Steering Column (Service Information): Overview Lexus IS III

Scheme 11

*1 STEERING WHEEL ASSEMBLY N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 12

Scheme 13

Scheme 14

*A for Manual Tilt and Manual Telescopic Steering Column *B w/o VGRS *C w/ VGRS - - *1 STEERING COLUMN ASSEMBLY *2 NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY *3 BRAKE PEDAL RETURN SPRING *4 AIR DUCT SUB-ASSEMBLY *5 STEERING LOCK ACTUATOR ASSEMBLY *6 STEERING LOCK SET BOLT *7 STEERING ACTUATOR ASSEMBLY - - N*m (kgf*cm, ft.*lbf): Specified torque • Non-reusable part

Scheme 15

*A for Power Tilt and Power Telescopic Steering Column *B w/o VGRS *C w/ VGRS - - *1 STEERING COLUMN ASSEMBLY *2 NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY *3 BRAKE PEDAL RETURN SPRING *4 AIR DUCT SUB-ASSEMBLY *5 STEERING LOCK ACTUATOR ASSEMBLY *6 STEERING LOCK SET BOLT *7 MULTIPLEX TILT AND TELESCOPIC ECU *8 STEERING ACTUATOR ASSEMBLY *9 TILT STEERING GEAR WITH MOTOR ASSEMBLY - - N*m (kgf*cm, ft.*lbf): Specified torque • Non-reusable part

Scheme 16

*A for 2WD *B w/ NO. 2 ENGINE UNDER COVER *C for 2GR-FSE *D for 4GR-FSE *1 NO. 2 ENGINE UNDER COVER *2 FRONT SUSPENSION MEMBER BRACE N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 17

*A w/o VGRS *B for 2WD *C for AWD - - *1 NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY *2 STEERING SLIDING YOKE SUB-ASSEMBLY N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 18

*A w/ VGRS - - *1 STEERING ACTUATOR ASSEMBLY *2 STEERING SLIDING YOKE SUB-ASSEMBLY *3 LOWER MAIN SHAFT DUST COVER - - N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. PRECAUTION Refer to «PRECAUTION [04/2013 - ]»(ref-665699-S19414013472014102400000)
2. CUSTOMIZE POWER TILT AND POWER TELESCOPIC STEERING COLUMN SYSTEM (for Power Tilt and Power Telescopic Steering Column) Disable the auto tilt away function by changing the customize parameter. Refer to «CUSTOMIZE PARAMETERS [04/2013 - ]»(ref-665534-S06837469632014102400000) NOTE: Record the current customize parameter setting (whether the auto tilt away function is enabled or disabled) in order to restore the current setting after finishing the operation. HINT: Performing the above operation causes the auto tilt away function to be disabled when the engine switch is turned off. Turn the engine switch on (IG). Operate the tilt and telescopic switch to fully extend and lower the steering column assembly.
3. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
4. REMOVE HORN BUTTON ASSEMBLY Refer to «REMOVAL [04/2013 - ]»(ref-665530-S03839713122014102400000)
5. REMOVE STEERING WHEEL ASSEMBLY See step 3
6. REMOVE STEERING COLUMN COVER for Manual Tilt and Manual Telescopic Steering Column: Remove the 2 screws. Disengage the 2 claws. Disengage the claw and remove the steering column cover (lower). for Power Tilt and Power Telescopic Steering Column: Remove the 3 screws. Disengage the 2 claws and remove the steering column cover (lower). Disengage the 6 clips from the steering column cover (upper). Disengage the 2 claws and remove the steering column cover (upper).
7. REMOVE TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY NOTE: Do not replace the spiral cable with sensor sub-assembly with the battery connected and the engine switch on (IG). Do not rotate the spiral cable with sensor sub-assembly without the steering wheel assembly with the battery connected and the engine switch on (IG). Ensure that the steering wheel assembly is installed and aligned straight when inspecting the steering sensor. Disconnect each connector from the turn signal switch assembly with spiral cable sub-assembly. Disengage the 3 claws to remove the turn signal switch assembly with spiral cable sub-assembly from the steering column assembly.
8. REMOVE LOWER NO. 1 INSTRUMENT PANEL AIRBAG ASSEMBLY Refer to «REMOVAL [04/2013 - ]»(ref-665530-S32248839872014102400000)
9. REMOVE AIR DUCT SUB-ASSEMBLY Remove the bolt and air duct sub-assembly.
10. REMOVE STEERING COLUMN ASSEMBLY w/o VGRS: Put matchmarks on the No. 2 steering intermediate shaft assembly and steering column assembly. *a Matchmark Remove the bolt. Remove the brake pedal return spring from the steering column assembly and push rod pin. w/ VGRS: Put matchmarks on the steering actuator assembly and steering column assembly. *a Matchmark Remove the bolt. Remove the brake pedal return spring from the steering column assembly and push rod pin. Disconnect each connector and disengage each wire harness clamp from the steering column assembly. for Manual Tilt and Manual Telescopic Steering Column: Remove the 4 nuts and steering column assembly. for Power Tilt and Power Telescopic Steering Column: Remove the 4 nuts and steering column assembly. w/o VGRS: Separate the steering column assembly from the No. 2 steering intermediate shaft assembly. w/ VGRS: Separate the steering column assembly from the steering actuator assembly.
11. REMOVE FRONT SUSPENSION MEMBER BRACE (for 2WD) for 4GR-FSE: Refer to «PROCEDURE - Step 13»(ref-665703-S21356895402014102400000) for 2GR-FSE: Refer to «PROCEDURE - Step 13»(ref-665702-S20097719102014102400000)
12. REMOVE NO. 2 ENGINE UNDER COVER (for 2WD w/ No. 2 Engine Under Cover) for 4GR-FSE: Refer to «PROCEDURE - Step 14»(ref-665703-S21356895402014102400000) for 2GR-FSE: Refer to «PROCEDURE - Step 14»(ref-665702-S20097719102014102400000)
13. REMOVE FRONT WHEEL LH (for AWD)
14. REMOVE NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY (w/o VGRS) for 2WD: Loosen the clamp. Loosen the bolt (A). NOTE: Do not remove the bolt (A) Remove the bolt (B). Slide the steering sliding yoke sub-assembly and put matchmarks on the steering sliding yoke sub-assembly and the power steering link assembly. *a Matchmark Separate the steering sliding yoke sub-assembly from the power steering link assembly. Remove the steering sliding yoke sub-assembly with the No. 2 steering intermediate shaft assembly from the vehicle. for AWD: Loosen the clamp. Remove the bolt. Slide the No. 2 steering intermediate shaft assembly and put matchmarks on the No. 2 steering intermediate shaft assembly and the power steering link assembly. *a Matchmark Separate the No. 2 steering intermediate shaft assembly from the power steering link assembly. Remove the No. 2 steering intermediate shaft assembly from the vehicle.
15. REMOVE LOWER MAIN SHAFT DUST COVER (w/ VGRS) Refer to «PROCEDURE - Step 5»(ref-665820-S03699271332014102400000)
16. REMOVE STEERING ACTUATOR ASSEMBLY (w/ VGRS) Refer to «PROCEDURE - Step 6»(ref-665820-S03699271332014102400000)
17. REMOVE STEERING SLIDING YOKE SUB-ASSEMBLY (for 2WD) w/o VGRS: Put matchmarks on the steering sliding yoke sub-assembly and No. 2 steering intermediate shaft assembly. *a Matchmark Remove the bolt. Using a screwdriver, disengage the claw and remove the steering sliding yoke sub-assembly from the No. 2 steering intermediate shaft assembly. HINT: Even if the claw is broken, the No. 2 steering intermediate shaft assembly can be reused if the claw is removed. *1 Steering Sliding Yoke Sub-assembly *2 No. 2 Steering Intermediate Shaft Assembly *a Claw w/ VGRS: Put matchmarks on the steering sliding yoke sub-assembly and steering actuator assembly. *a Matchmark Remove the bolt and steering sliding yoke sub-assembly.
