Sunroof: Overview Mazda 3 BM

Sun Roof/t-Top/convertible Top 8 illustrations ~790 words
Scheme 1: Identifying Sunroof Related Components

Scheme 1

Scheme 1: DEFLECTOR REMOVAL/INSTALLATION
  1. Fully open the glass panel.
  2. Press the spring in the direction shown by the arrow and remove it from the hook. (Scheme 1): Pressing Spring
  3. Remove the deflector.
  4. Install in the reverse order of removal.

Scheme 2

Scheme 2: GLASS PANEL REMOVAL/INSTALLATION

Scheme 3

Scheme 3
  1. Fully close the glass panel.
  2. Fully open the sunshade.
  3. Remove the screws, and then remove the glass panel. (Scheme 2): Identifying Glass Panel And Screws
  4. Peel the weatherstrip off the glass panel. (Scheme 3): Peeling Weatherstrip Off Glass Panel
  5. Install in the reverse order of removal.
  6. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-579491-S15547634062013100700000).)

Scheme 4

Scheme 4: GLASS PANEL ADJUSTMENT

Scheme 5

Scheme 5
  1. Fully close the glass panel.
  2. Measure the gap and height between the glass panel and body. (Scheme 4): Measuring Gap And Height Between Glass Panel And Body If not as specified, loosen the glass panel installation screws and reposition the glass panel. Clearance (4SD) a: -2.4-0.2 mm {-0.09-0.01 in} b: 0 mm {0 in} c: -2.2-0.4 mm {-0.08-0.01 in} d: 0 mm {0 in} Clearance (5HB) a: -2.3-0.3 mm {-0.09-0.01 in} b: 0 mm {0 in} c: -2.3-0.3 mm {-0.09-0.01 in} d: 0 mm {0 in}
  3. Tighten the installation screws.
  4. Insert a plastic card between the weatherstrip and the body of the vehicle. Verify that the sunroof is shut tightly (there is resistance when the plastic card is moved). (Scheme 5): Plastic Card Inserted Between Weatherstrip And Body Of Vehicle If the sunroof is not shut tightly, readjust by performing Steps 2 and 3.
CAUTIONIf the sunshade is forced close while the sunroof is open, the sunshade could be damaged.

Scheme 6

Scheme 6
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).)
  6. Disconnect the front and rear drain hose from the sunroof frame.
  7. Disconnect the sunroof motor connector.
  8. Remove the bolts. (Scheme 6): Sunroof Motor Connector, Sunroof Unit, Bolts, Front And Rear Drain Hose With Torque Specifications
  9. Remove the nuts, and then remove the sunroof unit.
  10. Install in the reverse order of removal.
  11. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-579491-S15547634062013100700000).)

Note. If the guide or sunroof motor is removed, the glass panel will not be positioned properly after the re-installation. To ensure proper positioning of the glass panel, place alignment marks on the guide pin and frame before removing the guide or sunroof motor.

  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.
Scheme 8: View Of Sunroof Unit Components

Note. If the guide or sunroof motor is removed, the sunroof motor initial position setting has to be performed. After installing the sunroof unit, perform the initial position setting using the following procedure.

  1. The initialization mode starts after approx. 13 s from when the tilt up switch has been pressed and held. The glass stops after it has moved approx. 30 mm {1.2 in} towards the closed position. NOTE: Only the tilt up switch is available during the initialization mode. The initialization may finish at the first inching operation depending on the glass position when the motor is installed. If the glass position is between the closed and semi-tilt positions when the motor is removed, the glass moves in the tilt up direction (to the full tilt position stored in the motor). However, if the tilt up switch is pressed and held, the initialization mode starts.
  2. When the tilt up switch is pressed again, the glass continues to move approx. 30 mm {1.2 in} and stops.
  3. Repeat this procedure several times so that the glass moves to the fully closed, full tilt (normal operation position), and full tilt (mechanical stopper position) positions.
  4. After the glass is moved to the full tilt position (mechanical stopper position), it returns to the tilt down direction slightly and the initialization is completed.
