Lighting System: Overhaul Lexus SC II

OVERHAUL

HINT

COMPONENTS: See COMPONENTS

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

1. REMOVE RADIATOR GRILLE (See «REPLACEMENT»(ref-211407-S22607084172005121700000) )
2. REMOVE FRONT FENDER LINER LH (See «REPLACEMENT»(ref-211407-S22607084172005121700000) )
3. REMOVE FRONT FENDER LINER RH (See «REPLACEMENT»(ref-211407-S22607084172005121700000) )
4. REMOVE FRONT BUMPER COVER (See «REPLACEMENT»(ref-211407-S22607084172005121700000) )
5. REMOVE HEADLAMP UNIT LH Remove the 2 bolts, nut and clip. Disconnect the connectors. Pull out the headlamp unit forward.
6. REMOVE DISCHARGE HEADLAMP BULB Remove the connector from the headlamp socket cover. Rotate the headlamp socket cover in the direction of the arrow and pull it off toward the rear of the vehicle. Rotate the bulb socket cover in the direction of the arrow and pull it off toward the rear of the vehicle. Release the lock of the set spring and remove the discharge headlamp bulb.
7. REMOVE HEADLAMP NO. 2 BULB Rotate the headlamp No. 2 bulb in the direction of the arrow and pull it off toward the rear of the vehicle.
8. REMOVE FRONT TURN SIGNAL LAMP BULB Remove the front turn signal lamp bulb.
9. REMOVE CLEARANCE LAMP BULB Remove the clearance lamp bulb.
10. HEADLIGHT AIM ONLY (See «ADJUSTMENT»(ref-234324-S03879461632006060800000) )
11. PUT VEHICLE THESE CONDITIONS
12. ADJUST FOG LIGHT AIM

Scheme 77

Scheme 78

1. HEADLIGHT AIM ONLY Place the vehicle in the following conditions. The area around the headlight is not deformed. The vehicle is parked on a level surface. Tire inflation pressure is the specified value. A driver is in the driver's seat and the vehicle is in a state ready for driving (with a tank full). The vehicle has been bounced several times. Check the headlight aiming. Prepare a thick white paper. Stand the paper perpendicular to the ground at the position 3 m (9.84 ft) away from the headlights. Ensure that the center line of the vehicle and the paper face forms a 90-degree angle as shown in the illustration. Draw a horizontal line (H line) on the paper, showing where the headlights should strike. Draw a vertical line (V line) to where the center line of the vehicle is to be. Draw 2 vertical lines to where the both headlights should strike (V RH and V LH lines). Draw a horizontal line (by connecting the both low beam center marks) to where the headlights should strike (H RH and H LH lines). HINT: The H RH and H LH line is 0.4° below the horizontal line (H line) of the light axis. Take appropriate measures to prevent influence of other lights. NOTE: Disconnect connectors of the other lights so that the aiming adjustment will not be affected Hole punch has destroyed the text. When connecting the connectors again, take care not to make the aiming out of adjustment. If covering the headlights, finish it within 3 min. Note that the headlight lens is made of synthetic resin and can be affected by heat. Start the engine. Turn the headlights ON. Check that the headlights properly strike the position shown in the illustration. If not, adjust the lights in the vertical direction. HINT: As shown in the illustration, adjust each aim of the RH and LH lights. When adjusting it in the vertical direction. Using adjusting bolt A and B, adjust the headlight aim to within the specified range. Basically adjust it with adjusting bolt A. Since the headlight swings in the horizontal direction during adjusting with adjusting bolt A, correct with adjusting bolt B in the horizontal direction. Rotate adjusting bolt A and B in the ratio of 5 to 1 to adjust the optical axis. HINT: Rotating a screwdriver clockwise makes the optical axis aim downward and rotating counterclockwise makes it upward.
