the drive plate (ATX) using the SST .
- Remove the crankshaft pulley lock bolt.
- Remove the crankshaft pulley using the SST and three (M8x 1.25x45) bolts.
Scheme 127
Scheme 128
- Remove the engine front cover bolts and studs in the order indicated in the figure.
- Remove the oil seal using a screwdriver.
Scheme 129
Scheme 130
- Before removing chain tensioner (RH), turn the crankshaft clockwise to position the crankshaft keyway in the 3 o'clock position, (camshafts (RH) are in the neutral position.)
- Hold the timing chain tensioner ratchet lock mechanism away from the ratchet stem with a thin screwdriver.
- Slowly press the tensioner piston.
- Hold the tensioner piston with a 1.5 mm (0.06 in) wire or paper clip.
