Sunroof: Removal & Installation Mazda 3 BM

Sun Roof/t-Top/convertible Top 6 illustrations ~1827 words

FRONT DRAIN HOSE INSTALLATION

CAUTIONIf the front drain hose is pinched or bent anywhere, the water in the hose may not discharge and enter the inside of the vehicle. During and after installation of the trims and the headliner, always make sure there is no interference with the front drain hose. Fix any problem if found.
  1. Apply soapy water to the front drain hose inserting area.
  2. Insert one end (the wider end) of the front drain hose into the sunroof frame.
  3. Install the front drain hose to the clips, parallel to the pillar and free of slack.
  4. Insert the front drain hose joint into the hinge pillar inner hole.
  5. Connect the auto-dimming mirror connector. (vehicles with auto-dimming mirror)
  6. Install the following parts: Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000) .) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000) .) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000) .) Sunroof seaming welt Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-579335-S29932544402013100700000) .) Windshield wiper motor (See «WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION»(ref-579338-S15405942432013100700000) .) Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-579341-S02671303742013100700000) .) Front fender molding (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-579341-S02671303742013100700000) .) Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-579338-S36386448362013100700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000) .) multi information display (with multi information display) (See «MULTI INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-579350-S13703502732013100700000) .) Information display (with information display) (See «INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-579350-S16567811822013100700000) .) Hole cover (See «HOLE COVER REMOVAL/INSTALLATION»(ref-579335-S15592194102013100700000) .) Dashboard upper panel (See «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S10363597352013100700000) .) Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-579335-S22707828702013100700000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000) .) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-579409-S33106125982013100700000) .) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-579407-S37725560872013100700000) .) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-579336-S10029739652013100700000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000) .) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000) .) Joint cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000) .) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-579340-S24478508062013100700000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000) .) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000) .) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S05413955052013100700000) .) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S10864358512013100700000) .) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-579335-S00619224222013100700000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000) .) Hood release lever from the lower panel (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-579383-S12047271642013100700000) .) Selector lever component (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000) .) Shift lever component (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000) .) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000) .) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000) .)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000) .) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000) .) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-579335-S39411275542013100700000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Front doors (See «FRONT DOOR REMOVAL/INSTALLATION»(ref-579410-S16415067902013100700000) .)
  7. Connect the rain sensor connector. (Vehicles with auto light / wiper system)
  8. Install the rain sensor cover. (Vehicles with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000) .)
  9. Install the seaming welt.
  10. Connect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)

Scheme 7

Scheme 7: REAR DRAIN HOSE REMOVAL
Scheme 7: REAR DRAIN HOSE REMOVAL

Scheme 8

Scheme 8
Scheme 8
  1. Disconnect the negative battery cable.
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welt.
  5. Remove the following parts: Sunroof seaming welt A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).)
  6. Disconnect the dimming mirror connector. (vehicles with dimming mirror)
  7. Disconnect the rain sensor connector. (vehicles with rain sensor)
  8. Disconnect the rear drain hose from the sunroof frame.
  9. Remove the rear drain hose from the clips.
  10. Pull the rear drain hose into the room side.
  11. Remove the rear drain hose. (Scheme 7): Identifying Rear Drain Hose Clip Position (1 Of 2) (Scheme 8): Identifying Rear Drain Hose Clip Position (2 Of 2)

REAR DRAIN HOSE INSTALLATION

CAUTIONIf the rear drain hose is pinched or bent anywhere, the water in the hose may not discharge and enter the inside of the vehicle. During and after installation of the trims and the headliner, always make sure there is no interference with the rear drain hose. Fix any problem if found.
  1. Apply soapy water to the rear drain hose inserting area.
  2. Insert one end (the wider side) of the rear drain hose into the sunroof frame.
  3. Install the rear drain hose to the clips parallel to the pillar and free of slack.
  4. Insert the rear drain hose joint into the rear pillar inner hole.
  5. Connect the rain sensor connector. (vehicles with rain sensor)
  6. Connect the dimming mirror connector. (vehicles with dimming mirror)
  7. Install the following parts: Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000) .) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000) .) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000) .) Sunroof seaming welt
  8. Install the seaming welt.
  9. Connect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)

Scheme 9

Scheme 9: SUNROOF MOTOR REMOVAL/INSTALLATION
Scheme 9: SUNROOF MOTOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).)
  6. Disconnect the sunroof motor connector. (Scheme 9): Identifying Sunroof Motor Connector, Sunroof Motor And Screws
  7. Remove the screws, and then remove the sunroof motor.
  8. Install in the reverse order of removal.

Note. If the glass panel or the sunroof motor is moved with the sunroof motor removed, initial position setting of the sunroof motor will be required. Perform initial position setting referring to the Sunroof Motor Assembly Note. (See SUNROOF UNIT DISASSEMBLY/ASSEMBLY .)

  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .)(See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000) .)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000) .) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) .) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000) .)
  6. Measure the voltage at each terminal. If not as specified, inspect the parts listed under "Inspection item" and the related wiring harnesses. If the parts and wiring harnesses are normal but the system still does not work properly, replace the sunroof motor.
Fig. 19: Identifying Sunroof Motor Wiring Harness-Side Connector Terminals And Pin Voltages
Scheme 19: Identifying Sunroof Motor Wiring Harness-Side Connector Terminals And Pin Voltages
TerminalSignalConnected toTest conditionVoltage (V)Inspection item
ASlide openSunroof switchSunroof is fully opening.B+Sunroof switch
Other1.0 or less
BSlide close/tilt downSunroof switchSunroof is closing/tilting down.B+Sunroof switch
Other1.0 or less
CTilt upSunroof switchSunroof is tilting up.B+Sunroof switch
Other1.0 or less
D
EIG2HEATER 10 A fuseSwitch the ignition ON.B+HEATER 10 A fuse
Other1.0 or less
F
GGNDGNDUnder any condition1.0 or lessGND
H
I
JPower supplySUNROOF 15 A fuseUnder any conditionB+SUNROOF 15 A fuse

Note. The sunroof switch is together with the front map light.

  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000) .)
  2. Remove the map light from the headliner. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000) .)
  3. Install in the reverse order of removal.

Note. The sunroof switch is together with the front map light.

Scheme 10

Scheme 10: SUNROOF SWITCH INSPECTION
Scheme 10: SUNROOF SWITCH INSPECTION

Scheme 11

Scheme 11
Scheme 11
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the map light from the headliner. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).)
  3. Inspect for continuity between the sunroof switch terminals using an ohmmeter. (Scheme 10): Sunroof Switch Circuit With Terminal Identification If not as specified, replace the sunroof switch. (Scheme 11): Sunroof Switch Terminal Continuity Chart
