Engine - Intake-Air System [Skyactiv-G 2.0]: Removal & Installation Mazda 3 BL рестайлинг

INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [SKYACTIV-G 2.0]

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000) .)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Intake-Air System With Torque Specifications. Scheme 170

Air Cleaner Cover Removal Note

1. Remove the MAF sensor/IAT sensor No.1. (See «MASS AIR FLOW (MAF) SENSOR/INTAKE AIR TEMPERATURE (IAT) SENSOR NO.1 REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520417-S40773341122013010300000) .)
2. Remove the air cleaner cover and air hose as a single unit.
3. Remove the air cleaner cover.

Air Cleaner Case Removal Note

1. Remove the air cleaner case and fresh-air duct No.3 as a single unit.
2. Remove the air cleaner case.

Resonance Chamber Removal Note

1. Remove the splash shield (LH). (See «SPLASH SHIELD REMOVAL/INSTALLATION»(ref-520448-S04813808932013010300000) .)
2. Set the front mudguard (LH) out of the way. (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-520448-S04135051462013010300000) .)
3. Remove the resonance chamber.

Vacuum Hose Removal Note

1. Remove the plug hole plate. (See «PLUG HOLE PLATE REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520419-S32364526322013010300000) .)
2. Remove the vacuum hose.

Scheme 171

1. Remove the MAP sensor/IAT sensor No.2. (See «MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR/INTAKE AIR TEMPERATURE (IAT) SENSOR NO.2 REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520417-S09157530642013010300000).)
2. Disconnect the harness clip from the intake manifold as shown in the figure. (Scheme 171): Identifying Harness Clip Installation Position

Scheme 172

1. Install the evaporative hose as shown in the figure. (Scheme 172): Identifying Evaporative Hose Installation

Scheme 173

1. Install the vacuum hose as shown in the figure. (Scheme 173): Identifying Vacuum Hose Installation

Scheme 174

1. Install the fresh-air duct No.3 as shown in the figure. (Scheme 174): Identifying Fresh-Air Duct No.3 Installation

Scheme 175

1. Install the air cleaner case as shown in the figure. (Scheme 175): Identifying Air Cleaner Case Installation

Scheme 176

Scheme 177

1. Install the air hose as shown in the figure. (Scheme 176): Identifying Air Hose Installation (1 Of 2) (Scheme 177): Identifying Air Hose Installation (2 Of 2)

Scheme 178

Scheme 179

1. Install the ventilation hose as shown in the figure. (Scheme 178): Identifying Ventilation Hose Installation (1 Of 2) (Scheme 179): Identifying Ventilation Hose Installation (2 Of 2)

Scheme 180

1. Install the water hose as shown in the figure. (Scheme 180): Identifying Water Hose Installation

Scheme 181

Scheme 182

1. Disconnect the harness clip as shown in the figure. (Scheme 181): Identifying Harness Clip And Air Cleaner Element
2. Remove the air cleaner element as shown in the figure. (Scheme 182): Removing Air Cleaner Element
3. Install in the reverse order of removal.
