Cellular Communication (Service Information): Removal & Installation Lexus HS I

Entertainment Systems 15 illustrations ~872 words

INSTALLATION

  1. INSTALL DCM (TELEMATICS TRANSCEIVER)
  2. INSTALL NO. 1 TELEMATICS TRANSCEIVER BRACKET Install the No. 1 telematics transceiver bracket with the 2 screws.
  3. INSTALL DCM (TELEMATICS TRANSCEIVER) WITH BRACKET Install the DCM (telematics transceiver) with bracket with the 3 screws.
  4. INSTALL INTEGRATION CONTROL AND PANEL WITH RADIO RECEIVER ASSEMBLY . Refer to «INSTALLATION - Step 5»(ref-398277-S29468340142011051600000)
  5. INSTALL CENTER INSTRUMENT PANEL REGISTER ASSEMBLY . Refer to «INSTALLATION - Step 48»(ref-398252-S05152107252011051600000)
  6. INSTALL REMOTE TOUCH ASSEMBLY (w/ Navigation System) . Refer to «INSTALLATION - Step 50»(ref-398252-S05152107252011051600000)
  7. INSTALL INSTRUMENT CLUSTER FINISH PANEL GARNISH ASSEMBLY (w/o Navigation System) . Refer to «INSTALLATION - Step 49»(ref-398252-S05152107252011051600000)
  8. INSTALL INSTRUMENT PANEL FINISH PANEL END RH . Refer to «INSTALLATION - Step 51»(ref-398252-S05152107252011051600000)
  9. INSTALL INSTRUMENT PANEL FINISH PANEL END LH . Refer to «INSTALLATION - Step 52»(ref-398252-S05152107252011051600000)
  10. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL . Refer to «INSTALLATION - Step 2»(ref-398219-S33566720602011051600000)
  11. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)
  12. ADJUST CLOCK

Scheme 163

Scheme 163: ILLUSTRATION
Scheme 163: ILLUSTRATION

Scheme 164

Scheme 164: REMOVAL
Scheme 164: REMOVAL

Scheme 165

Scheme 165
Scheme 165

Scheme 166

Scheme 166
Scheme 166

Scheme 167

Scheme 167
Scheme 167
  1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 3»(ref-398219-S28362000682011051600000)
  4. REMOVE GLOVE COMPARTMENT RETAINER Disengage the 3 claws to remove the glove compartment retainer.
  5. REMOVE LOWER INSTRUMENT COVER LH Disengage the claw and 2 guides to remove the lower instrument cover LH.
  6. REMOVE BACK-UP BATTERY WITH BRACKET Disconnect the connector. Remove the bolt and back-up battery with bracket.
  7. REMOVE NO. 3 TELEPHONE BRACKET Remove the No. 3 telephone bracket from the back-up battery.
  8. REMOVE BACK-UP BATTERY
  1. INSTALL BACK-UP BATTERY
  2. INSTALL NO. 3 TELEPHONE BRACKET Install the No. 3 telephone bracket to the back-up battery.
  3. INSTALL BACK-UP BATTERY WITH BRACKET Install the back-up battery with bracket with the bolt. Connect the connector.
  4. INSTALL LOWER INSTRUMENT COVER LH Engage the claw and 2 guides to install the lower instrument cover LH.
  5. INSTALL GLOVE COMPARTMENT RETAINER Engage the 3 claws to install the glove compartment retainer.
  6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL . Refer to «INSTALLATION - Step 2»(ref-398219-S33566720602011051600000)
  7. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)

Scheme 168

Scheme 168: ILLUSTRATION
Scheme 168: ILLUSTRATION

REMOVAL

  1. REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER (w/o Automatic High Beam System) . Refer to «REMOVAL - Step 1»(ref-398273-S04114327002011051600000)
  2. REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER (w/ Automatic High Beam System) . Refer to «REMOVAL - Step 2»(ref-398273-S04114327002011051600000)
  3. REMOVE RAIN SENSOR COVER (w/ Rain Sensor) . Refer to «REMOVAL - Step 1»(ref-398237-S36500708512011051600000)
  4. REMOVE FRONT ROOF TOP GARNISH (w/o Lane Keeping Assist System) . Refer to «REMOVAL - Step 39»(ref-398252-S41672440622011051600000)
  5. REMOVE FRONT ROOF TOP GARNISH (w/ Lane Keeping Assist System) . Refer to «REMOVAL - Step 40»(ref-398252-S41672440622011051600000)
  6. REMOVE MANUAL (SOS) SWITCH (MAP LIGHT ASSEMBLY) . Refer to «REMOVAL - Step 6»(ref-398274-S29760270842011051600000)
  1. INSTALL MANUAL (SOS) SWITCH (MAP LIGHT ASSEMBLY) . Refer to «INSTALLATION - Step 2»(ref-398274-S31959519242011051600000)
  2. INSTALL FRONT ROOF TOP GARNISH (w/o Lane Keeping Assist System) . Refer to «INSTALLATION - Step 11»(ref-398252-S34916510952011051600000)
  3. INSTALL FRONT ROOF TOP GARNISH (w/ Lane Keeping Assist System) . Refer to «INSTALLATION - Step 12»(ref-398252-S34916510952011051600000)
  4. INSTALL RAIN SENSOR COVER (w/ Rain Sensor) . Refer to «INSTALLATION - Step 3»(ref-398237-S29820104772011051600000)
  5. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER (w/o Automatic High Beam System) . Refer to «INSTALLATION - Step 3»(ref-398273-S29592052142011051600000)
  6. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER (w/ Automatic High Beam System) . Refer to «INSTALLATION - Step 4»(ref-398273-S29592052142011051600000)

Scheme 169

Scheme 169: ILLUSTRATION
Scheme 169: ILLUSTRATION

Scheme 170

Scheme 170: REMOVAL
Scheme 170: REMOVAL

Scheme 171

Scheme 171
Scheme 171

Scheme 172

Scheme 172
Scheme 172

Scheme 173

Scheme 173
Scheme 173
  1. REMOVE ROOF HEADLINING ASSEMBLY Remove the roof headlining assembly. Refer to «REMOVAL»(ref-398252-S15408195102011051600000) .
  2. REMOVE TELEPHONE ANTENNA PROTECTOR Disengage the 4 claws. Disconnect the 2 connectors. Disengage the 2 claws and remove the telephone antenna protector.
  3. REMOVE TELEPHONE AND GPS ANTENNA Remove the antenna nut. Disengage the 2 claws and remove the telephone and GPS antenna.

Scheme 174

Scheme 174: INSTALLATION
Scheme 174: INSTALLATION
  1. INSTALL TELEPHONE AND GPS ANTENNA Engage the 2 claws to temporarily install the telephone and GPS antenna. Place the antenna cord in the cutout of the antenna nut. TEXT IN ILLUSTRATION *1 Cutout Install the telephone and GPS antenna with the antenna nut. Torque: 4.5 N*m (46 kgf*cm, 40 in.*lbf)
  2. INSTALL TELEPHONE ANTENNA PROTECTOR Engage the 2 claws and install the telephone antenna protector. Connect the 2 connectors. Engage the 4 claws.
  3. INSTALL ROOF HEADLINING ASSEMBLY Install the roof headlining assembly. Refer to «INSTALLATION»(ref-398252-S11412627292011051600000) .

Scheme 175

Scheme 175: ILLUSTRATION
Scheme 175: ILLUSTRATION

Scheme 176

Scheme 176: REMOVAL
Scheme 176: REMOVAL

Scheme 177

Scheme 177
Scheme 177
  1. REMOVE ROOF HEADLINING ASSEMBLY Remove the roof headlining assembly. Refer to «REMOVAL»(ref-398252-S15408195102011051600000) .
  2. REMOVE TELEPHONE AND GPS ANTENNA CORDS (NO. 3 ANTENNA CORD SUB-ASSEMBLY) Disengage the 4 claws. Disconnect the 2 connectors. Disengage the 6 clamps and remove the telephone and GPS antenna cords (No. 3 antenna cord sub-assembly).
  1. INSTALL TELEPHONE AND GPS ANTENNA CORDS (NO. 3 ANTENNA CORD SUB-ASSEMBLY) Engage the 6 clamps to install the telephone and GPS antenna cords (No. 3 antenna cord sub-assembly). Connect the 2 connectors. Engage the 4 claws.
  2. INSTALL ROOF HEADLINING ASSEMBLY Install the roof headlining assembly. Refer to «INSTALLATION»(ref-398252-S11412627292011051600000) .
