SHIFT SPEED SPECIFICATIONS
| Application | MPH |
|---|
| "D" Or "M" Range |
| NORM Or PWR |
| 1st-2nd (1) | 32-38 |
| 2nd-3rd (1) | 50-57 |
| 3rd-4th (1) | 76-86 |
| 4th-5th (1) | 109-120 |
| 4th-5th (2) | 24-28 |
| 5th-4th (1) | 105-113 |
| 5th-4th (2) | 14-17 |
| 4th-3rd (1) | 69-76 |
| 3rd-2nd (1) | 38-43 |
| 2nd-1st (1) | 21-24 |
| SNOW |
| 1st-2nd (1) | 22-32 |
| 2nd-3rd (1) | 35-47 |
| 3rd-4th (1) | 55-70 |
| 4th-5th (1) | 78-98 |
| 4th-5th (2) | 24-27 |
| 5th-4th (1) | 42-57 |
| 5th-4th (2) | 14-17 |
| 4th-3rd (1) | 25-35 |
| 2nd-1st (1) | 11-20 |
| "3" Range |
| NORM Or PWR |
| 1st-2nd (1) | 32-38 |
| 2nd-3rd (1) | 50-57 |
| 3rd-2nd (1) | 38-43 |
| 2nd-1st (1) | 21-24 |
| SNOW |
| 1st-2nd (1) | 22-32 |
| 2nd-3rd (1) | 35-47 |
| 4th-3rd (1) | 79-87 |
| 3rd-2nd (1) | 11-20 |
| "2" Range |
| NORM Or PWR |
| 1st-2nd (1) | 32-38 |
| 3rd-2nd (1) | 53-58 |
| 2nd-1st (1) | 21-24 |
| SNOW |
| 1st-2nd (1) | 22-32 |
| 3rd-2nd (1) | 53-58 |
| "L" Range |
| 2nd-1st (1) | 10-13 |
| (1) Wide open throttle. (2) Fully closed throttle. |
| (2) | Fully closed throttle. |
SHIFT SPEED SPECIFICATIONS (GS 300)
| Application | MPH |
|---|
| "D" Range |
| NORM Or PWR |
| 1st-2nd (1) | 38-45 |
| 2nd-3rd (1) | 58-65 |
| 3rd-4th (1) | 89-100 |
| 4th-5th (1) | 131-143 |
| 4th-5th (2) | 21-25 |
| 5th-4th (1) | 126-136 |
| 5th-4th (2) | 16-19 |
| 4th-3rd (1) | 84-92 |
| 3rd-2nd (1) | 50-55 |
| 2nd-1st (1) | 26-30 |
| SNOW |
| 1st-2nd (1) | 22-33 |
| 2nd-3rd (1) | 36-50 |
| 3rd-4th (1) | 54-71 |
| 4th-5th (1) | 84-113 |
| 4th-5th (2) | 21-25 |
| 5th-4th (1) | 52-71 |
| 5th-4th (2) | 16-19 |
| 4th-3rd (1) | 35-48 |
| 2nd-1st (1) | 3-6 |
| "3" Range |
| NORM Or PWR |
| 1st-2nd (1) | 38-45 |
| 2nd-3rd (1) | 58-65 |
| 4th-3rd (1) | 95-104 |
| 3rd-2nd (1) | 50-55 |
| 2nd-1st (1) | 26-30 |
| SNOW |
| 1st-2nd (1) | 22-33 |
| 2nd-3rd (1) | 36-50 |
| 4th-3rd (2) | 95-104 |
| 2nd-1st (1) | 3-6 |
| "2" Range |
| NORM Or PWR |
| 1st-2nd (1) | 38-45 |
| 3rd-2nd (1) | 62-67 |
| 2nd-1st (1) | 26-30 |
| SNOW |
| 1st-2nd (1) | 22-33 |
| 3rd-2nd (1) | 62-67 |
| "L" Range |
| 2nd-1st (1) | 24-28 |
| (1) Wide open throttle. (2) Fully closed throttle. |
| (2) | Fully closed throttle. |
SHIFT SPEED SPECIFICATIONS (GS 430)
| Application | MPH |
|---|
| "D","4" Range |
| NORM Or PWR |
| 1st-2nd (1) | 29-37 |
| 2nd-3rd (1) | 45-55 |
| 3rd-4th (1) | 73-83 |
| 4th-5th (1) | 104-115 |
| 4th-5th (2) | 23-27 |
| 5th-4th (1) | 101-109 |
| 5th-4th (2) | 13-16 |
| 4th-3rd (1) | 66-73 |
| 3rd-2nd (1) | 37-41 |
| 2nd-1st (1) | 20-24 |
| SNOW |
| 1st-2nd (1) | 22-30 |
| 2nd-3rd (1) | 34-45 |
| 3rd-4th (1) | 52-68 |
| 4th-5th (1) | 75-94 |
| 4th-5th (2) | 23-27 |
| 5th-4th (1) | 40-55 |
| 5th-4th (2) | 13-16 |
| 4th-3rd (1) | 24-34 |
| 3rd-2nd (1) | 11-19 |
| "3" Range |
| NORM Or PWR |
| 1st-2nd (1) | 29-37 |
| 2nd-3rd (1) | 48-54 |
| 4th-3rd (1) | 76-83 |
| 3rd-2nd (1) | 37-41 |
| 2nd-1st (1) | 20-24 |
| SNOW |
| 1st-2nd (1) | 22-30 |
| 2nd-3rd (1) | 34-45 |
| 4th-3rd (1) | 76-83 |
| 2nd-3rd (1) | 11-19 |
| "2" Range |
| NORM Or PWR |
| 1st-2nd (1) | 29-37 |
| 3rd-2nd (1) | 51-56 |
| 2nd-1st (1) | 20-24 |
| SNOW |
| 1st-2nd (1) | 29-37 |
| 2nd-1st (1) | 51-56 |
| "L" Range |
| 2nd-1st (1) | 11-14 |
| (1) Wide open throttle. (2) Fully closed throttle. |
| (2) | Fully closed throttle. |
SHIFT SPEED SPECIFICATIONS (IS 300)
| Application | MPH |
|---|
| "D" Range |
| NORM Or PWR |
| 1st-2nd (1) | 40-46 |
| 2nd-3rd (1) | 60-66 |
| 3rd-4th (1) | 93-103 |
| 4th-5th (1) | 136-146 |
| 4th-5th (2) | 22-25 |
| 5th-4th (1) | 131-140 |
| 5th-4th (2) | 16-19 |
| 4th-3rd (1) | 88-94 |
| 3rd-2nd (1) | 52-60 |
| 2nd-1st (1) | 27-30 |
| "3" Range |
| NORM Or PWR |
| 1st-2nd (1) | 40-46 |
| 2nd-3rd (1) | 60-66 |
| 4th-3rd (1) | 99-106 |
| 3rd-2nd (1) | 52-60 |
| 2nd-1st (1) | 27-30 |
| "2" Range |
| NORM Or PWR |
| 1st-2nd (1) | 40-46 |
| 3rd-2nd (1) | 65-69 |
| 2nd-1st (1) | 27-30 |
| "L" Range |
| 2nd-1st (1) | 25-29 |
| (1) Wide open throttle. (2) Fully closed throttle. |
| (2) | Fully closed throttle. |
SHIFT SPEED SPECIFICATIONS (LS 430)
| Application | MPH |
|---|
| "D" Range |
| NORM Or PWR |
| 1st-2nd (1) | 36-43 |
| 2nd-3rd (1) | 56-63 |
| 3rd-4th (1) | 89-99 |
| 4th-5th (1) | 132-144 |
| 4th-5th (2) | 21-25 |
| 5th-4th (1) | 127-137 |
| 5th-4th (2) | 16-19 |
| 4th-3rd (1) | 85-93 |
| 3rd-2nd (1) | 50-55 |
| 2nd-1st (1) | 26-30 |
| SNOW |
| 1st-2nd (1) | 22-35 |
| 2nd-3rd (1) | 37-54 |
| 3rd-4th (1) | 54-80 |
| 4th-5th (1) | 85-132 |
| 4th-5th (2) | 21-25 |
| 5th-4th (1) | 52-81 |
| 5th-4th (2) | 16-19 |
| 4th-3rd (1) | 35-55 |
| 2nd-1st (1) | 3-6 |
| "3" Range |
| NORM Or PWR |
| 1st-2nd (1) | 36-43 |
| 2nd-3rd (1) | 56-63 |
| 4th-3rd (2) | 85-93 |
| 3rd-2nd (1) | 50-55 |
| 2nd-1st (1) | 26-30 |
| SNOW |
| 1st-2nd (1) | 22-35 |
| 2nd-3rd (1) | 37-54 |
| 4th-3rd (2) | 85-93 |
| 2nd-1st (1) | 3-6 |
| "2" Range |
| NORM Or PWR |
| 1st-2nd (1) | 36-43 |
| 3rd-2nd (1) | 51-56 |
| 2nd-1st (1) | 26-30 |
| SNOW |
| 1st-2nd (1) | 22-35 |
| 3rd-2nd (1) | 51-56 |
| "L" Range |
| 2nd-1st (1) | 24-28 |
| (1) Wide open throttle. (2) Fully closed throttle. |
| (2) | Fully closed throttle. |
SHIFT SPEED SPECIFICATIONS (SC 430)
LOCK-UP SPEED SPECIFICATIONS
| Application (1) | MPH |
|---|
| "D" Range (2) |
| NORM Or PWR |
| Lock-Up On In 5th | 35-38 |
| Lock-Up Off In 5th | 34-37 |
| "4" Range (2) |
| NORM Or PWR |
| Lock-Up On In 4th | 35-38 |
| Lock-Up On In 4th | 34-37 |
| (1) Throttle valve opened 5 percent. (2) No lock-up in "L", "2" or "3" range. |
| (1) | Throttle valve opened 5 percent. |
| (2) | No lock-up in "L", "2" or "3" range. |
LOCK-UP SPEED SPECIFICATIONS (GS 300)
| Application (1) | MPH |
|---|
| "D" Range (2) |
| NORM Or PWR |
| Lock-Up On In 5th | 37-41 |
| Lock-Up Off In 5th | 34-38 |
| "4" Range (2) |
| NORM Or PWR |
| Lock-Up On In 4th | 87-95 |
| Lock-Up Off In 4th | 83-91 |
| (1) Throttle valve opened 5 percent. (2) No lock-up in "L", "2" or "3" range. |
| (1) | Throttle valve opened 5 percent. |
| (2) | No lock-up in "L", "2" or "3" range. |
LOCK-UP SPEED SPECIFICATIONS (GS 430)
| Application (1) | MPH |
|---|
| "D" Range (2) |
| NORM Or PWR |
| Lock-Up On In 5th | 33-37 |
| Lock-Up Off In 5th | 32-36 |
| "4" Range (2) |
| NORM Or PWR |
| Lock-Up On In 4th | 33-37 |
| Lock-Up On In 4th | 32-36 |
| (1) Throttle valve opened 5 percent. (2) No lock-up in "L", "2" or "3" range. |
| (1) | Throttle valve opened 5 percent. |
| (2) | No lock-up in "L", "2" or "3" range. |
LOCK-UP SPEED SPECIFICATIONS (IS 300)
| Application (1) | MPH |
|---|
| "D" Range (2) |
| NORM Or PWR |
| Lock-Up On In 5th | 38-42 |
| Lock-Up Off In 5th | 35-39 |
| "4" Range (2) |
| NORM Or PWR |
| Lock-Up On In 4th | 90-97 |
| Lock-Up Off In 4th | 85-92 |
| (1) Throttle valve opened 5 percent. (2) No lock-up in "L", "2" or "3" range. |
| (1) | Throttle valve opened 5 percent. |
| (2) | No lock-up in "L", "2" or "3" range. |
LOCK-UP SPEED SPECIFICATIONS (LS 430)
| Application (1) | MPH |
|---|
| "D" Range (2) |
| NORM Or PWR |
| Lock-Up On In 5th | 37-41 |
| Lock-Up Off In 5th | 34-38 |
| "4" Range (2) |
| NORM Or PWR |
| Lock-Up On In 4th | 87-95 |
| Lock-Up Off In 4th | 83-91 |
| (1) Throttle valve opened 5 percent. (2) No lock-up in "L", "2" or "3" range. |
| (1) | Throttle valve opened 5 percent. |
| (2) | No lock-up in "L", "2" or "3" range. |
LOCK-UP SPEED SPECIFICATIONS (SC 430)
FLEX LOCK-UP SPEED SPECIFICATIONS
| Application | MPH |
|---|
| "D" Range (1) |
| When Accelerating |
| Lock-Up On In 5th | 24-27 |
| Lock-Up Off In 5th | 24-27 |
| Lock-Up On In 4th | 19-21 |
| Lock-Up Off In 4th | 17-19 |
| "4" Range (1) |
| Lock-Up On In 4th | 24-27 |
| Lock-Up Off In 4th | 23-26 |
| "D" Range (2) |
| When Decelerating (A/C On) |
| Lock-Up On In 5th | 58-63 |
| Lock-Up Off In 5th | 20-33 |
| "4" Range (2) |
| When Decelerating (A/C On) |
| Lock-Up On In 4th | 58-63 |
| Lock-Up Off In 4th | 15-25 |
| "D" Range (2) |
| When Decelerating (A/C Off) |
| Lock-Up On In 5th | 58-63 |
| Lock-Up Off In 5th | 20-23 |
| "4" Range (2) |
| When Decelerating (A/C Off) |
| Lock-Up Off In 4th | 13-17 |
| (1) Throttle valve opened 3 percent. (2) Throttle valve fully closed. |
| (1) | Throttle valve opened 3 percent. |
| (2) | Throttle valve fully closed. |
FLEX LOCK-UP SPEED SPECIFICATIONS (GS 300)
| Application | MPH |
|---|
| "D" Range (1) |
| When Accelerating |
| Lock-Up On In 5th | 29-33 |
| Lock-Up Off In 5th | 28-32 |
| "4" Range (1) |
| When Accelerating |
| Lock-Up On In 4th | 22-25 |
| Lock-Up Off In 4th | 21-24 |
| "3" Range (1) |
| When Accelerating |
| Lock-Up On In 3rd | 16-19 |
| Lock-Up Off In 3rd | 14-17 |
| (1) Throttle valve opened 3 percent. |
| (1) | Throttle valve opened 3 percent. |
FLEX LOCK-UP SPEED SPECIFICATIONS (GS 430)
| Application | MPH |
|---|
| "D" Range (1) |
| When Accelerating |
| Lock-Up On In 5th | 23-27 |
| Lock-Up Off In 5th | 22-25 |
| "4" Range |
| When Accelerating |
| Lock-Up On In 4th | 17-32 |
| Lock-Up Off In 4th | 18-20 |
| (1) Throttle valve opened 3 percent. |
| (1) | Throttle valve opened 3 percent. |
FLEX LOCK-UP SPEED SPECIFICATIONS (IS 300)
| Application | MPH |
|---|
| "D" Range (1) |
| When Accelerating |
| Lock-Up On In 5th | 29-33 |
| Lock-Up Off In 5th | 28-32 |
| "4" Range (1) |
| When Accelerating |
| Lock-Up On In 4th | 22-25 |
| Lock-Up Off In 4th | 21-24 |
| "3" Range (1) |
| When Accelerating |
| Lock-Up On In 3rd | 16-19 |
| Lock-Up Off In 3rd | 14-17 |
| (1) Throttle valve opened 3 percent. |
| (1) | Throttle valve opened 3 percent. |
FLEX LOCK-UP SPEED SPECIFICATIONS (SC 430)
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Control Shaft Lock Nut | 12 (16) |
| VSS Bolt | 12 (16) |
| INCH Lbs. (N.m) |
| OD Direct Clutch Speed Sensor Bolt | 48 (5.4) |
| PNP Switch Bolt | 115 (13) |
| PNP Switch Nut | 61 (6.9) |
| Shift Solenoid | 89 (10) |
Scheme 2
Scheme 2: CONNECTOR IDENTIFICATION
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
