Engine Controls - Tests W/codes: Other Lexus LS II

Testing & Diagnostics 1 illustration ~769 words

TWO-TRIP DETECTION LOGIC

When a malfunction initially occurs, Diagnostic Trouble Code (DTC) will be temporarily stored in ECM memory, but MIL on instrument panel will not illuminate. The second time that a malfunction is detected, MIL on instrument panel will illuminate, provided ignition is turned off and then back on after first malfunction was detected. This is referred to as the 2-Trip Detection Logic and only applies to specified DTCs. See DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION table under SELF-DIAGNOSTIC SYSTEM.

Note. When road testing vehicle in CHECK mode (Lexus scan tool only), the Two Trip Detection Logic will not function. Also, MIL will illuminate first time a malfunction is detected.

OBD-II regulations (SAE J-1850) standardizes Data Link Connector (DLC) configurations. On all models, DLC No. 3 connector is located under left side of instrument panel.

FREEZE-FRAME DATA

The ECM records engine operating condition when a misfire, fuel trim (mixture) malfunction or other malfunction (fuel system, calculated load, coolant temperature, fuel trim (mixture), engine speed, vehicle speed, etc.) exists. If more than one fault is detected, only data from the first malfunction is recorded. Recorded data is useful for determining conditions in which the malfunction occurs.

NORMAL Mode Code Retrieval

  1. Connect scan tool to Data Link Connector (DLC) No. 3. (Scheme 8) DLC No. 3 is located under left side of instrument panel. Turn ignition on with engine off. Turn scan tool on. Using scan tool manufacturer's instructions, check for DTCs and freeze-frame data.
  2. If scan tool displays UNABLE TO CONNECT TO VEHICLE, DLC No. 3 must be checked. See DLC NO. 3 INSPECTION under SCAN TOOL PROBLEMS. If scan tool does not display UNABLE TO CONNECT TO VEHICLE, go to next step.
  3. Record any DTCs and freeze-frame data displayed for system diagnosis. If driveability problem exists and no DTCs are present, go to «TESTS W/O CODES»(ref-22205) article for diagnosis by symptom.
  4. If any DTCs are present, perform appropriate circuit test(s) in this article. See «DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION»(ref-22204-S04545717932001010300000) table. For more information on freeze-frame data, see FREEZE-FRAME DATA under INTRODUCTION. For information on 2-trip detection logic codes, see TWO-TRIP DETECTION LOGIC under INTRODUCTION.
  5. After repairs for DTC have been completed, DTCs must be cleared from ECM memory. See «CLEARING DIAGNOSTIC TROUBLE CODES»(ref-22204-S17369188322001010300000).

Scheme 8

Scheme 8

SUMMARY

If no diagnostic trouble codes are present, driveability symptoms exist or intermittents exist, proceed to TESTS W/O CODES article for diagnosis by symptom (i.e., ROUGH IDLE, NO START, etc.) or intermittent procedures.

CIRCUIT TESTS

Note. Before performing any diagnostic circuit test, refer to SELF-DIAGNOSTICS INTRODUCTION article for diagnostic system functions and system diagnostic procedures. For component location, see appropriate illustration in the THEORY/OPERATION article.

Condition

Following conditions continue with engine speed of 900 RPM or less

  1. Closed throttle position switch in ON position.
  2. MAF sensor output is more than 2.2 volts.

DTC is set when sensor temperature is 86°F (30°C) or less for at least 20 minutes of engine operation. Possible causes are

  1. ECT sensor.
  2. Faulty cooling system.

DTC is set when ECM consistently detects more than 2 volts from VTA circuit and closed throttle position switch is on. Possible cause is

  1. TP sensor.

DTC is set when ECM detects a response time of one second or more from sensor to change from rich to lean, or lean to rich. Possible cause is

  1. Heated oxygen sensor.

DTC is set when either of the following conditions is present

  1. Sensor heater current draw exceeds 2 amps, or voltage drop of circuit exceeds 5 volts.
  2. Sensor heater current draw is .25 amp or less.

Possible causes are

  1. Heated oxygen sensor circuit open or shorted.
  2. Heated oxygen sensor heater.
  3. ECM.

DTC is set when heated oxygen sensor voltage remains at .4 volt or more, or .6 volt or less during vehicle operation (31 MPH or more), once engine is at normal operating temperature. Possible cause is

* Heated oxygen sensor malfunction.

DTCS P0301-P0308: CYLINDERS NO. 1-8 MISFIRE DETECTED

Note. When 2 or more codes for a misfiring cylinder are recorded repeatedly, but DTC P0300 is not recorded, it indicates that misfires were detected and stored into ECM memory at different times.

Two conditions can cause code to set. These are

  1. During any particular 200 revolutions of engine, misfiring is detected which can cause catalytic converter overheating and/or damage.
  2. During any particular 1000 revolutions of engine, misfiring is detected which can cause a deterioration in emission levels.

For possible causes, see DTC P0300: RANDOM MISFIRE DETECTED .

DTCS P1605: KNOCK CONTROL ECM MALFUNCTION

CAUTIONIf ECM replacement is instructed in following testing, always ensure ECM harness connector and ground circuit are okay. If either are suspect, repair and repeat testing to confirm ECM malfunction.

DTCS P1780: PARK/NEUTRAL POSITION SWITCH MALFUNCTION

CAUTIONIf ECM replacement is instructed in following testing, always ensure ECM harness connector and ground circuit are okay. If either are suspect, repair and repeat testing to confirm ECM malfunction.
  1. Short in park/neutral position switch circuit.
  2. Park/neutral position switch.
  3. ECM.
