Cellular Communication System (Service Information): Overview Lexus LX J200 рестайлинг

Scheme 205

Scheme 206

Scheme 207

Scheme 208

1. REMOVE ENGINE ROOM SIDE COVER LH . Refer to «REMOVAL [01/2012 - ] - Step 1»(ref-603939-S37335065822014031100000)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: w/ Navigation System: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [01/2012 - ]»(ref-603789-S23769828912014031100000) .
3. REMOVE REAR CONSOLE END PANEL SUB-ASSEMBLY . Refer to «REMOVAL [01/2012 - ] - Step 27»(ref-603940-S01610622482014031100000)
4. REMOVE DCM (TELEMATICS TRANSCEIVER) Disconnect the 4 connectors. Remove the 3 screws and telematics transceiver with bracket.
5. REMOVE NO. 2 TELEPHONE BRACKET Remove the 2 screws and telephone bracket LH. Remove the 2 screws and telephone bracket RH.
