Quarter Power Windows: Removal & Installation Lexus SC II

REPLACEMENT

HINT

1. The installation is in the reverse order of the removal. However, when there is a special point concerning the installation, it is indicated.
2. On the LH side, use the same procedures as on the RH side.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. MOVE ROOF PANEL TO HALF Referring to the manual operation procedures, move the roof panel to half. (See page «MANUAL OPERATING»(ref-183308-S21064813472005081300000) )
2. REMOVE REAR SEAT CUSHION ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
3. REMOVE REAR SEAT HEADREST PLATE COVER (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
4. REMOVE WIND DEFLECTOR BOARD ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
5. REMOVE REAR SEAT HEADREST PLATE (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
6. REMOVE REAR SEAT HEADREST ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
7. REMOVE REAR SEAT BACK ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
8. REMOVE DOOR SCUFF PLATE ASSY RH Using a screwdriver, remove the door scuff plate assy RH. HINT: Tape the screwdriver tip before use.
9. REMOVE QUARTER TRIM PANEL ASSY FRONT RH Using a screwdriver, release the 4 claws and remove the front seat outer belt garnish. HINT: Tape the screwdriver tip before use. Remove the 6 screws and clips. Disengage the 4 clips, then remove the quarter trim panel RH.
10. REMOVE CENTER PILLAR UPPER END WEATHER STRIP RH Using a clip remover, disengage the 4 clips. Remove the center pillar upper end weather strip RH.
11. REMOVE QUARTER BELT MOULDING RH Using a moulding remover, remove the quarter belt moulding RH.
12. REMOVE LUGGAGE COMPARTMENT DOOR WEATHERSTRIP Using a clip remover, disengage the 3 clips. Remove the front part of the luggage compartment door weatherstrip.
13. REMOVE REAR SPEAKER ASSY
14. REMOVE QUARTER WINDOW ASSY RH Disconnect the connector. Remove the connector and grommet. Remove the 2 bolts and 4 nuts. Remove the quarter window assy RH.
15. REMOVE QUARTER WINDOW STOP Remove the 2 bolts and 2 upper front door window stops.
16. REMOVE POWER WINDOW REGULATOR MOTOR ASSY LH Remove the 2 screws and power window regulator motor RH.
17. REMOVE QUARTER WINDOW ASSY RH As shown in the illustration, mark the 3 nuts position on the quarter window assy. Remove the 3 nuts and quarter window assy RH.
18. INSTALL QUARTER WINDOW ASSY RH Install the glass and 3 nuts so that the nut will be placed at the marked positions. HINT: When replacing the bracket with a new one, mark the bracket position on the panel assy side.
19. INSTALL POWER WINDOW REGULATOR MOTOR ASSY LH Torque: 5.0 N.m (51 kgf.cm, 44 in..lbf)
20. INSTALL QUARTER WINDOW STOP Torque: 13 N.m (133 kgf.cm, 10 ft.lbf)
21. INSTALL QUARTER WINDOW ASSY RH Torque: 8.0 N.m (82 kgf.cm, 71 in..lbf)
22. ADJUST QUARTER WINDOW ASSY RH (See page «ADJUSTMENT»(ref-211388-S07581640462005121700000) )
23. INSTALL REAR SEAT BACK ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) ) Torque: Bolt: 18 N.m (184 kgf.cm, 13 ft.lbf) Nut: 18 Mm (184 kgf.cm, 13 ft.lbf)
24. INSTALL REAR SEAT HEADREST ASSY Torque: 5.0 N.m (51 kgf.cm, 44 in..lbf)
25. INSTALL WIND DEFLECTOR BOARD ASSY Torque: 5.0 N.m (51 kgf.cm, 44 in..lbf)

Scheme 53

1. REMOVE REAR SEAT CUSHION ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
2. REMOVE WIND DEFLECTOR BOARD ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
3. REMOVE REAR SEAT HEADREST PLATE COVER (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
4. REMOVE REAR SEAT HEADREST PLATE (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
5. REMOVE REAR SEAT HEADREST ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
6. REMOVE REAR SEAT BACK ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
7. REMOVE DOOR SCUFF PLATE ASSY RH
8. REMOVE QUARTER TRIM PANEL ASSY FRONT RH
9. MANUALLY OPEN QUARTER WINDOW ASSY RH Remove the connector of the power window regulator motor RH. Connect the battery positive terminal to terminal 2 of the connector, and the negative one to terminal 1. Then open the quarter window assy. HINT: On the LH side, connect the battery positive terminal to terminal 1 and the negative one to terminal 2.
10. INSTALL QUARTER TRIM PANEL ASSY FRONT RH
11. INSTALL DOOR SCUFF PLATE ASSY RH
12. INSTALL REAR SEAT BACK ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) ) Torque: Bolt: 18 N.m (184 kgf.cm, 13 ft.lbf) Nut: 7.0 N.m (71 kgf.cm, 63 in..lbf)
13. INSTALL REAR SEAT HEADREST ASSY Torque: 5.0 N.m (51 kgf.cm, 44 in..lbf)
14. INSTALL WIND DEFLECTOR BOARD ASSY Torque: 5.0 N.m (51 kgf.cm, 44 in..lbf)

Scheme 54

1. REMOVE REAR SEAT CUSHION ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
2. REMOVE REAR SEAT HEADREST PLATE COVER (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
3. REMOVE WIND DEFLECTOR BOARD ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
4. REMOVE REAR SEAT HEADREST PLATE (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
5. REMOVE REAR SEAT HEADREST ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
6. REMOVE REAR SEAT BACK ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) )
7. REMOVE DOOR SCUFF PLATE ASSY RH
8. REMOVE QUARTER TRIM PANEL ASSY FRONT RH
9. MANUALLY CLOSE QUARTER WINDOW ASSY RH Remove the connector of the power window regulator motor RH. Connect the battery positive terminal to terminal 1 of the connector, and the negative one to terminal 2. Then open the quarter window assy. HINT: On the LH side, connect the battery positive terminal to terminal 2 and the negative one to terminal 1.
10. INSTALL QUARTER TRIM PANEL ASSY FRONT RH
11. INSTALL DOOR SCUFF PLATE ASSY RH
12. INSTALL REAR SEAT BACK ASSY (See page «OVERHAUL»(ref-211395-S00184599702005121700000) ) Torque: Bolt: 18 N.m (184 kgf.cm, 13 ft.lbf) Nut: 7.0 N.m (71 kgf.cm, 63 in..lbf)
13. INSTALL REAR SEAT HEADREST ASSY Torque: 5.0 N.m (51 kgf.cm, 44 in..lbf)
14. INSTALL WIND DEFLECTOR BOARD ASSY Torque: 5.0 N.m (51 kgf.cm, 44 in..lbf)
