Servicing - LS430: Removal & Installation Lexus LS III рестайлинг

Automatic Trans 12 illustrations ~1209 words

FILTER REPLACEMENT

This procedure is included in valve body removal and installation. See VALVE BODY ASSEMBLY under REMOVAL & INSTALLATION.

REMOVAL & INSTALLATION

WARNINGVehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See AIR BAG SAFETY PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in AIRBAG article in RESTRAINTS.
CAUTIONWhen battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery.

Note. For component locations. see scheme 7

Remove & Install

  1. Remove transmission revolution sensor (NCO SENSOR). (Scheme 2): Disconnect transmission revolution sensor connector. Remove the bolt and transmission revolution sensor. Remove the O-ring from the transmission revolution sensor.
  2. Remove transmission revolution sensor (SP2 SENSOR). (Scheme 3): Disconnect transmission revolution sensor connector. Remove the bolt and transmission revolution sensor. Remove the "O" ring from the transmission revolution sensor.
  3. Install transmission revolution sensor (SP2 SENSOR). (Scheme 3): Coat a new "O" ring with ATF and install it to the transmission revolution sensor. Install the transmission revolution sensor with the bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). Connect the transmission revolution sensor connector.
  4. Install transmission revolution sensor (NCO SENSOR). (Scheme 2): Coat a new "O" ring with ATF and install it to the transmission revolution sensor. Install the transmission revolution sensor with the bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). Connect the transmission revolution sensor connector.

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3
  1. Disconnect battery negative terminal.
  2. Drain automatic transmission fluid: Remove the drain plug, gasket and drain the ATF. Install a new gasket and the drain plug. Tighten drain plug to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000).
  3. Remove automatic transmission oil pan sub-assy: Remove the 20 bolts, oil pan and gasket. (Scheme 4) Remove the 3 magnets from the oil pan. (Scheme 5) NOTE: Collect any steel chips with the removed magnets. Carefully look at the foreign objects and particles in the pan and on the magnets to guess at the type of wear which might be found in the transmission. Steel (magnetic)... bearing, gear and clutch plate wear Brass (non-magnetic)... bushing wear Examine particles in pan.
  4. Remove valve body oil strainer assy: Remove the 4 bolts and oil strainer. (Scheme 6) Remove the "O" ring from the oil strainer. (Scheme 7)
  5. Disconnect transmission wire. (Scheme 8): remove bolt and lock plate, and separate the ATF temperature sensor. Remove the 2 bolts and 2 clamps. Separate the 9 connectors from the solenoid valves.
  6. Remove transmission wire: (Scheme 9) Disconnect the transmission wire connector. Remove the bolt and pull out the transmission wire.
  7. Install transmission wire. (Scheme 9): Coat an "O" ring of the transmission wire connector with ATF. Install the transmission wire with the bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). Connect the transmission wire connector.
  8. Connect transmission wire. (Scheme 8): Coat a new "O" ring of the ATF temperature sensor with ATF. Connect the 9 connectors to the solenoid valves. Install the 2 clamps with the 2 bolts. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). Install the ATF temperature sensor and lock plate with the bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000).
  9. Install valve body oil strainer assy. (Scheme 6): Coat a new "O" ring with ATF. Install the "O" ring. Install the oil strainer with the 4 bolts. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000).
  10. Install automatic transmission oil pan sub-assy: Install the 3 magnets in the oil pan. (Scheme 5) Using a new gasket, install the oil pan with the 20 bolts to the transmission case. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000).
  11. Connect battery negative terminal.
  12. Add automatic transmission fluid. See «DRAINING & REFILLING»(ref-168062-S16900793872004102900000) under LUBRICATION.
  13. Reset memory. See «COMPUTER RELEARN PROCEDURES»(ref-162030) article in GENERAL INFORMATION.
  14. Perform initialization. See «COMPUTER RELEARN PROCEDURES»(ref-162030) article in GENERAL INFORMATION.

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
CAUTIONA large amount of material debris including steel (magnetic) and non magnetic (brass, aluminum or clutch fiber particles) may indicate excessive transmission wear or damage. Check magnets in oil pan for steel particles which indicate bearing, plate or hardware damage.
CAUTIONWhen removing transmission oil pan, filter and valve body components, note bolt size, location and length for reassembly reference.
CAUTIONWhen working with FIPG material, perform the following: Using a razor blade and gasket scraper, remove all the old, FIPG material from the gasket surfaces. Thoroughly clean all components to remove any loose material. Clean both sealing surfaces with a non-residue solvent. Apply FIPG in continuous line width approximately 0.04 in. (1 mm) wide along the sealing surface. Parts must be assembled within 10 minutes of application. Otherwise, the FIPG material must be removed and reapplied.
  1. Disconnect battery negative terminal.
  2. Drain automatic transmission fluid: Remove the drain plug, gasket and drain the ATF. Install a new gasket and the drain plug. Tighten drain plug to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000).
  3. Remove automatic transmission oil pan sub-assy: Remove the 20 bolts, oil pan and gasket. (Scheme 4) Remove the 3 magnets from the oil pan. (Scheme 5) NOTE: Collect any steel chips with the removed magnets. Carefully look at the foreign objects and particles in the pan and on the magnets to guess at the type of wear which might be found in the transmission. Steel (magnetic)... bearing, gear and clutch plate wear Brass (non-magnetic)... bushing wear Examine particles in pan.
  4. Remove valve body oil strainer assy: Remove the 4 bolts and oil strainer. (Scheme 6) Remove the "O" ring from the oil strainer. (Scheme 7)
  5. Disconnect transmission wire. (Scheme 8): Remove the bolt and lock plate, and separate the ATF temperature sensor. Remove the 2 bolts and 2 clamps. Separate the 9 connectors from the solenoid valves.
  6. Remove transmission valve body assy. (Scheme 10): Remove the 20 bolts and valve body. CAUTION: Do not drop the check ball body and spring. Remove the check ball body and spring. (Scheme 11) Remove the bolt, lock plate and lock up control solenoid (SLU) and clutch control solenoid (SL2). (Scheme 12) Remove the bolt and automatic transmission 3-way solenoid assy (S3). Remove the bolt and automatic transmission 3-way solenoid (S2) and automatic transmission 3-way solenoid (S4). Remove the bolt and automatic transmission 3-way solenoid (S1). Remove the bolt and automatic transmission 3-way sole- noid (SR). Remove the bolt, lock plate and clutch control solenoid No.1 (SL1) and line pressure control solenoid (SLT).
  7. Install transmission valve body assy. (Scheme 10): Install the clutch control solenoid No.1 (SL1) and line pressure control solenoid (SLT) with the lock plate and bolt. (Scheme 12) Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). Install the automatic transmission 3-way solenoid (SR) with the bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). Install the automatic transmission 3-way solenoid (S1) with the bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). Install the automatic transmission 3-way solenoid (S2) and automatic transmission 3-way solenoid (S4) with the bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). Install the automatic transmission 3-way solenoid (S3) with the bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). Install the lock up control solenoid (SLU) and clutch control solenoid (SL2) with the lock plate and bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). CAUTION: Do not drop the check ball body and spring. Install the check ball body and spring. (Scheme 11) Align the groove of the manual valve with the pin of the lever. (Scheme 13) Install the 20 bolts. (Scheme 10)
  8. Install transmission wire. (Scheme 8): Coat a new "O" ring of the ATF temperature sensor with ATF. Install the 2 clamps with the 2 bolts. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000). Connect the 9 connectors to the solenoid valves. Install the ATF temperature sensor and lock plate with the bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000).
  9. Install valve body oil strainer assy: Coat a new "O" ring with ATF. Install the "O" ring. Install the oil strainer with the 4 bolts. (Scheme 6)
  10. Install automatic transmission oil pan sub-assy: Install the 3 magnets in the oil pan. (Scheme 5) Using a new gasket, Install the oil pan with the 20 bolts to the transmission case. (Scheme 4) Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-168062-S35340773342004102900000).
  11. Connect battery negative terminal.
  12. Add automatic transmission fluid. See «FLUID CAPACITIES»(ref-168062-S18665687542004102900000).
  13. Reset memory. See «COMPUTER RELEARN PROCEDURES»(ref-162030) article in GENERAL INFORMATION.
  14. Perform initialization. See «COMPUTER RELEARN PROCEDURES»(ref-162030) article in GENERAL INFORMATION.

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
