Garage Door Opener: Overview Lexus LS IV

Scheme 175

Scheme 176

Scheme 177

SYSTEM DESCRIPTION

1. DESCRIPTION A maximum of 3 kinds of transmitter code based systems (example: garage doors, gates and entry gates) can be registered with the vehicle's garage door opener. After registration, the vehicle's garage door opener can mimic the signal of the transmitter systems and the original transmitters of each transmitter system are not needed.

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

1. REGISTER TRANSMITTER CODE HINT: The vehicle's garage door opener records transmitter codes for systems such as garage doors, gates, entry gates, door locks, home lighting systems, security systems or other transmitter code based systems. The garage door opener is built into the map light assembly. If replacing the map light assembly transmitter, codes for any systems previously registered in the garage door opener must be reregistered. Reregister systems in the garage door opener registration mode. CAUTION: Do not perform transmitter code registration for a system if people or objects are near the system. When registering transmitter codes for a system, injury or damage can occur because the system may open, close, unlock or otherwise operate. NOTE: Before transmitter code registration, confirm that all the electrical systems (headlight, blower motor, rear defogger, etc.) are turned off and no key is in the vehicle. The garage door opener cannot be used with systems that: 1) were manufactured before April 1,1982, or 2) do not meet Federal Standards (for example, garage doors without a jam protection function). HINT: 3 transmitter codes can be registered with the garage door opener, one transmitter code for each of the 3 garage door opener switches. Disconnecting the battery will not erase the transmitter codes registered with the garage door opener. An attempt to overwrite a previously registered transmitter code with a new system's transmitter code may fail. In this situation, the previously registered transmitter code will not be erased. Select a garage door opener switch for transmitter code registration. Press and hold the selected switch for 20 seconds. The garage door opener will enter registration mode. HINT: Before entering registration mode, the LED is turned on. After entering registration mode, the LED flashes at a cycle of 1 Hz. For a "rolling code" type system, after entering registration mode, the LED flashes at a cycle of 8.8 Hz for 1.6 seconds, and then the LED flashes at a cycle of 1 Hz. After the garage door opener has entered registration mode, bring the original transmitter of the system to be registered within 1 to 3 inches of the garage door opener switches. Then press the original transmitter switch. If the transmitter code registration was successful, the LED of the garage door opener flashes at a cycle of 5.6 Hz. If no malfunction occurs, release both the garage door opener switch and the original transmitter switch. HINT: If transmitter code registration fails: 1) the original transmitter's battery may be low or need to be replaced, or 2) the system you are trying to register may not be compatible with the garage door opener. Some transmitter's signals stop after 1 to 2 seconds. For these types of transmitters: 1) press and hold one of the garage door opener switches, and 2) press and release (cycle) the transmitter switch every 2 seconds. Check if the transmitter code was successfully registered. After entering the garage door opener registration mode, transmitter code registration must be completed within 90 seconds. If 90 seconds elapse, the garage door opener will enter low power mode (refer to the c "low power mode" below). Erase transmitter codes in the garage door opener clear mode. HINT: All 3 registered transmitter codes will be erased. No option exists for only erasing one transmitter code. Press and hold the left and right switches of the garage door opener for 20 seconds. The LED will begin to flash at a cycle of 5.6 Hz. Releasing the switches will end clear mode. HINT: If the switches are released within 10 seconds after the transmitter codes have been erased, the garage door opener will enter registration mode. If the switches are held for 10 seconds or more after the transmitter codes have been erased, default codes will be set to the switches of the garage door opener. Using these default codes, operation of the garage door opener can be checked using a tester. Low power mode: If the garage door opener switch is held for 100 seconds or more, the garage door opener will enter low power mode to economize on power consumption. When the garage door opener has entered low power mode, the LED turns off.

Scheme 183

Scheme 184

Scheme 185

1. INSPECT GARAGE DOOR OPENER Press the switch and check that each red LED turns on. If one or more of the switches does not turn on the LED, confirm normal operation of the fuse and wire harness, then replace the garage door opener.
2. INSPECT GARAGE DOOR OPENER REGISTRATION AND TRANSMITTING HINT: Use the "Home Link" tester and a tester transmitter for this test. First erase the customer's transmitter code, and then register the tester transmitter code. Check if the tester transmitter code was successfully registered. HINT: If the code cannot be registered, replace the garage door opener. Press the garage door opener switch that was registered to the tester transmitter. Check if the "HomeLink" tester's green LED illuminates. HINT: If the green LED does not illuminate, replace the garage door opener. When the inspection is complete, reregister the customer's transmitter code(s) again.

Scheme 186

Scheme 187

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE MAP LIGHT ASSEMBLY Remove the map light for the standard body (see «REMOVAL»(ref-349734-S03706653952009120800000) ). Remove the map light for the long body (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
4. REMOVE GARAGE DOOR OPENER TRANSMITTER Disconnect the connector. Remove the 2 screws and remove the garage door opener transmitter.
