Sunroof: Overview Mazda 3 BK

Scheme 1

Scheme 2

Scheme 3

1. Fully close the glass panel.
2. Fully open the sunshade.
3. Remove the screws, then remove the glass panel.
4. Remove the weatherstrip from the glass panel.
5. Install in the reverse order of removal.
6. Adjust the glass panel. (See GLASS PANEL ADJUSTMENT .)

Scheme 4

Scheme 5

1. Fully close the glass panel.
2. Measure the gap and height difference between the glass panel and the body.
3. Loosen the glass panel installation screws and move the glass panel to adjust. Standard clearance a: 0.2-2.2 mm {0.008-0.08 in} b: 0 mm {0 in}
4. Tighten the screws.
5. Insert any available thin plastic card between the weatherstrip and the body, and verify that they are sealed. (There is resistance when the plastic card is moved.) If they are not sealed, perform Steps 3 - 4 and adjust again.

Scheme 6

1. Disconnect the negative battery cable.
2. Remove the following parts: Console (4 door) (See CONSOLE REMOVAL/INSTALLATION .) A-pillar trim (See A-PILLAR TRIM REMOVAL/INSTALLATION .) Upper anchor of the front seat belt (See FRONT SEAT BELT REMOVAL/INSTALLATION .) Front scuff plate (See FRONT SCUFF PLATE REMOVAL/INSTALLATION .) Rear scuff plate (See REAR SCUFF PLATE REMOVAL/INSTALLATION .) B-pillar lower trim (See B-PILLAR LOWER TRIM REMOVAL/INSTALLATION .) B-pillar upper trim (See B-PILLAR UPPER TRIM REMOVAL/INSTALLATION .) Rear seat (See REAR SEAT REMOVAL/INSTALLATION .) Tire house trim (See TIRE HOUSE TRIM REMOVAL/INSTALLATION .) Trunk side upper trim (5 door) (See TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION .) C-pillar trim (See C-PILLAR TRIM REMOVAL/INSTALLATION .) Map light (See MAP LIGHT REMOVAL/INSTALLATION .) Sunvisor (See SUNVISOR REMOVAL/INSTALLATION .) Assist handle (See ASSIST HANDLE REMOVAL/INSTALLATION .) Headliner (See HEADLINER REMOVAL/INSTALLATION .) Head impact pad (See HEAD IMPACT PAD REMOVAL/INSTALLATION .) Glass panel (See GLASS PANEL REMOVAL/INSTALLATION .)
3. Disconnect the front and rear drain hoses from the sunroof frame.
4. Remove the bolts and nuts, then remove the sunroof unit.
5. Install in the reverse order of removal.
6. Adjust the glass panel. (See GLASS PANEL ADJUSTMENT .)

Scheme 7

1. Disassembly in the order indicated in the table.
2. Assemble in the reverse order of disassembly.
