Automatic A/c-Heater Systems: Specifications Lexus LS III

Automatic HVAC System 3 illustrations

SPECIFICATIONS

ApplicationSpecification
Compressor TypeNippondenso 7SBU16
Compressor Belt Deflection(1)
Compressor Oil Capacity(2)
Refrigerant (R-134a) Capacity
Single A/C21.2-24.7 ozs.
Dual A/C30.0-33.5 ozs.
System Operating Pressures (3)
High Side199-228 psi (14-16 kg/cm 2 )
Low Side21-36 psi (1.5-2.5 kg/cm 2 )
(1) Belt tension is maintained automatically. (2) Use ND-OIL 8 refrigerant oil. Refrigerant oil quantity not available. Refer to underhood A/C specification label. (3) Specification is with ambient temperature at 86-95°F (30-35°C) and engine speed at 2000 RPM.
(1)Belt tension is maintained automatically.
(2)Use ND-OIL 8 refrigerant oil. Refrigerant oil quantity not available. Refer to underhood A/C specification label.
(3)Specification is with ambient temperature at 86-95°F (30-35°C) and engine speed at 2000 RPM.

SPECIFICATIONS

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
A/C Compressor
Bolt36 (49)
Nut22 (30)
A/C Compressor Bracket Bolt36 (49)
Expansion Valve-To-Discharge Tube
19 mm Nut10 (14)
24 mm Nut17 (23)
Front Seat Belt Outer Anchor Bolt31 (42)
Front Seat Mounting Bolts27 (37)
Instrument Panel & Braces15 (20)
INCH Lbs. (N.m)
Air Bag Module Torx Screw78 (8.8)
Blower Unit Fittings89 (10)
Compressor Clutch Center Bolt117 (13)
Compressor Discharge Tube89 (10)
Compressor Suction Tube89 (10)
Condenser Fittings48 (5.4)
Expansion Valve-To-Suction Tube89 (10)
Modulator (Receiver-Drier) Cap109 (12)
Rear Expansion Valve-To-Evaporator Bolts31 (3.5)
Rear Refrigerant Line Bolts89 (10)
Pressure Switch89 (10)
Receiver-Drier Fittings48 (5.4)
Steering Column Support Nuts19 (26)
Steering Column Pinch Bolts26 (35)
Steering Wheel Nut37 (50)

TORQUE SPECIFICATIONS

Automatic A/C-Heater System Wiring Diagram (2001 LS 430 - 1 Of 2). Scheme 1

Scheme 1: Automatic A/C-Heater System Wiring Diagram (2001 LS 430 - 1 Of 2)

Automatic A/C-Heater System Wiring Diagram (2001 LS 430 - 2 Of 2). Scheme 2

Scheme 2: Automatic A/C-Heater System Wiring Diagram (2001 LS 430 - 2 Of 2)

Rear A/C System Wiring Diagram (2001 LS 430). Scheme 3

Scheme 3: Rear A/C System Wiring Diagram (2001 LS 430)
