Automatic Transaxle Shift Mechanism: Removal & Installation Mazda 6 GG

SELECTOR CABLE REMOVAL NOTE

1. Remove the clip.
2. Remove the selector cable.

Scheme 824

Scheme 825

Scheme 826

Scheme 827

Scheme 828

Scheme 829

Scheme 830

1. Install the selector cable to the selector lever securely.
2. Install the selector cable to the bracket securely. NOTE: Steps 3 and 4 are for the selector cable replacement only.
3. Verify that the selector lever is in the P position.
4. Lock the lock piece of the selector cable (selector lever side) in the order (Scheme 827)
5. Verify that the manual shaft is in the P position. CAUTION: Bending the selector cable in the manner (Scheme 828)will damage the cable and it may become loose when shifted. When installing the selector cable, hold it straight.
6. Install the clip (Scheme 829) NOTE: Install the selector lever to the manual shaft lever with the clip side of the selector cable end facing the front of the vehicle.
7. Install the selector lever to the manual shaft lever in such a way that the selector cable does not bear a load.
8. Confirm that the end of the manual shift lever sticks out of the end of the selector cable.
9. Install the selector cable to the selector cable bracket securely.

Scheme 831

Scheme 832

Scheme 833

Scheme 834

Scheme 835

Scheme 836

1. Install the selector cable to the selector lever securely.
2. Install the selector cable and clip to the bracket (Scheme 832) NOTE: Steps 3 and 4 are for the selector cable replacement only.
3. Verify that the selector lever is in the P position.
4. Lock the lock piece of the selector cable (selector lever side) in the order (Scheme 833)
5. Verify that the manual shaft is in P position. CAUTION: Bending the selector cable in the manner (Scheme 834)will damage the cable and it may become loose when shifted. When installing the selector cable, hold it straight.
6. Install the clip (Scheme 835) NOTE: Install the selector lever to the manual shaft lever with the clip side of the selector cable end facing up.
7. Install the selector lever to the manual shaft lever so that no load acts on the selector cable.
8. Confirm that the tip of the manual shift lever projects out of the end of the selector cable.
9. Install the selector cable to the selector cable securely bracket.

Scheme 837

Scheme 838

Scheme 839

Scheme 840

Scheme 841

Scheme 842

Scheme 843

Scheme 844

Scheme 845

1. Install the interlock cable (Scheme 837) CAUTION: Position the sponge protector so that it is not crushed or squeezed by the SAS control module. If the interlock and selector cables cross over each other, position the interlock cable to pass over the selector cable.
2. Push the snap pin (or appropriate sized round bar or similar.) into hole A by fully pushing the slider pin in.
3. Push the snap pin into hole B and hole C of the lock unit until it passes through.
4. Disconnect the brake switch connector.
5. Remove the brake switch. (See «BRAKE PEDAL»(ref-164523-S38717772142004080900000).)
6. Install the new brake switch. (See «BRAKE PEDAL»(ref-164523-S38717772142004080900000).) CAUTION: Do not connect the brake switch connector until the interlock cable is installed.
7. With the slider pin pressed, slide the lock unit to fix the lock unit hook into the bracket hole securely (Scheme 839) CAUTION: Allowing the interlock cable to be bent or twisted during installation can affect the lock unit operation.
8. Rotate the slider pin to release the lock, and verify that it slides freely.
9. Pull the slider pin outward until it contacts the brake pedal stopper rubber and rotate the slider pin to lock.
10. Verify that the shift the selector lever in P position.
11. Install the interlock cable end to the cam pin on the selector lever.
12. Fit the interlock cable in the U-groove in the selector lever base plate, and install the clip.
13. Press the interlock cable lock piece in until it is locked. CAUTION: Applying a load to the interlock cable while pressing the lock piece in can affect the lock unit operation.
14. Remove the snap pin from the lock unit hole A, B C.
15. Connect the brake switch connector with the brake pedal released. CAUTION: The clearance between the brake switch and the brake pedal is automatically adjusted to the correct amount when the brake switch connector is connected after the brake switch has been properly installed. If the brake switch is not properly installed or the connector is connected before installation, the clearance may be incorrect, causing a brake light malfunction. Therefore, always verify that the brake switch is properly installed before connecting the connector. Once the brake switch clearance has automatically been adjusted, it cannot be adjusted again. Therefore, replace the switch with a new one when replacing the power brake unit or the pedal, or performing any procedure that changes the pedal stroke.
16. Turn the ignition switch to ON position.
17. Install the interlock cable to the key cylinder.
18. Slide the outer casing to the key cylinder, and insert the clip over the convex part of the outer casing.

Scheme 846

1. Disassemble in the order (Scheme 846)
2. Assemble in the reverse order of disassembly.
