DETERMINING OPEN CIRCUIT LOCATION (HS-CAN) [MULTIPLEX COMMUNICATION SYSTEM]
| CAUTION | Perform the following malfunction diagnosis only when it is diagnosed with an open circuit by CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [MULTIPLEX COMMUNICATION SYSTEM] . If the malfunctioning part is detected in the communication line, before disconnecting the related connector for inspection, press the connector in the connection direction to verify that there is no looseness or disconnection. When disconnecting the connector, verify that there is no damage, deformation, or corrosion of the connector terminals. |
- Verify the CAN system-related module DTCs and the failed module on the M-MDS screen.
- Apply the communication error DTC and the failed module to «DTC OUTPUT PATTERN AND MALFUNCTIONING PART»(ref-579440-S28568089832013100700000) , and select the possible cause for the diagnostic result and the reference for the inspection item. NOTE: The open circuit location can be determined by the DTCs indicated in «DTC OUTPUT PATTERN AND MALFUNCTIONING PART»(ref-579440-S28568089832013100700000) chart. DTCs not listed in the chart are not used for the determination of the open circuit location.
- Inspect the possible cause and inspection item of the applicable malfunctioning part.
- After repairing, return to «CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [MULTIPLEX COMMUNICATION SYSTEM]»(ref-579440-S17383330822013100700000) and verify that the repairs have been completed.
DETERMINING OPEN CIRCUIT LOCATION (MS-CAN) [MULTIPLEX COMMUNICATION SYSTEM]
| CAUTION | Perform the following malfunction diagnosis only when it is diagnosed with an open circuit by CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [MULTIPLEX COMMUNICATION SYSTEM] . If the malfunctioning part is detected in the communication line, before disconnecting the related connector for inspection, press the connector in the connection direction to verify that there is no looseness or disconnection. When disconnecting the connector, verify that there is no damage, deformation, or corrosion of the connector terminals. |
- Verify DTCs of the modules related to the CAN system.
- Apply the communication error DTC and the failed module to «DIAGNOSTIC TABLE FOR DETERMINING MALFUNCTIONING PART»(ref-579440-S01910823412013100700000) , and select the possible cause for the diagnostic result and the reference for the inspection item. NOTE: The open circuit location can be determined by the DTCs indicated in «DIAGNOSTIC TABLE FOR DETERMINING MALFUNCTIONING PART»(ref-579440-S01910823412013100700000) chart. DTCs not listed in the chart are not used for the determination of the open circuit location.
- Inspect the possible cause and inspection item of the applicable malfunctioning part.
- After repairing, return to «CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [MULTIPLEX COMMUNICATION SYSTEM]»(ref-579440-S17383330822013100700000) and verify that the repairs have been completed.
DETERMINING SHORT TO GROUND LOCATION (HS-CAN) [MULTIPLEX COMMUNICATION SYSTEM]
| CAUTION | Perform the following malfunction diagnosis only when it is diagnosed with a short to ground by CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [MULTIPLEX COMMUNICATION SYSTEM] . |
HS-CAN Short To Ground [Multiplex Communication System] System Wiring Diagram. Scheme 58
Scheme 58: HS-CAN Short To Ground [Multiplex Communication System] System Wiring Diagram
DETERMINING SHORT TO POWER SUPPLY LOCATION (HS-CAN) [MULTIPLEX COMMUNICATION SYSTEM]
| CAUTION | Perform the following malfunction diagnosis only when it is diagnosed with a short to power supply by CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [MULTIPLEX COMMUNICATION SYSTEM] . |
HS-CAN Short To Power Supply [Multiplex Communication System] System Wiring Diagram. Scheme 59
Scheme 59: HS-CAN Short To Power Supply [Multiplex Communication System] System Wiring Diagram
DETERMINING SHORT BETWEEN CIRCUITS LOCATION (HS-CAN) [MULTIPLEX COMMUNICATION SYSTEM]
| CAUTION | Perform the following malfunction diagnosis only when it is diagnosed with a short between circuits by CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [MULTIPLEX COMMUNICATION SYSTEM] . |
HS-CAN Short Between Circuits [Multiplex Communication System] System Wiring Diagram. Scheme 60
Scheme 60: HS-CAN Short Between Circuits [Multiplex Communication System] System Wiring Diagram
DETERMINING SHORT TO GROUND LOCATION (MS-CAN) [MULTIPLEX COMMUNICATION SYSTEM]
| CAUTION | Perform the following malfunction diagnosis only when it is diagnosed with a short to ground by CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [MULTIPLEX COMMUNICATION SYSTEM] . |
MS-CAN Short To Ground [Multiplex Communication System] System Wiring Diagram. Scheme 61
Scheme 61: MS-CAN Short To Ground [Multiplex Communication System] System Wiring Diagram
DETERMINING SHORT TO POWER SUPPLY LOCATION (MS-CAN) [MULTIPLEX COMMUNICATION SYSTEM]
| CAUTION | Perform the following malfunction diagnosis only when it is diagnosed with a short to power supply by CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [MULTIPLEX COMMUNICATION SYSTEM] . |
MS-CAN Short To Power Supply [Multiplex Communication System] System Wiring Diagram. Scheme 62
Scheme 62: MS-CAN Short To Power Supply [Multiplex Communication System] System Wiring Diagram
DETERMINING SHORT BETWEEN CIRCUITS LOCATION (MS-CAN) [MULTIPLEX COMMUNICATION SYSTEM]
| CAUTION | Perform the following malfunction diagnosis only when it is diagnosed with a short between circuits by CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW [MULTIPLEX COMMUNICATION SYSTEM] . |
MS-CAN Short Between Circuits [Multiplex Communication System] System Wiring Diagram. Scheme 63
Scheme 63: MS-CAN Short Between Circuits [Multiplex Communication System] System Wiring Diagram
