Lighting System: Removal & Installation Lexus SC II

Exterior Lights 17 illustrations ~1296 words

REPLACEMENT

HINT

COMPONENTS: See «COMPONENTS»

Scheme 54

Scheme 54: REPLACEMENT
Scheme 54: REPLACEMENT
  1. REMOVE RADIATOR GRILLE (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#front-bumper-cover__replacement) )
  2. REMOVE FRONT FENDER LINER LH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#front-bumper-cover__replacement) )
  3. REMOVE FRONT FENDER LINER RH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#front-bumper-cover__replacement) )
  4. REMOVE FRONT BUMPER COVER (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#front-bumper-cover__replacement) )
  5. REMOVE FOG LAMP, LAMP UNIT LH Remove the 3 bolts and fog lamp assy. Remove the screw and fog lamp bracket LH. Remove the bulb and fog lamp, lamp unit LH.
  6. PUT VEHICLE THESE CONDITIONS (See «ADJUSTMENT» )
  7. ADJUST FOG LIGHT AIM (See «ADJUSTMENT» )

Scheme 55

Scheme 55: ADJUSTMENT
Scheme 55: ADJUSTMENT
  1. PUT VEHICLE THESE CONDITIONS Tire inflation pressure is the specified value. Start the engine.
  2. ADJUST FOG LIGHT AIM Insert the screwdrivers tip into the hole in the front bumper and rotate the aiming screw while observing through the peephole of the front bumper.(Vertical adjustment) HINT: Rotating a screwdriver clockwise makes the optical axis aim downward and rotating counterclockwise makes it upward.

HINT

COMPONENTS: See «LIGHTING»

Scheme 56

Scheme 56: REPLACEMENT
Scheme 56: REPLACEMENT
  1. REMOVE RADIATOR GRILLE (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#front-bumper-cover__replacement) )
  2. REMOVE FRONT FENDER LINER LH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#front-bumper-cover__replacement) )
  3. REMOVE FRONT FENDER LINER RH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#front-bumper-cover__replacement) )
  4. REMOVE FRONT BUMPER COVER (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#front-bumper-cover__replacement) )
  5. REMOVE FRONT MARKER LAMP ASSY LH Remove the screw. Remove the front marker lamp assy. Remove the bulb socket and front marker lamp assy LH.

HINT

COMPONENTS: See «LIGHTING»

Scheme 57

Scheme 57: REPLACEMENT
Scheme 57: REPLACEMENT
  1. REMOVE TONNEAU COVER STOPPER SUB-ASSY LH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  2. REMOVE REAR FLOOR FINISH PLATE (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  3. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  4. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  5. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  6. REMOVE SPARE WHEEL COVER ASSY (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  7. REMOVE TOOL BOX COVER (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  8. REMOVE LUGGAGE COMPARTMENT TRIM COVER SUB-ASSY REAR (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  9. REMOVE TONNEAU COVER ASSY (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  10. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  11. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  12. REMOVE LUGGAGE COMPARTMENT TRIM COVER SIDE LH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  13. REMOVE REAR LAMP COVER LH Using a screwdriver, remove the rear lamp cover LH.
  14. REMOVE REAR COMBINATION LAMP LENS LH Remove the bolt. Pull out the rear combination lamp lens LH forward, then disconnect the 2 pins and rear combination lamp guide of body side. Remove the 2 bulb sockets and rear combination lamp lens LH.

HINT

COMPONENTS: See «LIGHTING»

Scheme 58

Scheme 58: REPLACEMENT
Scheme 58: REPLACEMENT
  1. REMOVE TONNEAU COVER STOPPER SUB-ASSY LH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  2. REMOVE TONNEAU COVER STOPPER SUB-ASSY RH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  3. REMOVE REAR FLOOR FINISH PLATE (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  4. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  5. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  6. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  7. REMOVE SPARE WHEEL COVER ASSY (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  8. REMOVE TOOL BOX COVER (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  9. REMOVE LUGGAGE COMPARTMENT TRIM COVER SUB-ASSY REAR (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  10. REMOVE TONNEAU COVER ASSY (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  11. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  12. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  13. REMOVE LUGGAGE COMPARTMENT TRIM COVER SIDE LH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  14. REMOVE LUGGAGE COMPARTMENT TRIM COVER SIDE RH (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  15. REMOVE REAR BUMPER COVER (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#rear-bumper-cover__replacement) )
  16. REMOVE REAR SIDE MARKER LAMP LENS LH Remove the screw. Remove the rear side marker lamp lens assy. Remove the bulb socket and rear side marker lamp lens LH.

HINT

COMPONENTS: See «LIGHTING»

Scheme 59

Scheme 59: REPLACEMENT
Scheme 59: REPLACEMENT
  1. REMOVE LICENSE PLATE LAMP LENS & COVER LH Using a screwdriver, remove the license plate lamp. HINT: Tape the screwdriver tip before use. Remove the bulb socket and license plate lamp lens and cover LH.

HINT

COMPONENTS: See «LIGHTING»

Scheme 60

Scheme 60: REPLACEMENT
Scheme 60: REPLACEMENT

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62
  1. REMOVE LUGGAGE COMPARTMENT DOOR ASSIST GRIP (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#luggage-compartment-door__replacement) )
  2. REMOVE LUGGAGE COMPARTMENT DOOR COVER (See «REPLACEMENT»(/lexus/sc/ii-2001-2005/remont/exteriorinterior-trim/#luggage-compartment-door__replacement) )
  3. REMOVE CENTER STOP LAMP ASSY Disconnect the connector. Remove the tape. Remove the 2 nuts. Apply protective tape to the body. Using a heat light, heat the center stop lamp assy to 40-60°C(104-140°F). NOTE: Do not heat the center stop lamp assy excessively. Tie both piano wire ends to wooden blocks or similar objects. Cut the double stick tape by pulling the piano wire as shown in the illustration. NOTE: If reusing the center stop lamp assy, take care not to damage the center stop lamp assy. Do not damage the body. Remove the center stop lamp assy.
  4. INSTALL CENTER STOP LAMP ASSY Using a heat light, heat the body mounting surface 40-60°C(104-140°F). NOTE: Do not heat the body excessively. Remove the double stick tape from body. Wipe off stains with cleaner. Using a heat light, heat the center stop lamp assy to 20-30°C(68-86°F). NOTE: Do not heat the center stop lamp assy excessively. Remove the double stick tape from center stop lamp assy. Wipe off stains with cleaner. Apply new double stick tape to the center stop lamp assy as shown in the illustration. Using a heat light, heat the body and center stop lamp assy. Body: 40 - 60 °C (104 - 140 °F) Center stop lamp assy: 20 - 30 C (68 - 86 F) NOTE: Do not heat the body and center stop lamp assy excessively. Install the center stop lamp assy with the 2 nuts.

HINT

COMPONENTS: See «LIGHTING»

Scheme 63

Scheme 63: REPLACEMENT
Scheme 63: REPLACEMENT
  1. REMOVE BACK UP LAMP LENS LH Disconnect the connector. Remove the 2 bolts and back up lamp lens assy. Remove the bulb socket and back up lamp lens LH.

HINT

COMPONENTS: See «LIGHTING»

Scheme 64

Scheme 64: Replacement
Scheme 64: Replacement
  1. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY (See «REPLACEMENT» )
  2. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY NO. 1 (See «REPLACEMENT» )
  3. REMOVE STEERING COLUMN COVER LWR (See «OVERHAUL» )
  4. REMOVE STEERING COLUMN COVER UPR (See «OVERHAUL» )
  5. REMOVE TURN SIGNAL SWITCH ASSY Disconnect the connector. Remove the 2 screws. Remove the turn signal switch assy.
  6. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY

HINT

COMPONENTS: See «LIGHTING»

Scheme 65

Scheme 65: REPLACEMENT
Scheme 65: REPLACEMENT

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67
  1. REMOVE FRONT WHEELS (See «REMOVAL & INSTALLATION» )
  2. REMOVE HEIGHT CONTROL SENSOR SUB-ASSY FRONT LH Disconnect the connector. Remove the nut and disconnect the height control sensor link. Remove the 2 bolts and height control sensor sub-assy front LH.
  3. INSTALL HEIGHT CONTROL SENSOR SUB-ASSY FRONT LH Install the height control sensor sub-assy front LH with the 2 bolts. Torque: 7.8 N.m (80 kgf.cm, 69 in..lbf) Install the nut. Torque: 5.4 N.m (55 kgf.cm, 48 in..lbf) Connect the connector.
  4. INSTALL FRONT WHEELS (See «REMOVAL & INSTALLATION» )
  5. ADJUST HEIGHT CONTROL SENSOR SUB-ASSY FRONT LH Adjust the front height control sensor link. Loosen the lock nut of the height control sensor link. While the vehicle is unloaded, adjust the length of the height control sensor's arm by rotating the link so that the arm is set in the normal position. Check that the length of the threaded part, dimension (A) in the illustration, is shorter than the standard value. Standard: 14 mm (0.55 In.) Tighten the look nut of the height control sensor link. Torque: 5.4 N.m (55 kgf.cm, 48 in..lbf)
  6. HEADLIGHT AIM ONLY (See «ADJUSTMENT» )

HINT

COMPONENTS: See «LIGHTING»

Scheme 68

Scheme 68: REPLACEMENT
Scheme 68: REPLACEMENT

Scheme 69

Scheme 69
Scheme 69
  1. REMOVE HEIGHT CONTROL SENSOR SUB-ASSY REAR LH Disconnect the connector. Place matchmarks on the link and bracket. Remove the nut and disconnect the height control sensor link. Remove the 2 bolts and height control sensor sub-assy rear LH.
  2. INSTALL HEIGHT CONTROL SENSOR SUB-ASSY REAR LH Install the height control sensor sub-assy rear LH with the 2 bolts. Torque: 7.8 N.m (80 kgf.cm, 69 in..lbf) Align the matchmarks on the height control sensor link and bracket. Install the nut. Torque: 5.4 N.m (55 kgf.cm, 48 in..lbf) Connect the connector.
  3. HEADLIGHT AIM ONLY (See «ADJUSTMENT» )

HINT

COMPONENTS: See «COMPONENTS»

Scheme 70

Scheme 70: REPLACEMENT
Scheme 70: REPLACEMENT
  1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY NO. 1 (See «REPLACEMENT» )
  2. REMOVE SKID CONTROL ECU ASSY (See «REMOVAL» )
  3. REMOVE HEADLAMP LEVELING ECU ASSY Disconnect the connector. Remove the bolt. Remove the headlamp leveling ECU assy.
