Audio / Video (Service Information): Overview Lexus RX III

Entertainment Systems 5 illustrations ~341 words

Scheme 43

Scheme 43: ILLUSTRATION
Scheme 43: ILLUSTRATION

Scheme 44

Scheme 44: ILLUSTRATION
Scheme 44: ILLUSTRATION

Scheme 45

Scheme 45: REMOVAL
Scheme 45: REMOVAL

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47
  1. PRECAUTION (w/ Navigation System for HDD) NOTE: After the engine switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION».
  3. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(/lexus/rx/iii-2008-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  4. REMOVE UPPER CONSOLE PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 12»(/lexus/rx/iii-2008-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  5. REMOVE INSTRUMENT PANEL GARNISH LH . Refer to «REMOVAL - Step 22»(/lexus/rx/iii-2008-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  6. REMOVE NO. 1 SWITCH HOLE BASE . Refer to «REMOVAL - Step 23»(/lexus/rx/iii-2008-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  7. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 24»(/lexus/rx/iii-2008-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  8. REMOVE INSTRUMENT PANEL FINISH PANEL . Refer to «REMOVAL - Step 34»(/lexus/rx/iii-2008-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  9. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL . Refer to «REMOVAL - Step 35»(/lexus/rx/iii-2008-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  10. REMOVE RADIO RECEIVER ASSEMBLY WITH REGISTER NOTE: The 4 bolts of the radio receiver assembly with register are installed though the service holes at the bottom in the instrument panel. Make sure to check all of them. If the radio receiver assembly with register is pulled without removing the 4 bolts, it may result in damage to the radio receiver assembly with register. Remove the 4 bolts. Disengage the 9 clips. Disconnect each connector and remove the radio receiver assembly with register.
  11. REMOVE HAZARD WARNING SIGNAL SWITCH ASSEMBLY. Refer to «REMOVAL - Step 11»
  12. REMOVE NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY Disengage the 5 claws and remove the No. 3 instrument panel register assembly.
  13. REMOVE NO. 4 INSTRUMENT PANEL REGISTER ASSEMBLY Disengage the 5 claws and remove the No. 4 instrument panel register assembly.
  14. REMOVE RADIO RECEIVER ASSEMBLY
