Other System: Overview Lexus LS IV

Communication Devices 32 illustrations ~1947 words

SYSTEM DESCRIPTION

  1. CLOCK SYSTEM OUTLINE The clock can be set through the multi-display screen. w/ Navigation system: The navigation system receives time data from the Global Positioning System (GPS) satellites. The clock receives time data from the navigation system every minute, and corrects the time.
  2. COMMUNICATION SYSTEM OUTLINE Components of the clock system communicate with each other via the AVC-LAN. The radio receiver has enough resistance (60 to 80 ft) necessary for transmitting the communication. This is essential for communication. If a short circuit or open circuit occurs in the AVC-LAN circuit, communication is interrupted and the clock system will stop functioning.

DESCRIPTION

The clock receives light control switch position information via the AVC-LAN, and performs nighttime illumination. When nighttime illumination is operating, the combination meter's rheostat performs the illumination adjustment.

Scheme 115

Scheme 115: WIRING DIAGRAM
Scheme 115: WIRING DIAGRAM

Scheme 116

Scheme 116: INSPECTION PROCEDURE
Scheme 116: INSPECTION PROCEDURE

Scheme 117

Scheme 117
Scheme 117
  1. INSPECT NIGHTTIME ILLUMINATION Turn on the light control switch and check the nighttime illumination of the vehicle interior. Result: RESULT CHART Result Proceed to Only clock does not perform nighttime illumination A Clock and multi-display do not perform nighttime illumination B No nighttime illumination at all C B: Go to step 3 C: GO TO METER/GAUGE SYSTEM (See «PROBLEM SYMPTOMS TABLE» ) A: Go to next step
  2. CHECK HARNESS AND CONNECTOR (CLOCK - COMBINATION METER) Disconnect the L38 clock connector. Disconnect the L10 meter connector. Measure the resistance according to the value(s) in the table below. Standard resistance: RESISTANCE SPECIFIED CONDITION Tester Connection Condition Specified Condition L38-3(ILL-) - L10-16 (ILL-) Always Below 1 ohms L38-3 (ILL-) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE (See «PROBLEM SYMPTOMS TABLE» )
  3. CHECK VEHICLE SIGNAL (DISPLAY CHECK MODE) Enter the "Display Check" mode (Vehicle Signal Check Mode) (see «DISPLAY CHECK MODE»(/lexus/ls/iv-2006-2012/remont/navigation-system/#navigation) ). Check that the display changes between ON and OFF according to the light control switch operation. OK DISPLAY REFERENCE Light Control Switch Display TAIL or ON TAIL: ON ADIM TCAN: DIM OFF TAIL: OFF ADIM TCAN: BRIGHT HINT: This display is updated once per second. As a result, it is normal for the display to lag behind the actual change in the switch. Result: RESULT CHART Result Proceed to OK A NG (w/ Navigation System (for HDD)) B NG (w/ Navigation System (for DVD)) C NG (w/o Navigation System) D B: GO TO NAVIGATION SYSTEM (See «NAVIGATION SYSTEM (FOR HDD)»(/lexus/ls/iv-2006-2012/remont/navigation-system/#navigation) ) C: GO TO NAVIGATION SYSTEM (See «NAVIGATION SYSTEM (FOR DVD)»(/lexus/ls/iv-2006-2012/remont/navigation-system/#navigation) ) D: GO TO AUDIO AND VISUAL SYSTEM (w/ Multi-display) (See «AUDIO AND VISUAL SYSTEM (W/ MULTI-DISPLAY)»(/lexus/ls/iv-2006-2012/remont/entertainment-systems/#audiovisual) ) A: PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE (See «PROBLEM SYMPTOMS TABLE» )

The clock receives light control switch position information and GPS information via the AVC-LAN. When a short to +B or short to ground occurs in this AVC-LAN, the clock system will not function normally as communication is discontinued.

Scheme 118

Scheme 118: WIRING DIAGRAM
Scheme 118: WIRING DIAGRAM

Scheme 119

Scheme 119: INSPECTION PROCEDURE
Scheme 119: INSPECTION PROCEDURE
  1. CHECK HARNESS AND CONNECTOR (CLOCK - MULTI-DISPLAY) Disconnect the L38 clock connector. Disconnect the L60 display connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITION Tester Connection Condition Specified Condition L38-5 (TX-1) - L60-17 (TX3-) Always Below 1 ohms L38-6 (TX+1) - L60-18 (TX3+) Always Below 1 ohms L38-S (TX-1) - Body ground Always 10 kohms or higher L38-6 (TX+1) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE (See «PROBLEM SYMPTOMS TABLE» )

The circuit provides power to the clock.

Scheme 120

Scheme 120: WIRING DIAGRAM
Scheme 120: WIRING DIAGRAM

Scheme 121

Scheme 121: INSPECTION PROCEDURE
Scheme 121: INSPECTION PROCEDURE
  1. INSPECT FUSE (P-ACC, DOME) Disconnect the DOME fuse from the main body ECU. Disconnect the P-ACC fuse from the passenger side junction block. Measure the resistance of the fuses. Standard resistance RESISTANCE SPECIFIED CONDITION Tester Connection Condition Specified Condition ACC fuse Always Below 1 ohms DOME fuse Always Below 1 ohms NG: REPLACE FUSE OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (CLOCK - BATTERY AND BODY GROUND) Disconnect the L38 clock connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFIED CONDITION Tester Connection Condition Specified Condition L38-7 (E) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition L38-4 (ACC) - Body ground Engine switch on (ACC) 11 to 14 V L38-8 (+B) - Body ground Always 11 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE CLOCK ASSEMBLY (See «REMOVAL» )

Scheme 122

Scheme 122: COMPONENTS
Scheme 122: COMPONENTS

Scheme 123

Scheme 123
Scheme 123

Scheme 124

Scheme 124: REMOVAL
Scheme 124: REMOVAL
  1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL» )
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
  3. REMOVE INSTRUMENT PANEL FINISH PANEL END LH (See «REMOVAL» )
  4. REMOVE INSTRUMENT PANEL FINISH PANEL END RH (See «REMOVAL» )
  5. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL» )
  6. REMOVE NO. 3 BOX PANEL (See «REMOVAL» )
  7. REMOVE REAR CONSOLE PANEL UPPER (See «REMOVAL» )
  8. REMOVE CONSOLE PANEL SUB-ASSEMBLY UPPER (See «REMOVAL» )
  9. REMOVE RADIO RECEIVER ASSEMBLY WITH BRACKET (See «REMOVAL»(/lexus/ls/iv-2006-2012/remont/entertainment-systems/#audiovisual) )
  10. REMOVE INTEGRATION CONTROL AND PANEL ASSEMBLY WITH BRACKET (w/o Multi-display) (See «REMOVAL» )
  11. REMOVE DISPLAY AND NAVIGATION ASSEMBLY WITH BRACKET (w/ Multi-display) (See «REMOVAL»(/lexus/ls/iv-2006-2012/remont/navigation-system/#navigation) )
  12. REMOVE CLOCK ASSEMBLY Using a screwdriver, detach the 2 claws and remove the clock. HINT: Tape the screwdriver tip before use.

Scheme 125

Scheme 125: INSTALLATION
Scheme 125: INSTALLATION
  1. INSTALL CLOCK ASSEMBLY Attach the 2 claws to install the clock.
  2. INSTALL INTEGRATION CONTROL AND PANEL ASSEMBLY WITH BRACKET (w/o Multi-display) (See «INSTALLATION» )
  3. INSTALL DISPLAY AND NAVIGATION ASSEMBLY WITH BRACKET (w/ Multi-display) (See «INSTALLATION»(/lexus/ls/iv-2006-2012/remont/navigation-system/#navigation) )
  4. INSTALL RADIO RECEIVER ASSEMBLY WITH BRACKET (See «INSTALLATION»(/lexus/ls/iv-2006-2012/remont/entertainment-systems/#audiovisual) )
  5. INSTALL CONSOLE PANEL SUB-ASSEMBLY UPPER (See «INSTALLATION» )
  6. INSTALL REAR CONSOLE PANEL UPPER (See «INSTALLATION» )
  7. INSTALL NO. 3 BOX PANEL (See «INSTALLATION» )
  8. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (See «INSTALLATION» )
  9. INSTALL INSTRUMENT PANEL FINISH PANEL END LH (See «INSTALLATION» )
  10. INSTALL INSTRUMENT PANEL FINISH PANEL END RH (See «INSTALLATION» )
  11. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  12. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION» )
  13. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION» ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 126

Scheme 126: COMPONENTS
Scheme 126: COMPONENTS

Scheme 127

Scheme 127: REMOVAL
Scheme 127: REMOVAL

Scheme 128

Scheme 128
Scheme 128

Scheme 129

Scheme 129
Scheme 129

Scheme 130

Scheme 130
Scheme 130
  1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL» )
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
  3. REMOVE INSTRUMENT PANEL FINISH PANEL END LH (See «REMOVAL» )
  4. REMOVE INSTRUMENT PANEL FINISH PANEL END RH (See «REMOVAL» )
  5. REMOVE NO. 3 BOX PANEL (See «REMOVAL» )
  6. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL» )
  7. REMOVE REAR CONSOLE PANEL UPPER (See «REMOVAL» )
  8. REMOVE CONSOLE PANEL SUB-ASSEMBLY UPPER (See «REMOVAL» )
  9. REMOVE CIGARETTE LIGHTER ASSEMBLY Remove the cigarette lighter knob and element. Detach the clamp and disconnect the connector. Rotate the ring nut in the direction indicated by the arrow, and remove the ring nut from the console panel. Remove the cigarette retainer from the console panel. Remove the cigarette lighter from the console panel.

Scheme 131

Scheme 131: INSTALLATION
Scheme 131: INSTALLATION

Scheme 132

Scheme 132
Scheme 132

Scheme 133

Scheme 133
Scheme 133
  1. INSTALL CIGARETTE LIGHTER ASSEMBLY Install the cigarette lighter socket to the console panel. Install the cigarette retainer to the console panel. Rotate the ring nut in the direction indicated by the arrow and install the ring nut to the console panel. Connect the connector and attach the clamp. Install the cigarette lighter knob and element to the console panel.
  2. INSTALL CONSOLE PANEL SUB-ASSEMBLY UPPER (See «INSTALLATION» )
  3. INSTALL REAR CONSOLE PANEL UPPER (See «INSTALLATION» )
  4. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (See «INSTALLATION» )
  5. INSTALL NO. 3 BOX PANEL (See «INSTALLATION» )
  6. INSTALL INSTRUMENT PANEL FINISH PANEL END LH (See «INSTALLATION» )
  7. INSTALL INSTRUMENT PANEL FINISH PANEL END RH (See «INSTALLATION» )
  8. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  9. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION» )
  10. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION» ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 134

Scheme 134: COMPONENTS
Scheme 134: COMPONENTS

Scheme 135

Scheme 135: REMOVAL
Scheme 135: REMOVAL

Scheme 136

Scheme 136
Scheme 136

Scheme 137

Scheme 137
Scheme 137

Scheme 138

Scheme 138
Scheme 138
  1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL» )
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
  3. REMOVE REAR CONSOLE END PANEL SUB-ASSEMBLY (See «REMOVAL» )
  4. REMOVE CONSOLE BOX PLATE Detach the clamp and disconnect the connector. Detach the 6 claws and remove the console box plate from the rear console end panel.
  5. REMOVE REAR CIGARETTE LIGHTER COVER Remove the cigarette lighter cover.
  6. REMOVE REAR CIGARETTE LIGHTER ASSEMBLY Remove the cigarette lighter knob and element. Using a screwdriver, detach the claw and remove the socket cover from the console box plate. HINT: Tape the screwdriver tip before use.
  7. REMOVE REAR CIGARETTE LIGHTER BEZEL STAY Remove the cigarette lighter bezel stay.
  8. REMOVE CIGARETTE LIGHTER HOLE BEZEL Detach the 2 claws and cigarette lighter hole bezel from the cigarette lighter hole bezel stay.

Scheme 139

Scheme 139
Scheme 139

Scheme 140

Scheme 140
Scheme 140

Scheme 141

Scheme 141
Scheme 141

Scheme 142

Scheme 142
Scheme 142

Scheme 143

Scheme 143
Scheme 143
  1. INSTALL CIGARETTE LIGHTER HOLE BEZEL Attach the 2 claws to install the cigarette lighter hole bezel.
  2. INSTALL REAR CIGARETTE LIGHTER BEZEL STAY Install the cigarette lighter bezel stay.
  3. INSTALL REAR CIGARETTE LIGHTER ASSEMBLY Attach the claw to install the cigarette lighter socket cover. Install the cigarette lighter knob and element. When replacing cigarette lighter assembly: Install a new wire harness clamp as shown in the illustration. Standard CLAMP DIMENSIONS Area Standard Measurement a 30 to 40 mm (1.18 to 1.57 in.) b 85 to 95 mm (3.35 to 3.74 in.) Clamp the cord securely. HINT: After clamping the cord, cut off any extra cord so that there is only 1 to 3 mm (0.04 to 0.12 in.) protruding.
  4. INSTALL REAR CIGARETTE LIGHTER COVER Install the cigarette lighter cover.
  5. INSTALL CONSOLE BOX PLATE Attach the 6 claws of the console box plate to the rear console end panel. Connect the connector and attach the clamp.
  6. INSTALL REAR CONSOLE END PANEL SUB-ASSEMBLY (See «INSTALLATION» )
  7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  8. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION» )
  9. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION» ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 144

Scheme 144: COMPONENTS
Scheme 144: COMPONENTS

Scheme 145

Scheme 145: REMOVAL
Scheme 145: REMOVAL

Scheme 146

Scheme 146
Scheme 146
  1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL» )
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
  3. REMOVE REAR SEAT CONSOLE ARMREST GARNISH LH (See «REMOVAL» )
  4. REMOVE REAR SEAT CONSOLE ARMREST GARNISH RH (See «REMOVAL» )
  5. REMOVE REAR SEAT CONSOLE PANEL ASSEMBLY (See «REMOVAL» )
  6. REMOVE VOLTAGE INVERTER ASSEMBLY Disconnect the connector. Remove the 2 nuts and voltage inverter.
