WHEEL ALIGNMENT SPECIFICATIONS & PROCEDURES
Note. See appropriate SPECIFICATIONS & PROCEDURES article in WHEEL ALIGNMENT.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| ABS Speed Sensor Wire Harness Bolt C | 21 (28) | |
| Adjusting Nut | 43 (59) | |
| Axle Hub Lock Nut | 47 (64) | |
| Axle Hub-To-Disc Bolt | 54 (74) | |
| Ball Joint Stud Nut | ||
| Lower Ball Joint | 118 (160) | |
| Upper Ball Joint | 81 (110) | |
| Brake Caliper Bolts | 90 (123) | |
| Cone Washer Nuts | 24 (33) | |
| Dust Cover | 13 (18) | |
| Flexible Hose Bolt | 21 (28) | |
| Lower Control Arm-To-Body Bolt | 170 (230) | |
| Lower Control Arm | 118 (159) | |
| Pressure Hose | 13 (18) | |
| Shock Absorber-To-Lower Control Arm | 135 (101) | |
| Shock Absorber Upper Shaft Nut | 51 (68) | |
| Stabilizer Bar Link Retaining Nut | 18 (24) | |
| Stabilizer Bar Link-To-Control Arm Bolt | 38 (52) | |
| Stabilizer Bar-To-Frame Retainer Bracket Bolt | 13 (18) | |
| Steering Knuckle Arm | 108 (147) | |
| Steering Knuckle-To-Upper Control Arm | 81 (110) | |
| Tie Rod End-To-Steering Knuckle | 90 (122) | |
| Torque Arm Nuts | 166 (225) | |
| Upper Control Arm Adjust Cam Nuts | 72 (98) | |
| Wheel Lug Nut | 97 (131) | |
| INCH Lbs. (N.m) | ||
| ABS Speed Sensor | 71 (8) | |
| ABS Speed Sensor Wire Harness Bolt B | 115 (13) | |
| Bleeder Valve | 73 (8.3) | |
| Height Control Sensor Link | 49 (5.6) | |
TORQUE SPECIFICATIONS
Scheme 1
