Cellular Communication (Service Information): Overview Lexus HS I

Entertainment Systems 4 illustrations ~239 words

Scheme 159

Scheme 159: ILLUSTRATION
Scheme 159: ILLUSTRATION

Scheme 160

Scheme 160: ILLUSTRATION
Scheme 160: ILLUSTRATION

Scheme 161

Scheme 161: ILLUSTRATION
Scheme 161: ILLUSTRATION

Scheme 162

Scheme 162: REMOVAL
Scheme 162: REMOVAL
  1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 3»(ref-398219-S28362000682011051600000)
  4. REMOVE INSTRUMENT PANEL FINISH PANEL END LH . Refer to «REMOVAL - Step 7»(/lexus/hs/i-2009-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  5. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL - Step 8»(/lexus/hs/i-2009-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  6. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH ASSEMBLY (w/o Navigation System) . Refer to «REMOVAL - Step 9»(/lexus/hs/i-2009-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  7. REMOVE REMOTE TOUCH ASSEMBLY (w/ Navigation System) . Refer to «REMOVAL - Step 10»(/lexus/hs/i-2009-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  8. REMOVE CENTER INSTRUMENT PANEL REGISTER ASSEMBLY . Refer to «REMOVAL - Step 11»(/lexus/hs/i-2009-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  9. REMOVE INTEGRATION CONTROL AND PANEL WITH RADIO RECEIVER ASSEMBLY . Refer to «REMOVAL - Step 9»(ref-398277-S40680051002011051600000)
  10. REMOVE DCM (TELEMATICS TRANSCEIVER) WITH BRACKET Remove the 3 screws and DCM (telematics transceiver) with bracket.
  11. REMOVE NO. 1 TELEMATICS TRANSCEIVER BRACKET Remove the 2 screws and No. 1 telematics transceiver bracket.
  12. REMOVE DCM (TELEMATICS TRANSCEIVER)
