Oil Shower Pipe Installation Note
| CAUTION | If the bolt is tightened with oil adhering to the bolt and the oil shower pipe connector seat shown in the figure, the a ial force of the bolt will strengthen and could cause the connector seat to deform. Before installing, remove oil from the bolt and the oil shower pipe connector seat. |
Identifying Oil Shower Pipe, Connector Seat And Mounting Bolts. Scheme 293
Scheme 293: Identifying Oil Shower Pipe, Connector Seat And Mounting Bolts
Scheme 294
- Install the oil shower pipe in the order shown in the figure. (Scheme 294): Identifying Oil Shower Pipe Mounting Bolt Tightening Sequence
| Installation position | Tightening torque |
|---|
| 1 | 9-12 N.m 92-122 kgf.cm, 80-106 in.lbf |
| 2,3 | 8.0-9.0 N.m 82-91 kgf.cm, 71-79 in.lbf |
Cylinder Head Cover Installation Note
| CAUTION | To assure the sealing performance of the cylinder head cover, be careful of the following Verify that the cylinder head cover gasket is inserted into the cylinder head cover groove and install the cylinder head cover. Completely clean and remove any oil, dirt, sealant or other foreign material from the seal surface. To prevent silicone sealant from hardening, adhere the cylinder head cover and the cylinder head within 10 min. after silicone sealant is applied. Tighten the Bolts completely soon after adhering. |
Scheme 295
Scheme 296
- Insert a new cylinder head cover gasket into the cylinder head cover groove.
- Apply silicone sealant to the areas shown in the figure. (Scheme 295): Identifying Silicone Sealant Applying Areas On Cylinder Head And Exhaust Side Rear Camshaft Cap
- Tighten the cylinder head cover bolts in the order shown in the figure. Tightening torque 4.5-7.0 N.m {46-71 kgf.cm, 40-61 in.lbf} (Scheme 296): Identifying Cylinder Head Cover Bolt Tightening Sequence
