ADJUSTMENT
HINT
On the LH side, use the same procedures as on the RH side.
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
- INSPECT QUARTER WINDOW ASSY RH Check that the clearance is within the standard value.
- ADJUST QUARTER WINDOW ASSY RH Adjust the lower part of the glass inward/outward. (1) Loosen the 2 bolts on the quarter window assy. (2) Insert the shim to adjust the glass position (inside/outside). HINT: The shim should be inserted between the power window regulator and body. (3) Tighten the 2 bolts after adjustment. Torque: 8.0 N.m (82 kgf.cm, 71 ft.lbf) Adjust the upper part of the glass inward/outward. (1) Remove the lock nut for the adjusting bolt. (2) Using a hexagon wrench, turn the bolt for adjustment. (3) Tighten the nut after adjustment. Torque: 13.0 N.m (133 kgf.cm, 10 ft.lbf) Adjust the glass vertically and forward/rearward. (1) Loosen the 3 bolts on the glass for adjustment. (2) Adjust the vertical and forward/rearward positions of the glass Vertical position: +/- 3 mm (+/- 0.12 in.) Horizontal position: +/- 5 mm (+/- 0.20 in.) (3) Tighten the 3 bolts after adjustment. Torque: 8.0 N.m (82 kgf.cm, 71 ft.lbf) Install the glass stopper. (1) After adjustment (step a to c), install the glass stopper. (2) Tighten the 2 bolts. Torque: 11.5 N.m (117 kgf.cm, 8.5 ft.lbf) HINT: When the window is fully closed, adjust the position so that the window touches the 2 stoppers at the same time.
