Security System and Locks System: Overview Mazda 3 BK

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Disconnect the negative battery cable. (Vehicles with power window system or power outer mirror)
2. Fully roll up the front door glass.
3. Remove the inner garnish. (See INNER GARNISH REMOVAL/INSTALLATION .)
4. Remove the regulator handle. (Vehicles with manual window system) (See REGULATOR HANDLE REMOVAL .) (See REGULATOR HANDLE INSTALLATION .)
5. Remove the front door trim. (See FRONT DOOR TRIM REMOVAL/INSTALLATION .)
6. Remove the hole cover.
7. Remove the nut, then remove the pad.
8. Remove the bolt.
9. Detach the rod from the outer handle.
10. Secure the rear part of the front outer handle and, with the front outer handle lever pulled outward (1), remove the rear part of the front outer handle from the front door.
11. Pull out the front side of the front outer handle from the front door.
12. Install in the reverse order of removal.

Scheme 5

Scheme 6

Scheme 7

1. Disconnect the negative battery cable. (Vehicles with power window system)
2. Fully roll up the rear door glass.
3. Remove the sail garnish. (5 door) (See SAIL GARNISH REMOVAL/INSTALLATION .)
4. Remove the regulator handle. (Vehicles with manual window system) (See REGULATOR HANDLE REMOVAL .) (See REGULATOR HANDLE INSTALLATION .)
5. Remove the rear door trim. (See REAR DOOR TRIM REMOVAL/INSTALLATION .)
6. Remove the hole cover.
7. Remove the hole plug.
8. Remove the bolt.
9. Remove the nut, then remove the pad.
10. Remove the bolt.
11. Detach the rod from the outer handle.
12. Secure the rear part of the rear outer handle and, with the rear outer handle lever pulled outward (1), remove the rear part of the rear outer handle from the rear door.
13. Install in the reverse order of removal.

Scheme 8

1. Disconnect the negative battery cable. (Vehicles with power window system or power outer mirror)
2. Remove the inner garnish. (front) (See INNER GARNISH REMOVAL/INSTALLATION .)
3. Remove the regulator handle. (Vehicles with manual window system) (See REGULATOR HANDLE REMOVAL .) (See REGULATOR HANDLE INSTALLATION .)
4. Remove the front door trim or rear door trim. (See FRONT DOOR TRIM REMOVAL/INSTALLATION .) (See REAR DOOR TRIM REMOVAL/INSTALLATION .)
5. Using a Flathead screwdriver, press and hold the tab in the direction indicated by arrow (1), and remove the shaft by pulling it in the direction indicated by arrow (2).
6. Pull off the inner handle, and remove the door lock knob cable and inner handle cable.
7. Install in the reverse order of removal.

Scheme 9

1. Disconnect the negative battery cable. (Vehicles with power window system or power outer mirror)
2. Fully roll up the front door glass.
3. Remove the following parts: Inner garnish (See INNER GARNISH REMOVAL/INSTALLATION .) Regulator handle (Vehicles with manual window system) (See REGULATOR HANDLE REMOVAL .) (See REGULATOR HANDLE INSTALLATION .) Front door trim (See FRONT DOOR TRIM REMOVAL/INSTALLATION .) Front outer handle (See «FRONT OUTER HANDLE REMOVAL/INSTALLATION»(ref-177783-S20434901182005060700000) .)
4. Remove the rod from the front door key cylinder.
5. Turn the key cylinder in the direction indicated by the arrow and move the tab to the notch.
6. Pull the front door key cylinder outward to remove it.
7. Install in the reverse order of removal.

Scheme 10

1. Disconnect the negative battery cable.
2. Remove the following parts: Inner garnish (See INNER GARNISH REMOVAL/INSTALLATION .) Regulator handle (Vehicles with manual window system) (See REGULATOR HANDLE REMOVAL .) (See REGULATOR HANDLE INSTALLATION .) Front door trim (See FRONT DOOR TRIM REMOVAL/INSTALLATION .) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-177733-S04813487652005060700000) .) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-177789-S29649909632005060700000) .) Inner handle (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-177783-S07301979192005060700000) .) Front door unit (See «FRONT DOOR UNIT REMOVAL/INSTALLATION»(ref-177731-S27059800082005060700000) .)
3. Pull the stopper of the front door lock actuator connector in the direction of the arrow (1).
4. Disconnect the front door lock actuator connector while pushing at point A.
5. Remove the front door latch and lock actuator from the front door unit.
6. Install in the reverse order of removal.

Scheme 11

1. Disconnect the negative battery cable.
2. Remove the following parts: Sail garnish (5 door) (See SAIL GARNISH REMOVAL/INSTALLATION .) Rear door garnish (5 door) (See REAR DOOR GARNISH REMOVAL/INSTALLATION .) Regulator handle (Vehicles with manual window system) (See REGULATOR HANDLE REMOVAL .) (See REGULATOR HANDLE INSTALLATION .) Rear door trim (See REAR DOOR TRIM REMOVAL/INSTALLATION .) Rear door glass (See «REAR DOOR GLASS REMOVAL/INSTALLATION»(ref-177733-S08869086412005060700000) .) Rear door speaker (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-177789-S04719230852005060700000) .) Inner handle (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-177783-S07301979192005060700000) .) Rear door unit (See «REAR DOOR UNIT REMOVAL/INSTALLATION»(ref-177731-S05441684022005060700000) .)
3. Pull the stopper of the rear door lock actuator connector in the direction of the arrow (1).
4. Disconnect the rear door lock actuator connector while pushing at point A.
5. Remove the rear door latch and lock actuator from the rear door unit.
6. Install in the reverse order of removal.

Scheme 12

1. The following actuators and switches are integrated with the front door latch and lock actuator. Inspect the front door latch and lock actuator according to each inspection procedure for the following items. Front door lock actuator (See «FRONT DOOR LOCK ACTUATOR INSPECTION»(ref-177783-S18751748202005060700000) .) Front door latch switch (See «FRONT DOOR LATCH SWITCH INSPECTION»(ref-177783-S28329553352005060700000) .) Front door key cylinder switch (Driver's side) (See «FRONT DOOR KEY CYLINDER SWITCH INSPECTION»(ref-177783-S40749513002005060700000) .) Door lock-link switch (Driver's side) (See «DOOR LOCK-LINK SWITCH INSPECTION»(ref-177783-S01196715572005060700000) .)

Scheme 13

1. The following actuator and switch are integrated with the rear door latch and lock actuator. Inspect the rear door latch and lock actuator according to each inspection procedure for the following items. Rear door lock actuator (See «REAR DOOR LOCK ACTUATOR INSPECTION»(ref-177783-S31957777482005060700000) .) Rear door latch switch (See «REAR DOOR LATCH SWITCH INSPECTION»(ref-177783-S12164586902005060700000) .)

Scheme 14

Scheme 15

1. Apply battery positive voltage and connect ground to the corresponding front door lock actuator terminals, and inspect the front door lock actuator operation. If not as specified, replace the front door latch and lock actuator.

Scheme 16

Scheme 17

1. Apply battery positive voltage and connect ground to the corresponding rear door lock actuator terminals, and inspect the rear door lock actuator operation. If not as specified, replace the rear door latch and lock actuator.

Scheme 18

Scheme 19

Scheme 20

1. When inspecting the latch, press the latch lever using a Flathead screwdriver or a similar tool.
2. Inspect for continuity between the front door latch switch terminals. If not as specified, replace the front door latch and lock actuator.

Scheme 21

Scheme 22

Scheme 23

1. When inspecting the latch, press the latch lever using a Flathead screwdriver or a similar tool.
2. Inspect for continuity between the rear door latch switch terminals. If not as specified, replace the rear door latch and lock actuator.

Scheme 24

Scheme 25

1. Inspect for continuity between the door lock-link switch terminals. If not as specified, replace the front door latch and lock actuator.

Scheme 26

Scheme 27

1. Inspect for continuity between the front door key cylinder switch terminals. If not as specified, replace the front door latch and lock actuator.

Scheme 28

1. Disconnect the negative battery cable.
2. Remove the inner handle cover. (See FRONT DOOR TRIM REMOVAL/INSTALLATION .)
3. Remove the screws, then remove the door lock switch.
4. Install in the reverse order of removal.

Scheme 29

Scheme 30

1. Inspect for continuity between the door lock switch terminals using an ohmmeter. If not as specified, replace the door lock switch.

Scheme 31

1. Remove the screws, then remove the door lock striker.
2. Install in the reverse order of removal.
3. Adjust the door. (See «DOOR ADJUSTMENT»(ref-177731-S20980832812005060700000) .)

Scheme 32

Scheme 33

1. To remove the fuel-filler lid opener, remove the following procedure: 5 door Remove the hole cover on the trunk side trim. (RH) 4 door Remove the trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-177786-S31599506232005060700000) .) Slightly bend back the trunk side trim. (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-177786-S14002586272005060700000) .)
2. To remove the fuel-filler lid opener lever, remove the following part: 2:1 Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-177786-S35097446782005060700000) .)
3. When removing the fuel-filler lid opener cable, perform the following procedure: 3:1 Remove the following parts: Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-177805-S40569716222005060700000) .) Rear scuff plate (Driver's side) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-177786-S15571640632005060700000) .) Tire house trim (Driver's side) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-177786-S13536083402005060700000) .) B-pillar lower trim (Driver's side) (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-177786-S07584945072005060700000) .) Partially peel back the floor covering so that the fuel-filler lid opener cable can be removed. Remove the fuel-filler lid opener cable from clips A.
4. Remove in the order indicated in the figure.
5. Install in the reverse order of removal.

Scheme 34

1. To remove the hood release cable, remove the following parts: Battery. Fresh-air duct (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [LF]»(ref-177563-S27802206012005060200000) .)
2. Remove in the order indicated in the figure.
3. Install in the reverse order of removal.
4. Adjust the hood. (See «HOOD ADJUSTMENT»(ref-177729-S12759145492005060700000) .)

Scheme 35

1. Pull the lever.
2. While pushing the tab in the direction of the arrow using a tape-wrapped, small Flathead screwdriver, detach it from the lower panel. CAUTION: Be careful not to damage the hood release cable when removing the hood release lever with the Flathead screwdriver.
3. Under the condition in Step 2 , pull the hood release lever outward, then remove it from the lower panel.

Scheme 36

Scheme 37

Scheme 38

1. When inspecting the latch, press the latch lever using a Flathead screwdriver or a similar tool.
2. Inspect for continuity between the hood latch switch terminals. If not as specified, replace the hood latch.

Scheme 39

1. Disconnect the negative battery cable.
2. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-177787-S26550087392005060700000) .)
3. Disconnect the keyless control module connector.
4. Remove the screw, then remove the keyless control module.
5. Install in the reverse order of removal.
6. When replacing the keyless control module, register the transmitter ID codes. (See «TRANSMITTER ID CODE REGISTRATION»(ref-177783-S14153699902005060700000) .)
