MONITOR STRATEGY
| Related DTCs | P0010: Camshaft timing oil control valve range check (bank 1) |
| Required Sensors/Components (Main) | Camshaft timing oil control valve assembly |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediately |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | A, B, C and D |
| Starter | OFF |
| Power switch | On (IG) |
| Time after power switch off to on (IG) | 0.5 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS
| One of the following conditions is met | Condition A, B, or C |
| A. All of the following conditions are met | A, b and c |
| A. Battery voltage | 11 V or more, and less than 13 V |
| B. Target duty ratio | Less than 70% |
| C. Output signal duty ratio | 100% or more |
| B. All of the following conditions are met | D, e and f |
| D. Battery voltage | 13 V or more |
| E. Target duty ratio | Less than 80% |
| F. Output signal duty ratio | 100% or more |
| C. Both of the following conditions are met | G and h |
| G. Current cut states | Not cut |
| H. Output signal duty ratio | 3% or less |
COMPONENT OPERATING RANGE
| VVT oil control valve condition | Operation record |
Scheme 171
Scheme 171: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 5 seconds [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTCs. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0010.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
Scheme 172
Scheme 172: WIRING DIAGRAM
| Related DTCs | P0011: Advanced camshaft timing P0012: Retarded camshaft timing |
| Required Sensors/Components (Main) | Camshaft timing oil control valve and VVT controller |
| Required Sensors/Components (Related) | Crankshaft position sensor Camshaft position sensor Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 10 seconds |
| MIL Operation | Advanced camshaft timing: Immediately Retarded camshaft timing: 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010 (Camshaft timing oil control valve assembly Bank 1) P0016 (VVT System Bank 1 - Misalignment) P0102, P0103 (Mass Air Flow Meter sub-assembly) P0107, P0108 (Manifold Absolute Pressure) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Battery voltage | 11 V or more |
| Engine RPM | 800 to 4000 rpm |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| All of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (crankshaft angle) |
| Valve timing | No change at advanced valve timing |
| All of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (crankshaft angle) |
| Valve timing | No change at retarded valve timing |
If the difference between the target and actual camshaft timing is greater than the specified value, the hybrid vehicle control ECU operates the VVT actuator (camshaft timing oil control valve assembly).
Then, the hybrid vehicle control ECU monitors the camshaft timing change for 10 seconds.
MONITOR RESULT
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 173
Scheme 173: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . HINT: P0011 is output: Clear the DTC without using the Techstream. P0012 is output: Clear the DTC with using the Techstream.
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
- Accelerate the vehicle to 47 mph (75 km/h) or more for 10 seconds or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 30 seconds or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [E]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0011 or P0012.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Accelerate the vehicle to 47 mph (75 km/h) or more for 10 seconds or more [F].
- Idle the engine for 30 seconds or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0011 or P0012.
- Check the DTC judgment result again [H]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
| Related DTCs | P0016: Camshaft Timing Misalignment at idling |
| Required Sensors/Components (Main) | VVT actuator |
| Required Sensors/Components (Related) | Camshaft position sensor Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010 (VVT Oil Control Valve Bank 1) P0102, P0103 (Mass Air Flow Meter Sub-assembly) P0107, P0108 (Manifold Absolute Pressure) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Engine RPM | 800 to 1000 rpm |
| One of the following conditions is met | |
| VVT learning value at maximum retarded valve timing | Less than 27.8°CA (crankshaft angle) |
| VVT learning value at maximum retarded valve timing | More than 48°CA (crankshaft angle) |
Scheme 174
Scheme 174: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0016.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle at 47 mph (75 km/h) for 2 to 3 minutes [E].
- Idle the engine for 5 minutes or more [F].
- Check the DTC judgment result [G]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
PROCEDURE
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0016 is output A DTC P0016 and other DTCs are output B HINT: If any DTCs other than P0016 are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE) See step 2 NG --> See step 5 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0016) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0016 is output B B --> See step 5 A --> See step 4
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY See step 2 NG --> See step 11 OK: Go to next step
- CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) See step 6 NG --> See step 12 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER See step 7 NG --> See step 13 OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly. Refer to «REMOVAL»(ref-398215-S26066177622011051600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0016) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0016 is output B B --> See step 14 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-398228-S42274326952011051600000)
- ADJUST VALVE TIMING. Refer to «REMOVAL»(ref-398215-S26066177622011051600000)
- REPLACE OIL CONTROL VALVE FILTER. Refer to «DISASSEMBLY - Step 40»(ref-398215-S22599542442011051600000)
- REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)
| Related DTCs | P0031: Air fuel ratio sensor heater open/short (Low electrical current) P0032: Air fuel ratio sensor heater open/short (High electrical current) P101D: Air fuel ratio sensor heater performance |
| Required Sensors/Components (Main) | Air fuel ratio sensor heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 10 seconds: P0031 10.24 seconds: P0032 1 second: P101D |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 10 seconds or more |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Heater output duty | 50% or more |
| Battery voltage | 10.5 V or more |
| Time after engine start | 10 seconds or more |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Heater output duty | More than 0% |
| Battery voltage | 10.5 V or more |
| Time after engine start | 10 seconds or more |
| Air fuel ratio sensor heater duty-cycle ratio | 10 to 60% |
| Air fuel ratio sensor heater ON current | 0.8 A or more |
| Air fuel ratio sensor heater range check low current fail (P0031) | Not detected |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Air fuel ratio sensor heater ON current | Less than 0.8 A |
| Air fuel ratio sensor heater output | ON |
| Hybrid IC high current limiter monitor input | Fail |
| Air fuel ratio sensor heater OFF current | More than 11 A |
| Active heater OFF control flag for ON stuck | ON |
| Hybrid IC high current limiter monitor input | Fail |
| Air fuel ratio sensor heater ON current | 0.8 A or more |
| All of the following conditions are met | |
| 1. Air fuel ratio sensor heater output | ON |
| 2. Hybrid IC high current limiter monitor input | Pass |
| Air fuel ratio sensor heater OFF current | 11 A or less |
Scheme 175
Scheme 175: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 2500 rpm for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [E]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0031, P0032, or P101D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] through [E] again.
Scheme 176
Scheme 176: WIRING DIAGRAM
| Related DTCs | P0037: Heated oxygen sensor heater open/short (Low electrical current) P0038: Heated oxygen sensor heater open/short (High electrical current) P0141: Heated oxygen sensor heater performance P102D: Heated oxygen sensor heater ON stuck |
| Required sensors/Components (Main) | Heated oxygen sensor heater |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous: P0037, P0038, P102D Once per driving cycle: P0141 |
| Duration | 0.5 seconds: P0037, P102D 2.064 seconds: P0038 10 seconds: P0141 |
| MIL operation | Immediately: P0037, P0038, P102D 2 driving cycles: P0141 |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation completed flag | ON |
| Learned heater OFF current get flag | ON |
| Heated oxygen sensor heater high current fail (P0038) | Not detected |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation completed flag | ON |
| Heated oxygen sensor heater OFF current | More than 3.5 A |
| Hybrid IC high current limiter monitor input | Fail |
| Heated oxygen sensor heater high current fail (P0038) | Not detected |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation completed flag | ON |
| Heated oxygen sensor heater circuit fail (P0037 and P0038) | Not detected |
| Battery voltage | 10.5 V or more |
| Fuel cut | OFF |
| Time after fuel cut ON to OFF | 30 seconds or more |
| Accumulated heater ON time | 100 seconds or more |
| Learned heater OFF current operation completed flag | ON |
| Duration that rear heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation completed flag | ON |
| Heated oxygen sensor heater OFF current | More than 3.5 A |
| Hybrid IC high current limiter monitor input | Fail |
| Heated oxygen sensor heater high current fail (P0038) | Not detected |
| Heater ON current - Learned heater OFF current | 0.3 A or less |
| Heated oxygen sensor heater ON current | 1 A or less |
| Hybrid IC high current limiter monitor input | Fail |
| Heated oxygen sensor heater output | ON |
| Accumulated heater resistance | Varies with sensor element temperature (Example: Higher than 23 ohms) |
| Heated oxygen sensor heater ON current | Higher than 1 A |
| Heated oxygen sensor heater current | 0.4 to 1 A (when engine idles, heated oxygen sensor warmed up and battery voltage 11 to 14 V) |
- Refer to Checking Monitor Status. Refer to «CHECKING MONITOR STATUS»(ref-398225-S00584894102011051600000) .
Scheme 177
Scheme 177: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 2500 rpm for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [E]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0141 or P102D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] through [E] again.
Scheme 178
Scheme 178: WIRING DIAGRAM
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors/Components (Main) | Mass air flow meter sub-assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor, engine coolant temperature sensor and throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 times |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Throttle position (Throttle position sensor voltage) | 0.2 to 2 V |
| Time after engine start | 5 seconds or more |
| Battery voltage | 10.5 V or more |
| Engine coolant temperature | 70°C (158°F) or more |
| Mass air flow sensor circuit fail (P0102, P0103) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Crankshaft position sensor circuit fail (P0335, P0337, P0338) | Not detected |
| Throttle position sensor circuit fail (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| Canister pressure sensor circuit fail (P0452, P0453) | Not detected |
| EVAP leak detection pump fail (P2401, P2402) | Not detected |
| EVAP vent valve fail (P2419, P2420) | Not detected |
| Both of the following conditions 1 and 2 are met | |
| 1. Averaged engine load value ratio | Less than 0.85, or more than 1.33 (varies with estimated engine load) |
| 2. Averaged air fuel ratio | Less than -20%, or more than 20% |
Scheme 179
Scheme 179: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG).
- Turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or more [A].
- Drive the vehicle at approximately 50 mph (80 km/h) to 70 mph (112 km/h) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTCs [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0101.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-398230-S02616932982011051600000) . OK No leaks from the intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-398228-S12654782472011051600000)
| Related DTCs | P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage) |
| Required Sensors/Components (Main) | Mass air flow meter sub-assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor Throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediately: Engine speed less than 4000 rpm 2 driving cycles: Engine speed 4000 rpm or more |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Mass air flow meter voltage | Less than 0.2 V |
| Mass air flow meter voltage | More than 4.9 V |
| Mass air flow meter voltage | Between 0.2 V and 4.9 V |
Scheme 180
Scheme 180: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [C]. HINT: If a pending DTC is outputs, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
Scheme 181
Scheme 181: WIRING DIAGRAM
| Related DTCs | P0106: Manifold absolute pressure sensor stuck |
| Required Sensor/Components (Main) | Manifold absolute pressure sensor |
| Required Sensor/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 6 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010 (Camshaft timing oil control valve assembly Bank 1) P0011 (VVT System Bank 1 - Advance) P0012 (VVT System Bank 1 - Retard) P0016 (VVT System Bank 1 - Misalignment) P0107, P0108 (Manifold Absolute Pressure) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P106A (Evaporative Emission Control System Pressure Sensor - Manifold Pressure Sensor Correlation) |
| Battery voltage | 10.5 V or more |
| Engine coolant temperature | 10°C (50°F) or more |
| Intake air temperature | 10°C (50°F) or more |
| Engine speed | 1000 rpm or more |
| Throttle position | Less than 2° |
| Atmospheric pressure | 76 kPa-a (570 mmHg-a) or more |
| Difference between manifold absolute pressure sensor and atmospheric pressure | More than -3 kPa (-22.5 mmHg) |
| Difference between manifold absolute pressure sensor and atmospheric pressure | 3 kPa (-22.5 mmHg) or less |
Scheme 182
Scheme 182: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [B].
- Move the shift lever to N.
- Idle the engine for 10 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read Pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0106.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [D] again.
- CHECK ANY OTHER DTC OUTPUT (IN ADDITION TO P0106) Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0106 is output A DTC P0106 and other DTCs are output B HINT: If any DTCs other than P0106 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
- READ VALUE USING TECHSTREAM (MANIFOLD ABSOLUTE PRESSURE SENSOR) Connect the Techstream to the DLC3. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Turn the Techstream on. Start the engine and warm it up. Enter the following menus: Powertrain / Engine and ECT / Data List / MAP. Read the MAP value at engine idling. Standard Engine Condition Techstream Display Power switch on (IG) 80 to 110 kPa-a (600 to 825 mmHg-a) Idling 20 to 40 kPa-a (150 to 300 mmHg-a) NG --> See step 3 OK --> See step 5
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-398230-S02616932982011051600000) . OK No leaks in the intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK --> See step 4
- REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR. Refer to «REMOVAL»(ref-398220-S31851525082011051600000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
| Related DTCs | P0107: Manifold absolute pressure sensor range check (Low voltage) P0108: Manifold absolute pressure sensor range check (High voltage) |
| Required Sensor/Components (Main) | Manifold absolute pressure sensor |
| Required Sensor/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Starter | Off |
| Time after starter on to off | 2 seconds or more |
| Manifold absolute pressure sensor voltage | Less than 0.5 V |
| Manifold absolute pressure sensor voltage | More than 4.5 V |
| Manifold absolute pressure sensor voltage | 0.5 V or more, and 4.5 V or less |
Scheme 183
Scheme 183: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [C]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0107 or P0108.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
Scheme 184
Scheme 184: WIRING DIAGRAM
| Related DTCs | P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 5 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or more |
| Intake air temperature circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Accumulated mass air flow amount before engine stop | 2440 g or more |
| Key-off duration | 30 minutes |
| Engine coolant temperature when 30 minutes elapsed after engine stop | 40°C (-40°F) or more |
| Key-off duration | 5 hours |
| Time after engine start | 10 seconds or more |
| Intake air temperature circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Engine coolant temperature | 70°C (158°F) or more |
| Accumulated mass air flow amount | 2440 g or more |
| Either of the following conditions 1 or 2 is met | |
| 1. Duration while engine load is low | 120 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| Intake air temperature change | Less than 1°C (1.8°F) |
| Intake air temperature change | Less than 0°C (0°F) |
Scheme 185
Scheme 185: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is below 1°C (1.8°F), the intake air temperature sensor (mass air flow meter sub-assembly) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [D]. HINT: If a pending DTC is outputs, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
- Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [E].
- Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F] again.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-398228-S12654782472011051600000)
| Related DTCs | P0112: Intake air temperature sensor range check (Low voltage) P0113: Intake air temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 8 V or more |
| Power switch | On (IG) |
| Intake air temperature sensor voltage | Less than 0.18 V |
| Intake air temperature sensor voltage | More than 4.91 V |
| Intake air temperature sensor voltage | 0.18 to 4.91 V |
Scheme 186
Scheme 186: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 0.5 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
Scheme 187
Scheme 187: WIRING DIAGRAM
| Related DTCs | P0115: Engine coolant temperature sensor range check (Chattering) P0117: Engine coolant temperature sensor range check (Low voltage) P0118: Engine coolant temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Engine coolant temperature sensor voltage | Less than 0.14 V, or more than 4.91 V |
| Engine coolant temperature sensor voltage | Less than 0.14 V |
| Engine coolant temperature sensor voltage | More than 4.91 V |
| Engine coolant temperature sensor voltage | 0.14 to 4.91 V |
Scheme 188
Scheme 188: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 0.5 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
Scheme 189
Scheme 189: WIRING DIAGRAM
| Related DTCs | P0116: Engine coolant temperature sensor cold start monitor P0116: Engine coolant temperature sensor soak monitor |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Once per driving cycle |
| Duration | 5 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 1 second or more |
| Engine coolant temperature at engine start | Less than 60°C (140°F) |
| Engine coolant temperature circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Soak time | 0 second or more |
| Accumulated mass air flow | 828 g or more |
| Fuel cut | OFF |
| Difference between engine coolant temperature at engine start and intake air temperature | Less than 40°C (72°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Engine coolant temperature circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Intake air temperature circuit fail (P0112, P0113) | Not detected |
| Soak time | 5 hours or more |
| Either of the following condition (a) or (b) is met | |
| (a) Engine coolant temperature | 60°C (140°F) or more |
| (b) Accumulated mass air flow | 1483 g or more |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature sensor value change | Less than 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Difference between current engine coolant temperature sensor value and previous engine coolant temperature sensor value when engine stopped | Less than 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
Scheme 190
Scheme 190: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
- Check that the engine coolant temperature is 60°C (140°F) or less.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or higher, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E].
- Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [D]. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E] again.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs other than P0116 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-398217-S20197114652011051600000) . Measure the valve opening temperature of the thermostat. Standard value 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-398217-S18552336912011051600000) . NG --> See step 4 OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-398217-S20197114652011051600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-398228-S30093668762011051600000)
| Related DTCs | P011B: Engine coolant temperature / Intake air temperature sensor correlation |
| Required Sensors/Components (Main) | Engine coolant temperature sensor Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 7 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | |
| Soak time | 7 hours or more |
| Battery voltage | 10.5 V or more |
| Time after engine start | 15 second or more |
| Either of the following conditions is met | (a) or (b) |
| (a) Minimum intake air temperature after engine start | 10°C (14°F) or more |
| (b) Engine coolant temperature before engine start | 10°C (14°F) or more |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Deviated engine coolant temperature and intake air temperature | Less than -20°C (-36°F) or more than 20°C (36°F) |
Scheme 191
Scheme 191: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) [A].
- Turn the power switch off.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [D] again.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Intake Air. Read the value displayed on the Techstream. OK The difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMPERATURE) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Coolant Temp. Read the value displayed on the Techstream. OK The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check if there are heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-398228-S12654782472011051600000)
- REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-398228-S30093668762011051600000)
| Related DTCs | P0120: Throttle position sensor 1 range check (Chattering) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (Chattering) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation) |
| Required Sensors/Components (Main) | Throttle position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 Within 2 seconds: P0121 0.5 seconds: P2135 Case 1 0.4 seconds: P2135 Case 2 |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Either of the following conditions A or B is met | |
| Power switch on (IG) | 0.012 seconds or more |
| B. Electronic throttle actuator power | ON |
P0120, P0122, P0123, P0220, P0222, P0223, P2135
| Monitor runs whenever following DTCs are not present | None |
| Either of the following conditions A or B is set | |
| A. Power switch | On (IG) |
| B. Electric throttle motor power | ON |
| Throttle position sensor malfunction (P0120, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| VTA voltage | 0.2 V or less, or 4.54 V or more |
| Either of the following conditions is set | |
| Difference of throttle position sensor voltage between VTA and (VTA2 x 0.8) | Higher than 1.6 V |
| Difference of throttle position sensor voltage between VTA and (VTA2 x 0.8) | Lower than 0.8 V |
| VTA voltage | 4.54 V or more |
| Either of the following conditions is met | A or B |
| A. VTA2 voltage | 1.75 V or less |
| B. All of the following conditions are met | (a) and (b) |
| (a) VTA2 voltage | 4.8 V or more |
| (b) VTA voltage | 0.2 V or more, and 2.02 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA 0.2 V or more, and 2.02 V or less | 4.8 V or more |
| Difference between VTA and VTA2 voltages | 0.02 V or less |
| VTA voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA voltage | 0.2 to 4.54 V |
| VTA2 voltage | 1.75 to 4.8 V |
Scheme 192
Scheme 192: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [D]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
FAIL-SAFE
When any of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions, are set, the hybrid vehicle control ECU enters fail-safe mode. During fail-safe mode, the hybrid vehicle control ECU cuts the current to the throttle actuator, and the throttle valve is returned to a 6.5° throttle angle by the return spring. The hybrid vehicle control ECU stops the engine and the vehicle can be driven using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the power switch is then turned off.
Scheme 193
Scheme 193: WIRING DIAGRAM
| Related DTCs | P0125: Insufficient engine coolant temperature for closed-loop fuel control |
| Required Sensors/Components (Main) | Engine coolant temperature sensor Thermostat Cooling system |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 59 seconds: Engine coolant temperature at engine start -3.33°C (-6°F) or more 107 seconds: Engine coolant temperature at engine start -14.44 to -3.33°C (-25 to -6°F) 1200 seconds: Engine coolant temperature at engine start less than -14.44°C (-25°F) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Thermostat fail (P0128) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Time until actual engine coolant temperature reaches closed-loop fuel control enabling temperature | 59 seconds: Engine coolant temperature at engine start -3.33°C (-6°F) or more 107 seconds: Engine coolant temperature at engine start -14.44 to -3.33°C (-25 to -6°F) 1200 seconds: Engine coolant temperature at engine start less than -14.44°C (-25°F) |
Scheme 194
Scheme 194: CONFIRMATION DRIVING PATTERN
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the engine coolant temperature is 5°C (41°F) or less.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine.
- After starting the engine, wait 21 minutes or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-398217-S20197114652011051600000) . Check the valve opening temperature of the thermostat. Standard value 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-398217-S18552336912011051600000) . NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-398217-S20197114652011051600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-398228-S30093668762011051600000)
| Related DTCs | P0128: Coolant Thermostat |
| Required Sensors/Components (Main) | Thermostat Engine coolant temperature sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 900 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010 (VVT Oil Control Valve Bank 1) P0011 (VVT System Bank 1 - Advance) P0012 (VVT System Bank 1 - Retard) P0016 (VVT System Bank 1 - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater - Sensor 1) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351, P0352, P0353, P0354 (Igniter) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor - Sensor 1) |
| Battery voltage | 11 V or more |
| Either of the following conditions 1 or 2 is met | |
| 1. All of following conditions are met | (a), (b) and (c) |
| (a) Engine coolant temperature at engine start - Intake air temperature at engine start | 15 to 7°C (-27 to 12.6°F) |
| (b) Engine coolant temperature at engine start | 10 to 56°C (14 to 133°F) |
| (c) Intake air temperature at engine start | 10 to 56°C (14 to 133°F) |
| 2. All of the following conditions are met | (d), (e) and (f) |
| (d) Engine coolant temperature at engine start - Intake air temperature at engine start | More than 7°C (12.6°F) |
| (e) Engine coolant temperature at engine start | 56°C (133°F) or less |
| (f) Intake air temperature at engine start | 10°C (14°F) or more |
| Accumulated time at 80 mph (128 km/h) or more | Less than 20 seconds |
| Duration that both of the following conditions (a) and (b) are met | 5 seconds or more |
| (a) Estimated engine coolant temperature | 75°C (167°F) or more |
| (b) Engine coolant temperature sensor output | Less than 75°C (167°F) |
Scheme 195
Scheme 195: CONFIRMATION DRIVING PATTERN
- Stop the engine and allow it to cool down.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on. [A]
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp and Intake Air.
- Check if "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Set the heater to the maximum hot setting with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle at 50 mph (80 km/h) for 15 minutes. [B] WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point. For example, setting the target point to an engine speed of 2500 rpm and then racing the engine, etc. to raise the engine speed to a speed of 2500 rpm or more will cause data capture to start.
- After driving the vehicle at 50 mph (80 km/h) and "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (67°F) or higher. [C]
If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 50 mph (80 km/h), inspect the cooling system and thermostat.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-398217-S20197114652011051600000) . Measure the valve opening temperature of the thermostat. Standard value 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-398217-S18552336912011051600000) . NG --> See step 5 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-398217-S20197114652011051600000)
- REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)
| Related DTCs | P0136: Heated Oxygen Sensor Output Voltage (Output Voltage) P0136: Heated Oxygen Sensor Impedance (Low) P0137: Heated Oxygen Sensor Output Voltage (Low Voltage) P0137: Heated Oxygen Sensor Impedance (High) P0138: Heated Oxygen Sensor Output Voltage (High Voltage) P0138: Heated Oxygen Sensor Output Voltage (Extremely High) P0139: Heated Oxygen Sensor Output Voltage During Fuel Cut |
| Required Sensors/Components (Main) | Heated oxygen sensor (bank 1 sensor 2) |
| Required Sensors/Components (Related) | Crankshaft position sensor Engine coolant temperature sensor Mass air flow meter Throttle position sensor |
| Frequency of Operation | Once per driving cycle: Active air fuel ratio control detection, Heated oxygen sensor voltage during fuel-cut Continuous: Other |
| Duration | 20 seconds: Heated oxygen sensor output (Output voltage, High voltage, Low voltage) 30 seconds: Heated oxygen sensor impedance (Low) 60 seconds: Heated oxygen sensor impedance (High) 10 seconds: Heated oxygen sensor voltage (Extremely high) 6 seconds: Heated oxygen sensor voltage during fuel cut |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016 (VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0037, P0038, P102D (Heated Oxygen Sensor Heater) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0451, P0452, P0453 (EVAP System) |
| Active air fuel ratio control | Performing |
| Active air fuel ratio control begins when all of following conditions met | |
| Battery voltage | 11 V or higher |
| Engine coolant temperature | 75°C (167°F) or more |
| Idling | OFF |
| Engine speed | Less than 3200 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Fuel cut | OFF |
| Engine load | 10 to 70% |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE, HIGH VOLTAGE AND LOW VOLTAGE)
| Battery voltage | 11 V or more |
| Estimated sensor temperature | Below 700°C (1292°F) |
| ECM (included in the hybrid vehicle control ECU) monitor | Completed |
| DTC P0607 | Not detected |
HEATED OXYGEN SENSOR IMPEDANCE (LOW IMPEDANCE)
| Battery voltage | 11 V or more |
| Estimated sensor temperature | 450 to 750°C (842 to 1382°F) |
| DTC P0607 | Not detected |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH IMPEDANCE)
| Battery voltage | 11 V or more |
| Time after engine start | 2 seconds or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Engine coolant temperature | 70°C (158°F) or more |
| Estimated catalyst temperature | 530°C (986°F) or more |
| Fuel cut | ON |
HEATED OXYGEN SENSOR VOLTAGE DURING FUEL-CUT
| Either of following conditions met | 1 or 2 |
| 1. All of following conditions met | |
| (a) Commanded air fuel ratio | 14.3 or less |
| (b) Heated oxygen sensor voltage | 0.21 to 0.59 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 2.3 g or more |
| 2. All of following conditions met | |
| (a) Commanded air fuel ratio | 14.9 or more |
| (b) Heated oxygen sensor voltage | 0.21 to 0.59 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 2.3 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE)
| All of following conditions met | |
| (a) Commanded air fuel ratio | 14.3 or less |
| (b) Heated oxygen sensor voltage | Less than 0.21 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 2.3 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (LOW VOLTAGE)
| All of following conditions met | |
| (a) Commanded air fuel ratio | 14.9 or more |
| (b) Heated oxygen sensor voltage | More than 0.59 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 2.3 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (HIGH VOLTAGE)
| Duration of following condition | 30 seconds or more |
| Heated oxygen sensor impedance | Less than 5 ohms |
HEATED OXYGEN SENSOR IMPEDANCE (LOW IMPEDANCE)
| Duration of following condition | 60 seconds or more |
| Heated oxygen sensor impedance | 15 kohms or more |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH IMPEDANCE)
| Duration of following condition | 10 seconds or more |
| Heated oxygen sensor voltage | 1.2 V or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Duration until rear heated oxygen sensor voltage drops to 0.2 V after fuel cut | 6 seconds or more |
| Duration that rear heated oxygen sensor voltage drops from 0.35 V to 0.2 V during fuel cut | 1 second or more |
HEATED OXYGEN SENSOR VOLTAGE DURING FUEL-CUT
| Duration of following condition | 30 seconds or more |
| Heated oxygen sensor voltage | Varies between 0.1 V and 0.9 V |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
CONFIRMATION DRIVING PATTERN
Scheme 196
Scheme 196: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 47 to 75 mph (75 to 120 km/h) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0136, P0137 or P0138.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] though [D] again.
Scheme 197
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 47 mph (75 km/h), and then decelerate the vehicle by releasing the accelerator pedal for 6 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0139.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, move the shift lever to B and then perform [C] and [D] again.
| Related DTCs | P0171: Fuel Trim Lean P0172: Fuel Trim Rich |
| Required Sensors/Components (Main) | Fuel system |
| Required Sensors/Components (Related) | Air fuel ratio sensor Mass air flow meter Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (Camshaft Timing Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351 - P0354 (Igniter) |
| Fuel system status | Closed loop |
| Battery voltage | 11 V or higher |
| Either of following conditions met | |
| 1. Engine speed | Less than 1400 rpm |
| 2. Engine load | 0.22 g/rev or more |
| Catalyst monitor | Not executed |
| Purge-cut | Executing |
| Either of following conditions met | |
| 1. Average between short-term fuel trim and long-term fuel trim | 35% or more (varies with engine coolant temperature) |
| 2. Average between short-term fuel trim and long-term fuel trim | 35% or less (varies with engine coolant temperature) |
Scheme 198
Scheme 198: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) with all the accessories switched off [B].
- With the engine warmed up, idle the engine for 2 minutes or more [C].
- Drive the vehicle at between 47 and 75 mph (75 and 120 km/h) and at an engine speed of between 1400 and 3200 rpm for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [E]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0171 or P0172.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [E] again.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171 or P0172 is output A DTC P0171 or P0172 and other DTCs are output B HINT: If any DTCs other than P0171 or P0172 are output, troubleshoot those DTCs first. B --> See step 23 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-398230-S12813372942011051600000) . OK No leaks in the intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine. Warm up the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor. Perform the Control the Injection Volume for A/F Sensor operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio sensor and the heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by -12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +25% Rich Less than 3.1 V -12.5% Lean More than 3.4 V O2S B1S2 (Heated oxygen) +25% Rich More than 0.55 V -12.5% Lean Less than 0.4 V Result Status AFS Voltage B1S1 Status O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Misfire Suspected Trouble Area Proceed to Lean Lean Actual air fuel ratio lean May occur PCV valve and hose PCV hose connections Injector blockage Gas leaks from exhaust system Intake system Fuel pressure Mass air flow meter Engine coolant temperature sensor A Rich Rich Actual air fuel ratio rich - Injector leak or blockage Gas leaks from exhaust system Ignition system Fuel pressure Mass air flow meter Engine coolant temperature sensor Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor Lean/Rich Lean/Rich Normal - - C Lean: During Control the Injection Volume for A/F Sensor, the air fuel ratio sensor output voltage (AFS Voltage B1S1) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S2) is consistently below 0.4 V. Rich: During Control the Injection Volume for A/F Sensor, the AFS Voltage B1S1 is consistently below 3.1 V, and the O2S B1S2 is consistently higher than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F Sensor of the Active Test, the output voltage of the heated oxygen sensor alternates correctly. C --> See step 21 B --> See step 11 A: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp. Read the Data List twice, when the engine is both cold and warmed up. Standard value With cold engine: Same as ambient air temperature. With warm engine: 80 to 100°C (176 to 212°F). NG --> See step 24 OK: Go to next step
- INSPECT MASS AIR FLOW METER Inspect the mass air flow meter See step 4 . NG --> See step 25 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-398233-S24986668062011051600000) . NG --> REPAIR OR REPLACE FUEL SYSTEM OK: Go to next step
- INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
- CHECK SPARK AND IGNITION HINT: Refer to the ignition system inspection procedure. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-398218-S14737801732011051600000) . If the spark plugs or ignition system malfunctions, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Cylinder #1 Misfire Count (to Cylinder #4 Misfire Count). NG --> REPAIR OR REPLACE IGNITION SYSTEM OK: Go to next step
- INSPECT FUEL INJECTOR ASSEMBLY (INJECTION AND VOLUME) HINT: Refer to the fuel injector inspection procedure. Refer to «INSPECTION»(ref-398229-S38217131622011051600000) . If the injectors malfunction, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Cylinder #1 Misfire Count (to Cylinder #4 Misfire Count). NG --> See step 26 OK --> See step 21
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 27 OK: Go to next step
- CHECK TERMINAL VOLTAGE (POWER SOURCE OF AIR FUEL RATIO SENSOR) See step 2 NG --> See step 17 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - HYBRID VEHICLE CONTROL ECU). Refer to «PROCEDURE - Step 11»(ref-398226-S37436521942011051600000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-398228-S39900601942011051600000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Turn the power switch off and wait for 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) with all the accessories switched off. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0171 OR P0172) Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0171 or P0172. Check the DTC judgment. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0171 or P0172 is output) B B --> See step 28 A --> END
- INSPECT INTEGRATION RELAY (EFI MAIN RELAY) Inspect the integration relay. Refer to «INSPECTION - Step 1»(ref-398228-S17880478372011051600000) . NG --> See step 29 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (EFI MAIN RELAY - AIR FUEL RATIO SENSOR) See step 6 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK HARNESS AND CONNECTOR (EFI MAIN RELAY - IGCT RELAY) See step 7 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK HARNESS AND CONNECTOR (EFI MAIN RELAY - BODY GROUND) See step 8 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (BATTERY - EFI MAIN RELAY)
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Turn the power switch off and wait for 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) with all the accessories switched off. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0171 OR P0172) Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0171 or P0172. Check the DTC judgment. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0171 or P0172 is output) B B --> See step 28 A --> See step 30
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-398228-S30093668762011051600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-398228-S12654782472011051600000)
- REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-398229-S34024863372011051600000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-398228-S39900601942011051600000)
- REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)
- REPLACE INTEGRATION RELAY. Refer to «REMOVAL»(ref-398228-S32500819222011051600000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-398225-S22017638762011051600000)
| Related DTCs | P0300: Multiple Cylinder Misfire P0301: Cylinder 1 Misfire P0302: Cylinder 2 Misfire P0303: Cylinder 3 Misfire P0304: Cylinder 4 Misfire |
| Required Sensors/Components (Main) | Crankshaft position sensor Camshaft position sensor |
| Required Sensors/Components (Related) | Engine coolant temperature Intake air temperature sensor Mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 1000 to 4000 crankshaft revolutions: Emission-related misfire 200 to 600 crankshaft revolutions: Catalyst-damaging misfire |
| MIL Operation | 2 driving cycles: Emission-related misfire MIL flashes immediately: Catalyst-damaging misfire |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016 (VVT System - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0327, P0328 (Knock Control Sensor) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351 - P0354 (Igniter) |
| Battery voltage | 8 V or higher |
| VVT system | Not operated by scan tool |
| Engine speed | 750 to 6400 rpm |
| Either of following conditions (a) or (b) met | |
| (a) Engine coolant temperature at engine start | Higher than -7°C (19°F) |
| (b) Engine coolant temperature | Higher than 20°C (68°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or during check mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED MISFIRE
| All of following conditions 1, 2 and 3 met | Crankshaft 200 revolutions x 3 |
| 1. Driving cycles | 1st |
| 2. Check mode | OFF |
| 3. Engine speed | Less than 3500 rpm |
| Except above (MIL blinks immediately) | Crankshaft 200 revolutions |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
MONITOR PERIOD OF EMISSION-RELATED MISFIRE
| Number of misfires per 200 revolutions | 82 or more (varies with intake air amount and RPM) |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 199
Scheme 199: WIRING DIAGRAM
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG).
- Turn the Techstream on.
- Record the DTC(s) and freeze frame data.
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Using the Techstream, switch the hybrid vehicle control ECU from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-398225-S06565800662011051600000) .
- Read the misfire counts of each cylinder, Cylinder #1 Misfire Count to Cylinder #4 Misfire Count, with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- Drive the vehicle several times with the conditions, such as engine speed and engine load, shown in Misfire RPM and Misfire Load in the Data List. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below. Confirm the Misfire RPM and Misfire Load in the Data List. Engine Speed Duration Idling 5 minutes or more 1000 4 minutes or more 1500 3 minutes or more 2500 2 minutes or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the power switch off until the output DTC(s) and freeze frame data have been recorded. When the hybrid vehicle control ECU returns to normal mode (default), the stored DTC(s), freeze frame data and other data are cleared.
- Record the DTC(s), freeze frame data and misfire counts.
- Turn the power switch off and wait for at least 5 seconds.
| Related DTCs | P0327: Knock control sensor (bank 1) range check (Low voltage) P0328: Knock control sensor (bank 1) range check (High voltage) |
| Required Sensors/Components (Main) | Knock control sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 5 seconds or more |
| Knock control sensor voltage | Less than 0.5 V |
KNOCK CONTROL SENSOR RANGE CHECK (LOW VOLTAGE) P0327
| Knock control sensor voltage | More than 4.5 V |
KNOCK CONTROL SENSOR RANGE CHECK (HIGH VOLTAGE) P0328
Scheme 200
Scheme 200: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and wait 10 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0327 or P0328.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes and check the DTC judgment result again [C].
Scheme 201
Scheme 201: WIRING DIAGRAM
| Related DTCs | P0335: Crankshaft position sensor verify pulse input |
| Required Sensors/Components (Main) | Crankshaft position sensor |
| Required Sensors/Components (Related) | Camshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 times |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Time after starter OFF to ON | 2.5 seconds or more |
| Number of camshaft position sensor signal pulse | 6 times |
| Battery voltage | 7 V or more |
| Camshaft position sensor circuit fail (P0340) | Not detected |
| Power switch | On (IG) |
| Engine speed | 600 rpm or more |
| Stater | Off |
| Time after starter OFF to ON | 3 seconds or more |
| Number of crankshaft position sensor signal pulse | 29 times or less, or 73 times or more |
| Engine speed signal | No signal |
| Crankshaft position sensor | Crankshaft position sensor output voltage fluctuates while crankshaft revolving 34 crankshaft position sensor signals per crankshaft revolution |
Scheme 202
Scheme 202: WIRING DIAGRAM
Scheme 203
Scheme 203: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine.
- Idle the engine for 20 seconds or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [C]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0335.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
| Related DTCs | P0340: Camshaft position sensor range check P0340: Camshaft position/crankshaft position misalignment |
| Required Sensors/Components (Main) | Camshaft position sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Engine speed | 600 rpm or more |
| Starter | Off |
| All of the following conditions are met | Conditions A and B |
| A. Camshaft position sensor signal | No signal |
| B. Camshaft position and crankshaft position phase | Misaligned |
| Camshaft position sensor | Camshaft position sensor output voltage fluctuates while camshaft rotating 3 camshaft position sensor signals per 2 crankshaft revolutions |
Scheme 204
Scheme 204: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine.
- Idle the engine for 10 seconds or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [C]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0340.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- INSPECT CAMSHAFT POSITION SENSOR (RESISTANCE) Inspect the camshaft position sensor. Refer to «INSPECTION»(ref-398228-S22117860722011051600000) . NG --> See step 8 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT POSITION SENSOR - HYBRID VEHICLE CONTROL ECU) Disconnect the camshaft position sensor connector. Disconnect the hybrid vehicle control ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition C20-1 - C28-55 (G2+) Always Below 1 ohms C20-2 - C28-54 (G2-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition C20-1 or C28-55 (G2+) - Body ground Always 10 kohms or higher C20-2 or C28-54 (G2-) - Body ground Always 10 kohms or higher Reconnect the hybrid vehicle control ECU connector. Reconnect the camshaft position sensor connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK SENSOR INSTALLATION (CAMSHAFT POSITION SENSOR) Check the camshaft position sensor installation. OK Sensor is installed correctly. NG --> See step 9 OK: Go to next step
- CHECK VALVE TIMING See step 6 NG --> See step 10 OK: Go to next step
- INSPECT INTAKE CAMSHAFT Check the teeth of the timing rotor of the intake camshaft. OK Timing rotor does not have any cracks or deformation. NG --> See step 11 OK: Go to next step
- REPLACE CAMSHAFT POSITION SENSOR Replace the camshaft position sensor. Refer to «REMOVAL»(ref-398228-S19400721632011051600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) . Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0340 is output B HINT: If the engine does not start, replace the hybrid vehicle control ECU. B --> See step 12 A --> END
- REPLACE CAMSHAFT POSITION SENSOR. Refer to «REMOVAL»(ref-398228-S19400721632011051600000)
- SECURELY REINSTALL CAMSHAFT POSITION SENSOR. Refer to «INSTALLATION»(ref-398228-S16770036372011051600000)
- ADJUST VALVE TIMING. Refer to «REMOVAL»(ref-398215-S26066177622011051600000)
- REPLACE INTAKE CAMSHAFT. Refer to «REMOVAL»(ref-398215-S26066177622011051600000)
- REPLACE HYBRID VEHICLE CONTROL ECU. Refer to «REMOVAL»(ref-398232-S36824664312011051600000)
| Related DTCs | P0351: Igniter (cylinder 1) malfunction P0352: Igniter (cylinder 2) malfunction P0353: Igniter (cylinder 3) malfunction P0354: Igniter (cylinder 4) malfunction |
| Required Sensors/Components (Main) | Igniter |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 0.256 seconds and 2 times |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Either of the following conditions A or B is met | |
| A. Engine speed | 1500 rpm or less |
| B. Starter | OFF |
| Either of the following conditions C or D met | |
| C. All of the following conditions (a) and (b) are met | |
| (a) Engine speed | 500 rpm or less |
| (b) Battery voltage | 6 V or more |
| D. All of the following conditions (c), (d) and (e) are met | |
| (c) Engine speed | More than 500 rpm |
| (d) Battery voltage | 10 V or more |
| (e) Number of sparks after CPU reset | 5 sparks or more |
| Lost communication with hybrid vehicle control ECU (U0293) | Not detected |
| All of the following conditions are met | Conditions A, B and C |
| A. Ignition signal fail counter | More than 2 times |
| B. Time after condition A is met | 0.256 seconds or more |
| C. Ignition signal fail count after condition B is met | More than 2 times |
| Confirmed ignition signal input when ignition signal is ON to OFF | 2 times |
Scheme 205
Scheme 205: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398225-S11190546532011051600000) .
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine.
- Idle the engine for 10 seconds or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [C]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0351, P0352, P0353 or P0354.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
Scheme 206
Scheme 206: WIRING DIAGRAM
Scheme 207
| Related DTCs | P0420: Catalyst Deterioration |
| Required Sensors/Components (Main) | Air fuel ratio sensor Heated oxygen sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor Mass air flow meter Crankshaft position sensor Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | About 30 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (Camshaft Timing Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0037, P0038, P102D (Heated Oxygen Sensor Heater) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0136, P0137, P0138, P0139, P0607 (Rear Oxygen Sensor) P0102, P0103 (Mass Air Flow Meter) P0107, P0108 (Manifold Absolute Pressure) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351 - P0354 (Igniter) |
| Battery voltage | 11 V or more |
| Intake air temperature | 10°C (14°F) or more |
| Engine coolant temperature | 75°C (167°F) or more |
| Atmospheric pressure | 76 kPa-a (570 mmHg-a) or more |
| Idling | OFF |
| Engine speed | Less than 3200 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Engine load | 10 to 70% |
| All of the following conditions are met | Condition 1, 2 and 3 |
| 1. Mass air flow rate | 10 to 28 gm/sec |
| 2. Front catalyst temperature (estimated) | 600 to 800°C (1112 to 1472°F) |
| 3. Rear catalyst temperature (estimated) | 370 to 675°C (698 to 1247°F) |
| Oxygen Storage Capacity (OSC) of catalyst | Less than 0.09 g |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Performing this confirmation driving pattern will activate the catalyst monitor. This is very useful for verifying the completion of a repair.
Scheme 208
Scheme 208: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG).
- Turn the Techstream on.
- Clear the DTCs.
- Turn the power switch off.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Monitor.
- Check that Catalyst Efficiency / Status2 is Incomplete.
- Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) .
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
- Drive the vehicle at between 47 and 75 mph (75 and 120 km/h) for at least 10 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Those items will change to Complete after completing the driving pattern.
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Check if any DTCs (pending DTCs) are set.
If Catalyst does not change to Complete, and no pending DTCs are stored, extend the driving time.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0420 is output A DTC P0420 and other DTCs are output B HINT: If any DTCs other than P0420 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . Start the engine and warm it up. Run the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor. Perform the Active Test operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio sensor and heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by -12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1 S1 (Air fuel ratio) +25% Rich Less than 3.1 V -12.5% Lean More than 3.4 V O2S B1 S2 (Heated oxygen) +25% Rich More than 0.55 V -12.5% Lean Less than 0.4 V Result Status AFS Voltage B1 S1 Status O2S B1 S2 Air Fuel Ratio Condition and Air Fuel Ratio and Heated Oxygen Sensors Condition Misfire Main Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Three-way catalytic converter Gas leaks from exhaust system A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system Lean Lean Actual air fuel ratio lean May occur Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system D Rich Rich Actual air fuel ratio rich - Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system Lean: During Control the Injection Volume for A/F Sensor, the air fuel ratio sensor output voltage (AFS Voltage B1S1) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S2) is consistently below 0.4 V. Rich: During Control the Injection Volume for A/F Sensor, the AFS Voltage B1S1 is consistently below 3.1 V, and the O2S B1S2 is consistently higher than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F Sensor of the Active Test, the output voltage of the heated oxygen sensor alternates correctly. D --> See step 6 C --> See step 9 B --> See step 5 A: Go to next step
- INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-398225-S07453478932011051600000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-398228-S39900601942011051600000)
- GO TO NEXT STEP AFTER CHECKING ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1)»(ref-398227-S19521690262011051600000)
- REPLACE EXHAUST MANIFOLD CONVERTER SUB-ASSEMBLY (TWC: FRONT CATALYST) Replace the exhaust manifold converter sub-assembly (TWC: Front catalyst). Refer to «COMPONENTS»(ref-398234-S39746434962011051600000) . NEXT --> See step 8
- REPLACE CENTER EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST). Refer to «COMPONENTS»(ref-398234-S07455741482011051600000)
- INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK --> See step 10
- REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL»(ref-398228-S03267976182011051600000)
