Security System and Locks System: Removal & Installation Mazda 3 BK

COIL ANTENNA REMOVAL/INSTALLATION

Note. Do not remove the coil antenna unless you are replacing it.

Scheme 46

1. Disconnect the negative battery cable.
2. Remove the following parts: Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-177783-S33436475022005060700000) .) Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-177786-S35097446782005060700000) .) Front side trim (Driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-177786-S00759394172005060700000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-177786-S23426726492005060700000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-177786-S25465886942005060700000) .)
3. Disconnect the coil antenna connector.
4. Detach the steering lock tabs from the holes on the coil antenna.
5. Install in the reverse order of removal.

Scheme 47

Scheme 48

1. When performing the following procedures, the immobilizer resetting procedure using the WDS or equivalent must also always be performed: "instrument cluster replacement", "PCM replacement", "instrument cluster and PCM joint replacement", "Key ID number clearing". The engine will not start unless all work is performed using the WDS or equivalent.
2. There are two methods for registering an additional key: Using the WDS or equivalent and using two keys that are able to start the engine.
3. When replacing any of the immobilizer system component parts, adding/erasing keys or performing other functions, refer to the following table and perform the applicable procedure (No. 1 to 5).

Scheme 49

Note. Within the following procedures, the term a "valid key" means a "key that can start the engine". After adding/registering keys, clearing ID numbers or replacing any component part of the immobilizer system, verify that all keys can start the engine within 5 s. When verifying that the keys can start the engine, wait at least 5 s or more between inserting them. If the engine cannot be started using a registered key, repeat the procedure from the beginning. Do not start the engine until the key registration procedure for all the necessary keys is completed. If the engine is started during the registration procedure, registration is stopped at that point. Repeat the procedure starting from the beginning if the engine is started before completion. Two or more key ID numbers must be registered for the engine to start. A maximum of eight key ID numbers can be registered for one vehicle. The WDS or equivalent can be used to verify the number of key ID numbers registered to a single vehicle. Do not select screen menus of the WDS or equivalent that are not indicated within the procedures.
