Engine Control (Diagnostic Codes (P043E-U0293) & Circuit Tests): Other Lexus HS I

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

TYPICAL MALFUNCTION THRESHOLDS

MONITOR RESULT

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Scheme 81

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
7. After "Evaporative System Check" is completed, check All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All readiness.
8. Input the DTC: P043E, P043F, P2401, P2402 or P2419.
9. Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

ALL

KEY-OFF MONITOR

PURGE FLOW MONITOR

PURGE VSV STUCK OPEN

PURGE VSV STUCK CLOSED

PURGE FLOW

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Scheme 82

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
7. Start the engine and wait 15 minutes or more [B].
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes/ Pending.
9. Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
11. Input the DTC: P0441.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit NOTE: The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
13. Turn the power switch on (IG) and turn the Techstream on.
14. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
15. Turn the power switch off and wait for 30 seconds.
16. Turn the power switch on (IG) and turn the Techstream on.
17. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [D].
18. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
19. Input the DTC: P0441.
20. Check the DTC judgment result [E]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

ALL

P0451

P0452 AND P0453

P0451

P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE

P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE

Scheme 83

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Enter the following menus: Powertrain / Engine and ECT / Data List / Intake Air.
4. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
5. Turn the power switch off and wait for at least 30 seconds.
6. Turn the power switch on (IG) and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
8. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
9. Input the DTC: P0451, P0452 or P0453.
10. Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

Scheme 84

P0455, P0456

P0455: EVAP GROSS LEAK

P0456: EVAP 0.02 INCH LEAK

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Scheme 85

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
7. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
8. Input the DTC: P0455 or P0456.
9. Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

Scheme 86

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs.
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
7. Make sure that the coolant temperature is 60°C (140°F) or less [A]. HINT: If the coolant temperature is 60°C (140°F) or more, the engine may stop when idling. Make sure to keep the coolant temperature at 60°C (140°F) or less during the driving pattern.
8. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
9. Start the engine and drive the vehicle until the coolant temperature reaches 70°C (158°F) [B].
10. Stop the vehicle (0 mph (0 km/h)) [C].
11. Accelerate the vehicle to 34 to 37 mph (55 to 60 km/h) or more, and then idle the engine [D]. HINT: If the vehicle speed reaches more than 37 mph (60 km/h), the engine may stop while decelerating.
12. Stop the vehicle (0 mph (0 km/h)) [E].
13. Repeat steps [D] and [E] for 5 times or more.
14. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
15. Read the pending DTC [F]. HINT: If a pending DTC is outputs, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
16. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
17. Input the DTC: P0505.
18. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, repeat steps [D] and [E] for 5 times or more.

PROCEDURE

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0505 is output A DTC P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
2. CHECK PCV HOSE (HOSE CONNECTIONS) Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-398230-S02616932982011051600000) . OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
3. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-398230-S02616932982011051600000) . OK No leaks in the intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
4. INSPECT THROTTLE BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and the housing. Also check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 6 OK --> See step 7
5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
6. REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-398228-S35546107362011051600000)
7. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

Scheme 87

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
7. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
8. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
9. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
10. Idle the engine for 1 minute or more [B].
11. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
12. Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
14. Input the DTC: P050A.
15. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following the menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 17 A: Go to next step
2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Short FT #1 and Long FT #1. Read the values displayed on the Techstream at engine idles. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 7 OK: Go to next step
3. INSPECT THROTTLE BODY ASSEMBLY Check for deposits around the throttle valve and throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. NG --> See step 5 OK: Go to next step
4. REPLACE HYBRID VEHICLE CONTROL ECU Replace the hybrid vehicle control ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000) . NEXT --> See step 6
5. REPAIR OR REPLACE THROTTLE BODY ASSEMBLY Repair or replace the throttle body assembly. Refer to «REMOVAL»(ref-398228-S35546107362011051600000) . NEXT: Go to next step
6. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and wait 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. NEXT --> END
7. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM (BANK 1)) Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. OK Techstream Operation Engine Condition OFF Normal engine speed ON Engine idles roughly or stalls (soon after camshaft timing oil control valve assembly switched from off to on) NG --> See step 12 OK: Go to next step
8. CHECK PCV HOSE (HOSE CONNECTIONS) Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-398230-S02616932982011051600000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 13 OK: Go to next step
9. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-398230-S12813372942011051600000) . OK No leaks in the intake system. NG --> See step 14 OK: Go to next step
10. CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK Air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 15 OK: Go to next step
11. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-398228-S12654782472011051600000) . NEXT --> See step 16
12. CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT --> See step 16
13. REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 16
14. REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 16
15. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 16
16. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and wait 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. NEXT --> END
17. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)

Scheme 88

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
7. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
8. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
9. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
10. Idle the engine for 1 minute or more [B].
11. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
12. Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
14. Input the DTC: P050B.
15. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following the menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P050B is output A DTC P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 17 A: Go to next step
2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Short FT #1 and Long FT #1. Read the values displayed on the Techstream at engine idle. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 7 OK: Go to next step
3. INSPECT THROTTLE BODY ASSEMBLY Check for deposits around the throttle valve and throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. NG --> See step 5 OK: Go to next step
4. REPLACE HYBRID VEHICLE CONTROL ECU Replace the hybrid vehicle control ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000) . NEXT --> See step 6
5. REPAIR OR REPLACE THROTTLE BODY ASSEMBLY Repair or replace the throttle body assembly. Refer to «REMOVAL»(ref-398228-S35546107362011051600000) . NEXT: Go to next step
6. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and wait 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. NEXT --> END
7. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM (BANK 1)) Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. OK Techstream Operation Engine Condition OFF Normal engine speed ON Engine idles roughly or stalls (soon after camshaft timing oil control valve assembly switched from off to on) NG --> See step 12 OK: Go to next step
8. CHECK PCV HOSE (HOSE CONNECTIONS) Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION»(ref-398230-S12813372942011051600000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 13 OK: Go to next step
9. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-398230-S12813372942011051600000) . OK No leaks in the intake system. NG --> See step 14 OK: Go to next step
10. CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK Air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. NG --> See step 15 OK: Go to next step
11. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-398228-S12654782472011051600000) . NEXT --> See step 16
12. CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT --> See step 16
13. REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 16
14. REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 16
15. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 16
16. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and wait 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the power and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. NEXT --> END
17. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)

Scheme 89

Scheme 90

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Wait 5 seconds or more [A].
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0560.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

1. CHECK HARNESS AND CONNECTOR (HYBRID VEHICLE CONTROL ECU - IGCT FUSE) Disconnect the negative battery terminal. Disconnect the positive battery terminal. Remove the IGCT fuse from the engine room relay block. Disconnect the hybrid vehicle control ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition IGCT fuse (2) - A58-4 (BATT) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition IGCT fuse (2) or A58-4 (BATT) - Body ground Always 10 kohms or higher Reinstall the IGCT fuse. Reconnect the hybrid vehicle control ECU connector. Reconnect the positive battery terminal. Reconnect the negative battery terminal. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT BATTERY Check that the battery is not discharged or weak. OK Battery is not discharged or weak. NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
3. CHECK BATTERY TERMINAL Check that the battery terminals are not loose or corroded. OK Battery terminals are not loose or corroded. NG --> REPAIR OR REPLACE BATTERY TERMINAL OK: Go to next step
4. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and turn the Techstream off. Turn the power switch on (IG) and turn the Techstream on. Wait for 5 seconds. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0560 is output A DTC is not output B B --> See step 5 A --> See step 6
5. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
6. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

Scheme 91

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Wait 16 seconds or more [A].
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0604.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

1. READ OUTPUT DTC (DTC P0604) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 16 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0604 is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
3. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

Scheme 92

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Wait 16 seconds or more [A].
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0606.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

1. READ OUTPUT DTC (DTC P0606) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 16 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0606 is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
3. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

Scheme 93

1. Stop the engine for 30 minutes or more [A].
2. Connect the Techstream to the DLC3.
3. Turn the power switch on (IG) and turn the Techstream on [B].
4. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
5. Turn the power switch off and wait for at least 30 seconds.
6. Turn the power switch on (IG) and turn the Techstream on [C].
7. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
8. Start the engine, and wait 2 minutes [D].
9. Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [E].
10. Idle the engine for 1 minute [F].
11. Accelerate the vehicle to 50 mph (80 km/h) and stop the vehicle [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
12. Drive the vehicle at 35 to 50 mph (56 to 80 km/h) for 5 minutes or more [H].
13. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
14. Read the DTC [I]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
15. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
16. Input the DTC: P0607, P0136, P0137 or P0138.
17. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [I] again.

Scheme 94

1. CHECK ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to P0607 and P0136, P0137 or P0138 are output A P0607 is output B B --> See step 3 A: Go to next step
2. INSPECT DTC (P0136, P0137 OR P0138) Inspect the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-398227-S24411943702011051600000). Then proceed to "INSPECT «ON-VEHICLE INSPECTION»(ref-396927-S40171248772011051000000) HYBRID VEHICLE CONTROL ECU". If P0137 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-398227-S24411943702011051600000). Then proceed to «ON-VEHICLE INSPECTION»(ref-396927-S40171248772011051000000) "INSPECT HYBRID VEHICLE CONTROL ECU". If P0138 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-398227-S24411943702011051600000). Then proceed to «ON-VEHICLE INSPECTION»(ref-396927-S40171248772011051000000) "INSPECT HYBRID VEHICLE CONTROL ECU". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or more). NEXT --> See step 6
3. CHECK FOR EXHAUST GAS LEAK Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000). Allow the engine to idle and rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair them and proceed to 4 "PERFORM CONFIRMATION DRIVING PATTERN". If no exhaust gas leaks are present, proceed to (Scheme 94) "PERFORM CONFIRMATION DRIVING PATTERN". HINT: If no exhaust gas leaks are present, a malfunction in the heated oxygen sensor circuit is suspected. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. NEXT: Go to next step
4. PERFORM CONFIRMATION DRIVING PATTERN Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000). Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000). Start the engine. Warm up the engine until the engine coolant temperature becomes 75°C (167°F) or more. Perform the driving pattern. Accelerate the vehicle to 50 mph (80 km/h) and stop the vehicle. Drive the vehicle between 38 and 50 mph (60 and 80 km/h) for 5 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to P0607 and P0136, P0137 or P0138 are output A Only P0607 is output B No DTC is output C C --> See step 6 B --> See step 7 A: Go to next step
5. INSPECT DTC (P0136, P0137 OR P0138) Inspect the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-398227-S24411943702011051600000). Then proceed to «ON-VEHICLE INSPECTION»(ref-396927-S40171248772011051000000) "INSPECT HYBRID VEHICLE CONTROL ECU". If P0137 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-398227-S24411943702011051600000). Then proceed to «ON-VEHICLE INSPECTION»(ref-396927-S40171248772011051000000) "INSPECT HYBRID VEHICLE CONTROL ECU". If P0138 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-398227-S24411943702011051600000). Then proceed to «ON-VEHICLE INSPECTION»(ref-396927-S40171248772011051000000) "INSPECT HYBRID VEHICLE CONTROL ECU". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or more). NEXT: Go to next step
6. INSPECT HYBRID VEHICLE CONTROL ECU Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000). Stop the engine and wait for 30 minutes. Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000). Start the engine and allow it to idle for 2 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check the DTCs. Result Result Proceed to DTC is not output A P0607 is output B B --> See step 7 A --> END
7. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

Scheme 95

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Wait 16 seconds or more [A].
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P060A.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

1. READ OUTPUT DTC (DTC P060A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 16 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060A is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
3. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

Scheme 96

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Wait 16 seconds or more [A].
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P060E.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

1. READ OUTPUT DTC (DTC P060E) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 16 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060E is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
3. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

Scheme 97

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Wait 5 seconds or more [A].
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0657.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

1. READ OUTPUT DTC (DTC P0657) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Turn the power switch on (IG) for 10 seconds. Turn the power switch off. Connect the Techstream to the DLC3. Turn the power switch on (IG). Wait 16 seconds or more. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0657 is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
3. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

Scheme 98

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) [A].
4. Turn the power switch off and wait for at least 30 seconds.
5. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
6. Start the engine and idle it for 10 seconds [B].
7. Leave the power switch off for 55 minutes [C].
8. Turn the power switch on (IG) and turn the Techstream on.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
10. Read the pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P106A.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [D].

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P106A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P106A is output A DTC P106A and other DTCs are output B HINT: If any DTCs other than P106A are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
2. READ VALUE USING TECHSTREAM (VAPOR PRESSURE PUMP AND MAP) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Vapor Pressure Pump and MAP. Compare the Vapor Pressure Pump and MAP data from the Data List with day's atmospheric pressure*. HINT: *: Standard atmospheric pressure is 101 kPa-a (760 mmHg-a) at sea level. The atmospheric pressure decreases by approximately 1 kPa-g (7.5 mmHg-g) for every 100 m of elevation increase. Atmospheric pressure is also affected by weather conditions. The Atmosphere pressure listed in the Data List cannot be used as a reference for this check. If you do not know the atmospheric pressure, refer to the Vapor Pressure Pump value of other vehicles in the workshop and check the difference in pressure. Result Result Proceed to If the Vapor Pressure Pump value differs from the atmospheric pressure by 3.5 kPa-g (26.25 mmHg-g) or more A If the MAP value differs from the atmospheric pressure by 3.5 kPa-g (26.25 mmHg-g) or more B B --> See step 4 A: Go to next step
3. REPLACE CANISTER Replace the canister. Refer to «REMOVAL»(ref-398220-S02225982392011051600000) . NEXT --> See step 5
4. REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR Replace the manifold absolute pressure sensor. Refer to «REMOVAL»(ref-398220-S31851525082011051600000) . NEXT: Go to next step
5. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG) and the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / MAP and Vapor Pressure Pump. Confirm that the difference between Vapor Pressure Pump and MAP is 3.5 kPa-g (26.25 mmHg-g) or less. NEXT --> END
6. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)

ALL

P2102

P2103

P2102

P2103

Scheme 99

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
7. Start the engine.
8. With the vehicle stationary, fully depress the accelerator pedal and quickly release it [B].
9. Check that 16 seconds or more have elapsed from the instant when the accelerator pedal is first depressed.
10. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
11. Read the DTC [C]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
13. Input the DTC: P2102 or P2103.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.

FAIL-SAFE

When either of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions is stored, the hybrid vehicle control ECU enters fail-safe mode. During fail-safe mode, the hybrid vehicle control ECU cuts the current to the throttle actuator, and the throttle valve is returned to a 6.5° throttle angle by the return spring. The hybrid vehicle control ECU stops the engine and the vehicle can be driven using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the power switch is then turned off.

Scheme 100

ALL

P2111 (THROTTLE ACTUATOR STUCK OPEN)

P2112 (THROTTLE ACTUATOR STUCK CLOSED)

P2111 (THROTTLE ACTUATOR STUCK OPEN)

P2112 (THROTTLE ACTUATOR STUCK CLOSED)

Scheme 101

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
7. Start the engine and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve).
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
9. Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P2111 or P2112.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

When either of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions is stored, the hybrid vehicle control ECU enters fail-safe mode. During fail-safe mode, the hybrid vehicle control ECU cuts the current to the throttle actuator, and the throttle valve is returned to a 6.5° throttle angle by the return spring. The hybrid vehicle control ECU stops the engine and the vehicle can be driven using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the power switch is then turned off.

1. INSPECT THROTTLE BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and the housing. If necessary, clean the throttle body assembly. And check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 3 OK: Go to next step
2. CHECK WHETHER DTC OUTPUT RECURS (DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine, and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve). Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P2111 or P2112 is output B B --> See step 4 A --> See step 5
3. REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-398228-S35546107362011051600000)
4. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)
5. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)

COMPONENT OPERATING RANGE

Scheme 102

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
7. Start the engine.
8. Slowly depress the accelerator pedal, raise the engine speed to approximately 2500 rpm for approximately 5 seconds, and then idle the engine [B].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
10. Read the DTC [C]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P2118.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.

When this DTC or other DTCs relating to electronic throttle control system malfunctions are stored, the hybrid vehicle control ECU enters fail-safe mode. During fail-safe mode, the hybrid vehicle control ECU cuts the current to the throttle actuator, and the throttle valve is returned to a 6.5° throttle angle by the return spring. The hybrid vehicle control ECU stops the engine and the vehicle can be driven using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly. Fail-safe mode continues until a pass condition is detected, and the power switch is then turned off.

Scheme 103

1. READ VALUE USING TECHSTREAM (+BM VOLTAGE) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / +BM voltage. Read the value displayed on the Techstream. Standard Voltage 11 to 14 V NG --> See step 2 OK --> See step 3
2. CHECK HARNESS AND CONNECTOR (HYBRID VEHICLE CONTROL ECU - BATTERY, BODY GROUND) Disconnect the hybrid vehicle control ECU connectors. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A58-3 (+BM) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition C28-13 (ME01) - Body ground Always Below 1 ohms C28-14 (E1) - Body ground Always Below 1 ohms Reconnect the hybrid vehicle control ECU connectors. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
3. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
4. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

Scheme 104

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
7. Start the engine.
8. Idle the engine for 20 seconds.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
10. Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P2119.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, fully depress and release the accelerator pedal 3 times and then check the DTC judgment result [C].

When this DTC, as well as other DTCs relating to electronic throttle control system malfunctions is stored, the hybrid vehicle control ECU enters fail-safe mode. During fail-safe mode, the hybrid vehicle control ECU cuts the current to the throttle actuator, and the throttle valve is returned to a 6.5° throttle angle by the return spring. The hybrid vehicle control ECU stops the engine and the vehicle can be driven using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly. Fail-safe mode continues until a pass condition is detected, and the power switch is then turned off.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2119) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2119 is output A DTC P2119 and other DTCs are output B HINT: If any DTCs other than P2119 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
2. INSPECT THROTTLE BODY ASSEMBLY (RESISTANCE OF THROTTLE ACTUATOR) NG --> See step 6 OK: Go to next step
3. REPLACE HYBRID VEHICLE CONTROL ECU Replace the hybrid vehicle control ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000) . NEXT: Go to next step
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P2119) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Allow the engine to idle for 20 seconds or more. Fully depress and release the accelerator pedal 3 times quickly. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. HINT: The output voltage of the throttle position sensor can be checked using the Techstream. Variations in the output voltage indicate that the throttle actuator is in operation. To check the output voltage using the Techstream, enter the following menus: Powertrain / Engine and ECT / Data List / Throttle Position No. 1. Result Result Proceed to DTC is not output A DTC P2119 is output B B --> See step 6 A --> END
5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
6. REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-398228-S35546107362011051600000)

ALL

SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195)

SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION P2196)

SENSOR CURRENT DETECTION MONITOR (P2195, P2196)

SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195)

SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION P2196)

SENSOR CURRENT DETECTION MONITOR (HIGH SIDE MALFUNCTION P2195)

SENSOR CURRENT DETECTION MONITOR (LOW SIDE MALFUNCTION P2196)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Scheme 105

CONFIRMATION DRIVING PATTERN

HINT

This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.

Scheme 106

Scheme 107

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG).
3. Turn the Techstream on.
4. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
5. Turn the power switch off and wait for at least 30 seconds.
6. Turn the power switch on (IG) and turn the Techstream on.
7. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
8. Start the engine, and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A].
9. On the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine and ECT / Data List / All Data / Idle Fuel Cut.
10. Drive the vehicle at between 47 and 75 mph (75 and 120 km/h) for at least 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. Move the shift lever in B [C].
12. Accelerate the vehicle to 47 mph (75 km/h) or more by depressing the accelerator pedal for at least 10 seconds [D].
13. Soon after performing step [D] above, release the accelerator pedal for at least 8 seconds without depressing the brake pedal in order to execute fuel-cut control [E]. HINT: Fuel-cut is performed when the following conditions are met: Accelerator pedal is fully released. Engine speed is 1800 rpm or more (fuel injection returns at 1500 rpm).
14. Allow the vehicle to decelerate until the vehicle speed decreases to less than 6 mph (10 km/h).
15. Repeat steps [C] through [E] above at least 3 times in one driving cycle.
16. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
17. Read the pending DTC [F]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
19. Input the DTC: P2195 or P2196.
20. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [F].

P2237 AND P2238

OTHER

P2237 (AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)

P2238 (AIR FUEL RATIO SENSOR LOW IMPEDANCE)

OTHER

P2237 (AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)

P2238 (AIR FUEL RATIO SENSOR LOW IMPEDANCE)

P2238 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND GND)

P2239 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND +B)

P2252 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND GND)

P2253 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND +B)

P2238 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A-)

Scheme 108

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
7. Start the engine and wait 2 minutes.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
9. Read the pending DTC [B]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P2237, P2238, P2239, P2252 or P2253.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes and check the DTC judgment result again [C].

1. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - HYBRID VEHICLE CONTROL ECU) See step 11 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-398228-S39900601942011051600000) . NEXT: Go to next step
3. PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Drive the vehicle referring to the Confirmation Driving Pattern. NEXT: Go to next step
4. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the Pending DTCs. Result Result Proceed to DTC is not output A DTC P2237, P2238, P2239, P2252 or P2253 is output B B --> See step 5 A --> END
5. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Scheme 109

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
7. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
8. Input the DTC: P2420.
9. Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

ALL

CASE 1

CASE 2

CASE 3

CASE 1

CASE 2

CASE 3

Scheme 110

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
7. Start the engine.
8. Idle the engine for 10 minutes or more [B].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
10. Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P2610.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

1. REPLACE HYBRID VEHICLE CONTROL ECU Replace the hybrid vehicle control ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000) . NEXT: Go to next step
2. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine and wait for 10 minutes or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. If no pending DTC is displayed, the repair has been successfully completed. NEXT --> END

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

HINT

This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.

Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.

Scheme 111

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG).
3. Turn the Techstream on.
4. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
5. Turn the power switch off and wait for at least 30 seconds.
6. Turn the power switch on (IG) and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine and ECT / Monitor / O2 Sensor.
8. Check that the Status2 of O2 Sensor is Incomplete.
9. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
10. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
11. Drive the vehicle at a constant speed of between 47 and 62 mph (75 and 100 km/h) for 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
12. Those items will change to Complete after completing the drive pattern.
13. If the values indicated on the Techstream do not change, perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-398225-S06961916662011051600000) .
14. Check the monitor result values on the Techstream by entering the following menus: Powertrain / Engine and ECT / Monitor / O2 Sensor / Details / RANGE B1S1.
15. Note the value of the Monitor Result.
16. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
17. Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
19. Input the DTC: P2A00.
20. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2A00) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2A00 is output A DTC P2A00 and other DTCs are output B HINT: If any DTCs other than P2A00 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
2. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE). Refer to «PROCEDURE - Step 1»(ref-398227-S29996924012011051600000) NG --> See step 10 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - HYBRID VEHICLE CONTROL ECU) See step 11 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
5. CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC P2A00 is output A DTC is not output B B --> See step 11 A: Go to next step
6. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-398228-S39900601942011051600000) . NEXT: Go to next step
7. PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC P2A00 is output A DTC is not output B B --> END A --> See step 12
9. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
10. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-398228-S39900601942011051600000)
11. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
12. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

P3190

P3191

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P3190, P3191 AND/OR P3193) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P3190, P3191 and/or P3193 are output A DTC P3190, P3191 and/or P3193, and other DTCs are output B HINT: If any DTCs other than P3190, P3191 and P3193 are output, troubleshoot those DTCs first. B --> See step 16 A: Go to next step
2. CHECK SHORTAGE OF FUEL NG --> REFILL FUEL OK: Go to next step
3. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-398230-S12813372942011051600000) . OK No leaks in the intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
4. CHECK FOR UNUSUAL NOISE OR VIBRATION WHEN STARTING ENGINE OR REVVING UP OK Unusual noise and vibration do not occur. NG --> REPAIR OR REPLACE MALFUNCTIONING PART OK: Go to next step
5. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-398233-S24986668062011051600000) . NG --> See step 15 OK: Go to next step
6. INSPECT FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT Trouble Codes / Freeze Frame Data. Calculate the requested torque* and compare it with Actual Engine Torque. HINT: *: The requested torque is calculated by putting "Requested Engine Torque" and "HV Target Engine Speed" from the freeze frame data into the following formula: Requested torque = Requested Engine Torque (kW) / HV Target Engine Speed (rpm) x 6112 Standard Actual Engine Torque is 60% or more of the request torque. Result Result Proceed to NG A OK B B --> See step 8 A: Go to next step
7. INSPECT THROTTLE BODY ASSEMBLY Inspect the throttle body assembly. Refer to «INSPECTION»(ref-398228-S21981680632011051600000) . NG --> See step 17 OK: Go to next step
8. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Inspect the mass air flow meter sub-assembly. Refer to «INSPECTION»(ref-398228-S30049738682011051600000) . NG --> See step 18 OK: Go to next step
9. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «REMOVAL»(ref-398228-S30093668762011051600000) . NG --> See step 19 OK: Go to next step
10. INSPECT CRANKSHAFT POSITION SENSOR Inspect the crankshaft position sensor. Refer to «INSPECTION»(ref-398228-S28900959662011051600000) . NG --> See step 20 OK: Go to next step
11. INSPECT CAMSHAFT POSITION SENSOR Inspect the camshaft position sensor. Refer to «INSPECTION»(ref-398228-S22117860722011051600000) . NG --> See step 21 OK: Go to next step
12. CHECK WHETHER DTC OUTPUT RECURS (DTC P3190, P3191 OR P3193) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine. Allow the engine to idle for 10 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to P3190, P3191 or P3193 is output A DTC is not output B B --> END A: Go to next step
13. REPLACE HYBRID VEHICLE CONTROL ECU Replace the hybrid vehicle control ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000) . NEXT: Go to next step
14. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine. Allow the engine to idle for 10 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P3190, P3191 or P3193. Check the DTC judgment result. NEXT --> END
15. CHECK FUEL LINE Check the fuel lines for leaks or blockage. NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 22
16. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
17. REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-398228-S35546107362011051600000)
18. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-398228-S12654782472011051600000)
19. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-398228-S30093668762011051600000)
20. REPLACE CRANKSHAFT POSITION SENSOR. Refer to «REMOVAL»(ref-398228-S26820741352011051600000)
21. REPLACE CAMSHAFT POSITION SENSOR. Refer to «REMOVAL»(ref-398228-S19400721632011051600000)
22. REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-398229-S11139890962011051600000)

Scheme 112

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Wait 5 seconds or more [A].
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: U0001.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

Scheme 113

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (READY) and turn the Techstream on [A].
6. Drive the vehicle for 10 minutes or more [B].
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Check for DTCs [C]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: U0028 or U0037.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Wait 5 seconds or more [A].
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Check for DTCs [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: U0293.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.

1. CHECK DTC OUTPUT (IN ADDITION TO DTC U0293) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. Result Result Proceed to DTC U0293 is output A DTC U0293 and other DTCs are output B HINT: If any DTCs other than U0293 are output, troubleshoot those DTCs first. B --> See step 2 A --> See step 3
2. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
3. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

RELATED DTCS

If any EVAP system DTCs are set, the malfunctioning area can be determined using the table below.

Scheme 114

Note. If the reference pressure difference between the first and second checks is greater than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P2401, P2402 and P2419) are stored.

Scheme 115

TEXT IN ILLUSTRATION

HINT

The canister pressure sensor, the leak detection pump and the vent valve are built into the canister pump module.

Scheme 116

TEXT IN ILLUSTRATION

Note. In this vehicle's EVAP system, turning on the vent valve does not seal off the EVAP system. To check for leaks in the EVAP system, disconnect the air inlet vent hose and apply pressure from the atmospheric side of the canister.

While the engine is running, if a predetermined condition (closed-loop, etc.) is met, the purge VSV is opened by the hybrid vehicle control ECU and stored fuel vapors in the canister are purged into the intake manifold.

The purge flow volume is affected by the intake manifold pressure (vacuum). To control the purge volume, the hybrid vehicle control ECU changes the duty cycle ratio of the purge VSV based on the pressure (vacuum) in the intake manifold. The hybrid vehicle control ECU uses values received from the manifold absolute pressure sensor to monitor the pressure (vacuum) in the intake manifold.

Atmospheric pressure is allowed into the canister through the vent valve to ensure that the purge flow is maintained when negative pressure (vacuum) is applied to the canister.

The following two monitors run to confirm the appropriate EVAP system operation.

Scheme 117

Scheme 118

Scheme 119

Scheme 120

1. Key-off monitor This monitor checks for EVAP (evaporative emission) system leaks and canister pump module malfunctions. The monitor starts 5 hours* after the power switch is turned off. At least 5 hours are required for the fuel to cool down to stabilize the EVAP pressure, thus making the EVAP system monitor more accurate. The leak detection pump creates negative pressure (vacuum) in the EVAP system and the pressure is measured. Finally, the hybrid vehicle control ECU monitors for leaks from the EVAP system, and malfunctions in both the canister pump module and purge VSV based on the EVAP pressure. HINT: *: If the engine coolant temperature is not below 35°C (95°F) 5 hours after the power switch is turned off, the monitor check starts 2 hours later. If it is still not below 35°C (95°F) 7 hours after the power switch is turned off, the monitor check starts 2.5 hours later.
2. Purge flow monitor The purge flow monitor consists of the 2 monitors. The 1st monitor is conducted every time and the 2nd monitor is activated if necessary. The 1st monitor While the engine is running and the purge VSV (Vacuum Switching Valve) is on (open), the hybrid vehicle control ECU monitors the purge flow by measuring the EVAP pressure change. If negative pressure is not created, the hybrid vehicle control ECU begins the 2nd monitor. The 2nd monitor The vent valve is turned off (open) and the EVAP pressure is measured. If the variation in the pressure is less than 0.5 kPa-g (3.75 mmHg-g), the hybrid vehicle control ECU interprets this as the purge VSV being stuck closed, and illuminates the MIL and sets DTC P0441 (2 trip detection logic). Atmospheric pressure check: In order to ensure reliable malfunction detection, the variation between the atmospheric pressures, before and after the purge flow monitor, is measured by the hybrid vehicle control ECU. TEXT IN ILLUSTRATION *1 EVAP Purge Flow *2 to Intake Manifold *3 Hybrid Vehicle Control ECU *4 Soak Timer *5 Purge VSV (on) *6 Fuel Cap *7 Canister Filter *8 Fuel Tank *9 Leak Detection Pump (off) *10 Canister Pressure Sensor *11 Reference Orifice (0.02 inch) *12 Vent Valve (off) *13 Canister Pump Module *14 Canister Component Operation Canister Contains activated charcoal to absorb EVAP (evaporative emissions) generated in fuel tank. Cut-off valve Located in fuel tank. Valve floats and closes when fuel tank is 100% full. Purge VSV (Vacuum Switching Valve) Opens or closes line between canister and intake manifold. The hybrid vehicle control ECU uses purge VSV to control EVAP purge flow. In order to discharge EVAP absorbed by canister to intake manifold, hybrid vehicle control ECU opens purge VSV. EVAP discharge volume to intake manifold is controlled by purge VSV duty cycle (current-carrying time) (Open: on; Closed: off). Manifold absolute pressure sensor Measures the pressure (vacuum) of the intake manifold. The hybrid vehicle control ECU changes the duty cycle ratio of the purge VSV based on measured values to control the purge flow volume. Soak timer Built into hybrid vehicle control ECU. To ensure accurate EVAP monitor, it measures 5 hours (+/-15 min) after power switch is turned off. This allows fuel to cool down, stabilizing EVAP pressure. When approximately 5 hours elapsed, hybrid vehicle control ECU activates (Scheme 81) Canister pump module Consists of (a) to (d) below. Canister pump module cannot be disassembled. (a) Vent valve Vents and closes EVAP system. When hybrid vehicle control ECU turns valve on, EVAP system is closed. When hybrid vehicle control ECU turns valve off, EVAP system is vented. Negative pressure (vacuum) is created in EVAP system to check for EVAP leaks by closing purge VSV, turning on vent valve (closing it) and operating leak detection pump see scheme 1 (b) Canister pressure sensor Indicates pressure as voltage. Hybrid vehicle control ECU supplies regulated 5 V to canister pressure sensor, and uses feedback from sensor to monitor EVAP system pressure see scheme 2 (c) Leak detection pump Creates negative pressure (vacuum) in EVAP system for leak check. (d) Reference orifice Has opening with 0.02 inch diameter. Vacuum is produced through orifice by closing purge VSV, turning off vent valve and operating leak detection pump to monitor reference pressure. Reference pressure indicates small leak of EVAP.

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

HINT

After a repair, check Monitor Status by performing the Key-off Monitor Confirmation and Purge Flow Monitor Confirmation described below.

1. KEY-OFF MONITOR CONFIRMATION Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The fuel tank is less than 90% full. The altitude is less than 7875 ft. (2400 m). The engine coolant temperature is between 4.4°C and 35°C (40°F and 95°F). The intake air temperature is between 4.4°C and 35°C (40°F and 95°F). The vehicle remains stationary (the vehicle speed is 0 mph [0 km/h]). Monitor Conditions Allow the engine to idle for at least 5 minutes. Turn the power switch off and wait for 6 hours (8 or 10.5 hours). HINT: Do not start the engine until the Monitor Status has been checked. If the engine is started, the steps described above must be repeated. Monitor Status Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Monitor / Evaporative System. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor did not complete. Make sure that the preconditions have been met, and perform the Monitor Conditions again.
2. PURGE FLOW MONITOR CONFIRMATION (P0441) HINT: Perform this monitor confirmation after the Key-off Monitor Confirmation shows Complete. Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The engine coolant temperature is between 4.4°C and 35°C (40°F and 95°F). The intake air temperature is between 4.4°C and 35°C (40°F and 95°F). Monitor Conditions Release the pressure from the fuel tank by removing and reinstalling the fuel cap. Warm the engine up until the engine coolant temperature reaches more than 75°C (167°F). Increase the engine speed to 3000 rpm once. Allow the engine to idle and turn the the A/C switch on for 1 minute. Monitor Status Turn the power switch off (if on (IG) or if the engine is running). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Monitor / Evaporative System. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor did not complete. Make sure that the preconditions have been met, and perform the Monitor Conditions again.

1. CHECK MIL Check that the Malfunction Indicator Lamp (MIL) illuminates when turning the power switch on (IG). OK MIL lights up. NG --> See step 2 OK --> See step 9
2. CHECK CONNECTION BETWEEN TECHSTREAM AND HYBRID VEHICLE CONTROL ECU Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Check the communication between the Techstream and hybrid vehicle control ECU. Result Result Proceed to Communication is not possible A Communication is possible B B --> See step 10 A: Go to next step
3. CHECK MIL (THROTTLE POSITION SENSOR) Disconnect the throttle position sensor connector. Turn the power switch on (IG). Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B Reconnect the throttle position sensor connector. B --> See step 11 A: Go to next step
4. CHECK MIL (MANIFOLD ABSOLUTE PRESSURE SENSOR) Disconnect the manifold absolute pressure sensor connector. Turn the power switch on (IG). Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B Reconnect the manifold absolute pressure sensor connector. B --> See step 12 A: Go to next step
5. CHECK MIL (CANISTER PUMP MODULE) Disconnect the canister pump module connector. Turn the power switch on (IG). Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B Reconnect the canister pump module connector. B --> See step 13 A: Go to next step
6. CHECK HARNESS AND CONNECTOR (THROTTLE POSITION SENSOR - HYBRID VEHICLE CONTROL ECU) Disconnect the throttle position sensor connector. Disconnect the hybrid vehicle control ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Short) Tester Connection Condition Specified Condition C28-71 (VCTA) or C3-5 (VC) - Body ground Always 10 kohms or higher Reconnect the throttle position sensor connector. Reconnect the hybrid vehicle control ECU connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. CHECK HARNESS AND CONNECTOR (MANIFOLD ABSOLUTE PRESSURE SENSOR - HYBRID ECU) Disconnect the manifold absolute pressure sensor connector. Disconnect the hybrid vehicle control ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Short) Tester Connection Condition Specified Condition C13-3 (VC) or A58-65 (VCPM) - Body ground Always 10 kohms or higher Reconnect the manifold absolute pressure sensor connector. Reconnect the hybrid vehicle control ECU connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
8. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - HYBRID VEHICLE CONTROL ECU) Disconnect the canister pump module connector. Disconnect the hybrid vehicle control ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Short) Tester Connection Condition Specified Condition O2-6 (VCC) or A58-64 (VCPP) - Body ground Always 10 kohms or higher Reconnect the canister pump module connector. Reconnect the hybrid vehicle control ECU connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 14
9. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-398225-S28102712272011051600000)
10. GO TO MIL CIRCUIT. Refer to «MIL Circuit»(ref-398226-S22188282202011051600000)
11. REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-398228-S35546107362011051600000)
12. REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR. Refer to «REMOVAL»(ref-398220-S31851525082011051600000)
13. REPLACE CANISTER. Refer to «REMOVAL»(ref-398220-S02225982392011051600000)
14. REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)

1. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE C/OPN RELAY) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Fuel Pump / Speed. Check whether the fuel pump operation sound occurs when performing the Active Test on the Techstream. OK Fuel pump operating sound occurs. NG --> See step 2 OK --> See step 9
2. INSPECT INTEGRATION RELAY (C/OPN, EFI MAIN AND IG2 RELAY) Inspect the C/OPN relay, EFI MAIN relay and IG2 relay. Refer to «INSPECTION»(ref-398228-S24128564672011051600000) . NG --> See step 10 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (C/OPN RELAY - HYBRID VEHICLE CONTROL ECU) Disconnect the hybrid vehicle control ECU connector. Remove the integration relay from the engine room relay block. Disconnect the integration relay connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1B-7 - A58-94 (FC) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1B-7 or A58-94 (FC) - Body ground Always 10 kohms or higher Reconnect the hybrid vehicle control ECU connector. Reconnect the integration relay connector. Reinstall the integration relay. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (IG2 RELAY - IGN FUSE - C/OPN RELAY) Remove the integration relay from the engine room relay block. Disconnect the integration relay connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1A-4 - 1B-6 Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1A-4 or 1B-6 - Body ground Always 10 kohms or higher Reconnect the integration relay connector. Reinstall the integration relay. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (C/OPN RELAY - FUEL PUMP) Disconnect the fuel pump connector. Remove the integration relay from the engine room relay block. Disconnect the integration relay connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1B-8 - L13-4 Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1B-8 or L13-4 - Body ground Always 10 kohms or higher Reconnect the fuel pump connector. Reconnect the integration relay connector. Reinstall the integration relay. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (FUEL PUMP - BODY GROUND) Disconnect the fuel pump connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition L13-5 - Body ground Always Below 1 ohms Reconnect the fuel pump connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. INSPECT FUEL PUMP Inspect the fuel pump assembly. Refer to «INSPECTION»(ref-398229-S12513094102011051600000) . NG --> See step 11 OK: Go to next step
8. CHECK HARNESS AND CONNECTOR (EFI MAIN RELAY - IGCT RELAY) Remove the integration relay from the engine room relay block. Disconnect the integration relay connector. Remove the IGCT relay from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1B-2 - IGCT relay terminal 5 Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1B-2 or IGCT relay terminal 5 - Body ground Always 10 kohms or higher Reconnect the integration relay connector. Reinstall the relay. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 12
9. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-398225-S28102712272011051600000)
10. REPLACE INTEGRATION RELAY (C/OPN, EFI MAIN AND IG2 RELAY). Refer to «REMOVAL»(ref-398228-S32500819222011051600000)
11. REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-398229-S11139890962011051600000)
12. CHECK ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit»(ref-398226-S37492599822011051600000)
