Sunroof: Overhaul Mazda 3 BM

Rear Drip Assembly Note

Note. If the rear drip is removed, butyl seal must be applied when re-installing.

Scheme 12

1. Apply a 6.0-8.0 mm {0.24-0.31 in} wide line of butyl seal to the area shown in the figure. (Scheme 12): Identifying Wide Line Of Butyl Seal Application Area In Rear Drip

Scheme 13

Scheme 14

1. Place an alignment mark on the guide pin and flame. (Scheme 13): Identifying Alignment Mark, Guide Pin And Frame
2. Slide the guide to the rear of the sunroof frame, and remove the guide and decoration link as a single unit. (Scheme 14): Sliding Guide To Rear Of Sunroof Frame

Scheme 15

1. Move the pin to the position shown in the figure. (Scheme 15): Identifying Alignment Mark, Guide Pin And Frame

Scheme 16

1. Set the guide pin to the decoration link. (Scheme 16): Identifying Decoration Link, Guide And Pin

Scheme 17

Scheme 18

1. Set the air intake mode to FRESH.
2. Set the air mix mode to MAX COLD.
3. Disconnect the negative battery cable.
4. Remove the rain sensor cover. (Vehicles with auto light / wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000).)
5. Disconnect the rain sensor connector. (Vehicles with auto light / wiper system)
6. Partially peel back the seaming welt.
7. Remove the following parts: Front doors (See «FRONT DOOR REMOVAL/INSTALLATION»(ref-579410-S16415067902013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-579335-S39411275542013100700000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).) Shift lever component (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).)(See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever component (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Hood release lever from the lower panel (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-579383-S12047271642013100700000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-579335-S00619224222013100700000).) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S05413955052013100700000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S10864358512013100700000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-579340-S24478508062013100700000).) Joint cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000).) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000).) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000).) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-579336-S10029739652013100700000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-579409-S33106125982013100700000).) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-579407-S37725560872013100700000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000).) aa. Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-579335-S22707828702013100700000).) ab. Dashboard upper panel (See «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S10363597352013100700000).) ac. Hole cover (See «HOLE COVER REMOVAL/INSTALLATION»(ref-579335-S15592194102013100700000).) ad. Information display (with information display) (See «INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-579350-S16567811822013100700000).) ae. multi information display (with multi information display) (See «MULTI INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-579350-S13703502732013100700000).) af. A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) ag. Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-579338-S36386448362013100700000).) ah. Front fender molding (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-579341-S02671303742013100700000).) ai. Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-579341-S02671303742013100700000).) aj. Windshield wiper motor (See «WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION»(ref-579338-S15405942432013100700000).) ak. Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-579335-S29932544402013100700000).) al. Sunroof seaming welt am. Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) an. B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) ao. Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) ap. B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) aq. Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) ar. Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) as. Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) at. C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) au. Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) av. Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) aw. Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) ax. Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).)
8. Disconnect the auto-dimming mirror connector. (vehicles with auto-dimming mirror)
9. Disconnect the roof harness connector, remove the clip, and remove the connector.
10. Disconnect the front drain hose from the sunroof frame.
11. Remove the front drain hose from the clips.
12. Pull the front drain hose into the room side.
13. Remove the front drain hose. (Scheme 17): Identifying Front Drain Hose Clip Position (1 Of 2) (Scheme 18): Identifying Front Drain Hose Clip Position (2 Of 2)
