Wiper System/washer System: Removal & Installation Mazda 3 BM

Wiper/washer Systems 43 illustrations ~2305 words

Cap Installation Note

CAUTIONAfter installing the cap, verify that there is no gap between the upper part of the cap and the bottom surface of the washer tank. Otherwise, water leakage could occur.

Identifying Washer Tank Cap. Scheme 15

Scheme 15: Identifying Washer Tank Cap
Scheme 15: Identifying Washer Tank Cap

Scheme 16

Scheme 16: 4SD
Scheme 16: 4SD
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the front mudguard (RH). (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-579341-S42819834192013100700000).)
  3. Remove in the order indicated in the table. (Scheme 16): Identifying Washer Motor Components (4SD)
  4. Install in the reverse order of removal.

Scheme 17

Scheme 17: 5HB
Scheme 17: 5HB
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the front mudguard (RH). (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-579341-S42819834192013100700000).)
  3. Remove in the order indicated in the table. (Scheme 17): Identifying Washer Motor Components (5HB)
  4. Install in the reverse order of removal.

Scheme 18

Scheme 18: WASHER MOTOR INSPECTION
Scheme 18: WASHER MOTOR INSPECTION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the front mudguard (RH). (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-579341-S42819834192013100700000).)
  3. Disconnect the washer motor connector.
  4. After connecting washer motor terminal A to the positive battery terminal, and terminal B to the negative battery terminal, verify that washer fluid flows to the windshield washer hose. (Scheme 18): Identifying Washer Motor Connector Terminals If there is any malfunction, replace the washer motor.
  5. After connecting washer motor terminal B to the positive battery terminal, and terminal A to the negative battery terminal, verify that washer fluid flows to the rear washer hose.(5HB) If there is any malfunction, replace the washer motor.

Scheme 19

Scheme 19: WINDSHIELD WASHER NOZZLE REMOVAL/INSTALLATION
Scheme 19: WINDSHIELD WASHER NOZZLE REMOVAL/INSTALLATION
  1. Remove the following parts: Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-579338-S36386448362013100700000).) Front fender molding (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-579341-S02671303742013100700000).) Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-579341-S02671303742013100700000).)
  2. Remove the windshield washer hose from the windshield washer nozzle.
  3. Squeeze the tabs of the windshield washer nozzle.
  4. Pull the windshield washer nozzle out to remove it. (Scheme 19): Pulling Windshield Washer Nozzle
  5. Install in the reverse order of removal.

Scheme 20

Scheme 20: WINDSHIELD WASHER HOSE REMOVAL/INSTALLATION
Scheme 20: WINDSHIELD WASHER HOSE REMOVAL/INSTALLATION

Scheme 21

Scheme 21
Scheme 21
  1. Remove the following parts: Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-579338-S36386448362013100700000).) Front fender molding (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-579341-S02671303742013100700000).) Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-579341-S02671303742013100700000).) Front mudguard (RH) (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-579341-S42819834192013100700000).)
  2. Disconnect joint pipes, then remove windshield washer hose B, C and D.
  3. Remove the windshield washer hose B.
  4. Disconnect windshield washer hose C from the washer nozzle.
  5. Remove the windshield washer hose C.
  6. Disconnect windshield washer hose D from the washer nozzle.
  7. Remove the windshield washer hose D. (Scheme 20): Removing Windshield Washer Hose D
  8. Disconnect the windshield washer hose A from the windshield washer motor.
  9. Remove the clip A and B.
  10. Disconnect joint pipes, then remove windshield washer hose A.
  11. Remove the windshield washer hose A. (Scheme 21): Windshield Washer Hose A And Clip
  12. Install in the reverse order of removal.

Scheme 22

Scheme 22: WASHER FLUID-LEVEL SENSOR REMOVAL/INSTALLATION
Scheme 22: WASHER FLUID-LEVEL SENSOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-579342-S31619184642013100700000).)
  3. Remove the washer tank. (See «WASHER TANK REMOVAL/INSTALLATION»(ref-579338-S11048955312013100700000).)
  4. Remove the connector of the washer fluid-level sensor from the washer tank. (Scheme 22): Identifying Connector Of Washer Fluid-Level Sensor And Washer Tank
  5. Remove the washer fluid-level sensor.
  6. Remove the grommet.
  7. Install in the reverse order of removal.

Scheme 23

Scheme 23: WASHER FLUID-LEVEL SENSOR INSPECTION
Scheme 23: WASHER FLUID-LEVEL SENSOR INSPECTION

Scheme 24

Scheme 24
Scheme 24
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-579342-S31619184642013100700000).)
  3. Verify that continuity between the washer fluid-level sensor terminals is as indicated in the table. (Scheme 23): Identifying Washer Fluid-Level Sensor Connector Terminals If not as specified, replace the washer fluid-level sensor. (Scheme 24): Washer Fluid-Level Sensor Terminals Continuity Chart

Scheme 25

Scheme 25: REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION
Scheme 25: REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION
  1. Remove in the order indicated in the table. (Scheme 25): Identifying Rear Wiper Arm And Blade Components With Torque Specifications
  2. Install in the reverse order of removal.
  3. Adjust the rear wiper arm and blade. (See «REAR WIPER ARM AND BLADE ADJUSTMENT»(ref-579338-S27342678572013100700000).)

Scheme 26

Scheme 26: Rear Wiper Arm Installation Note
Scheme 26: Rear Wiper Arm Installation Note
  1. Clean the rear wiper arm connector shaft using a wire brush before installing the rear wiper arm. (Scheme 26): Cleaning Rear Wiper Arm Connector Shaft Using Wire Brush

Scheme 27

Scheme 27: REAR WIPER ARM AND BLADE ADJUSTMENT
Scheme 27: REAR WIPER ARM AND BLADE ADJUSTMENT
  1. Turn off the rear wiper switch while operating the rear wiper motor, and then stop the rear wiper at the auto stop position.
  2. Set the rear wiper arm onto the ceramic end line. (Scheme 27): Identifying Rear Wiper Arm Onto Ceramic End Line

Scheme 28

Scheme 28: REAR WIPER MOTOR REMOVAL/INSTALLATION
Scheme 28: REAR WIPER MOTOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the following parts: Rear wiper arm and blade (See «REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-579338-S31257464012013100700000).) Liftgate upper trim (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000).) Liftgate side trim (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S13559719922013100700000).) Liftgate lower trim (See «LIFTGATE LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S24474748562013100700000).)
  3. Disconnect the rear wiper motor connector. (Scheme 28): Identifying Rear Wiper Motor Connector Bolt With Torque Specifications
  4. Remove the bolts, then remove the rear wiper motor.
  5. Remove the outer bushing.
  6. Install in the reverse order of removal.

Scheme 29

Scheme 29: REAR WIPER MOTOR INSPECTION
Scheme 29: REAR WIPER MOTOR INSPECTION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the following parts: Rear wiper arm and blade (See «REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-579338-S31257464012013100700000).) Liftgate upper trim (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000).) Liftgate side trim (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S13559719922013100700000).) Liftgate lower trim (See «LIFTGATE LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S24474748562013100700000).)
  3. Disconnect the rear wiper motor connector.
  4. Apply battery positive voltage to rear wiper motor connector terminal B, and connect terminals A and C to the ground.
  5. Verify that the rear wiper motor operates. (Scheme 29): Identifying Rear Wiper Motor Connector Terminals If there is any malfunction, replace the rear wiper motor.
  6. Disconnect the ground to the terminal A while the rear wiper is operating.
  7. Verify that the rear wiper stops in the auto stop position. If there is any malfunction, replace the rear wiper motor.

Scheme 30

Scheme 30: REAR WASHER NOZZLE REMOVAL/INSTALLATION
Scheme 30: REAR WASHER NOZZLE REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the following parts: Liftgate upper trim (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000).) Rear spoiler (See «REAR SPOILER REMOVAL/INSTALLATION»(ref-579341-S36523223132013100700000).) High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-579340-S10122912622013100700000).)
  3. Disconnect the rear washer hose.
  4. Press the tabs and remove the rear washer nozzle. (Scheme 30): Pressing Tabs And Rear Washer Nozzle
  5. Install in the reverse order of removal.
  6. Adjust the rear washer nozzle. (See «REAR WASHER NOZZLE ADJUSTMENT»(ref-579338-S09667435052013100700000).)

Scheme 31

Scheme 31: REAR WASHER NOZZLE ADJUSTMENT
Scheme 31: REAR WASHER NOZZLE ADJUSTMENT
  1. Insert a needle or an equivalent tool into the spray hole of the rear washer nozzle and adjust the nozzle direction as shown. (Scheme 31): Identifying Rear Washer Nozzle Adjustment

Scheme 32

Scheme 32: REAR WASHER HOSE REMOVAL/INSTALLATION
Scheme 32: REAR WASHER HOSE REMOVAL/INSTALLATION

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the front mudguard (RH). (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-579341-S42819834192013100700000).)
  3. Disconnect rear washer hose A from the washer motor. (Scheme 32): Disconnecting Rear Washer Hose A From Washer Motor
  4. Remove the rear washer hose A from clip A, B, C, D, E, F, G.
  5. Disconnect joint pipes and remove rear washer hose A.
  6. Partially peel back the seaming welts.
  7. Remove the following parts: Sunroof seaming welt (vehicles with sunroof only) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-579337-S39191899042013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Interior light (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-579340-S23543662542013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).)
  8. Peel off the tape and remove rear washer hose B. VEHICLES WITH SUNROOF (Scheme 33): Identifying Rear Washer Hose B (Vehicles With Sunroof) VEHICLES WITH SUNROOF (Scheme 34): Identifying Rear Washer Hose B (Vehicles Without Sunroof)
  9. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000).)
  10. Partially peel back the grommet. (Scheme 35): Peeling Back Grommet
  11. Remove the bracket in the direction of the arrow (2) shown in the figure while pressing the bracket tabs in the direction of the arrow (1). (Scheme 36): Pressing Bracket Tabs
  12. Remove the rear washer hose C from clip H, I, J, K. (Scheme 37): Removing Rear Washer Hose C From Clip H, I, J, K
  13. Disconnect joint pipes and remove rear washer hose C.
  14. Disconnect check valve and remove rear washer hose C.
  15. Remove rear washer hose D from the rear washer nozzle.
  16. Install in the reverse order of removal.

Scheme 38

Scheme 38: WIPER AND WASHER SWITCH REMOVAL/INSTALLATION
Scheme 38: WIPER AND WASHER SWITCH REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).)
  3. Disconnect the wiper and washer switch connector. (Scheme 38): Identifying Wiper And Washer Switch Connector
  4. Remove the screws.
  5. Remove the wiper and washer switch.
  6. Install in the reverse order of removal.

Scheme 39

Scheme 39: WINDSHIELD WIPER AND WASHER SWITCH INSPECTION
Scheme 39: WINDSHIELD WIPER AND WASHER SWITCH INSPECTION

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the following parts: Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Front side trim (Driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-579383-S12047271642013100700000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000) ) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Wiper and washer switch (See «WIPER AND WASHER SWITCH REMOVAL/INSTALLATION»(ref-579338-S39040555752013100700000).)
  3. Verify that the resistance and continuity between the windshield wiper and washer switch terminals as indicated in the table. If the continuity is not as indicated in the table, or if the resistance is not within the Specifications, replace the windshield wiper and washer switch. Vehicles With Auto Wiper System (Scheme 39): Identifying Windshield Wiper And Washer Switch Connector Terminals - Vehicles With Auto Wiper System (Scheme 40): Windshield Wiper And Washer Switch Connector Terminals Continuity Chart - Vehicles With Auto Wiper System (Scheme 41): Windshield Wiper And Washer Switch Connector Terminals Resistance Chart - Vehicles With Auto Wiper System Vehicle Without Auto Wiper System (Scheme 42): Identifying Windshield Wiper And Washer Switch Connector Terminals - Vehicles Without Auto Wiper System (Scheme 43): Windshield Wiper And Washer Switch Connector Terminals Continuity Chart - Vehicles Without Auto Wiper System (Scheme 44): Windshield Wiper And Washer Switch Connector Terminals Resistance Chart - Vehicles Without Auto Wiper System

Scheme 45

Scheme 45: REAR WIPER AND WASHER SWITCH INSPECTION
Scheme 45: REAR WIPER AND WASHER SWITCH INSPECTION

Scheme 46

Scheme 46
Scheme 46
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the following parts: Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Front side trim (Driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-579383-S12047271642013100700000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Wiper and washer switch (See «WIPER AND WASHER SWITCH REMOVAL/INSTALLATION»(ref-579338-S39040555752013100700000).)
  3. Verify that the continuity between the rear wiper and washer switch terminals is as indicated in the table. (Scheme 45): Identifying Rear Wiper And Washer Switch Connector Terminals If not as indicated in the table, replace the wiper and washer switch. (Scheme 46): Rear Wiper And Washer Switch Terminals Continuity Chart

Scheme 47

Scheme 47: RAIN SENSOR REMOVAL/INSTALLATION
Scheme 47: RAIN SENSOR REMOVAL/INSTALLATION

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Spread open the rain sensor cover in the direction of the arrows and disengage tabs A to remove it. (Scheme 47): Opening Rain Sensor Cover
  3. Disconnect the rain sensor connector. (Scheme 48): Identifying Rain Sensor Connector
  4. Slide rain sensor tab B in the direction of the arrow shown in the figure and detach tab B. (Scheme 49): Sliding Rain Sensor Tab B
  5. Remove the rain sensor in the direction of the arrow shown in the figure. (Scheme 50): Removing Rain Sensor
  6. Peel off the rain sensor protective sheet from the rain sensor. (Scheme 51): Peeling Off Rain Sensor Protective Sheet From Rain Sensor
  7. Install in the reverse order of removal. (See «RAIN SENSOR INSTALLATION NOTE»(ref-579338-S16082742112013100700000).)

Rain Sensor Installation Note

CAUTIONIf the rate at which the rain sensor reflects or transmits infrared light between the rain sensor and the windshield, or through the protective sheet is changed, the rain sensor will determine that there is a malfunction in the rain detection function and stop auto wiper system control. Be careful of the following when installing the rain sensor: Do not reuse rain sensor protective sheet Do not touch rain sensor lens, rain sensor protective sheet, and sensor installation area on windshield with your finger Verify that there is no air bubble after installing rain sensor

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57
  1. Wipe off any oil or dirt from the rain sensor lens and the windshield using a clean rag. (Scheme 52): Cleaning Rain Sensor Lens And Windshield Using Clean Rag
  2. Peel off double-sided adhesive tape A from the rain sensor protective sheet. (Scheme 53): Peeling Off Double-Sided Adhesive Tape A From Rain Sensor Protective Sheet
  3. Adhere the rain sensor protective sheet to the rain sensor lens. (Scheme 54): Identifying Rain Sensor Protective Sheet To Rain Sensor Lens
  4. Peel off double-sided adhesive tape B from the rain sensor protective sheet. (Scheme 55): Peeling Off Double-Sided Adhesive Tape B From Rain Sensor Protective Sheet
  5. Install the rain sensor. (Scheme 56): Installing Rain Sensor
  6. Press the rain sensor in the direction of the windshield and press out any air bubbles. (Scheme 57): Pressing Rain Sensor Of Windshield
  7. Verify that there is no air bubble between the windshield and the rain sensor.
