Other System: Removal & Installation Lexus LS IV

Communication Devices 14 illustrations ~607 words

INSTALLATION

  1. INSTALL VOLTAGE INVERTER ASSEMBLY Install the voltage inverter with the 2 nuts. Connect the connector.
  2. INSTALL REAR SEAT CONSOLE PANEL ASSEMBLY (See «INSTALLATION»(ref-349734-S14024558482009120800000) )
  3. INSTALL REAR SEAT CONSOLE ARMREST GARNISH LH (See «INSTALLATION»(ref-349734-S14024558482009120800000) )
  4. INSTALL REAR SEAT CONSOLE ARMREST GARNISH RH (See «INSTALLATION»(ref-349734-S14024558482009120800000) )
  5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  6. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
  7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 159

Scheme 159: COMPONENTS
Scheme 159: COMPONENTS

Scheme 160

Scheme 160
Scheme 160

Scheme 161

Scheme 161: REMOVAL
Scheme 161: REMOVAL

Scheme 162

Scheme 162
Scheme 162

Scheme 163

Scheme 163
Scheme 163

Scheme 164

Scheme 164
Scheme 164

Scheme 165

Scheme 165
Scheme 165
  1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
  3. REMOVE REAR SEAT CONSOLE ARMREST BASE (See «DISASSEMBLY»(ref-349734-S05633489522009120800000) )
  4. REMOVE POWER OUTLET SOCKET Detach the claw and remove the power outlet socket. HINT: Open the cover.
  5. REMOVE POWER OUTLET SOCKET COVER Detach the 2 claws and remove the power outlet socket cover.
  6. REMOVE REAR CIGARETTE LIGHTER COVER (w/ Cigarette Lighter) Remove the cover.
  7. REMOVE REAR CIGARETTE LIGHTER ASSEMBLY (w/ Cigarette Lighter) Remove the cigarette lighter knob and element. Using a screwdriver, detach the claw and remove the cigarette lighter socket and retainer. HINT: Tape the screwdriver tip before use.
  8. REMOVE REAR CIGARETTE LIGHTER BEZEL STAY (w/ Cigarette Lighter) Detach the 2 claws and remove the bezel stay.

Scheme 166

Scheme 166: INSTALLATION
Scheme 166: INSTALLATION

Scheme 167

Scheme 167
Scheme 167

Scheme 168

Scheme 168
Scheme 168

Scheme 169

Scheme 169
Scheme 169
  1. INSTALL REAR CIGARETTE LIGHTER BEZEL STAY (w/ Cigarette Lighter) Attach the 2 claws to install the bezel stay.
  2. INSTALL REAR CIGARETTE LIGHTER ASSEMBLY (w/ Cigarette Lighter) Attach the claw to install the rear cigarette lighter.
  3. INSTALL REAR CIGARETTE LIGHTER COVER (w/ Cigarette Lighter) Install the rear cigarette lighter cover.
  4. INSTALL POWER OUTLET SOCKET COVER Attach the 2 claws to install the socket cover.
  5. INSTALL POWER OUTLET SOCKET Attach the claw to install the socket.
  6. INSTALL REAR SEAT CONSOLE ARMREST BASE (See «REASSEMBLY»(ref-349734-S19003666302009120800000) )
  7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  8. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
  9. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 170

Scheme 170: COMPONENTS
Scheme 170: COMPONENTS

Scheme 171

Scheme 171: REMOVAL
Scheme 171: REMOVAL

Scheme 172

Scheme 172
Scheme 172
  1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
  3. REMOVE REAR CONSOLE END PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
  4. REMOVE CONSOLE BOX PLATE Detach the 6 claws and remove the console box plate from the rear console end panel.
  5. REMOVE POWER OUTLET SOCKET Detach the 2 claws and remove the outlet socket from the box plate.
  1. INSTALL POWER OUTLET SOCKET Attach the 2 claws to install the outlet socket to the box plate.
  2. INSTALL CONSOLE BOX PLATE Attach the 6 claws of the box plate to the rear console end panel.
  3. INSTALL REAR CONSOLE END PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
  4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  5. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
  6. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
