Lighting: Removal & Installation — Lexus LS IV (2006-2012)

INSTALLATION

INSTALL HEADLIGHT ASSEMBLY LH (w/ Headlight Cleaner System) Attach the clamp. Connect the connectors. Install the headlight LH with the 3 bolts. Connect the headlight cleaner hose.
INSTALL HEADLIGHT ASSEMBLY LH (w/o Headlight Cleaner System) Attach the clamp. Connect the connectors. Install the headlight LH with the 3 bolts.
INSTALL FRONT BUMPER COVER (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
INSTALL FRONT WHEEL OPENING EXTENSION PAD LH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
INSTALL FRONT WHEEL OPENING EXTENSION PAD RH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
INSTALL RADIATOR GRILLE ASSEMBLY (See «INSTALLATION»(ref-349736-S28013553762009120800000) )
INSTALL FRONT FENDER WHEEL OPENING MOLDING LH (See «INSTALLATION»(ref-349736-S35594191962009120800000) )
INSTALL FRONT FENDER WHEEL OPENING MOLDING RH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
CHECK HEADLIGHT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
ADJUST HEADLIGHT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
INSTALL COOL AIR INTAKE DUCT SEAL (See «INSTALLATION»(ref-349716-S01754793652009120800000) )
INSTALL AIR CLEANER INLET COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-349724-S09859827162009120800000) )
INSTALL ENGINE ROOM SIDE COVER (See «INSTALLATION»(ref-349714-S23488176532009120800000) )
INSTALL ENGINE ROOM SIDE COVER LH (See «INSTALLATION»(ref-349714-S23488176532009120800000) )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
PERFORM INITIALIZATION NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
VEHICLE PREPARATION FOR HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
PREPARATION FOR HEADLIGHT AIMING (Using a screen) (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
HEADLIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
VEHICLE PREPARATION FOR FOG LIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S17005230462009120800000) )
PREPARATION FOR FOG LIGHT AIMING (See «ADJUSTMENT»(ref-349731-S17005230462009120800000) )
FOG LIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-349731-S17005230462009120800000) )
FOG LIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S17005230462009120800000) )

Scheme 211

Scheme 211: REPAIR

Scheme 212

Scheme 213

Scheme 214

INSTALL UPPER HEADLIGHT PROTECTOR RETAINER LH HINT: If the installation area of the headlight is damaged, use the supply retainer for low-cost repair. Ensure that the headlight is not damaged. Cut off the part shaded in the illustration and smooth with sandpaper. NOTE: After cutting off the part, place the headlight protector retainer against the bosses and gradually file away the old bracket if it interferes with the installation of the supply retainer. Install the headlight protector retainer with the screw.
INSTALL LOWER HEADLIGHT PROTECTOR RETAINER LH HINT: If the installation area of the headlight is damaged, use the supply retainer for low-cost repair. Ensure that the headlight is not damaged. Cut off the part shaded in the illustration and smooth with sandpaper. NOTE: After cutting off the part, place the headlight protector retainer against the bosses and gradually file away the old bracket if it interferes with the installation of the supply retainer. Install the headlight protector retainer with the screw.

Scheme 215

Scheme 215: COMPONENTS

Scheme 216

Scheme 216: REMOVAL

Scheme 217

Scheme 218

REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
REMOVE FRONT FENDER WHEEL OPENING MOLDING LH (See «REMOVAL»(ref-349736-S01821793382009120800000) )
REMOVE FRONT WHEEL OPENING EXTENSION PAD LH (See «REMOVAL»(ref-349736-S30791494642009120800000) )
REMOVE FRONT FENDER LINER LH Remove the 7 screws and 5 clips on the front side of the front fender liner LH, and bend the front fender liner LH.
REMOVE DISCHARGE HEADLIGHT BULB Turn the back cover in the direction indicated by the arrow and remove it. Turn the headlight control ECU in the direction indicated by the arrow and remove the socket. Release the set spring lock as shown in the illustration and remove the discharge headlight bulb. NOTE: Do not touch the glass part of the bulb.

Scheme 219

Scheme 219: INSTALLATION

Scheme 220

INSTALL DISCHARGE HEADLIGHT BULB Lock the set spring and install the discharge headlight bulb. NOTE: Do not touch the glass part of the bulb. Turn the headlight control ECU in the direction indicated by the arrow and install the socket. NOTE: Install the socket so that the wire harness is pointed downwards. Turn the back cover in the direction indicated by the arrow and install it.
INSTALL FRONT FENDER LINER LH Install the front fender liner LH with the 7 screws and 5 clips.
INSTALL FRONT WHEEL OPENING EXTENSION PAD LH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
INSTALL FRONT FENDER WHEEL OPENING MOLDING LH (See «INSTALLATION»(ref-349736-S35594191962009120800000) )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
PERFORM INITIALIZATION NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 221

Scheme 221: COMPONENTS

Scheme 222

Scheme 222: REMOVAL

Scheme 223

REMOVE SIDE TURN SIGNAL LIGHT ASSEMBLY Disengage the 2 claws and disconnect the side turn signal light in the order shown in the illustration. Rotate the cover 40°, disconnect the connector and remove the side turn signal light.

Scheme 224

Scheme 224: INSTALLATION

INSTALL SIDE TURN SIGNAL LIGHT ASSEMBLY Connect the connector. Rotate the cover 40°. Engage the 2 claws in the order shown in the illustration and install the side turn signal light.

Scheme 225

Scheme 225: COMPONENTS

Scheme 226

Scheme 227

Scheme 227: REMOVAL

REMOVE ENGINE ROOM SIDE COVER LH (See «REMOVAL»(ref-349714-S31912998822009120800000) )
REMOVE ENGINE ROOM SIDE COVER (See «REMOVAL»(ref-349714-S31912998822009120800000) )
REMOVE AIR CLEANER INLET COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349724-S31319866602009120800000) )
REMOVE COOL AIR INTAKE DUCT SEAL (See «REMOVAL»(ref-349716-S20016930692009120800000) )
REMOVE FRONT FENDER WHEEL OPENING MOLDING LH (See «REMOVAL»(ref-349736-S01821793382009120800000) )
REMOVE FRONT FENDER WHEEL OPENING MOLDING RH (See «REMOVAL»(ref-349736-S30791494642009120800000) )
REMOVE RADIATOR GRILLE ASSEMBLY (See «REMOVAL»(ref-349736-S03523530332009120800000) )
REMOVE FRONT WHEEL OPENING EXTENSION PAD LH (See «REMOVAL»(ref-349736-S30791494642009120800000) )
REMOVE FRONT WHEEL OPENING EXTENSION PAD RH (See «REMOVAL»(ref-349736-S30791494642009120800000) )
REMOVE FRONT BUMPER COVER (See «REMOVAL»(ref-349736-S30791494642009120800000) )
REMOVE FOG LIGHT ASSEMBLY LH Disconnect the clamp. Remove the 2 bolts and fog light LH.

Scheme 228

Scheme 228: DISASSEMBLY

REMOVE FOG LIGHT BULB Turn the fog light bulb in the direction indicated by the arrow in the illustration and remove it from the fog light unit LH.

INSTALL FOG LIGHT ASSEMBLY LH Install the fog light LH with the 2 bolts. Connect the clamp.
INSTALL FRONT BUMPER COVER (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
INSTALL FRONT WHEEL OPENING EXTENSION PAD LH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
INSTALL FRONT WHEEL OPENING EXTENSION PAD RH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
INSTALL RADIATOR GRILLE ASSEMBLY (See «INSTALLATION»(ref-349736-S28013553762009120800000) )
INSTALL FRONT FENDER WHEEL OPENING MOLDING LH (See «INSTALLATION»(ref-349736-S35594191962009120800000) )
INSTALL FRONT FENDER WHEEL OPENING MOLDING RH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
INSTALL COOL AIR INTAKE DUCT SEAL (See «INSTALLATION»(ref-349716-S01754793652009120800000) )
INSTALL AIR CLEANER INLET COVER (See «INSTALLATION»(ref-349724-S09859827162009120800000) )
INSTALL ENGINE ROOM SIDE COVER LH (See «INSTALLATION»(ref-349714-S23488176532009120800000) )
INSTALL ENGINE ROOM SIDE COVER (See «INSTALLATION»(ref-349714-S23488176532009120800000) )
VEHICLE PREPARATION FOR FOG LIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S17005230462009120800000) )
PREPARATION FOR FOG LIGHT AIMING (See «ADJUSTMENT»(ref-349731-S17005230462009120800000) )
FOG LIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-349731-S17005230462009120800000) )
FOG LIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S17005230462009120800000) )

Scheme 229

Scheme 229: COMPONENTS

Scheme 230

Scheme 231

Scheme 232

Scheme 233

Scheme 233: REMOVAL

Scheme 234

REMOVE LUGGAGE COMPARTMENT MAT SUB-ASSEMBLY (See «REMOVAL»(ref-349743-S29102114712009120800000) )
REMOVE ROPE HOOK (See «REMOVAL»(ref-349743-S29102114712009120800000) )
REMOVE ROPE HOOK ASSEMBLY (See «REMOVAL»(ref-349743-S29102114712009120800000) )
REMOVE DECK TRIM SIDE BOARD LH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
REMOVE DECK TRIM SIDE BOARD RH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
REMOVE NO. 2 COURTESY LIGHT ASSEMBLY (See «REMOVAL»(ref-349731-S10305724672009120800000) )
REMOVE FRONT LUGGAGE COMPARTMENT TRIM COVER (See «REMOVAL»(ref-349743-S29102114712009120800000) )
REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-349743-S29102114712009120800000) )
REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY LH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
REMOVE REAR COMBINATION LIGHT ASSEMBLY LH Disconnect the connector. Remove the 3 nuts. Detach the rear combination light guide, rear bumper retainer attachment and 2 claws to remove the rear combination light LH.
REMOVE LUGGAGE COMPARTMENT DOOR COVER RH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
REMOVE LUGGAGE COMPARTMENT DOOR COVER LH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
REMOVE REAR COMBINATION LIGHT SERVICE COVER RH (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE REAR COMBINATION LIGHT SERVICE COVER LH (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE LUGGAGE COMPARTMENT DOOR ASSIST GRIP (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE SWITCH BEZEL (w/ Power Trunk Lid System) (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY (See «REMOVAL»(ref-349731-S10305724672009120800000) )
REMOVE BACK DOOR TRIM COVER (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE REAR LIGHT ASSEMBLY LH Disconnect the connector. Remove the 4 nuts and rear light LH.

Scheme 235

Scheme 235: DISASSEMBLY

Scheme 236

REMOVE REAR TURN SIGNAL LIGHT BULB Turn the 2 rear turn signal light bulbs in the direction indicated by the arrow and remove them.
REMOVE BACK UP LIGHT BULB Turn the back up light bulb in the direction indicated by the arrow and remove it.

Scheme 237

Scheme 237: INSPECTION

INSPECT REAR COMBINATION LIGHT ASSEMBLY LH Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK REAR COMBINATION LIGHT ILLUMINATION CONDITION Tester Connection Specified Condition 1 (STP) - 4 (E) Stop light Illuminates 3 (TL) - 4 (E) Rear combination light illuminates
INSPECT REAR LIGHT ASSEMBLY LH Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK REAR LIGHT ASSEMBLY ILLUMINATION CONDITION Tester Connection Specified Condition 2 (T/P) - 4 (E) Rear combination light Illuminates

Scheme 238

Scheme 238: REASSEMBLY

INSTALL REAR TURN SIGNAL LIGHT BULB Install the 2 rear turn signal light bulbs.
INSTALL BACK UP LIGHT BULB Install the back up light bulb.

INSTALL REAR COMBINATION LIGHT ASSEMBLY LH Attach the rear combination light guide, rear bumper retainer attachment and 2 claws. Install the rear combination light LH with the 3 nuts. Connect the connector.
INSTALL LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY LH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
INSTALL FRONT LUGGAGE COMPARTMENT TRIM COVER (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
INSTALL NO. 2 COURTESY LIGHT ASSEMBLY (See «REASSEMBLY»(ref-349731-S24881682882009120800000) )
INSTALL DECK TRIM SIDE BOARD RH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
INSTALL DECK TRIM SIDE BOARD LH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
INSTALL ROPE HOOK ASSEMBLY (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
INSTALL ROPE HOOK (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
INSTALL LUGGAGE COMPARTMENT MAT SUB-ASSEMBLY (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
INSTALL REAR LIGHT ASSEMBLY LH Install the rear light LH with the 4 nuts. Connect the connector.
INSTALL BACK DOOR TRIM COVER (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY (See «REASSEMBLY»(ref-349731-S24881682882009120800000) )
INSTALL SWITCH BEZEL (w/ Power Trunk Lid System) (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL LUGGAGE COMPARTMENT DOOR ASSIST GRIP (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL REAR COMBINATION LIGHT SERVICE COVER RH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL REAR COMBINATION LIGHT SERVICE COVER LH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL LUGGAGE COMPARTMENT DOOR COVER RH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL LUGGAGE COMPARTMENT DOOR COVER LH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )

Scheme 239

Scheme 239: COMPONENTS

Scheme 240

Scheme 241

Scheme 241: REMOVAL

REMOVE LUGGAGE COMPARTMENT DOOR COVER RH (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE LUGGAGE COMPARTMENT DOOR COVER LH (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE REAR COMBINATION LIGHT SERVICE COVER RH (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE REAR COMBINATION LIGHT SERVICE COVER LH (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE LUGGAGE COMPARTMENT DOOR ASSIST GRIP (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE SWITCH BEZEL (w/ Power Trunk Lid System) (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY (See «REMOVAL»(ref-349731-S10305724672009120800000) )
REMOVE BACK DOOR TRIM COVER (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE TELEVISION CAMERA ASSEMBLY (w/ Rear View Monitor System) (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE REAR LIGHT ASSEMBLY LH (See «REMOVAL»(ref-349731-S35321606872009120800000) )
REMOVE REAR LIGHT ASSEMBLY RH Disconnect the connector. Remove the 4 nuts and rear light RH.
REMOVE LUGGAGE COMPARTMENT DOOR OUTSIDE GARNISH (See «REMOVAL»(ref-349736-S08860982142009120800000) )
REMOVE BACK DOOR GARNISH RETAINER (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE BACK DOOR OPENER SWITCH (See «REMOVAL»(ref-349743-S41897858242009120800000) )
REMOVE LICENSE PLATE LIGHT ASSEMBLY Remove the 2 screws and license plate light.

Scheme 242

Scheme 242: INSPECTION

INSPECT LICENSE PLATE LIGHT ASSEMBLY Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK LICENSE PLATE LIGHT ILLUMINATION CONDITION Tester Connection Specified Condition 1 (B) - 2 (E) License plate light Illuminates

INSTALL LICENSE PLATE LIGHT ASSEMBLY Install the license plate light with the 2 screws.
INSTALL BACK DOOR OPENER SWITCH (See «INSTALLATION»(ref-349743-S15734776522009120800000) )
INSTALL BACK DOOR GARNISH RETAINER (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL LUGGAGE COMPARTMENT DOOR OUTSIDE GARNISH (See «INSTALLATION»(ref-349736-S32372131822009120800000) )
INSTALL REAR LIGHT ASSEMBLY RH Install the rear light RH with the 4 nuts. Connect the connector.
INSTALL REAR LIGHT ASSEMBLY LH (See «INSTALLATION»(ref-349731-S14864716142009120800000) )
INSTALL TELEVISION CAMERA ASSEMBLY (w/ Rear View Monitor System) (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL BACK DOOR TRIM COVER (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY (See «REASSEMBLY»(ref-349731-S24881682882009120800000) )
INSTALL SWITCH BEZEL (w/ Power Trunk Lid System) (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL LUGGAGE COMPARTMENT DOOR ASSIST GRIP (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL REAR COMBINATION LIGHT SERVICE COVER RH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL REAR COMBINATION LIGHT SERVICE COVER LH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL LUGGAGE COMPARTMENT DOOR COVER RH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL LUGGAGE COMPARTMENT DOOR COVER LH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )

Scheme 243

Scheme 243: COMPONENTS

Scheme 244

Scheme 244: REMOVAL

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

REMOVE CENTER STOP LIGHT COVER Push in the stop light cover at a point 10 mm (0.393 in.) from the end of the cover as shown in the illustration. With the stop light cover pushed in, slide it towards the outside of the vehicle to detach the 4 claws. Lift up the stop light cover to remove it as shown in the illustration.
REMOVE NO. 2 CENTER STOP LIGHT COVER Push in the stop light cover at a point 10 mm (0.393 in.) from the end of the cover as shown in the illustration. With the stop light cover pushed in, slide it towards the outside of the vehicle to detach the 4 claws. Lift up the stop light cover to remove it as shown in the illustration.
REMOVE CENTER STOP LIGHT CLIP Turn the 2 center stop light clips 90° and remove them.
REMOVE CENTER STOP LIGHT ASSEMBLY Disconnect the harness and connector. Remove the 2 screws. Detach the 2 claws and remove the center stop light.

Scheme 252

Scheme 252: INSPECTION

INSPECT CENTER STOP LIGHT ASSEMBLY Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK CENTER STOP LIGHT ILLUMINATION CONDITION Tester Connection Specified Condition 1 (B) - 2 (E) Center stop light illuminates

INSTALL CENTER STOP LIGHT ASSEMBLY Attach the 2 claws. Install the center stop light with the 2 screws. Connect the harness and connector.
INSTALL CENTER STOP LIGHT CLIP Turn the 2 center stop light clips 90° and install them.
INSTALL NO. 2 CENTER STOP LIGHT COVER Install the No. 2 center stop light cover.
INSTALL CENTER STOP LIGHT COVER Install the center stop light cover.

Scheme 253

Scheme 253: COMPONENTS

Scheme 254

Scheme 254: ON-VEHICLE INSPECTION

INSPECT MAP LIGHT ASSEMBLY Remove the map light with connecting connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFIED CONDITIONS Tester Connection Switch Condition Specified Condition X4-3 (RLSW) - X4-16 (GND9) Rear spot light RH switch OFF Below 1 V Rear spot light RH switch ON 11 to 14 V X4-4 (RRSW) - X4-16 (GND9) Rear spot light LH switch OFF Below 1 V Rear spot light LH switch ON 11 to 14 V X4-6 (+B) - X4-16 (GND9) Always 11 to 14 V X4-11 (ILLB) - X4-16 (GND9) Always 11 to 14 V X4-12 (RLVS) - X4-16 (GND9) Rear vanity light LH switch OFF Below 1 V Rear vanity light LH switch ON 11 to 14 V X4-13 (RRVS) - X4-16 (GND9) Rear vanity light RH switch OFF Below 1 V Rear vanity light RH switch ON 11 to 14 V X4-27 (DOME) - X4-16 (GND9) Always 11 to 14 V X6-7 (RLMP) - X4-16 (GND9) Always 11 to 14 V X6-8 (RRMP) - X4-16 (GND9) Always 11 to 14 V X6-11 (ILL+) - X4-16 (GND9) Engine switch on (ACC) 11 to 14 V X6-13 (ILL-) - X4-16 (GND9) Headlight dimmer switch OFF 11 to 14 V Headlight dimmer switch TAIL Below 1 V X6-14 (RRVT) - X4-16 (GND9) Rear vanity light RH switch OFF 11 to 14 V Rear vanity light RH switch ON Below 1 V X6-16 (RLVT) - X4-16 (GND9) Rear vanity light LH switch OFF 11 to 14 V Rear vanity light LH switch ON Below 1 V X6-18 (RILL) - X4-16 (GND9) Rear dome light OFF 11 to 14 V Rear dome light ON Below 1 V Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Condition Specified Condition X4-15 (GND6) - Body ground Always Below 1 ohms X4-16 (GND9) - Body ground Always Below 1 ohms X6-17 (GND6) - Body ground Always Below 1 ohms X6-20 (GND4) - Body ground Always Below 1 ohms If the result is not as specified, replace the map light.

Scheme 255

Scheme 255: REMOVAL

Scheme 256

REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
REMOVE MAP LIGHT ASSEMBLY Using a screwdriver, detach the 2 claws and 2 covers. HINT: Tape the screwdriver tip before use. Remove the 2 screws. Using a molding remover, detach the 2 clips. Disconnect the connectors and remove the map light.

Scheme 257

Scheme 257: DISASSEMBLY

REMOVE MAP LIGHT BULB Remove the 2 map light bulbs.

INSTALL NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY Connect the connector. Attach the 2 claws and install the No. 1 luggage compartment light.
INSTALL NO. 2 COURTESY LIGHT ASSEMBLY Connect the connector. Attach the 2 claws and install the No. 2 courtesy light.

Scheme 258

Scheme 258: COMPONENTS

Scheme 259

Scheme 260

Scheme 260: REMOVAL

Scheme 261

Scheme 262

Scheme 263

REMOVE VANITY LIGHT ASSEMBLY Using a screwdriver, detach the claw. HINT: Tape the screwdriver tip before use. Detach the 2 claws and remove the vanity light.
REMOVE VANITY LIGHT BULB Remove the vanity light bulb.
REMOVE VISOR BRACKET COVER Using a molding remover, detach the 4 claws and remove the visor bracket cover.
REMOVE VISOR ASSEMBLY RH Remove the 2 screws and visor RH.

Scheme 264

Scheme 264: INSPECTION

INSPECT VISOR ASSEMBLY RH Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Condition Specified Condition 2 (SW) - 1 (GND) Visor raised 10 kohms or higher 2 (SW) - 1 (GND) Visor lowered and mirror cover closed 10 kohms or higher 2 (SW) - 1 (GND) Visor lowered and mirror cover open Below 1 ohms

INSTALL VANITY LIGHT BULB Install the vanity light bulb.
INSTALL VANITY LIGHT ASSEMBLY Attach the 2 claws. Attach the claw and install the vanity light.
INSTALL VISOR ASSEMBLY RH Install the visor RH with the 2 screws.
INSTALL VISOR BRACKET COVER Attach the 4 claws and install the visor bracket cover.

Scheme 265

Scheme 265: COMPONENTS

Scheme 266

Scheme 266: REMOVAL

REMOVE REAR VANITY LIGHT ASSEMBLY Using a screwdriver, detach the 4 claws and remove the lens. HINT: Tape the screwdriver tip before use. Remove the 2 screws. Disconnect the connector and remove the rear vanity light.

Scheme 267

Scheme 267: DISASSEMBLY

REMOVE REAR VANITY LIGHT BULB Remove the 3 rear vanity light bulbs.

Scheme 268

Scheme 268: INSPECTION

INSPECT REAR VANITY LIGHT ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance: Rear right side RESISTANCE SPECIFIED CONDITIONS Tester Connection Condition Specified Condition 1 (B) - 3 (RRVS) Rear vanity light CLOSE 10 kohms or higher Rear vanity light OPEN Below 1 ohms Rear left side RESISTANCE SPECIFIED CONDITIONS Tester Connection Condition Specified Condition 1 (B) - 3 (RRVS) Rear vanity light CLOSE 10 kohms or higher Rear vanity light OPEN Below 1 ohms If the result is not as specified, replace the rear vanity light.

INSTALL CONSOLE BOX LIGHT Attach the 2 claws. Install the console box light with the 2 screws.
INSTALL ROOF CONSOLE BOX ASSEMBLY (See «INSTALLATION»(ref-349734-S24814211142009120800000) )
INSTALL SPOT LIGHT LENS Attach the 4 claws and install the spot light lens.

Scheme 269

Scheme 269: COMPONENTS

Scheme 270

Scheme 271

Scheme 271: REMOVAL

Scheme 272

REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG LH (See «REMOVAL»(ref-349743-S08783415772009120800000) )
REMOVE FRONT POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY LH (See «REMOVAL»(ref-349743-S08783415772009120800000) )
REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (See «REMOVAL»(ref-349743-S08783415772009120800000) )
REMOVE FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH Detach the claw, disconnect the connector and then remove the light.
REMOVE REAR DOOR INSIDE HANDLE BEZEL PLUG LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (See «REMOVAL»(ref-349743-S08341206512009120800000) )
REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (w/ Rear Door Sunshade) (See «REMOVAL»(ref-349743-S08341206512009120800000) )
REMOVE REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH Detach the 2 claws, disconnect the connector and then remove the light.

Scheme 273

Scheme 273: INSPECTION

Scheme 274

Scheme 275

Scheme 276

INSPECT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ILLUMINATION CONDITION Tester Connection Specified Condition 2 (+B) - 1 (GND) Door inside handle illumination light illuminates
INSPECT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY RH Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ILLUMINATION CONDITION Tester Connection Specified Condition 2 (+B) -1 (GND) Door inside handle illumination light illuminates
INSPECT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ILLUMINATION CONDITION Tester Connection Specified Condition 2 (+B) - 1 (GND) Door Inside handle Illumination light Illuminates
INSPECT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY RH Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ILLUMINATION CONDITION Tester Connection Specified Condition 2 (+B) - 1 (GND) Door inside handle illumination light illuminates

Scheme 277

Scheme 277: INSTALLATION

INSTALL REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH Connect the connector.
INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (w/ Rear Door Sunshade) (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
INSTALL REAR DOOR INSIDE HANDLE BEZEL PLUG LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
INSTALL FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH Connect the connector. Attach the claw to install the light.
INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
INSTALL FRONT POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )

Scheme 278

Scheme 278: COMPONENTS

Scheme 279

Scheme 280

Scheme 280: REMOVAL

Scheme 281

Scheme 282

REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY LH Detach the 2 hooks and remove the interior illumination light.
REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY RH Detach the 2 hooks and remove the interior illumination light.
REMOVE FRONT SEATBACK BOARD SUB-ASSEMBLY LH Remove the 2 screws. Detach the 2 hooks and remove the seatback board. Remove the interior illumination light wire harness clamp. Disconnect the interior illumination light wire harness connector.
REMOVE INTERIOR ILLUMINATION LIGHT SUB-ASSEMBLY Remove the screw and interior illumination light.

Scheme 283

Scheme 283: INSPECTION

Scheme 284

Scheme 285

INSPECT NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY LH Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK NO. 1 INTERIOR ILLUMINATION LIGHT ILLUMINATION CONDITION Tester Connection Specified Condition 2 (+B) - 1 (GND) Interior illumination light illuminates
INSPECT NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY RH Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK NO. 1 INTERIOR ILLUMINATION LIGHT ILLUMINATION CONDITION Tester Connection Specified Condition 2 (+B) - 1 (GND) Interior Illumination light illuminates
INSPECT INTERIOR ILLUMINATION LIGHT SUB-ASSEMBLY Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK NO. 1 INTERIOR ILLUMINATION LIGHT ILLUMINATION CONDITION Tester Connection Specified Condition 2 (+B) - 1 (GND) Interior illumination light illuminates

Scheme 286

Scheme 286: INSTALLATION

Scheme 287

INSTALL INTERIOR ILLUMINATION LIGHT SUB-ASSEMBLY Install the interior illumination light with the screw.
INSTALL FRONT SEATBACK BOARD SUB-ASSEMBLY LH Attach the 2 hooks and install the seatback board. Connect the interior illumination light wire harness connector. Install the interior illumination light wire harness clamp. Install the 2 screws.
REMOVE NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY RH Attach the 2 hooks and install the interior illumination light.
REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY LH Attach the 2 hooks and install the interior illumination light.
REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )

Scheme 288

Scheme 288: COMPONENTS

REMOVAL

CAUTION

Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. Some of these service operations affect the SRS airbag system. Read the precautionary notices concerning the SRS airbag system before servicing the steering column (see AIRBAG SYSTEM ).

Scheme 289

Scheme 290

Scheme 291

PLACE FRONT WHEELS FACING STRAIGHT AHEAD
REMOVE FRONT WHEELS
REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL Disable the AUTO TILT AWAY function by changing the customize parameter (see «CUSTOMIZE PARAMETERS»(ref-349720-S36027932202009120800000) ). NOTE: Record the current customize parameter setting (whether the AUTO TILT AWAY function is enabled or disabled) in order to restore the current setting after finishing the operation. HINT: Performing the above operation causes the AUTO TILT AWAY function to be disabled when the engine switch is turned off. Turn the engine switch on (IG). Operate the tilt and telescopic switch to fully extend and lower the steering column assembly. Turn the engine switch off and disconnect the cable from the negative battery terminal. CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
REMOVE SWITCH AND VOLUME CASE (See «REMOVAL»(ref-349738-S10852294072009120800000) )
REMOVE LOWER NO. 2 STEERING WHEEL COVER (See «REMOVAL»(ref-349738-S10852294072009120800000) )
REMOVE STEERING PAD ASSEMBLY (See «REMOVAL»(ref-349738-S10852294072009120800000) )
REMOVE STEERING WHEEL ASSEMBLY (See «REMOVAL»(ref-349720-S38166401772009120800000) )
REMOVE STEERING COLUMN COVER (w/o Driver Monitor Camera) (See «REMOVAL»(ref-349720-S06801168612009120800000) )
REMOVE STEERING COLUMN COVER (w/ Driver Monitor Camera) (See «REMOVAL»(ref-349720-S38166401772009120800000) )
REMOVE SPIRAL CABLE (See «REMOVAL»(ref-349738-S11261728212009120800000) )
REMOVE WINDSHIELD WIPER SWITCH ASSEMBLY Disconnect the connectors. Using a screwdriver, detach the claw and remove the windshield wiper switch. HINT: Tape the screwdriver tip before use. NOTE: If the claw is pressed forcefully, it will break.
REMOVE HEADLIGHT DIMMER SWITCH ASSEMBLY Disconnect the band clamp as shown in the illustration. Detach the claw and remove the headlight dimmer switch. NOTE: If the claw is pressed forcefully, it will break.

Scheme 292

Scheme 292: INSPECTION

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

INSPECT HEADLIGHT DIMMER SWITCH ASSEMBLY Check the light control switch. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Switch Condition Specified Condition 13 (T) - 11 (H) - 12 (A) - 19 (EL) Light control switch OFF 10 kohms or higher 13 (T) - 19 (EL) Light control switch TAIL Below 1 ohms 13 (T) - 11 (H) - 19 (EL) Light control switch HEAD Below 1 ohms 12 (A) - 19 (EL) Light control switch AUTO Below 1 ohms If the result is not as specified, replace the headlight dimmer switch. Check the headlight dimmer switch. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Switch Condition Specified Condition 14 (HF) - 19 (EL) Headlight dimmer switch FLASH Below 1 ohms 15 (HL) - 19 (EL) Headlight dimmer switch LOW BEAM Below 1 ohms 20 (HU) - 19 (EL) Headlight dimmer switch HI BEAM Below 1 ohms If the result is not as specified, replace the headlight dimmer switch. HINT: Perform the "LOW BEAM" and "HI BEAM" inspection with the light control switch on "HEAD". Check the turn signal switch. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Switch Condition Specified Condition 17 (CR) - 16 (TR) - 19 (EL) Turn signal switch right turn Below 1 ohms 16 (TR) - 19 (EL) Turn signal switch right lane change Below 1 ohms 17 (CR) - 16 (TR) - 18 (TL) - 19 (EL) Turn signal switch neutral 10 kohms or higher 18 (TL) - 19 (EL) Turn signal switch left lane change Below 1 ohms 17 (CR) - 18 (TL) - 19 (EL) Turn signal switch left turn Below 1 ohms If the result is not as specified, replace the headlight dimmer switch. Check fog light switch. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Switch Condition Specified Condition 7 (BFOG) - 8 (LFOG) Front fog light switch OFF 10 kohms or higher 7 (BFOG) - 8 (LFOG) Front fog light switch ON Below 1 ohms If the result is not as specified, replace the front fog light switch. Check rear fog light switch. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Switch Condition Specified Condition 9 (B) - 7 (BFOG) - 8 (LFOG) Rear fog light switch OFF 10 kohms or higher 9 (B) - 7 (BFOG) - 8 (LFOG) Rear fog light switch ON Below 1 ohms If the result is not as specified, replace the rear fog light switch.

Scheme 298

Scheme 298: INSTALLATION

Scheme 299

INSTALL HEADLIGHT DIMMER SWITCH ASSEMBLY Insert the headlight dimmer switch assembly into the steering column making sure that the stopper's protrusions and cutout parts align. Install the headlight dimmer switch assembly with the band clamp and claw.
INSTALL WINDSHIELD WIPER SWITCH ASSEMBLY Attach the claw and install the windshield wiper switch. Connect the connectors.
INSTALL STEERING COLUMN COVER (w/o Driver Monitor Camera) (See «INSTALLATION»(ref-349720-S29560656232009120800000) )
INSTALL STEERING COLUMN COVER (w/ Driver Monitor Camera) (See «INSTALLATION»(ref-349720-S01586454122009120800000) )
INSPECT SPIRAL CABLE SUB- ASSEMBLY (See «INSPECTION»(ref-349738-S12100839192009120800000) )
INSTALL STEERING WHEEL ASSEMBLY (See «INSTALLATION»(ref-349720-S01586454122009120800000) )
INSPECT STEERING WHEEL CENTER POINT
INSPECT STEERING PAD ASSEMBLY (See «INSTALLATION»(ref-349720-S01586454122009120800000) )
INSTALL STEERING PAD ASSEMBLY (See «INSTALLATION»(ref-349738-S18853029572009120800000) )
INSTALL LOWER NO. 2 STEERING WHEEL COVER (See «INSTALLATION»(ref-349738-S18853029572009120800000) )
INSTALL SWITCH AND VOLUME CASE (See «INSTALLATION»(ref-349738-S18853029572009120800000) )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: Reset the AUTO TILT AWAY function setting to the previous condition by changing the customize parameter (see «CUSTOMIZE PARAMETERS»(ref-349720-S36027932202009120800000) ).
INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
CHECK SRS WARNING LIGHT Check the SRS warning light (see «DIAGNOSIS SYSTEM»(ref-349738-S23481667942009120800000) ).
PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 300

Scheme 300: COMPONENTS

Scheme 301

Scheme 302

Scheme 302: ON-VEHICLE INSPECTION

INSPECT HAZARD WARNING SIGNAL SWITCH ASSEMBLY Connect the voltmeter's positive (+) lead to terminal Lr1-2, 3, 4 and negative (-) lead to terminal Lr1-6. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFIED CONDITIONS Tester Connection Switch Condition Specified Condition Lr1-2 (FRLY) - Lr1-6 (GND) Hazard warning signal switch ON Below 1 V 9 V or higher (60 to 120 times per minute) Lr1-3 (LJB) - Lr1-6 (GND) Hazard warning signal switch ON 11 to 14 V Lr1-4 (FLSW) - Lr1-6 (GND) Hazard warning signal switch ON 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Condition Specified Condition Lr1-6 (GND) - Body ground Always Below 1 ohms If the result is not as specified, replace the hazard warning signal switch.

Scheme 303

Scheme 303: REMOVAL

REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
REMOVE INSTRUMENT PANEL FINISH PANEL END RH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE INSTRUMENT PANEL FINISH PANEL END LH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE SHIFT LEVER KNOB (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 3 BOX PANEL (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE REAR CONSOLE PANEL UPPER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE CONSOLE PANEL SUB-ASSEMBLY UPPER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE RADIO RECEIVER ASSEMBLY (See «REMOVAL»(ref-349754-S18155731442009120800000) )
REMOVE INTEGRATION CONTROL AND PANEL ASSEMBLY (w/o Multi-display) (See «REMOVAL»(ref-349754-S09351547702009120800000) )
REMOVE MULTI-MEDIA MODULE DISPLAY ASSEMBLY (w/ Multi-display) (See «REMOVAL»(ref-349759-S27877475092009120800000) )
REMOVE HAZARD WARNING SIGNAL SWITCH ASSEMBLY Disconnect the connector. Detach the 2 claws and remove the hazard warning signal switch.

Scheme 304

Scheme 304: INSPECTION

Scheme 305

INSPECT HAZARD WARNING SIGNAL SWITCH ASSEMBLY LED illumination inspection Apply battery voltage to the terminals of the connector, and check the LED illumination condition. OK HAZARD WARNING SIGNAL SWITCH ILLUMINATION CONDITION Tester Connection Specified Condition 1 (ILL+) - 5 (ILL-) Night illumination comes on Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Switch Condition Specified Condition 7 (HAZ) - 6 (GND) Hazard warning signal switch OFF 10 kohms or higher 7 (HAZ) - 6 (GND) Hazard warning signal switch ON Below 1 ohms If the result is not as specified, replace the hazard warning signal switch.

INSTALL HAZARD WARNING SIGNAL SWITCH ASSEMBLY Attach the 2 claws and install the hazard warning signal switch. Connect the connector.
INSTALL INTEGRATION CONTROL AND PANEL ASSEMBLY (w/o Multi-display) (See «INSTALLATION»(ref-349754-S17698085462009120800000) )
INSTALL MULTI-MEDIA MODULE DISPLAY ASSEMBLY (w/ Multi-display) (See «INSTALLATION»(ref-349759-S13296077332009120800000) )
INSTALL RADIO RECEIVER ASSEMBLY (See «INSTALLATION»(ref-349754-S17698085462009120800000) )
INSTALL CONSOLE PANEL SUB-ASSEMBLY UPPER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL REAR CONSOLE PANEL UPPER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 3 BOX PANEL (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL SHIFT LEVER KNOB (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT PANEL FINISH PANEL END LH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT PANEL FINISH PANEL END RH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 306

Scheme 306: COMPONENTS

Scheme 307

Scheme 307: REMOVAL

REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE STOP LIGHT SWITCH Disconnect the switch connector. Loosen the lock nut, and then remove the stop light switch.

INSTALL FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY Connect the connector. Install the switch with the bolt.

Scheme 308

Scheme 308: COMPONENTS

Scheme 309

Scheme 309: REMOVAL

REMOVE REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY Remove the bolt and switch. Disconnect the connector.

Scheme 310

Scheme 310: INSPECTION

INSPECT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Condition Specified Condition 1 - Body ground Pin not pushed Below 1 ohms 1 - Body ground Pin pushed 10 kohms or higher If the result is not as specified, replace the rear door courtesy light switch.

INSTALL REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY Connect the connector. Install the switch with the bolt.

Scheme 311

Scheme 311: COMPONENTS

Scheme 312

Scheme 312: REMOVAL

REMOVE LUGGAGE COMPARTMENT DOOR ASSIST GRIP (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE SWITCH BEZEL (w/ Power Trunk Lid System) (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE NO. 2 COURTESY LIGHT ASSEMBLY (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE REAR COMBINATION LIGHT SERVICE COVER LH (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE REAR COMBINATION LIGHT SERVICE COVER RH (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE LUGGAGE COMPARTMENT DOOR HINGE COVER LH (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE LUGGAGE COMPARTMENT DOOR HINGE COVER RH (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE BACK DOOR TRIM COVER (See «REMOVAL»(ref-349743-S11026400252009120800000) )
REMOVE LUGGAGE DOOR CLOSER ASSEMBLY Disconnect the connector. Remove the 3 bolts and luggage door closer.

Scheme 313

Scheme 313: INSPECTION

INSPECT LUGGAGE COMPARTMENT DOOR CLOSER ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Condition Specified Condition 7 (CTY) - 8 (E) UNLOCK Below 1 ohms 7 (CTY) - 8 (E) LOCK 10 kohms or higher If the result is not as specified, replace the luggage compartment door closer.

Scheme 314

Scheme 314: INSTALLATION

INSTALL LUGGAGE DOOR CLOSER ASSEMBLY Connect the connector. Install the luggage door closer with the 3 bolts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf)
INSTALL BACK DOOR TRIM COVER (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL LUGGAGE COMPARTMENT DOOR HINGE COVER LH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL LUGGAGE COMPARTMENT DOOR HINGE COVER RH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL REAR COMBINATION LIGHT SERVICE COVER LH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL REAR COMBINATION LIGHT SERVICE COVER RH (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL NO. 2 COURTESY LIGHT ASSEMBLY (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL SWITCH BEZEL (w/ Power Trunk Lid System) (See «INSTALLATION»(ref-349743-S42172268012009120800000) )
INSTALL LUGGAGE COMPARTMENT DOOR ASSIST GRIP (See «INSTALLATION»(ref-349743-S42172268012009120800000) )

Scheme 315

Scheme 315: COMPONENTS

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

Scheme 321

Scheme 322

Scheme 322: ON-VEHICLE INSPECTION

Scheme 323

INSPECT AUTOMATIC LIGHT CONTROL SENSOR Connect the voltmeter's positive (+) lead to terminal M2-6 and the negative (-) lead to terminal M2-3. Measure the voltage of the connector. Standard voltage VOLTAGE SPECIFIED CONDITIONS Tester Connection Switch Condition Specified Condition M2-6 (CLTB) - M2-3 (CLTE) Engine switch on (IG) 11 to 14 V Measure the resistance of the connector. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Condition Specified Condition M2-3 (CLTE) - Body ground Always Below 1 ohms Check the waveform of the M2 sensor connector. Wave form WAVEFORM REFERENCE CHART Tester Connection Switch Condition Specified Condition Tester Range M2-3 (CLTE) - M2-5 (CLTS) Engine switch on (IG), Headlight dimmer switch on AUTO Correct waveform is as shown 5 V/DIV., 5 msec./DIV. HINT: If the ambient light becomes brighter, width A becomes narrower. If the result is not as specified, replace the automatic light control sensor.

Scheme 324

Scheme 324: REMOVAL

TABLE OF BOLT, SCREW AND NUT (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL Disable the AUTO TILT AWAY function by changing the customize parameter (see «CUSTOMIZE PARAMETERS»(ref-349720-S36027932202009120800000) ). NOTE: Record the current customize parameter setting (whether the AUTO TILT AWAY function is enabled or disabled) in order to restore the current setting after finishing the operation. HINT: Performing the above operation causes the AUTO TILT AWAY function to be disabled when the engine switch is turned off. Turn the engine switch on (IG). Operate the tilt and telescopic switch to fully extend and lower the steering column. Turn the engine switch off and disconnect the cable from the negative (-) battery terminal. CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
REMOVE INSTRUMENT PANEL FINISH PANEL END RH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE INSTRUMENT PANEL FINISH PANEL END LH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE SHIFT LEVER KNOB (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 3 BOX PANEL (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE REAR CONSOLE PANEL UPPER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE CONSOLE PANEL SUB-ASSEMBLY UPPER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE CONSOLE REAR END PANEL (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE CONSOLE COVER LOWER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE SWITCH AND VOLUME CASE (See «REMOVAL»(ref-349738-S10852294072009120800000) )
REMOVE NO. 2 STEERING WHEEL COVER LOWER (See «REMOVAL»(ref-349738-S10852294072009120800000) )
REMOVE STEERING PAD ASSEMBLY (See «REMOVAL»(ref-349738-S10852294072009120800000) )
REMOVE STEERING WHEEL ASSEMBLY (See «REMOVAL»(ref-349720-S38166401772009120800000) )
REMOVE STEERING COLUMN COVER (w/o Driver Monitor Camera) (See «REMOVAL»(ref-349720-S06801168612009120800000) )
REMOVE STEERING COLUMN COVER (w/ Driver Monitor Camera) (See «REMOVAL»(ref-349720-S38166401772009120800000) )
REMOVE TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE (See «REMOVAL»(ref-349720-S38166401772009120800000) )
REMOVE INSTRUMENT CLUSTER FINISH PANEL (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE COMBINATION METER ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE INSTRUMENT SIDE PANEL LH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INSTRUMENT CLUSTER MOLDING (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INSTRUMENT PANEL SAFETY PAD (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INSTRUMENT PANEL LOWER AIRBAG (See «REMOVAL»(ref-349738-S31284329952009120800000) )
REMOVE INSTRUMENT SIDE PANEL RH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 2 INSTRUMENT CLUSTER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE INSTRUMENT PANEL LOWER (See «REMOVAL»(ref-349738-S29970248672009120800000) )
REMOVE NO. 2 INSTRUMENT PANEL LOWER AIRBAG (See «REMOVAL»(ref-349738-S29970248672009120800000) )
REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE RADIO RECEIVER ASSEMBLY (See «REMOVAL»(ref-349754-S18155731442009120800000) )
REMOVE INTEGRATION CONTROL AND PANEL ASSEMBLY WITH BRACKET (w/o Navigation System) (See «REMOVAL»(ref-349723-S41495230852009120800000) )
REMOVE MULTI-DISPLAY ASSEMBLY WITH BRACKET (for DVD) (See «REMOVAL»(ref-349759-S27877475092009120800000) )
REMOVE DISPLAY AND NAVIGATION ASSEMBLY WITH BRACKET (for HDD) (See «REMOVAL»(ref-349759-S17468250422009120800000) )
REMOVE FRONT PILLAR GARNISH RH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
REMOVE FRONT PILLAR GARNISH LH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
REMOVE NO. 1 INSTRUMENT PANEL SPEAKER PANEL (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE FRONT NO. 2 SPEAKER ASSEMBLY (for RH) (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE NO. 2 INSTRUMENT PANEL SPEAKER PANEL (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE FRONT NO. 2 SPEAKER ASSEMBLY (for LH) (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE NO. 1 SPEAKER HOLE COVER (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE FRONT NO. 3 SPEAKER ASSEMBLY (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE TIRE PRESSURE WARNING ECU (See «DISASSEMBLY»(ref-349746-S05234743332009120800000) )
REMOVE NO. 1 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE INSTRUMENT PANEL SAFETY PAD (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 SIDE DEFROSTER NOZZLE DUCT (See «DISASSEMBLY»(ref-349746-S05234743332009120800000) )
REMOVE NO. 2 SIDE DEFROSTER NOZZLE DUCT (See «DISASSEMBLY»(ref-349746-S05234743332009120800000) )
REMOVE DEFROSTER NOZZLE ASSEMBLY (See «DISASSEMBLY»(ref-349746-S05234743332009120800000) )
REMOVE AUTOMATIC LIGHT CONTROL SENSOR Disconnect the connector. Detach the 2 claws and remove the automatic light control sensor.

INSTALL AUTOMATIC LIGHT CONTROL SENSOR Attach the 2 claws and install the automatic control sensor. Connect the connector.
INSTALL DEFROSTER NOZZLE ASSEMBLY (See «REASSEMBLY»(ref-349746-S33213030562009120800000) )
INSTALL NO. 2 SIDE DEFROSTER NOZZLE DUCT (See «REASSEMBLY»(ref-349746-S33213030562009120800000) )
INSTALL NO. 1 SIDE DEFROSTER NOZZLE DUCT (See «REASSEMBLY»(ref-349746-S33213030562009120800000) )
INSTALL INSTRUMENT PANEL SAFETY PAD (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 1 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL TIRE PRESSURE WARNING ECU (See «REASSEMBLY»(ref-349746-S33213030562009120800000) )
INSTALL FRONT NO. 3 SPEAKER ASSEMBLY (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL NO. 1 SPEAKER HOLE COVER (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL FRONT NO. 2 SPEAKER ASSEMBLY (for LH) (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL NO. 2 INSTRUMENT PANEL SPEAKER PANEL (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL FRONT NO. 2 SPEAKER ASSEMBLY (for RH) (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL NO. 1 INSTRUMENT PANEL SPEAKER PANEL (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
INSTALL FRONT PILLAR GARNISH RH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
INSTALL INTEGRATION CONTROL AND PANEL ASSEMBLY WITH BRACKET (w/o Navigation System) (See «INSTALLATION»(ref-349723-S09274112792009120800000) )
INSTALL MULTI-DISPLAY ASSEMBLY WITH BRACKET (for DVD) (See «INSTALLATION»(ref-349759-S13296077332009120800000) )
INSTALL DISPLAY AND NAVIGATION ASSEMBLY WITH BRACKET (for HDD) (See «INSTALLATION»(ref-349759-S36533396952009120800000) )
INSTALL RADIO RECEIVER ASSEMBLY (See «INSTALLATION»(ref-349754-S17698085462009120800000) )
INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 2 INSTRUMENT PANEL LOWER AIRBAG (See «INSTALLATION»(ref-349738-S07188766952009120800000) )
INSTALL INSTRUMENT PANEL LOWER (See «INSTALLATION»(ref-349738-S07188766952009120800000) )
INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 2 INSTRUMENT CLUSTER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT SIDE PANEL RH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 1 INSTRUMENT PANEL LOWER AIRBAG (See «INSTALLATION»(ref-349738-S41995772282009120800000) )
INSTALL NO. 1 INSTRUMENT PANEL SAFETY PAD (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 1 INSTRUMENT CLUSTER MOLDING (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT SIDE PANEL LH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL COMBINATION METER ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT CLUSTER FINISH PANEL (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE (See «INSTALLATION»(ref-349720-S01586454122009120800000) )
INSTALL STEERING COLUMN COVER (w/o Driver Monitor Camera) (See «INSTALLATION»(ref-349720-S29560656232009120800000) )
INSTALL STEERING COLUMN COVER (w/ Driver Monitor Camera) (See «INSTALLATION»(ref-349720-S01586454122009120800000) )
INSTALL STEERING WHEEL ASSEMBLY (See «INSTALLATION»(ref-349720-S01586454122009120800000) )
INSTALL STEERING PAD ASSEMBLY (See «INSTALLATION»(ref-349738-S18853029572009120800000) )
INSTALL NO. 2 STEERING WHEEL COVER LOWER (See «INSTALLATION»(ref-349738-S18853029572009120800000) )
INSTALL SWITCH AND VOLUME CASE (See «INSTALLATION»(ref-349738-S18853029572009120800000) )
INSTALL CONSOLE BOX ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL CONSOLE COVER LOWER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL CONSOLE REAR END PANEL (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL CONSOLE PANEL SUB-ASSEMBLY UPPER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL REAR CONSOLE PANEL UPPER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 3 BOX PANEL (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL SHIFT LEVER KNOB (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT PANEL FINISH PANEL END LH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT PANEL FINISH PANEL END RH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: Reset the AUTO TILT AWAY function setting to the previous condition by changing the customize parameter (see «CUSTOMIZE PARAMETERS»(ref-349720-S36027932202009120800000) ).
INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
CHECK SRS WARNING LIGHT Check the SRS warning light (see «DIAGNOSIS SYSTEM»(ref-349738-S23481667942009120800000) ).
PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 325

Scheme 325: COMPONENTS

Scheme 326

Scheme 326: REMOVAL

Scheme 327

REMOVE FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY Disconnect the connector. Remove the 3 nuts and front height control sensor.
REMOVE REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY Disconnect the connector. Remove the 3 nuts and rear height control sensor.

INSTALL REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY Install the rear height control sensor with the 3 nuts. Torque: Rear suspension member side 8.0 N*m (82 kgf*cm, 71 in.*lbf) Lower arm side 5.4 N*m (55 kgf*cm, 48 in.*lbf) Connect the connector.
INSTALL FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY Install the front height control sensor with the 3 nuts. Torque: Rear suspension member side 8.0 N*m (82 kgf*cm, 71 in.*lbf) Lower arm side 5.4 N*m (55 kgf*cm, 48 in.*lbf) Connect the connector.
VEHICLE PREPARATION FOR HEADLIGHT AIMING ADJUSTMENT
PREPARATION FOR HEADLIGHT AIMING (Using a screen)
HEADLIGHT AIMING INSPECTION
HEADLIGHT AIMING ADJUSTMENT

Scheme 328

Scheme 328: COMPONENTS

Scheme 329

Scheme 329: REMOVAL

REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
REMOVE FRONT DOOR SCUFF PLATE RH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
REMOVE COWL SIDE TRIM BOARD RH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
REMOVE AFS ECU Disconnect the connector and clamp. Remove the 3 nuts and AFS ECU.

INSTALL AFS ECU Install the AFS ECU with the 3 nuts. Connect the connector and clamp.
INSTALL COWL SIDE TRIM BOARD RH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
INSTALL FRONT DOOR SCUFF PLATE RH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
PERFORM INITIALIZATION NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
VEHICLE PREPARATION FOR HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
PREPARATION FOR HEADLIGHT AIMING (Using a screen) (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
HEADLIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )
HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) )

Scheme 330

Scheme 331

Scheme 331: ON-VEHICLE INSPECTION

INSPECT TURN SIGNAL FLASHER ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITIONS Tester Connection Condition Specified Condition L1-7 (GND) - Body ground Always Below 1 ohms If the result is not as specified, replace the turn signal flasher. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFIED CONDITIONS Tester Connection Switch Condition Specified Condition L1-1 (IG) - L1-7 (GND) Engine switch on (IG) 11 to 14 V L1-2 (LR) - L1-7 (GND) Hazard warning switch OFF Below 1 V Hazard warning switch ON 9 V or higher (60 to 120 times per minute) L1-3 (LL) - L1-7 (GND) Hazard warning switch OFF Below 1 V Hazard warning switch ON 9 V or higher (60 to 120 times per minute) L1-4 (+B) - L1-7 (GND) Always 11 to 14 V L1-5 (EL) - L1-7 (GND) Headlight dimmer switch (TURN L) OFF 9 V or higher Headlight dimmer switch (TURN L) ON Below 1 V L1-6 (ER) - L1-7 (GND) Headlight dimmer switch (TURN R) OFF 9 V or higher Headlight dimmer switch (TURN R) ON Below 1 V L1-8 (EHW) - L1-7 (GND) Hazard warning switch OFF 9 V or higher Hazard warning switch ON Below 1 V

Scheme 332

Scheme 332: REMOVAL

TABLE OF BOLT, SCREW AND NUT (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL Disable the AUTO TILT AWAY function by changing the customize parameter (see «CUSTOMIZE PARAMETERS»(ref-349720-S36027932202009120800000) ). NOTE: Record the current customize parameter setting (whether the AUTO TILT AWAY function is enabled or disabled) in order to restore the current setting after finishing the operation. HINT: Performing the above operation causes the AUTO TILT AWAY function to be disabled when the engine switch is turned off. Turn the engine switch on (IG). Operate the tilt and telescopic switch to fully extend and lower the steering column. Turn the engine switch off and disconnect the cable from the negative (-) battery terminal. CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
REMOVE INSTRUMENT PANEL FINISH PANEL END RH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE INSTRUMENT PANEL FINISH PANEL END LH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE SHIFT LEVER KNOB (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 3 BOX PANEL (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE REAR CONSOLE PANEL UPPER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE CONSOLE PANEL SUB-ASSEMBLY UPPER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE CONSOLE REAR END PANEL (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE CONSOLE COVER LOWER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE SWITCH AND VOLUME CASE (See «REMOVAL»(ref-349738-S10852294072009120800000) )
REMOVE NO. 2 STEERING WHEEL COVER LOWER (See «REMOVAL»(ref-349738-S10852294072009120800000) )
REMOVE STEERING PAD ASSEMBLY (See «REMOVAL»(ref-349738-S10852294072009120800000) )
REMOVE STEERING WHEEL ASSEMBLY (See «REMOVAL»(ref-349720-S38166401772009120800000) )
REMOVE STEERING COLUMN COVER (w/o Driver Monitor Camera) (See «REMOVAL»(ref-349720-S06801168612009120800000) )
REMOVE STEERING COLUMN COVER (w/ Driver Monitor Camera) (See «REMOVAL»(ref-349720-S38166401772009120800000) )
REMOVE TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE (See «REMOVAL»(ref-349720-S38166401772009120800000) )
REMOVE INSTRUMENT CLUSTER FINISH PANEL (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE COMBINATION METER ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE INSTRUMENT SIDE PANEL LH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INSTRUMENT CLUSTER MOLDING (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INSTRUMENT PANEL SAFETY PAD (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 1 INSTRUMENT PANEL LOWER AIRBAG (See «REMOVAL»(ref-349738-S29970248672009120800000) )
REMOVE INSTRUMENT SIDE PANEL RH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 2 INSTRUMENT CLUSTER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE INSTRUMENT PANEL LOWER (See «REMOVAL»(ref-349738-S29970248672009120800000) )
REMOVE NO. 2 INSTRUMENT PANEL LOWER AIRBAG (See «REMOVAL»(ref-349738-S29970248672009120800000) )
REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE RADIO RECEIVER ASSEMBLY (See «REMOVAL»(ref-349754-S18155731442009120800000) )
REMOVE INTEGRATION CONTROL AND PANEL ASSEMBLY WITH BRACKET (w/o Navigation System) (See «REMOVAL»(ref-349723-S41495230852009120800000) )
REMOVE MULTI-DISPLAY ASSEMBLY WITH BRACKET (for DVD) (See «REMOVAL»(ref-349759-S27877475092009120800000) )
REMOVE DISPLAY AND NAVIGATION ASSEMBLY WITH BRACKET (for HDD) (See «REMOVAL»(ref-349759-S17468250422009120800000) )
REMOVE FRONT PILLAR GARNISH RH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
REMOVE FRONT PILLAR GARNISH LH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
REMOVE NO. 1 INSTRUMENT PANEL SPEAKER PANEL (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE FRONT NO. 2 SPEAKER ASSEMBLY (for RH) (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE NO. 2 INSTRUMENT PANEL SPEAKER PANEL (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE FRONT NO. 2 SPEAKER ASSEMBLY (for LH) (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE NO. 1 SPEAKER HOLE COVER (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE FRONT NO. 3 SPEAKER ASSEMBLY (See «REMOVAL»(ref-349754-S09013440672009120800000) )
REMOVE TIRE PRESSURE WARNING ECU (See «DISASSEMBLY»(ref-349746-S05234743332009120800000) )
REMOVE NO. 1 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE INSTRUMENT PANEL SAFETY PAD (See «REMOVAL»(ref-349746-S04541701892009120800000) )
REMOVE TURN SIGNAL FLASHER ASSEMBLY Detach the clip. Disconnect the connector and remove the turn signal flasher.

INSTALL TURN SIGNAL FLASHER ASSEMBLY Connect the connector. Attach the clip and install the turn signal flasher.
INSTALL INSTRUMENT PANEL SAFETY PAD (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 2 INSTRUMENT PANEL REGISTER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 1 INSTRUMENT PANEL REGISTER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL TIRE PRESSURE WARNING ECU (See «REASSEMBLY»(ref-349746-S33213030562009120800000) )
INSTALL FRONT NO. 3 SPEAKER ASSEMBLY (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL NO. 1 SPEAKER HOLE COVER (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL FRONT NO. 2 SPEAKER ASSEMBLY (for LH) (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL NO. 2 INSTRUMENT PANEL SPEAKER PANEL (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL FRONT NO. 2 SPEAKER ASSEMBLY (for RH) (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL NO. 1 INSTRUMENT PANEL SPEAKER PANEL (See «INSTALLATION»(ref-349754-S20399033732009120800000) )
INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
INSTALL FRONT PILLAR GARNISH RH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
INSTALL INTEGRATION CONTROL AND PANEL ASSEMBLY WITH BRACKET (w/o Navigation System) (See «INSTALLATION»(ref-349723-S09274112792009120800000) )
INSTALL MULTI-DISPLAY ASSEMBLY WITH BRACKET (for DVD) (See «INSTALLATION»(ref-349759-S13296077332009120800000) )
INSTALL DISPLAY AND NAVIGATION ASSEMBLY WITH BRACKET (for HDD) (See «INSTALLATION»(ref-349759-S36533396952009120800000) )
INSTALL RADIO RECEIVER ASSEMBLY (See «INSTALLATION»(ref-349754-S17698085462009120800000) )
INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 2 INSTRUMENT PANEL LOWER AIRBAG (See «INSTALLATION»(ref-349738-S07188766952009120800000) )
INSTALL INSTRUMENT PANEL LOWER (See «INSTALLATION»(ref-349738-S07188766952009120800000) )
INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 2 INSTRUMENT CLUSTER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT SIDE PANEL RH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 1 INSTRUMENT PANEL LOWER AIRBAG (See «INSTALLATION»(ref-349738-S41995772282009120800000) )
INSTALL NO. 1 INSTRUMENT PANEL SAFETY PAD (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 1 INSTRUMENT CLUSTER MOLDING (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT SIDE PANEL LH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL COMBINATION METER ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT CLUSTER FINISH PANEL (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE (See «INSTALLATION»(ref-349720-S01586454122009120800000) )
INSTALL STEERING COLUMN COVER (w/o Driver Monitor Camera) (See «INSTALLATION»(ref-349720-S29560656232009120800000) )
INSTALL STEERING COLUMN COVER (w/ Driver Monitor Camera) (See «INSTALLATION»(ref-349720-S01586454122009120800000) )
INSTALL STEERING WHEEL ASSEMBLY (See «INSTALLATION»(ref-349720-S01586454122009120800000) )
INSTALL STEERING PAD ASSEMBLY (See «INSTALLATION»(ref-349738-S18853029572009120800000) )
INSTALL NO. 2 STEERING WHEEL COVER LOWER (See «INSTALLATION»(ref-349738-S18853029572009120800000) )
INSTALL SWITCH AND VOLUME CASE (See «INSTALLATION»(ref-349738-S18853029572009120800000) )
INSTALL CONSOLE BOX ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL CONSOLE COVER LOWER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL CONSOLE REAR END PANEL (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL CONSOLE PANEL SUB-ASSEMBLY UPPER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL REAR CONSOLE PANEL UPPER (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL NO. 3 BOX PANEL (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL SHIFT LEVER KNOB (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT PANEL FINISH PANEL END LH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL INSTRUMENT PANEL FINISH PANEL END RH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
INSTALL CABLE TO NEGATIVE BATTERY TERMINAL NOTE: Reset the AUTO TILT AWAY function setting to the previous condition by changing the customize parameter (see «CUSTOMIZE PARAMETERS»(ref-349720-S36027932202009120800000) ).
INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
CHECK SRS WARNING LIGHT Check the SRS warning light (see «DIAGNOSIS SYSTEM»(ref-349738-S23481667942009120800000) ).
PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Lighting: Removal & Installation Lexus LS IV
