Audio / Video (Service Information): Overview Lexus HS I

Entertainment Systems 7 illustrations ~310 words

Scheme 22

Scheme 22: ILLUSTRATION

Scheme 23

Scheme 23: ILLUSTRATION

Scheme 24

Scheme 24: ILLUSTRATION

Scheme 25

Scheme 25: REMOVAL

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28
  1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 3»(ref-398219-S28362000682011051600000)
  4. REMOVE INSTRUMENT PANEL FINISH PANEL END LH . Refer to «REMOVAL - Step 7»(/lexus/hs/i-2009-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  5. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL - Step 8»(/lexus/hs/i-2009-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  6. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH ASSEMBLY (w/o Navigation System) . Refer to «REMOVAL - Step 9»(/lexus/hs/i-2009-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  7. REMOVE REMOTE TOUCH ASSEMBLY (w/ Navigation System) . Refer to «REMOVAL - Step 10»(/lexus/hs/i-2009-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  8. REMOVE CENTER INSTRUMENT PANEL REGISTER ASSEMBLY . Refer to «REMOVAL - Step 11»(/lexus/hs/i-2009-2012/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  9. REMOVE INTEGRATION CONTROL AND PANEL WITH RADIO RECEIVER ASSEMBLY Remove the 4 bolts. Pull the integration control and panel with radio receiver assembly toward the rear of the vehicle. Disconnect each connector and remove the integration control and panel with radio receiver assembly.
  10. REMOVE DCM (TELEMATICS TRANSCEIVER) WITH BRACKET (w/ Manual (SOS) Switch) . Refer to «REMOVAL - Step 10»(ref-398300-S23491416312011051600000)
  11. REMOVE NO. 1 RADIO BRACKET Remove the 6 bolts and No. 1 radio bracket.
  12. REMOVE NO. 2 RADIO BRACKET Remove the 5 bolts and No. 2 radio bracket.
  13. REMOVE RADIO RECEIVER ASSEMBLY Disengage the 2 claws and 2 guides to remove the radio receiver assembly from the integration control and panel assembly.
