Lighting System: Other Mazda 3 BM

Discharge Headlight Service Warnings

1. To prevent electrical shock when replacing the discharge headlight bulb, always perform the servicing with dry hands and in an area where it does not get wet.

Scheme 67

1. Never probe the discharge headlight bulb connector directly with a finger or tester. Otherwise, it could result in electrical shock. When the light switch is ON, high voltage of approx. 25,000 V flows the discharge headlight bulb connector. (Scheme 67): Precaution For Discharge Headlight Service

1. When the headlights are on, high voltage flows around the discharge headlight bulb and discharge headlight bulb connector. When servicing the discharge headlights while they are illuminated, always perform the servicing with the headlights in their installed condition.

Scheme 68

1. Do not use a tester to inspect or disassemble a discharge headlight control module. Otherwise, it could result in electrical shock. (Scheme 68): Precaution For Discharge Headlight Control Module Service

Discharge Headlight Control Module Reuse

1. If the discharge headlight control module is damaged, replace the module with a new one. Otherwise, it could result in electrical shock or operation malfunction.
2. The discharge headlight control module may temporarily operate normally even though it may have been hit, however, the inside of the module could be damaged. If the control module is reused, inspect the following items related to the discharge headlight bulb illumination, and verify that there is no malfunction. Perform the tests for the discharge headlight bulb several times under cold lighting condition (switch on after switching discharge headlight bulb off for approx. 10 min or more) and under warm-up lighting condition (switch off for approx. 1 min after switching discharge headlight bulb on for approx. 15 min or more, and switch on), and verify that the discharge headlight bulb illuminates. Inspect the discharge headlight bulb illumination until it illuminates evenly after cold lighting, verify that the discharge headlight bulb illumination has no flicker or uneven brightness level. Illuminate the headlight for approx. 30 min using a proper discharge headlight bulb, and verify that the illumination condition is stabilized on the left and right with no difference in brightness level.

Discharge Type

Scheme 69

Scheme 70

Scheme 71

Scheme 72

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-579342-S31619184642013100700000).)
3. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-579340-S07056950912013100700000).)
4. Rotate the cover in the direction of the arrow shown in the figure to remove it. (Scheme 69): Rotating Front Combination Light Cover
5. Rotate the discharge headlight connector in the direction of the arrow shown in the figure to remove it. (Scheme 70): Rotating Discharge Headlight Connector
6. Press sections A to release the bulb retaining wire. (Scheme 71): Identifying Bulb Retaining Wire
7. Remove the discharge headlight bulb. (Scheme 72): Identifying Discharge Headlight Bulb CAUTION: The bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
8. Install in the reverse order of removal. (See «DISCHARGE HEADLIGHT CONNECTOR INSTALLATION NOTE»(ref-579340-S18168639272013100700000).) (with AFS (Adaptive front lighting system) only)

HEADLIGHT AIMING

Note. The reflectors for the low and high beams are an integrated unit. Therefore, perform the headlight aiming adjustment on only the low beam.

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. Point the headlight beams to a wall and verify that the headlight beams are as shown in the figure. (Scheme 73): Brightness Borderline Right Headlight And Left Headlight
2. Make a screen as shown in the figure using double-weight, white paper. (Scheme 75)(Scheme 74): Identifying Headlight Brightness Borderline And Elbow Point
3. Seat one person in the driver's seat.
4. Line up the vehicle with the wall so that the center of the headlight is 3 m {9.8 ft} away from the wall. (Scheme 75): Setting Up Vehicle For Checking Headlight Alignment
5. Measure the height at the center of the headlight. (Scheme 76): Measuring Height At Center Of Headlight NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the headlight using the actual vehicle.
6. Align the center of the headlight with the center of the screen. (Scheme 77): Measuring Height Of Center Of Headlight Using Actual Vehicle
7. Block the light of the other headlight using a partition.
8. Start the engine. NOTE: If servicing is performed when the engine is stopped and the headlight illuminates, it could result in a discharged battery. For the aiming adjustment, start the engine and perform servicing while the engine is idling.
9. Turn on the headlight low beams.
10. Set the headlight leveling switch to the 0 position. (vehicles with headlight leveling system)
11. Verify that the elbow point of the headlight is in the position indicated on the screen. If the elbow point is not in the position indicated on the screen, perform the following adjustment: Insert a Phillips driver into the position shown in the figure and adjust the headlights. (Scheme 78): Inserting Phillips Driver Into Position

Scheme 79

Scheme 80

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).)
2. Disconnect the connector. (Scheme 79): Identifying DRL Bulb And Connector
3. Rotate the DRL bulb in the direction of the arrow shown in the figure to remove it. (Scheme 80): Rotating DRL Bulb
4. Remove the DRL bulb.
5. Install in the reverse order of removal.

Scheme 81

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Rotate the socket in the direction of the arrow shown in the figure to remove it. (Scheme 81): Rotating Socket
3. Remove the DRL bulb from the socket.
4. Install in the reverse order of removal.

Discharge headlight inoperative

Locating Headlight Relay And Identifying Discharge Headlight Control Module Connector Terminals. Scheme 82

STEERING ANGLE SENSOR INITIALIZATION PROCEDURE

Note. If the following servicing is to be done, perform the steering angle sensor initialization procedure. The negative battery cable is disconnected Battery is replaced A fuse (ROOM) is removed Main fuse is replaced The steering angle sensor connector is disconnected Steering angle sensor is replaced Steering angle sensor connector is disconnected BCM connector is disconnected BCM is replaced

1. Inspect the wheel alignment, inflation pressure, and the installation condition of the steering wheel. If there is any malfunction, adjust the applicable part.
2. Start the engine.
3. Turn the steering wheel to full right lock, then turn it to full left lock. NOTE: The steering wheel can be turned first to the left or right. If the steering wheel is turned in the opposite direction before it locks, the correct steering angle will not be stored in memory.
4. Switch the ignition OFF (LOCK).

FRONT FOG LIGHT AIMING

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

1. Make a screen as shown in the figure using double-weight, white paper. (Scheme 83): Identifying Front Fog Light Aiming (Brightness Borderline)
2. Seat one person in the driver's seat.
3. Line up the vehicle with the wall so that the center of the front fog light is 3 m {9.8 ft} away from the wall. (Scheme 84): Setting Up Vehicle For Checking Front Fog Light Adjustment
4. Measure the height at the center of the front fog light. (Scheme 85): Measuring Height At Center Of Front Fog Light NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the front fog light using the actual vehicle.
5. Align the center of the front fog light with the center of the screen. (Scheme 86): Measuring Height Of Center Of Front Fog Light Using Actual Vehicle
6. Block the light of the other front fog light using a partition.
7. Start the engine. NOTE: If servicing is performed when the engine is stopped and the front fog light illuminates, it could result in a discharged battery. For the aiming adjustment, start the engine and perform servicing while the engine is idling.
8. Turn the front fog lights on.
9. Verify that the brightness border line of the front fog light is at the position indicated on the adjustment screen. If the brightness border line is not at the position indicated on the adjustment screen, perform the following adjustment. Loosen the bolt. (Scheme 87): Front Fog Light Bolt And Screw With Torque Specification Loosen the screw. Move the front fog light in the direction of the arrow shown in the figure to adjust the brightness border line to the position indicated on the adjustment screen. Tighten the screw and bolt.

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

1. Make a screen as shown in the figure using double-weight, white paper. (Scheme 88): Identifying Center Of Front Fog Light (Brightness Borderline)
2. Seat one person in the driver's seat.
3. Line up the vehicle with the wall so that the center of the front fog light is 3 m {9.8 ft} away from the wall. (Scheme 89): Setting Up Vehicle For Checking Front Fog Light Adjustment
4. Measure the height at the center of the front fog light. (Scheme 90): Measuring Height At Center Of Front Fog Light NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the front fog light using the actual vehicle.
5. Align the center of the front fog light with the center of the screen. (Scheme 91): Measuring Height Of Center Of Front Fog Light Using Actual Vehicle
6. Block the light of the other front fog light using a partition.
7. Start the engine. NOTE: If servicing is performed when the engine is stopped and the front fog light illuminates, it could result in a discharged battery. For the aiming adjustment, start the engine and perform servicing while the engine is idling.
8. Turn the front fog lights on.
9. Verify that the brightness border line of the front fog light is at the position indicated on the adjustment screen. If the brightness border line is not at the position indicated on the adjustment screen, perform the following adjustment. Loosen the bolt. (Scheme 92): Front Fog Light Bolt With Torque Specification Loosen the screw. Move the front fog light in the direction of the arrow shown in the figure to adjust the brightness border line to the position indicated on the adjustment screen. Tighten the screw and bolt.

Scheme 93

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the outer mirror glass. (See «OUTER MIRROR GLASS REMOVAL»(ref-579414-S03064323412013100700000).) (See «OUTER MIRROR GLASS INSTALLATION»(ref-579414-S03782179392013100700000).)
3. Remove the outer mirror garnish. (See «OUTER MIRROR GARNISH REMOVAL/INSTALLATION»(ref-579414-S01394896842013100700000).)
4. Remove the screw. (Scheme 93): Identifying Side Turn Light, Connector And Screw
5. Disconnect the connector.
6. Remove the side turn light while detaching tab. CAUTION: If the tabs of the side turn light are detached, the side turn light may fall off and be damaged. When detaching the tabs of the side turn light, hold the side turn light with a hand during the servicing.
7. Install in the reverse order of removal.

Scheme 94

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the outer mirror glass. (See «OUTER MIRROR GLASS REMOVAL»(ref-579414-S03064323412013100700000).) (See «OUTER MIRROR GLASS INSTALLATION»(ref-579414-S03782179392013100700000).)
3. Remove the outer mirror garnish. (See «OUTER MIRROR GARNISH REMOVAL/INSTALLATION»(ref-579414-S01394896842013100700000).)
4. Remove the side turn light. (See «SIDE TURN LIGHT REMOVAL/INSTALLATION»(ref-579340-S41636160952013100700000).)
5. Connect the battery voltage as shown in the figure. (Scheme 94): Applying Battery Voltage And Ground To Side Turn Light If the side turn light does illuminate, replace it. If the side turn light illuminate, inspect the short-code.

Scheme 95

Scheme 96

1. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).)
2. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).)
3. Disconnect the power outer mirror connector. (See «POWER OUTER MIRROR REMOVAL/INSTALLATION»(ref-579414-S20927855772013100700000).)
4. Verify that the continuity between side turn light terminals is as indicated in the table. (Scheme 95): Identifying Side Turn Light Connector Terminals
5. If not as indicated in the table, replace the power outer mirror. (Scheme 96): Side Turn Light Connector Terminal Continuity Chart

Scheme 97

Scheme 98

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Trunk mat (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000).) Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-579335-S26041262432013100700000).) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).)
3. Disconnect the connectors shown in the figure and remove the nuts. (Scheme 97): Rear Combination Light, Connectors And Nuts With Torque Specification
4. Pull the rear combination light in the direction of the arrow to detach it from the hook. (Scheme 98): Rear Combination Light Mounting
5. Remove the rear combination light.
6. Install in the reverse order of removal.

Scheme 99

Scheme 100

Scheme 101

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the service hole cover. (Scheme 99): Service Hole Cover
3. Disconnect the connectors shown in the figure and remove the nuts.
4. Pull the rear combination light in the direction of the arrow to detach it from the hook. (Scheme 101): Rear Combination Light Mounting With Torque Specifications
5. Remove the rear combination light.
6. Install in the reverse order of removal.

Scheme 102

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Trunk mat (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000).) Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-579335-S26041262432013100700000).)
3. Partially peel back the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).)
4. Remove in the order indicated in the table. (Scheme 102): Rear Turn Light Bulb, Socket And Connector
5. Install in the reverse order of removal.

Scheme 103

Scheme 104

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the service hole cover. (Scheme 103): Service Hole Cover
3. Remove in the order indicated in the table. (Scheme 104): Rear Turn Light Bulb, Socket And Connector
4. Install in the reverse order of removal.

Scheme 105

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Trunk mat (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000).) Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-579335-S26041262432013100700000).)
3. Partially peel back the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).)
4. Remove in the order indicated in the table. (Scheme 105): Brake/Taillight Bulb, Socket And Connector
5. Install in the reverse order of removal.

Scheme 106

Scheme 107

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the service hole cover. (Scheme 106): Service Hole Cover
3. Remove in the order indicated in the table. (Scheme 107): Brake/Taillight Bulb, Socket And Connector
4. Install in the reverse order of removal.

Scheme 108

Scheme 109

Scheme 110

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the trunk rid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-579335-S08118126462013100700000).)
3. Disconnect the connector. (Scheme 108): Back-Up Light Bulb And Connector
4. Rotate the socket in the direction of the arrow as shown in the figure to remove it. (Scheme 109): Rotating Socket
5. Remove the back-up light bulb. (Scheme 110): Back-Up Light Bulb And Socket
6. Install in the reverse order of removal.

Scheme 111

Scheme 112

Scheme 113

Scheme 114

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the service hole cover. (Scheme 111): Service Hole Cover
3. Disconnect the connector. (Scheme 112): Back-Up Light Bulb And Connector
4. Rotate the socket in the direction of the arrow as shown in the figure to remove it. (Scheme 113): Rotating Socket
5. Remove the back-up light bulb. (Scheme 114): Back-Up Light Bulb
6. Install in the reverse order of removal.

Scheme 115

Scheme 116

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-579335-S08118126462013100700000).)
3. Disconnect the connector. (Scheme 115): Inboard Light Connector Bracket And Nut With Torque Specification
4. Remove the nut.
5. Remove the bracket.
6. Remove the inboard light as shown in the figure. (Scheme 116): Inboard Light
7. Install in the reverse order of removal. (See «INBOARD LIGHT INSTALLATION NOTE»(ref-579340-S40106482712013100700000).)

Scheme 117

Scheme 118

Scheme 119

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the service hole cover. (Scheme 117): Service Hole Cover
3. Disconnect the connector. (Scheme 118): Liftgate, Bracket, Connector And Nuts With Torque Specification
4. Remove the nut.
5. Remove the bracket.
6. Remove the inboard light as shown in the figure. (Scheme 119): Inboard Light
7. Remove the request switch. (With Advanced keyless entry and push button start system) (See «REQUEST SWITCH REMOVAL/INSTALLATION»(ref-579383-S12534802852013100700000).)
8. Install in the reverse order of removal. (See «INBOARD LIGHT INSTALLATION NOTE»(ref-579340-S40106482712013100700000).)

Scheme 120

1. Push the bracket onto the trunk lid as shown in the figure and install. (Scheme 120): Pushing Bracket Onto Trunk Lid (Sedan)

Scheme 121

1. Push the bracket into the liftgate as shown in the figure and install. (Scheme 121): Pushing Bracket Into Liftgate (Hatchback)

Scheme 122

Scheme 123

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-579335-S08118126462013100700000).)
3. Disconnect the connector. (Scheme 122): High-Mount Brake Light Connector And Nuts With Torque Specification
4. Remove the nuts.
5. While pressing the tabs shown in the figure, pull the high-mount brake light outward and remove it. (Scheme 123): Pressing Tabs
6. Remove the high-mount brake light.
7. Install in the reverse order of removal.

Scheme 124

Scheme 125

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000).)
3. While pressing the tabs shown in the figure, pull the high-mount brake light outward and remove it. (Scheme 124): Pressing Tabs
4. Remove the high-mount brake light socket. (Scheme 125): High-Mount Brake Light Socket
5. Remove the high-mount brake light.
6. Install in the reverse order of removal.

Scheme 126

Scheme 127

Scheme 128

Scheme 129

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).)
2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000).)
3. Remove the rear spoiler. (See «REAR SPOILER REMOVAL/INSTALLATION»(ref-579341-S36523223132013100700000).)
4. Remove the screws shown in the figure. (Scheme 126): High-Mount Brake Light And Screws
5. Set the pin aside and remove the cover. (Scheme 127): High-Mount Brake Light, Cover And Pin
6. Remove the screws shown in the figure. (Scheme 128): High-Mount Brake Light And Screws
7. Pull out the wiring harness from the rear spoiler. (Scheme 129): Pulling Out Wiring Harness From Rear Spoiler
8. Remove the high-mount brake light.
9. Install in the reverse order of removal.

Scheme 130

Scheme 131

Scheme 132

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-579335-S08118126462013100700000).)
3. Remove the high-mount brake light. (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-579340-S10122912622013100700000).)
4. Remove the high-mount brake light outer lens. (Scheme 130): High-Mount Brake Light Outer Lens
5. Remove the high-mount brake light inner lens. (Scheme 131): High-Mount Brake Light Inner Lens
6. Remove the screws (with advanced keyless entry and push button start system). (Scheme 132): Trunk Lid Opener Switch Screws
7. Remove the trunk lid opener switch (with advanced keyless entry and push button start system).
8. Install in the reverse order of removal.

Scheme 133

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000).)
3. Remove the high-mount brake light. (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-579340-S10122912622013100700000).)
4. Remove the high-mount brake light lens. (Scheme 133): High-Mount Brake Light Lens
5. Install in the reverse order of removal.

Scheme 134

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-579335-S08118126462013100700000).)
3. Remove in the order indicated in the table. (Scheme 134): High-Mount Brake Light Bulb, Socket And Connector
4. Install in the reverse order of removal.

Scheme 135

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000).)
3. Remove the high-mount brake light. (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-579340-S10122912622013100700000).)
4. Remove in the order indicated in the table. (Scheme 135): High-Mount Brake Light Bulb, Socket And Connector
5. Install in the reverse order of removal.

Scheme 136

Scheme 137

Scheme 138

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the lens. (See «LICENSE PLATE LIGHT BULB REMOVAL/INSTALLATION»(ref-579340-S20320907672013100700000).)
3. Insert a tape-wrapped fastener remover to the position shown in the figure, release the tabs. (Scheme 136): Releasing Tabs
4. Pull the rear bumper in the direction of the arrow (1) in the figure, and pull out the license plate lights in the direction of the arrow (2). (Scheme 137): License Plate And Rear Bumper
5. Pull out the wiring harness in the direction of the arrow and set it aside from the hook. (Scheme 138): License Plate Wiring Harness
6. Remove the license plate light.
7. Install in the reverse order of removal.

Scheme 139

Scheme 140

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Insert a tape-wrapped fastener remover to the position shown in the figure, release the tabs, and remove the lens. (Scheme 139): Releasing Tabs
3. Remove the license plate light bulb. (Scheme 140): License Plate Light Bulb
4. Install in the reverse order of removal.

Scheme 141

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Lift up the vehicle.
3. Disconnect the quick release connector. (charcoal canister side) (See «CHARCOAL CANISTER REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579419-S25406758822013100700000).) (See «CHARCOAL CANISTER REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579418-S27192925112013100700000).) (See «CHARCOAL CANISTER REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579420-S37936743952013100700000).)
4. Remove in the order indicated in the table. (Scheme 141): Auto Leveling Sensor, Connector And Bolts With Torque Specification
5. Install in the reverse order of removal.
6. Perform the headlight auto leveling system initialization. (See «HEADLIGHT AUTO LEVELING SYSTEM INITIALIZATION»(ref-579340-S05932459082013100700000).)

Scheme 142

Scheme 143

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the auto leveling sensor. (See «AUTO LEVELING SENSOR REMOVAL/INSTALLATION»(ref-579340-S33890764012013100700000).)
3. Connect the three dry cell batteries (1.5 V) in a series. (Scheme 142): Testing Auto Leveling Sensor
4. Connect auto leveling sensor terminal A to the battery's minus terminal, and terminal C to the battery's plus terminal, and apply 4.5 V of voltage between terminals A and C.
5. Connect the tester as shown in the figure.
6. When slowly moving the link up and down, verify that the shift is linear while the voltage is 0.5 to 4.5 V. (Scheme 143): Auto Leveling Sensor Voltage Graph If the voltage cannot be verified as indicated in the graph, replace the auto leveling sensor.

HEADLIGHT AUTO LEVELING SYSTEM INITIALIZATION

Note. The headlight auto leveling system initial setting has a procedure which uses the M-MDS and one which does not. Because the procedure differs depending on the part which is replaced in the method not using the M-MDS, refer to the following and perform the initial setting. If the following servicing is to be done, perform the procedure for the case where system initialization has never been done. (See INITIALIZATION HAS NEVER BEEN PERFORMED .) AFS (adaptive front lighting system) control module is newly replaced.

1. If the following servicing is done, perform the procedure for the case where the system is reset after initialization has already been completed. (See «INITIALIZATION OPERATION IMPLEMENTED AND RESETTING TO BE PERFORMED»(ref-579340-S40907493802013100700000) .) Auto leveling sensor is removed/installed. Auto leveling sensor is replaced. Procedure for changing vehicle height is performed such as changing suspension.

Scheme 144

1. Connect the M-MDS to the DLC-2. (Scheme 144): Identifying DLC-2
2. After the vehicle is identified, select the following items from the initial screen of the M-MDS. When using the IDS (laptop PC) Select "Electrical". Select "Exterior Lighting". Select "Headlamp". Select "Auto Leveling Sensor Re-zero Procedure"
3. Adjust the headlight aiming. (See «HEADLIGHT AIMING»(ref-579340-S29759205522013100700000).)

Scheme 145

Scheme 146

1. Switch the ignition ON. NOTE: If the headlight auto leveling system initial setting is not completed, the AFS OFF indicator light flashes at 0.5 s intervals when the ignition is switched ON. This does not indicate a system malfunction, therefore, perform the initial setting.
2. Ground the DLC-2 B terminal 3 times or more at 1 s intervals using the jumper wire. (Scheme 145): Identifying Ground DLC-2 Connector Terminal B
3. If the headlight auto leveling system initial setting is completed normally, the AFS OFF indicator light flashes three times at 0.5 s intervals and it turns off. (Scheme 146): Identifying AFS OFF Indicator Light NOTE: If the AFS OFF indicator light continues to flash at 0.5 s intervals, the following malfunction can be considered. Repair or replace the malfunctioning area, then repeat the procedure from Step 1. (See «TROUBLESHOOTING INDEX [AFS (ADAPTIVE FRONT LIGHTING SYSTEM)]»(ref-579459-S00669418442013100700000).) With the normal completion of the headlight auto leveling system initial setting, the headlight leveling actuator operation can also be verified. If the headlight auto leveling system initial setting is completed normally, the headlight leveling actuator lowers from its current position for approx. 2 s and returns to its original position.
4. Disconnect the jumper wire from DLC-2.
5. Verify that the AFS OFF indicator light is not illuminated.
6. Adjust the headlight aiming. (See «HEADLIGHT AIMING»(ref-579340-S29759205522013100700000).)

Interior Light Control System / Turn Light System

1. The interior light control system and turn light system is controlled by the BCM. For the interior light control system setting, refer to the personalization function setting procedure. (See «CONTROL SYSTEM PERSONALIZATION FEATURES SETTING PROCEDURE»(ref-579382-S26017535002013100700000) .)

Scheme 147

Scheme 148

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the tabs shown in the figure. (Scheme 151): Map Light Mounting
3. Pull the map light in the direction of the arrow (1) shown in the figure and remove the map light while detaching the clips.
4. Disconnect the connector. (Scheme 152): Map Light And Connector
5. Install in the reverse order of removal.

Scheme 149

Scheme 150

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Insert a tape-wrapped fastener remover into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens. (Scheme 153): Locating Service Hole
3. Remove the map light bulb. (Scheme 154): Map Light Bulbs
4. Install in the reverse order of removal.

Scheme 151

Scheme 152

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).)
3. Verify that the continuity between the map light terminals is as indicated in the table. (Scheme 155): Identifying Map Light Connector Terminals If not as indicated in the table, inspect the bulb. If there is no malfunction, replace the map light. (Scheme 156): Map Light Terminal Continuity Chart
4. Apply battery positive voltage to map light terminal C, and connect terminal F to ground.
5. Switch the interior light switch to the DOOR position and verify that the map light illuminates. If the light does not illuminate, replace the map light.

Scheme 153

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000) )
3. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-579335-S17162348942013100700000).)
4. Pull in the direction of the arrows and detach the tabs. (Scheme 157): Detaching Tabs
5. Disconnect the connector.
6. Remove the interior light.
7. Install in the reverse order of removal. NOTE: After installing the wiring harness, reinforce the urethane that was cut when removing the valve housing with vinyl tape.

Scheme 154

Scheme 155

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Insert a tape-wrapped fastener remover into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens. (Scheme 158): Identifying Service Hole
3. Remove the interior light bulb. (Scheme 159): Interior Light Bulb
4. Install in the reverse order of removal.

Scheme 156

Scheme 157

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Insert a tape-wrapped fastener remover into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the cargo compartment light. (Scheme 160): Locating Service Hole
3. Disconnect the connector. (Scheme 161): Cargo Compartment Light And Connector
4. Remove the cargo compartment light.
5. Install in the reverse order of removal.

Scheme 158

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the cargo compartment light. (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-579340-S38317987032013100700000).)
3. Remove the cargo compartment light bulb. (Scheme 162): Cargo Compartment Light And Bulb
4. Install in the reverse order of removal.

Scheme 159

Scheme 160

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the cargo compartment light. (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-579340-S38317987032013100700000).)
3. Verify that the continuity between the cargo compartment light terminals is as indicated in the table. (Scheme 163): Identifying Cargo Compartment Light Connector Terminals If not as indicated in the table, inspect the bulb. If there is no malfunction, replace the cargo compartment light. (Scheme 164): Cargo Compartment Light Terminal Continuity Chart

Scheme 161

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Disengage the tabs by pressing both ends of the lens in the directions indicated by the arrows and remove the lens. (Scheme 165): Disengaging Tabs
3. Remove the trunk compartment light bulb.
4. Install in the reverse order of removal.

Scheme 162

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the column cover upper. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).)
3. Remove the ignition key illumination bulb. (Scheme 166): Ignition Key Illumination Bulb
4. Install in the reverse order of removal.

Scheme 163

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-579335-S39411275542013100700000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).)
3. Remove the glove comportment bulb from the socket. (Scheme 167): Glove Compartment Bulb And Socket
4. Install in the reverse order of removal.

Scheme 164

Scheme 165

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the sunvisor. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).)
3. Verify that the continuity between the vanity mirror illumination terminals is as indicated in the table. (Scheme 168): Identifying Vanity Mirror Illumination Connector Terminals If not as indicated in the table, inspect the bulb. If there is no malfunction, replace the sunvisor. (Scheme 169): Vanity Mirror Continuity Chart

Scheme 166

Scheme 167

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Insert a tape-wrapped fastener remover into the service hole, and pry it in the direction indicated by the arrow to remove the lens. see scheme 172: Service Hole
3. Remove the vanity mirror illumination bulb. see scheme 173: Vanity Mirror Illumination Bulb
4. Install in the reverse order of removal.

Scheme 168

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the assist handle cover. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).)
3. Remove in the order indicated in the table. see scheme 174: Identifying Power Window Switch And Connector
4. Install in the reverse order of removal.

Scheme 169

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).)
3. Remove in the order indicated in the table. see scheme 175: Identifying Console And Connector
4. Install in the reverse order of removal.
