MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

ALL

TYPICAL MALFUNCTION THRESHOLDS

1. One of the following conditions is met: Condition (A), (B), (C) or (D) Condition (A) When 2 or more of the following signals are input at the same time P switch ON N switch ON R switch ON D switch ON Condition (B) When 2 or more of the following signals are input at the same time NSW switch ON R switch ON D switch ON Condition (C) When the shift lever is in S, one of the following conditions is met NSW switch ON P switch ON N switch ON R switch ON Condition (D) All of the following conditions are met P switch OFF N switch OFF NSW switch OFF R switch OFF D switch OFF

COMPONENT OPERATING RANGE

Scheme 469

ALL

P0710, P0712: RANGE CHECK (CHATTERING, LOW RESISTANCE)

P0713: RANGE CHECK (HIGH RESISTANCE)

P0710: RANGE CHECK (CHATTERING)

P0712: RANGE CHECK (LOW RESISTANCE)

P0713: RANGE CHECK (HIGH RESISTANCE)

Scheme 470

ALL

CONDITION (A)

CONDITION (B)

When either condition below is met: Condition (A) or (B)

CONDITION (A)

CONDITION (B)

PROCEDURE

1. CHECK DTC OUTPUT (IN ADDITION TO DTC P0711) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0711 is output A P0711 and other DTCs are output B HINT: If any other codes besides P0711 are output, perform troubleshooting for those DTCs first. B --> See step 4 A: Go to next step
2. CHECK TRANSMISSION FLUID LEVEL Check the transmission fluid level. Refer to «ADJUSTMENT»(ref-385187-S08585595432011021400000) . OK Automatic transmission fluid level is correct. NG --> See step 5 OK --> See step 3
3. REPAIR OR REPLACE NO. 1 ATF TEMPERATURE SENSOR (NO. 1 TRANSMISSION WIRE). Refer to «REMOVAL»(ref-385187-S37128766922011021400000)
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-385197-S16653522462011021400000)
5. ADD FLUID. Refer to «ADJUSTMENT»(ref-385187-S08585595432011021400000)

Scheme 471

Scheme 472

The stop light switch remains ON during GO and STOP 5 times.

GO AND STOP IS DEFINED AS FOLLOWS

Scheme 473

ALL

HINT

*: Following conditions met

CONDITION (A)

CONDITION (B)

When both conditions below are met: Condition (A) and (B)

CONDITION (A)

CONDITION (B)

Scheme 474

1. CHECK DTC OUTPUT (IN ADDITION TO DTC P0729) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0729 is output A P0729 and other DTCs are output B HINT: If any other codes besides P0729 are output, perform troubleshooting for those DTCs first. B --> See step 5 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (RUNNING TEST) WARNING: This test should always be performed with at least 2 people. NOTE: Perform the test at the normal operating ATF temperature: 50 to 80°C (122 to 176°F). Perform the test with the A/C turned off. HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-385197-S07537012942011021400000) . Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART»(ref-385197-S14012301422011021400000) . ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valve and set each shift position Press "-->" button: Shift up Press "<--" button: Shift down It is possible to check the operation of the shift solenoid valves. [Vehicle Condition] The vehicle speed is 50 km/h (31 mph) or less. HINT: This test can be conducted when the vehicle speed is 50 km/h (31 mph) or less. The 4th to 5th and 5th to 6th up-shifts must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shifts must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List display on the Techstream. Gear positions in the event of a shift solenoid valve mechanical problem: Techstream gear shift command 1st 2nd 3rd 4th 5th 6th Actual gear position under malfunction 1st 2nd 3rd 4th 5th 4th OK Gear position changes in accordance with the Techstream command. NG --> See step 6 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test at the normal operating ATF temperature: 50 to 80°C (122 to 176°F). Be careful to prevent SST hose from interfering with the exhaust pipe. Perform the test with the A/C turned off. HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Remove the test plug on the transmission case center right side and connect SST. SST: 09992-00095 09992-00231 09992-00271 Connect the Techstream to the DLC3. Start the engine and warm it up. Measure the line pressure with SST. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. Measure the line pressure. ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Activate the Solenoid (SLT)* Operate shift solenoid valve SLT and raise line pressure ON or OFF HINT: OFF: Line pressure up (when Active Test "Activate the Solenoid (SLT)" is performed, ECM commands shift solenoid valve SLT to turn OFF) ON: No action (normal operation) [Vehicle Condition] The vehicle is stopped. The engine is idling. HINT: *: Activate the Solenoid (SLT) in the Active Test is performed to check the line pressure changes by connecting SST to the automatic transmission, which is used in the Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-385197-S07014838072011021400000) as well. Note that the pressure values in the Active Test and hydraulic test are different. OK The line pressure changes as specified when performing the Active Test. NG --> See step 7 OK: Go to next step
4. CLEAR DTC AND PERFORM RUNNING TEST Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-385197-S07537012942011021400000) . Check for DTC again after conducting the Monitor Drive Pattern. Refer to «MONITOR DRIVE PATTERN»(ref-385197-S40898441462011021400000) . OK No DTC output. NG --> See step 8 OK --> END
5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-385197-S16653522462011021400000)
6. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-385187-S09262429312011021400000)
7. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «DISASSEMBLY - Step 3»(ref-385187-S15636757722011021400000)
8. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-385187-S09262429312011021400000)

ALL

CONDITION (A)

CONDITION (B)

When either condition below is met: Condition (A) or (B)

CONDITION (A)

CONDITION (B)

Scheme 475

ALL

HINT

*: Following conditions met

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

OFF MALFUNCTION (C)

OFF MALFUNCTION (D)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

1. When both conditions below are met: OFF malfunction (A) and OFF malfunction (B), (C) or (D)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

OFF MALFUNCTION (C)

OFF MALFUNCTION (D)

1. When both conditions below are met: ON malfunction (A) and (B)
2. 2 detections are necessary per driving cycle
3. 1st detection: temporary flag ON
4. 2nd detection: pending fault code ON

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ALL

HINT

*: Following conditions met

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

1. When both conditions below are met: OFF malfunction (A) and (B)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

1. When both conditions below are met: ON malfunction (A) and (B)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ALL

HINT

*: Following conditions met

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

1. When both conditions below are met: OFF malfunctions (A) and (B)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

1. When one of following conditions is met: ON malfunctions (A), (B) or (C)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

ALL

HINT

*: Following conditions met

P0766 OFF MALFUNCTION (A) AND P0776 ON MALFUNCTION (A)

P0766 OFF MALFUNCTION (B) AND P0776 ON MALFUNCTION (B)

1. When both conditions below are met: OFF malfunction (A) and (B)

P0766 OFF MALFUNCTION (A)

P0766 OFF MALFUNCTION (B)

1. When both conditions below are met: ON malfunction (A) and (B)

P0776 ON MALFUNCTION (A)

P0776 ON MALFUNCTION (B)

ALL

CONDITION (A)

CONDITION (B)

When either condition below is met: Condition (A) or (B)

CONDITION (A)

CONDITION (B)

Scheme 476

ALL

HINT

*: Following conditions met

CONDITION (A)

CONDITION (B)

CONDITION (C)

CONDITION (D)

When both conditions below are met: Condition (A), and Condition (B), (C) or (D)

CONDITION (A)

CONDITION (B)

CONDITION (C)

CONDITION (D)

1. CHECK DTC OUTPUT (IN ADDITION TO DTC P0781) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0781 is output A P0781 and other DTCs are output B HINT: If any other codes besides P0781 are output, perform troubleshooting for those DTCs first. B --> See step 5 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (RUNNING TEST) WARNING: This test should always be performed with at least 2 people. NOTE: Perform the test at the normal operating ATF temperature: 50 to 80°C (122 to 176°F). Perform the test with the A/C turned off. HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-385197-S07537012942011021400000) . Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART»(ref-385197-S14012301422011021400000) . ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valve and set each shift position Press "-->" button: Shift up Press "<--" button: Shift down It is possible to check the operation of the shift solenoid valves. [Vehicle Condition] The vehicle speed is 50 km/h (31 mph) or less. HINT: This test can be conducted when the vehicle speed is 50 km/h (31 mph) or less. The 4th to 5th and 5th to 6th up-shifts must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shifts must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List display on the Techstream. Gear positions in the event of a shift solenoid valve mechanical problem: Techstream gear shift command 1st 2nd 3rd 4th 5th 6th Actual gear position under malfunction 1st 1st 3rd 3rd N* N* N*: Neutral OK Gear position changes in accordance with the Techstream command. NG --> See step 6 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test at the normal operating ATF temperature: 50 to 80°C (122 to 176°F). Be careful to prevent SST hose from interfering with the exhaust pipe. Perform the test with the A/C turned off. HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Remove the test plug on the transmission case center right side and connect SST. SST: 09992-00095 09992-00231 09992-00271 Connect the Techstream to the DLC3. Start the engine and warm it up. Measure the line pressure with SST. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. Measure the line pressure. ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Activate the Solenoid (SLT)* Operate shift solenoid valve SLT and raise line pressure ON or OFF HINT: OFF: Line pressure up (when Active Test "Activate the Solenoid (SLT)" is performed, ECM commands shift solenoid valve SLT to turn OFF) ON: No action (normal operation) [Vehicle Condition] The vehicle is stopped. The engine is idling. HINT: *: Activate the Solenoid (SLT) in the Active Test is performed to check the line pressure changes by connecting SST to the automatic transmission, which is used in the Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-385197-S07014838072011021400000) as well. Note that the pressure values in the Active Test and hydraulic test are different. OK The line pressure changes as specified when performing the Active Test. NG --> See step 7 OK: Go to next step
4. CLEAR DTC AND PERFORM RUNNING TEST Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-385197-S07537012942011021400000) . Check for DTC again after conducting the Monitor Drive Pattern. Refer to «MONITOR DRIVE PATTERN»(ref-385197-S40898441462011021400000) . OK No DTC output. NG --> See step 8 OK --> END
5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-385197-S16653522462011021400000)
6. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-385187-S09262429312011021400000)
7. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «DISASSEMBLY - Step 3»(ref-385187-S15636757722011021400000)
8. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-385187-S09262429312011021400000)

Scheme 477

Scheme 478

Scheme 479

Scheme 480

1. CHECK HARNESS AND CONNECTOR (TRANSFER SHIFT ACTUATOR ASSEMBLY - BODY GROUND) Disconnect the C44 transfer shift actuator assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C44-3 (N) - Body ground Always 10 kohms or higher NG --> See step 3 OK --> See step 2
2. GO TO TRANSFER SYSTEM INSPECTION. Refer to «INSPECTION - Step 5»(ref-385235-S39413997002011021400000)
3. CHECK HARNESS AND CONNECTOR (FOUR WHEEL DRIVE CONTROL ECU - BODY GROUND) Disconnect the A27 four wheel drive control ECU connector. Disconnect the C44 transfer shift actuator assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A27-16 (NP) - Body ground Always 10 kohms or higher NG --> See step 5 OK --> See step 4
4. GO TO TRANSFER SYSTEM INSPECTION. Refer to «INSPECTION - Step 7»(ref-385235-S39413997002011021400000)
5. CHECK HARNESS AND CONNECTOR (TRANSFER SHIFT ACTUATOR ASSEMBLY, FOUR WHEEL DRIVE CONTROL ECU - ECM) Disconnect the A38 ECM connector. Disconnect the C44 transfer shift actuator assembly connector. Disconnect the A27 four wheel drive control ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A38-5 (TFN) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
6. REPLACE ECM. Refer to «REMOVAL»(ref-385180-S10778133792011021400000)

ALL

HINT

*: Following conditions met

1. When either condition below is met: ON malfunction (A) or (B)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

1. When one of following conditions is met: ON malfunction (A), (B), (C), (D), (E), (F), (G) or (H)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

ON MALFUNCTION (D)

ON MALFUNCTION (E)

ON MALFUNCTION (F)

ON MALFUNCTION (G)

ON MALFUNCTION (H)

Scheme 481

1. CHECK DTC OUTPUT (IN ADDITION TO DTCS P0894 AND P2714) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0894 is output Only P0894 and P2714 are output A P0894, P2714 and other DTCs are output B HINT: If any other codes besides P0894 and P2714 are output, perform troubleshooting for those DTCs first. B --> See step 25 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test at the normal operating ATF temperature: 50 to 80°C (122 to 176°F). Be careful to prevent SST hose from interfering with the exhaust pipe. Perform the test with the A/C turned off. HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Remove the test plug on the transmission case center right side and connect SST. SST: 09992-00095 09992-00231 09992-00271 Connect the Techstream to the DLC3. Start the engine and warm it up. Measure the line pressure with SST. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. Measure the line pressure. ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Activate the Solenoid (SLT)* Operate shift solenoid valve SLT and raise line pressure ON or OFF HINT: OFF: Line pressure up (when Active Test "Activate the Solenoid (SLT)" is performed, ECM commands shift solenoid valve SLT to turn OFF) ON: No action (normal operation) [Vehicle Condition] The vehicle is stopped. The engine is idling. HINT: *: Activate the Solenoid (SLT) in the Active Test is performed to check the line pressure changes by connecting SST to the automatic transmission, which is used in the Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-385197-S07014838072011021400000) as well. Note that the pressure values in the Active Test and hydraulic test are different. OK The line pressure changes as specified when performing the Active Test. NG --> See step 21 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (RUNNING TEST) WARNING: This test should always be performed with at least 2 people. NOTE: Perform the test at the normal operating ATF temperature: 50 to 80°C (122 to 176°F). Perform the test with the A/C turned off. HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-385197-S07537012942011021400000) . Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valve and set each shift position Press "-->" button: Shift up Press "<--" button: Shift down It is possible to check the operation of the shift solenoid valves. [Vehicle Condition] The vehicle speed is 50 km/h (31 mph) or less. HINT: This test can be conducted when the vehicle speed is 50 km/h (31 mph) or less. The 4th to 5th and 5th to 6th up-shifts must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shifts must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List display on the Techstream. Compare the ECM gear shift command and the actual gear position. OK Gear position changes in accordance with the Techstream command. RESULT System Condition ECM Gear Shift Command Proceed to 1st 2nd 3rd 4th 5th 6th Malfunction Shift solenoid valve S1 Stuck ON*1 2nd 2nd 3rd 4th 5th 6th A Stuck OFF 1st 1st 3rd 4th 5th N*2 Shift solenoid valve S2 Stuck ON 1st 2nd 2nd 4th 6th 6th B Stuck OFF 3rd 3rd 3rd 4th 5th 5th Shift solenoid valve S3 Stuck ON 1st 2nd 3rd 3rd N*2 N*2 C Stuck OFF 3rd 4th 4th 4th 5th 6th Shift solenoid valve S4 Stuck ON*3 1st 2nd 3rd 4th 5th 6th D Stuck OFF 1st 2nd 3rd 4th 4th 4th Normal 1st 2nd 3rd 4th 5th 6th E HINT: *1: When shift solenoid valve S1 is stuck ON, the vehicle cannot drive in reverse. *2: Neutral *3: When shift solenoid valve S4 is stuck ON, gear shifting is normal. E --> See step 21 D --> See step 16 C --> See step 12 B --> See step 8 A: Go to next step
4. INSPECT SHIFT SOLENOID VALVE S1 Remove shift solenoid valve S1. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve S1 connector terminal - Shift solenoid valve S1 body 20°C (68°F) 11 to 15 ohms Apply battery voltage (12 V) to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) --> Shift solenoid valve S1 connector Battery negative (-) --> Shift solenoid valve S1 body Valve moves and makes an operating noise NG --> See step 26 OK: Go to next step
5. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «DISASSEMBLY»(ref-385187-S04181891772011021400000) . OK There are no foreign objects on any valve. NG --> See step 27 OK: Go to next step
6. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-385187-S13784599832011021400000) . OK The torque converter clutch operates normally. NG --> See step 28 OK --> See step 7
7. REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)
8. INSPECT SHIFT SOLENOID VALVE S2 Remove shift solenoid valve S2. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve S2 connector terminal - Shift solenoid valve S2 body 20°C (68°F) 11 to 15 ohms Apply battery voltage (12 V) to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) --> Shift solenoid valve S2 connector Battery negative (-) --> Shift solenoid valve S2 body Valve moves and makes an operating noise NG --> See step 29 OK: Go to next step
9. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «DISASSEMBLY»(ref-385187-S04181891772011021400000) . OK There are no foreign objects on any valve. NG --> See step 30 OK: Go to next step
10. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-385187-S13784599832011021400000) . OK The torque converter clutch operates normally. NG --> See step 31 OK --> See step 11
11. REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)
12. INSPECT SHIFT SOLENOID VALVE S3 Remove shift solenoid valve S3. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve S3 connector terminal - Shift solenoid valve S3 body 20°C (68°F) 11 to 15 ohms Apply battery voltage (12 V) to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) --> Shift solenoid valve S3 connector Battery negative (-) --> Shift solenoid valve S3 body Valve moves and makes an operating noise NG --> See step 32 OK: Go to next step
13. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «DISASSEMBLY»(ref-385187-S04181891772011021400000) . OK There are no foreign objects on any valve. NG --> See step 33 OK: Go to next step
14. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-385187-S13784599832011021400000) . OK The torque converter clutch operates normally. NG --> See step 34 OK --> See step 15
15. REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)
16. INSPECT SHIFT SOLENOID VALVE S4 Remove shift solenoid valve S4. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve S4 connector terminal - Shift solenoid valve S4 body 20°C (68°F) 11 to 15 ohms Apply battery voltage (12 V) to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) --> Shift solenoid valve S4 connector Battery negative (-) --> Shift solenoid valve S4 body Valve moves and makes an operating noise NG --> See step 35 OK: Go to next step
17. INSPECT SHIFT SOLENOID VALVE SL2 Remove shift solenoid valve SL2. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Apply battery voltage (12 V) to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) with a 21 W bulb --> Terminal 1 Battery negative (-) --> Terminal 2 Valve moves and makes an operating noise NG --> See step 36 OK: Go to next step
18. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «DISASSEMBLY»(ref-385187-S04181891772011021400000) . OK There are no foreign objects on any valve. NG --> See step 37 OK: Go to next step
19. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-385187-S13784599832011021400000) . OK The torque converter clutch operates normally. NG --> See step 38 OK --> See step 20
20. REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)
21. INSPECT SHIFT SOLENOID VALVE SLT Remove shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Apply battery voltage (12 V) to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) with a 21 W bulb --> Terminal 2 Battery negative (-) --> Terminal 1 Valve moves and makes an operating noise NG --> See step 39 OK: Go to next step
22. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «DISASSEMBLY»(ref-385187-S04181891772011021400000) . OK There are no foreign objects on any valve. NG --> See step 40 OK: Go to next step
23. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-385187-S13784599832011021400000) . OK The torque converter clutch operates normally. NG --> See step 41 OK --> See step 24
24. REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)
25. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-385197-S16653522462011021400000)
26. REPLACE SHIFT SOLENOID VALVE S1. Refer to «DISASSEMBLY - Step 6»(ref-385187-S15636757722011021400000)
27. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-385187-S09262429312011021400000)
28. REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)
29. REPLACE SHIFT SOLENOID VALVE S2. Refer to «DISASSEMBLY - Step 8»(ref-385187-S15636757722011021400000)
30. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-385187-S09262429312011021400000)
31. REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)
32. REPLACE SHIFT SOLENOID VALVE S3. Refer to «DISASSEMBLY - Step 9»(ref-385187-S15636757722011021400000)
33. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-385187-S09262429312011021400000)
34. REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)
35. REPLACE SHIFT SOLENOID VALVE S4. Refer to «DISASSEMBLY - Step 7»(ref-385187-S15636757722011021400000)
36. REPLACE SHIFT SOLENOID VALVE SL2. Refer to «DISASSEMBLY - Step 1»(ref-385187-S15636757722011021400000)
37. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-385187-S09262429312011021400000)
38. REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)
39. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «DISASSEMBLY - Step 3»(ref-385187-S15636757722011021400000)
40. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-385187-S09262429312011021400000)
41. REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)

ALL

P0973: RANGE CHECK (LOW RESISTANCE)

P0974: RANGE CHECK (HIGH RESISTANCE)

P0973: RANGE CHECK (LOW RESISTANCE)

P0974: RANGE CHECK (HIGH RESISTANCE)

Scheme 482

ALL

P0976: RANGE CHECK (LOW RESISTANCE)

P0977: RANGE CHECK (HIGH RESISTANCE)

P0976: RANGE CHECK (LOW RESISTANCE)

P0977: RANGE CHECK (HIGH RESISTANCE)

Scheme 483

ALL

P0979: RANGE CHECK (LOW RESISTANCE)

P0980: RANGE CHECK (HIGH RESISTANCE)

P0979: RANGE CHECK (LOW RESISTANCE)

P0980: RANGE CHECK (HIGH RESISTANCE)

Scheme 484

ALL

P0982: RANGE CHECK (LOW RESISTANCE)

P0983: RANGE CHECK (HIGH RESISTANCE)

P0982: RANGE CHECK (LOW RESISTANCE)

P0983: RANGE CHECK (HIGH RESISTANCE)

Scheme 485

ALL

P0985: RANGE CHECK (LOW RESISTANCE)

P0986: RANGE CHECK (HIGH RESISTANCE)

P0985: RANGE CHECK (LOW RESISTANCE)

P0986: RANGE CHECK (HIGH RESISTANCE)

Scheme 486

Scheme 487

Scheme 488

Scheme 489

1. INSPECT NO. 1 TRANSMISSION WIRE (SHIFT SOLENOID VALVE SLT) Disconnect the C39 No. 1 transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 13 (SLT+) - 5 (SLT-) 20°C (68°F) 5.0 to 5.6 ohms 13 (SLT+) - Body ground Always 10 kohms or higher 5 (SLT-) - Body ground Always 10 kohms or higher NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (NO. 1 TRANSMISSION WIRE - ECM) Disconnect the C53 ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C53-9 (SLT+) - C53-8 (SLT-) 20°C (68°F) 5.0 to 5.6 ohms C53-9 (SLT+) - Body ground Always 10 kohms or higher C53-8 (SLT-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
3. INSPECT SHIFT SOLENOID VALVE SLT Remove shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Apply battery voltage (12 V) to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) with a 21 W bulb --> Terminal 2 Battery negative (-) --> Terminal 1 Valve moves and makes an operating noise NG --> See step 6 OK --> See step 4
4. REPAIR OR REPLACE NO. 1 TRANSMISSION WIRE. Refer to «REMOVAL»(ref-385187-S37128766922011021400000)
5. REPLACE ECM. Refer to «REMOVAL»(ref-385180-S10778133792011021400000)
6. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «DISASSEMBLY - Step 3»(ref-385187-S15636757722011021400000)

ALL

P2740, P2742: RANGE CHECK (CHATTERING, LOW VOLTAGE)

P2743: RANGE CHECK (HIGH VOLTAGE)

P2740: RANGE CHECK (CHATTERING)

P2742: RANGE CHECK (LOW VOLTAGE)

P2743: RANGE CHECK (HIGH VOLTAGE)

ALL

HINT

*: Following conditions met

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

ON MALFUNCTION

1. When both conditions below are met: OFF malfunction (A) and (B)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

1. 2 detections are necessary per driving cycle: 1st detection: temporary flag ON 2nd detection: pending fault code ON Vehicle speed must be less than 10 km/h (6.2 mph) once before 2nd detection.

Scheme 490

1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Activate the Lock Up Control shift solenoid valve SLU to set automatic transmission to lock-up condition ON or OFF It is possible to check the shift solenoid valve SLU operation. [Vehicle Condition] The throttle valve opening angle is less than 35%. The vehicle speed is 60 km/h (37 mph) or more. HINT: This test can be conducted when the vehicle speed is 60 km/h (37 mph) or more. Perform this test while driving in 5th or 6th gear. Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: When changing the accelerator pedal opening angle while driving, if the engine speed does not change abruptly, lock-up is on. Slowly release the accelerator pedal in order to decelerate, but do not fully release the pedal (fully releasing the pedal will close the throttle valve and lock-up may be turned off automatically).

Scheme 491

1. CHECK DTC OUTPUT (IN ADDITION TO DTC P2757) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P2757 is output A P2757 and other DTCs are output B HINT: If any other codes besides P2757 are output, perform troubleshooting for those DTCs first. B --> See step 6 A: Go to next step
2. INSPECT SHIFT SOLENOID VALVE SLU Remove shift solenoid valve SLU. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Apply battery voltage (12 V) to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) with a 21 W bulb --> Terminal 2 Battery negative (-) --> Terminal 1 Valve moves and makes an operating noise NG --> See step 7 OK: Go to next step
3. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «DISASSEMBLY»(ref-385187-S04181891772011021400000) . OK There are no foreign objects on any valve. NG --> See step 8 OK: Go to next step
4. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-385187-S13784599832011021400000) . OK The torque converter clutch operates normally. NG --> See step 9 OK --> See step 5
5. REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)
6. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-385197-S16653522462011021400000)
7. REPLACE SHIFT SOLENOID VALVE SLU. Refer to «DISASSEMBLY - Step 2»(ref-385187-S15636757722011021400000)
8. REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-385187-S09262429312011021400000)
9. REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY. Refer to «REMOVAL»(ref-385187-S02660299292011021400000)

ALL

CONDITION (A)

CONDITION (B)

When either condition below is met: Condition (A) or (B)

CONDITION (A)

CONDITION (B)

Scheme 492

Scheme 493

Scheme 494

1. INSPECT NO. 1 TRANSMISSION WIRE (SHIFT SOLENOID VALVE SLU) Disconnect the C39 No. 1 transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 12 (SLU+) - 4 (SLU-) 20°C (68°F) 5.0 to 5.6 ohms 12 (SLU+) - Body ground Always 10 kohms or higher 4 (SLU-) - Body ground Always 10 kohms or higher NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (NO. 1 TRANSMISSION WIRE - ECM) Disconnect the C53 ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C53-10 (SLU+) - C53-11 (SLU-) 20°C (68°F) 5.0 to 5.6 ohms C53-10 (SLU+) - Body ground Always 10 kohms or higher C53-11 (SLU-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
3. INSPECT SHIFT SOLENOID VALVE SLU Remove shift solenoid valve SLU. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Apply battery voltage (12 V) to the shift solenoid valve and check that the valve moves and makes an operating noise. OK Measurement Condition Specified Condition Battery positive (+) with a 21 W bulb --> Terminal 2 Battery negative (-) --> Terminal 1 Valve moves and makes an operating noise NG --> See step 6 OK --> See step 4
4. REPAIR OR REPLACE NO. 1 TRANSMISSION WIRE. Refer to «REMOVAL»(ref-385187-S37128766922011021400000)
5. REPLACE ECM. Refer to «REMOVAL»(ref-385180-S10778133792011021400000)
6. REPLACE SHIFT SOLENOID VALVE SLU. Refer to «DISASSEMBLY - Step 2»(ref-385187-S15636757722011021400000)

ALL

ON MALFUNCTION (A)

ON MALFUNCTION (B)

When both conditions below are met: ON malfunction (A) and (B)

ON MALFUNCTION (A)

ON MALFUNCTION (B)
