DESCRIPTION
This DTC is stored when the steering lock ECU (steering lock actuator assembly) detects an IG2 power supply malfunction.
HINT
The steering lock ECU (steering lock actuator assembly) is not connected to the CAN communication system. However, the steering lock ECU (steering lock actuator assembly) is connected to the certification ECU (smart key ECU assembly) via LIN communication and communicates with other components via CAN communication through the certification ECU (smart key ECU assembly).
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | Note |
|---|---|---|---|---|
| B2788 | IG2 Signal Malfunction | Mismatch between the steering lock ECU (steering lock actuator assembly) IG2 input from the LIN communication system and from the direct line (1-trip detection logic (Only output while a malfunction is present and the engine switch is on (IG).)). | IGN No. 2 fuse Steering lock ECU (Steering lock actuator assembly) Harness or connector | DTC Output Confirmation Operation: No confirmation operation is necessary (monitoring is continuous). |
| Vehicle Condition when Malfunction Detected | Fail-safe Function when Malfunction Detected |
|---|---|
| The steering cannot be locked or unlocked. For this reason, the engine cannot be started. |
VEHICLE CONDITION AND FAIL-SAFE FUNCTION WHEN MALFUNCTION DETECTED
| DTC No. | Data List Item | Active Test Item |
|---|---|---|
| B2788 |
RELATED DATA LIST AND ACTIVE TEST ITEMS
Scheme 71
The certification ECU (smart key ECU assembly) has a power source mode switching function.
This DTC is stored when the IGE input (the steering lock motor activation permission signal) sent directly from the certification ECU (smart key ECU assembly) to the steering lock ECU (steering lock actuator assembly) is determined to be abnormal.
HINT
The steering lock ECU (steering lock actuator assembly) is not connected to the CAN communication system. However, the steering lock ECU (steering lock actuator assembly) is connected to the certification ECU (smart key ECU assembly) via LIN communication and communicates with other components via CAN communication through the certification ECU (smart key ECU assembly).
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | Note |
|---|---|---|---|---|
| B2782 | Power Source Control ECU Malfunction | Either of the following conditions is met (1-trip detection logic (Only output while a malfunction is present and the engine switch is on (IG).)): The steering lock motor activation command circuit has a short circuit. The steering lock motor activation command circuit has an open circuit. HINT: If the power supply signal from the LIN communication line does not match the power supply signal from the direct line, the system is determined to be malfunctioning. | Steering lock ECU (Steering lock actuator assembly) Certification ECU (Smart key ECU assembly) Harness or connector | DTC Output Confirmation Operation: Perform a steering lock/unlock operation. (The steering locks when a door is opened with the shift lever in P and the engine switch off. The steering unlocks when the engine switch is turned on (ACC) or on (IG) while carrying the key.) |
| Vehicle Condition when Malfunction Detected | Fail-safe Function when Malfunction Detected |
|---|---|
| The steering cannot be locked or unlocked. For this reason, the engine cannot be started. | Prohibits the engine from being started (the engine does not crank). |
VEHICLE CONDITION AND FAIL-SAFE FUNCTION WHEN MALFUNCTION DETECTED
| DTC No. | Data List Item | Active Test Item |
|---|---|---|
| B2782 | Smart Access Power Supply Short |
RELATED DATA LIST AND ACTIVE TEST ITEMS
Scheme 72
The steering lock ECU and steering lock motor are built into the steering lock actuator assembly.
The steering lock ECU (steering lock actuator assembly) detects whether the steering lock is in the lock or unlock position by using the lock sensor and unlock sensor of the steering lock motor.
The steering lock ECU (steering lock actuator assembly) receives lock and unlock request signals from the certification ECU (smart key ECU assembly) and responds with lock and unlock operation signals.
HINT
The steering lock ECU (steering lock actuator assembly) is not connected to the CAN communication system. However, the steering lock ECU (steering lock actuator assembly) is connected to the certification ECU (smart key ECU assembly) via LIN communication and communicates with other components via CAN communication through the certification ECU (smart key ECU assembly).
| DTC No. | Detection Item | DTC Detection Condition | Trouble Area | Note |
|---|---|---|---|---|
| B2781 | Open / Short in Steering Lock ECU | One of the following conditions is met (1-trip detection logic (Only output while a malfunction is present and the engine switch is on (IG).)): The steering lock sensor or unlock sensor is malfunctioning (When both detection switches turn on, the system is determined to be malfunctioning.). The steering lock motor activation circuit has a short circuit. The steering lock motor activation circuit has an open circuit. | Steering lock ECU (Steering lock actuator assembly) LIN communication system | DTC Output Confirmation Operation: No confirmation operation is necessary (monitoring is continuous). |
Scheme 73
| Vehicle Condition when Malfunction Detected | Fail-safe Function when Malfunction Detected |
|---|---|
| The steering cannot be locked or unlocked. For this reason, the engine cannot be started. | Prohibits the engine from being started (the engine does not crank). |
VEHICLE CONDITION AND FAIL-SAFE FUNCTION WHEN MALFUNCTION DETECTED
| DTC No. | Data List Item | Active Test Item |
|---|---|---|
| B2781 | Smart Access Sensor Value Motor Driver Short |
RELATED DATA LIST AND ACTIVE TEST ITEMS
The steering lock actuator assembly activates the steering lock motor and moves the lock bar into the steering column to lock the steering.
When the steering lock is operating, the steering may not lock when the lock bar is not aligned with the lock hole of the steering column. In this case, the steering can be locked by turning the steering wheel a little, as is done for a vehicle with a mechanical key, to change the position of the lock hole.
| Problem Symptom | Data List Item | Active Test Item |
|---|---|---|
| Steering Lock does not Lock | Smart Access Lock Request Receive S Code Check L Code Check Main Body FL Door Courtesy SW |
RELATED DATA LIST AND ACTIVE TEST ITEMS
Scheme 74
The steering lock actuator assembly activates the steering lock motor and moves the lock bar into the steering column to lock the steering.
The steering may not unlock when the lock bar gets stuck in the lock hole of the steering column. In this case, if the engine switch is turned on (IG) while shaking the steering wheel, as is done for a vehicle with a mechanical key, the lock bar will be unlocked. If the certification ECU (smart key ECU assembly), ID code box (immobilizer code ECU) or ECM is replaced, the system needs to be initialized. Otherwise, the steering cannot be unlocked and the engine cannot be started.
| Problem Symptom | Data List Item | Active Test Item |
|---|---|---|
| Unable to unlock steering wheel (Engine cannot start) | Smart Access Unlock Request Receive S Code Check L Code Check |
RELATED DATA LIST AND ACTIVE TEST ITEMS
