Removal
Note. If the Smart Junction Box (SJB) is dropped, damage to the internal components may occur. A new SJB must be installed.
Note. Electronic modules are sensitive to static electrical charges. If exposed to these charges, damage may result.
Note. Prior to the replacement of the module, it is necessary to upload the module configuration information to the scan tool. This information must be downloaded into the new module after installation. For additional information, refer to MODULE CONFIGURATION . In the event that As-Built data is required (the SJB does not communicate), all Remote Keyless Entry (RKE) devices must be programmed to the new SJB . A minimum of 2 devices are necessary to complete the configuration and turn off the flashing interior lights.
Note. The Tire Pressure Monitoring System (TPMS) functionality is integral to the SJB .
Note. The steps included in the SJB removal and installation procedure are critical to restoring the vehicle security and the TPMS to normal operation. A new SJB is delivered in a manufacturing mode with 8 pre-set DTCs related to the TPMS . To clear the 8 DTCs, successful configuration of the SJB must occur, followed by successful TPMS sensor training, and a successful self-test, including clearing of the DTCs. The 8 DTCs are as follows: B106D (Tire Pressure Monitor System [ TPMS ] Initiators Not Configured) B2477 (Module Configuration Failure) B2868 (Left Front Tire Pressure Sensor Fault) B2869 (Right Front Tire Pressure Sensor Fault) B2870 (Right Rear Tire Pressure Sensor Fault) B2871 (Left Rear Tire Pressure Sensor Fault) B2A21 (One or More Configuration Files Missing or Corrupt) C2780 ( ECU in Manufacturer Sub-State)
Pinpoint Test P
- NOTE: This step is necessary only if the SJB is being replaced.
Installation
Pinpoint Test P
- NOTE: Align the SJB bracket to the upper 2 mounting studs, then rotate the bracket onto the lower mounting stud.
- NOTE: If the SJB was not replaced, this is the last step that is necessary.
- NOTE: When successful, this step provides the calibration necessary for the SJB operation and clears DTCs B106D, B2477 and B2A21. The clearing of these DTCs indicates the calibration data has been successfully downloaded to the new SJB .
- NOTE: The RKE transmitter portion of the Integrated Keyhead Transmitter (IKT) key is automatically transferred during Programmable Module Installation (PMI). Passive Anti-Theft System (PATS) programming is not necessary. If As-Built data is required during PMI , all ( IKT or fob) remote transmitters must be programmed to the new SJB . Cycling the ignition to run for 6 seconds with each IKT programs the RKE function of the IKT key. For additional information, refer to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-356622) for the remote transmitter programming instructions.
- NOTE: DTC B2276 may set, indicating there are less than 2 transmitters programmed to the SJB . For additional information, refer to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-356622) .
- NOTE: When successful, this step clears DTCs B2868, B2869, B2870 and B2871. The clearing of these DTCs indicates the SJB has recognized the tire pressure sensors during the training procedure.
- NOTE: DTC C2780 does not clear if any of the pre-set DTCs are still present in the SJB . When successful, this step clears DTC C2780.
Removal and Installation
Pinpoint Test P
- NOTE: This step is necessary only if the Driver Seat Module (DSM) is being replaced.
- NOTE: Prior to the replacement of the module, it is necessary to upload the module configuration information to the scan tool. This information must be downloaded into the new module after installation. For additional information, refer to «MODULE CONFIGURATION»(ref-356608) .
- NOTE: If installing a new DSM , make certain to download the module configuration information to the new module after installation.
Scheme 147
| Item | Part Number | Description |
|---|---|---|
| 1 | Remote Function Actuator (RFA) module electrical connectors (part of 14401) | |
| 2 | W707628-S424 | RFA module screws (3 required) |
| 3 | 15604 | RFA module and bracket |
PARTS DESCRIPTION TABLE
Pinpoint Test P
- NOTE: This step is necessary only if the Remote Function Actuator (RFA) module is being replaced.
- NOTE: Prior to the replacement of the module, it is necessary to upload the module configuration information to the scan tool. This information must be downloaded into the new module after installation. For additional information, refer to «MODULE CONFIGURATION»(ref-356608) .
- NOTE: The Programmable Module Installation (PMI) process does not include the Intelligent Access (IA) key programming into the new RFA module. After the PMI process has been completed, the IA keys need to be programmed into the new RFA module during ignition off. For additional information, refer to Key Programming Using Diagnostic Equipment - Intelligent Access (IA) in «ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS)»(ref-356662) . After the IA keys have been programmed into the new RFA module, the ignition must be turned to the ON mode in order to reset the parameters in the new RFA module and the PCM. For additional information, refer to Passive Anti-Theft System (PATS) Parameter Reset - Intelligent Access (IA) in «ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS)»(ref-356662) .
- NOTE: It may be necessary to configure the factory set 5-digit permanent entry code from the Smart Junction Box (SJB) into the new RFA module. If this does not occur, DTC U2100:55 sets, indicating the module configuration is not complete (there is no entry code in the RFA module). A new RFA module does not come equipped with a factory set 5-digit permanent entry code and the entry code from the SJB must be configured into the new RFA module in order for the entry codes in both the RFA module and the SJB to match. If the entry codes do not match (or the entry code in the RFA module is missing), the keyless entry keypad may not operate correctly. For additional information, refer to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-356622) . This does not occur during Programmable Module Installation (PMI).
Scheme 148
| Item | Part Number | Description |
|---|---|---|
| 1 | Driver Door Module (DDM) electrical connectors (part of 14631) | |
| 2 | W705314-S424 | DDM screws (2 required) |
| 3 | 13C791 | DDM |
PARTS DESCRIPTION TABLE
Pinpoint Test P
- NOTE: This step is necessary only if the Driver Door Module (DDM) is being replaced.
- NOTE: Prior to the replacement of the module, it is necessary to upload the module configuration information to the scan tool. This information must be downloaded into the new module after installation. For additional information, refer to «MODULE CONFIGURATION»(ref-356608) .
