Lighting System: Removal & Installation Mazda 3 BM

Steering Column Switches 22 illustrations ~1076 words

FRONT COMBINATION LIGHT REMOVAL/INSTALLATION

WARNINGIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to the discharge headlight service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS .)

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).)(See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-579342-S31619184642013100700000).)
  3. Disconnect the connector. (Scheme 30): Front Combination Light, Connector And Bolts With Torque Specification
  4. Remove the bolt A.
  5. Remove the bolt B.
  6. Remove the bolt C.
  7. Remove the fastener.
  8. Pull the front combination light in the direction of the arrow shown in the figure and remove the pin from the body. (Scheme 31): Pulling Front Combination Light And Pin
  9. Remove the front combination light.
  10. Remove the bolts D. (Scheme 32): Front Combination Light, Bracket And Bolts D With Torque Specification
  11. Remove the bracket in the direction of the arrow (2) shown in the figure while pressing the bracket tabs in the direction of the arrow (1). (Scheme 33): Pressing Bracket Tabs
  12. Install in the reverse order of removal.
  13. Adjust the headlight aiming. (See «HEADLIGHT AIMING»(ref-579340-S29759205522013100700000).)

FRONT COMBINATION LIGHT BRACKET REPLACEMENT

Note. Verify that the front combination light is not damaged before using the repair bracket for installation when the original brackets are damaged. If the front combination light component is damaged, replace the light as a single unit.

Scheme 34

Scheme 34: FRONT COMBINATION LIGHT BRACKET REPLACEMENT
Scheme 34: FRONT COMBINATION LIGHT BRACKET REPLACEMENT

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
  1. Cut off the front combination light bracket at the locations shown in the figure. (Scheme 34): Cutting Off Front Combination Light Bracket At Locations
  2. Smoothen the cut surfaces using sandpaper so that the repair bracket can be properly installed.
  3. Cut the projection at the position shown in the figure. (Scheme 35): Cutting Projection At Position
  4. After disconnecting the projection, verify that the projection is less than 1mm {0.04 in} from the front combination light housing.
  5. Securely attach the repair bracket to the front combination light using the screws. (Scheme 36): Attaching Bracket To Front Combination Light Using Screws

Scheme 37

Scheme 37: Low-beam
Scheme 37: Low-beam

Scheme 38

Scheme 38
Scheme 38
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Disconnect the connector. (Scheme 37): Identifying Headlight Bulb (LO) And Connector
  3. Remove the cover. (Scheme 38): Identifying Headlight Bulb (LO), Adaptor And Cover
  4. Remove the adaptor.
  5. Remove the headlight bulb (LO). CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
  6. Install in the reverse order of removal.

Scheme 39

Scheme 39: High-beam
Scheme 39: High-beam

Scheme 40

Scheme 40
Scheme 40
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Disconnect the connector. (Scheme 39): Identifying Headlight Bulb (HI) And Connector
  3. Rotate the headlight bulb (HI) in the direction of the arrow shown in the figure to remove it. (Scheme 40): Rotating Headlight Bulb (HI)
  4. Remove the headlight bulb (HI). CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
  5. Install in the reverse order of removal.

Discharge headlight connector installation note

CAUTIONIf the installation direction of the discharge headlight connector is incorrect when the connector is installed, the connector may contact the front combination light housing during the AFS operation and the AFS may not operate normally. After installing the connector to the position shown in the figure, verify that the connector does not contact the front combination light housing.

Precaution For Discharge Headlight Connector. Scheme 41

Scheme 41: Precaution For Discharge Headlight Connector
Scheme 41: Precaution For Discharge Headlight Connector

DISCHARGE HEADLIGHT CONTROL MODULE REMOVAL/INSTALLATION

CAUTIONIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to the discharge headlight service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS .)

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-579342-S31619184642013100700000).)
  3. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-579340-S07056950912013100700000).)
  4. Remove the screws. (Scheme 42): Identifying Discharge Headlight Control Module, Connector A And Screws
  5. Disconnect the connector A.
  6. Remove the screw. (Scheme 43): Identifying Discharge Headlight Control Module, Connector B And Screws
  7. Disconnect the connector B.
  8. Remove the discharge headlight control module.
  9. Rotate the cover in the direction of the arrow shown in the figure to remove it. (Scheme 44): Rotating Front Combination Light Cover
  10. Rotate the connector in the direction of the arrow shown in the figure to remove it. (Scheme 45): Rotating Front Combination Light Connector
  11. Remove the short cord. (Scheme 46): Identifying Short Cord
  12. Install in the reverse order of removal.

STEERING ANGLE SENSOR REMOVAL/INSTALLATION

WARNINGHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 47

Scheme 47
Scheme 47
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  3. Remove the following parts: Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S05413955052013100700000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S10864358512013100700000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000).) Clock spring (See «CLOCK SPRING REMOVAL/INSTALLATION»(ref-579329-S06854914382013100700000).)
  4. Remove the steering angle sensor. (Scheme 47): Identifying Steering Angle Sensor And Clock Spring
  5. Install in the reverse order of removal.

Scheme 48

Scheme 48: STEERING ANGLE SENSOR INSPECTION
Scheme 48: STEERING ANGLE SENSOR INSPECTION
  1. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).)
  2. Turn the steering wheel to the right and left, and verify that the voltage and pulses at the terminals are as shown in the figure. If not as specified, replace the steering angle sensor. (Scheme 48): Identifying Steering Angle Sensor Connector Terminals

COMBINATION SWITCH REMOVAL/INSTALLATION

CAUTIONHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  3. Remove the following parts: Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S05413955052013100700000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S10864358512013100700000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Clock spring (See «CLOCK SPRING REMOVAL/INSTALLATION»(ref-579329-S06854914382013100700000).)
  4. Disconnect the connector A. see scheme 135: Identifying Combination Switch Connector A
  5. Disconnect the connector B. see scheme 136: Identifying Combination Switch Connector B
  6. Detach the clips and set the wiring harness aside.
  7. Remove the screws. see scheme 137: Identifying Combination Switch And Screws
  8. Remove the combination switch.
  9. Install in the reverse order of removal.
