FOREWORD [DYNAMIC STABILITY CONTROL (DSC)]

1. If there is any vehicle malfunction complaint lodged by a customer, perform malfunction diagnosis according to the troubleshooting procedure.

Foreword (DSC) Troubleshooting Procedure Flow Chart. Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. If the malfunction does not recur, verify the malfunction cause by performing the following actions: Verify that a DTC has been recorded in the memory using the M-MDS. (See «ON-BOARD DIAGNOSIS [DYNAMIC STABILITY CONTROL (DSC)]»(ref-520373-S26681232002013010300000).) (Scheme 13): Identifying Data Link Connector (DLC-2) Perform a simulation test in the simulation mode based on the repair order form, record the data at that time, and detect the malfunction cause. Shake the wiring harness or connector of the electrical component which is suspected to be the cause of the malfunction, and inspect for the occurrence of any malfunction or DTCs. (Scheme 14): Shaking Wiring Harness Or Connector Of Electrical Component Inspect the female terminals for poor connection. (Scheme 15): Inspecting Female Terminals For Poor Connection

On-Board Diagnostic (OBD) Test Description

1. The OBD test inspects the integrity and function of the DSC and outputs the results when requested by the specific tests.
2. On-board diagnostic test also: Provides a quick inspection of the DSC usually performed at the start of each diagnostic procedure. Provides verification after repairs to ensure that no other faults occurred during service.
3. The OBD test is divided into 3 tests: Read/clear diagnostic results, PID monitor and record and active command modes.

PID/Data monitor and record

1. This function allows you to access certain data values, input signals, calculated values, and system status information.

Active command modes

1. This function allows you to control devices through the M-MDS.

Reading DTCs Procedure

1. Connect the M-MDS (IDS) to the DLC-2. see scheme 6: Identifying Data Link Connector (DLC-2)
2. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Self Test". Select "Modules". Select "ABS".
3. Verify the DTC according to the directions on the screen. If any DTCs are displayed, perform troubleshooting according to the corresponding DTC inspection.
4. After completion of repairs, clear all DTCs stored in the DSC. (See «CLEARING DTCS PROCEDURE»(ref-520372-S16273300702013010300000).)

Clearing DTCs Procedure

1. Connect the M-MDS (IDS) to the DLC-2. see scheme 7: Identifying Data Link Connector (DLC-2)
2. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Self Test". Select "Modules". Select "ABS".
3. Verify the DTC according to the directions on the screen.
4. Press the clear button on the DTC screen to clear the DTC.
5. Switch the ignition to off.
6. Switch the ignition to ON and wait for 5 s or more.
7. Perform DTC inspection. (See «READING DTCS PROCEDURE»(ref-520442-S37163240442013010300000).)
8. Verify that no DTCs are displayed.

PID/Data Monitor and Record Procedure

1. Connect the M-MDS (IDS) to the DLC-2. see scheme 8: Identifying Data Link Connector (DLC-2)
2. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "DataLogger". Select "Modules". Select "ABS".
3. Select the applicable PID from the PID table.
4. Verify the PID data according to the directions on the screen. NOTE: The PID data screen function is used for monitoring the calculated value of input/output signals in the module. Therefore, if the monitored value of the output parts is not within the specification, it is necessary to inspect the monitored value of input parts corresponding to the applicable output part control. In addition, because the system does not display an output part malfunction as an abnormality in the monitored value, it is necessary to inspect the output parts individually. When detecting DTCs, PIDs related to a malfunctioning system may not display even if the module is normal. Therefore, if a PID is not displayed, it is necessary to verify the DTC, perform malfunction diagnosis of the DTC that was detected, and do repairs.

Active Command Modes Procedure

1. Connect the M-MDS (IDS) to the DLC-2. see scheme 9: Identifying Data Link Connector (DLC-2)
2. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "DataLogger". Select "Modules". Select "ABS".
3. Select the simulation items from the PID table.
4. Perform the active command modes function, inspect the operations for each parts. If the operation of output parts cannot be verified after the active command mode inspection is performed, this could indicate the possibility of an open or short circuit, sticking, or operation malfunction in the output parts.

PID/DATA Monitor Table

Active Command Modes Table
