CAN Communication System (Diagnostics - Introduction): Other Lexus HS I

TERMINALS OF ECU

Note. Turn the power switch off before measuring the resistances between CAN bus main wires and between CAN bus branch wires. Turn the power switch off before inspecting CAN bus wires for a ground short. After the power switch is turned off, check that the key reminder warning system and light reminder warning system are not operating. Before measuring the resistance, leave the vehicle as is for at least 1 minute and do not operate the power switch, any other switches or the doors. If any doors need to be opened in order to check connectors, open the doors and leave them open. This information describes the standard CAN values for all CAN related components.

HINT

1. Operating the power switch, any other switches or a door triggers related ECU and sensor communication on the CAN. This communication will cause the resistance value to change.
2. Even after DTCs are cleared, if a DTC is stored again after driving the vehicle for a while, the malfunction may be occurring due to vibration of the vehicle. In such a case, wiggling the ECUs or wire harness while performing the inspection below may help determine the cause of the malfunction.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

1. CAN NO. 1 JUNCTION CONNECTOR (for CAN No. 1 Bus) Check the CAN No. 1 junction connector (Instrument panel connector holder upper side). Connection diagram TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to CAN No. 1 Junction Connector) *2 to CAN Junction Connector LH *3 to Driving Support ECU *4 to DLC3 *5 to Seat Belt Control ECU - - Check the connection diagram of the components which are connected to the CAN No. 1 junction connector. Terminal No. (Symbol) Wiring Color Connected to F89-1 (CANH) G CAN junction connector LH F89-2 (CANL) B F89-4 (CANH) G Driving support ECU F89-5 (CANL) B F89-7 (CANH) G DLC3 F89-8 (CANL) B F89-10 (CANH) G Seat belt control ECU F89-11 (CANL) B Check the CAN No. 1 junction connector (Instrument panel connector holder lower side). Connection diagram TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to CAN No. 1 Junction Connector) *2 to Certification ECU *3 to Power Management Control ECU *4 to Airbag Sensor Assembly *5 to Display and Navigation Module Display (Navigation ECU) *6 to CAN Junction Connector RH Check the connection diagram of the components which are connected to the CAN No. 1 junction connector. Terminal No. (Symbol) Wiring Color Connected to F90-3 (CANH) V Certification ECU F90-2 (CANL) B F90-6 (CANH) V Power management control ECU F90-5 (CANL) B F90-9 (CANH) V Airbag sensor assembly F90-8 (CANL) B F90-12 (CANH) V Display and navigation module display (Navigation ECU) F90-11 (CANL) B F90-15 (CANH) G CAN junction connector RH F90-14 (CANL) B
2. CAN JUNCTION CONNECTOR LH (for CAN No. 1 Bus) Check the CAN junction connector LH (Instrument panel wire side). Connection diagram TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to CAN Junction Connector LH) *2 to CAN No. 1 Junction Connector *3 Multiplex Network Body ECU (Main Body ECU) - - Check the connection diagram of the components which are connected to the CAN junction connector LH. Terminal No. (Symbol) Wiring Color Connected to F91-5 (CANH) G CAN No. 1 junction connector F91-3 (CANL) B F91-6 (CANH) P Multiplex network body ECU (Main body ECU) F91-4 (CANL) W Check the CAN junction connector LH (Engine room main wire side). Connection diagram TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to CAN Junction Connector LH) *2 to Hybrid Vehicle Control ECU *3 to Brake Booster with Master Cylinder (Skid Control ECU) - - Check the connection diagram of the components which are connected to the CAN junction connector LH. Terminal No. (Symbol) Wiring Color Connected to A54-1 (CANH) Y Hybrid vehicle control ECU A54-3 (CANL) W A54-2 (CANH) L Brake booster with master cylinder (Skid control ECU) A54-4 (CANL) W
3. CAN JUNCTION CONNECTOR RH (for CAN No. 1 Bus and CAN No. 2 Bus) Check the CAN junction connector RH (Instrument panel wire side). Connection diagram TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to CAN Junction Connector RH) *2 to Combination Meter (CAN No. 1 Bus Main Wire) *3 to CAN No. 1 Junction Connector (CAN No. 1 Bus Main Wire) *4 to CAN No. 2 Junction Connector (CAN No. 2 Bus Main Wire) Check the connection diagram of the components which are connected to the CAN junction connector RH. FOR CAN NO. 1 BUS Terminal No. (Symbol) Wiring Color Connected to F92-5 (CANH) G Combination meter F92-3 (CANL) W F92-6 (CANH) G CAN No. 1 junction connector F92-4 (CANL) B FOR CAN NO. 2 BUS Terminal No. (Symbol) Wiring Color Connected to F92-12 (CANH) R CAN No. 2 junction connector F92-7 (CANL) W Check the CAN junction connector RH (Engine room main wire side). Connection diagram TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to CAN Junction Connector RH) *2 to Transmission Control ECU (CAN No. 1 Bus Branch Wire) *3 Headlight Swivel ECU (AFS ECU) (CAN No. 1 Bus Branch Wire) *4 Brake booster with master cylinder (Skid control ECU) (CAN No. 2 Bus Branch Wire) *5 Hybrid Vehicle Control ECU (CAN No. 2 Bus Branch Wire) *6 Clearance Warning ECU (CAN No. 2 Bus Branch Wire) Check the connection diagram of the components which are connected to the CAN junction connector RH. FOR CAN NO. 1 BUS Terminal No. (Symbol) Wiring Color Connected to A55-1 (CANH) GR Transmission control ECU A55-4 (CANL) W A55-2 (CANH) B Headlight swivel ECU (AFS ECU) A55-3 (CANL) W FOR CAN NO. 2 BUS Terminal No. (Symbol) Wiring Color Connected to A55-7 (CANH) GR Brake booster with master cylinder (Skid control ECU) A55-11 (CANL) W A55-8 (CANH) G Hybrid vehicle control ECU A55-12 (CANL) W A55-9 (CANH) L Clearance warning ECU A55-10 (CANL) W
4. CAN NO. 2 JUNCTION CONNECTOR Check the CAN No. 2 junction connector (Instrument panel connector holder upper side). Connection diagram TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to CAN No. 2 Junction Connector) *2 to Spiral Cable with Sensor (Steering Angle Sensor) *3 to CAN Junction Connector RH *4 to Parking Assist ECU *5 to Yaw Rate Sensor - - Check the connection diagram of the components which are connected to the CAN No. 2 junction connector. Terminal No. (Symbol) Wiring Color Connected to F87-1 (CANH) R Spiral cable with sensor (Steering angle sensor) F87-2 (CANL) W F87-4 (CANH) R CAN junction connector RH F87-5 (CANL) W F87-7 (CANH) R Parking assist ECU F87-8 (CANL) W F87-10 (CANH) R Yaw rate sensor F87-11 (CANL) W Check the CAN No. 2 junction connector (Instrument panel connector holder lower side). Connection diagram TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to CAN No. 2 Junction Connector) *2 to Power Management Control ECU *3 to Power Steering ECU - - Check the connection diagram of the components which are connected to the CAN No. 2 junction connector. Terminal No. (Symbol) Wiring Color Connected to F88-3 (CANH) L Power management control ECU F88-2 (CANL) W F88-6 (CANH) L Power steering ECU F88-5 (CANL) W
5. CAN NO. 3 JUNCTION CONNECTOR (for CAN MS Bus) Check the CAN No. 3 junction connector. Connection diagram TEXT IN ILLUSTRATION *1 CAN No. 3 Junction Connector *2 Junction Connector B Side *3 Junction Connector A Side *4 Earth Terminal *5 Rear view of wire harness connector (to CAN No. 3 Junction Connector) - - Check the connection diagram of the components which are connected to the CAN No. 3 junction connector. JUNCTION CONNECTOR B SIDE Terminal No. (Symbol) Wiring Color Connected to F122-1 (CANH) BR Front power seat switch LH F122-2 (CANL) W F85-1 (CANH) V Tire pressure monitor ECU F85-2 (CANL) W JUNCTION CONNECTOR A SIDE Terminal No. (Symbol) Wiring Color Connected to F86-1 (GND) W-B (Body ground) F84-1 (CANH) G Multiplex network body ECU (Main body ECU) F84-2 (CANL) W F119-1 (CANH) L Multiplex tilt and telescopic ECU F119-2 (CANL) W F120-1 (CANH) Y Outer mirror control ECU RH F120-2 (CANL) W F121-1 (CANH) B Outer mirror control ECU LH F121-2 (CANL) W
6. CAN NO. 4 JUNCTION CONNECTOR (for Driving Support Bus) Check the CAN No. 4 junction connector. Connection diagram TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to CAN No. 4 Junction Connector) *2 to Driver Monitor ECU *3 to Millimeter Wave Radar Sensor *4 to Driving Support ECU *5 to Lane Recognition Camera Sensor - - Check the connection diagram of the components which are connected to the CAN No. 4 junction connector. Terminal No. (Symbol) Wiring Color Connected to F123-1 (CANH) G Driver monitor ECU F123-5 (CANL) V F123-6 (CANH) Y Millimeter wave radar sensor F123-12 (CANL) W F123-7 (CANH) B Driving support ECU F123-10 (CANL) W F123-8 (CANH) R Lane recognition camera sensor F123-11 (CANL) W
7. DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F11-6 (CANH) - F11-14 (CANL) G - B HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F11-6 (CANH) - F11-4 (CG) G - W-B HIGH-level CAN bus line - Chassis ground Power switch off 200 ohms or higher F11-14 (CANL) - F11-4 (CG) B - W-B LOW-level CAN bus line - Chassis ground Power switch off 200 ohms or higher F11-6 (CANH) - F11-16 (BAT) G - Y HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F11-14 (CANL) - F11-16 (BAT) B - Y LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher TEXT IN ILLUSTRATION *1 DLC3
8. HYBRID VEHICLE CONTROL ECU Disconnect the hybrid vehicle control ECU connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Hybrid Vehicle Control ECU) Measure the resistance according to the value(s) in the table below. Standard Resistance FOR CAN NO. 1 BUS MAIN WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A58-20 (CANH) - A58-19 (CANL) Y - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 108 to 132 ohms A58-20 (CANH) - A58-40 (EC) Y - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher A58-19 (CANL) - A58-40 (EC) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher A58-20 (CANH) - A58-4 (BATT) Y - L HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A58-19 (CANL) - A58-4 (BATT) W - L LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher FOR CAN NO. 2 BUS MAIN WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A58-18 (CAN+) - A58-17 (CAN-) G - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 108 to 132 ohms A58-18 (CAN+) - A58-40 (EC) G - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher A58-17 (CAN-) - A58-40 (EC) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher A58-18 (CAN+) - A58-4 (BATT) G - L HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A58-17 (CAN-) - A58-4 (BATT) W - L LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
9. POWER MANAGEMENT CONTROL ECU CAN No. 1 Bus Branch Wire Disconnect the power management control ECU connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Power Management Control ECU) Measure the resistance according to the value(s) in the table below. Standard Resistance FOR CAN NO. 1 BUS BRANCH WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F52-14 (CA1H) - F52-13 (CA1L) V - B HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F52-14 (CA1H) - F52-6 (GND) V - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F52-13 (CA1L) - F52-6 (GND) B - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F52-14 (CA1H) - F52-1 (AM22) V - R HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F52-13 (CA1L) - F52-1 (AM22) B - R LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher CAN No. 2 Bus Main Wire Disconnect the power management control ECU connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Power Management Control ECU) Measure the resistance according to the value(s) in the table below. Standard Resistance FOR CAN NO. 2 BUS MAIN WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F52-26 (CA2H) - F52-25 (CA2L) L - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 108 to 132 ohms F52-26 (CA2H) - F52-6 (GND) L - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F52-25 (CA2L) - F52-6 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F52-26 (CA2H) - F52-1 (AM22) L - R HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F52-25 (CA2L) - F52-1 (AM22) W - R LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher Power Management Bus Main Wire Disconnect the power management control ECU connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Power Management Control ECU) Measure the resistance according to the value(s) in the table below. Standard Resistance FOR POWER MANAGEMENT BUS MAIN WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F52-12 (CA3P) - F52-11 (CA3N) B - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 108 to 132 ohms F52-12 (CA3P) - F52-6 (GND) B - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F52-11 (CA3N) - F52-6 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F52-12 (CA3P) - F52-1 (AM22) B - R HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F52-11 (CA3N) - F52-1 (AM22) W - R LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
10. TRANSMISSION CONTROL ECU Disconnect the transmission control ECU connectors. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Transmission Control ECU) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A36-16 (CA1H) - A36-15 (CA1L) GR - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms A36-16 (CA1H) - A36-1 (E1) GR - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher A36-15 (CA1L) - A36-1 (E1) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher A36-16 (CA1H) - A35-15 (BATT) GR - P HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A36-15 (CA1L) - A35-15 (BATT) W - P LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
11. BRAKE BOOSTER WITH MASTER CYLINDER (SKID CONTROL ECU) Disconnect the brake booster with master cylinder (skid control ECU) connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Brake Booster with Master Cylinder) Measure the resistance according to the value(s) in the table below. Standard Resistance CAN NO. 1 BUS BRANCH WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A60-37 (CA1H) - A60-38 (CA1L) L - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms A60-37 (CA1H) - A60-28 (GND) L - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher A60-38 (CA1L) - A60-28 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher A60-37 (CA1H) - A60-15 (BS) L - Y HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A60-38 (CA1L) - A60-15 (BS) W - Y LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher CAN NO. 2 BUS BRANCH WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A60-35 (CA2H) - A60-34 (CA2L) GR - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms A60-35 (CA2H) - A60-28 (GND) GR - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher A60-34 (CA2L) - A60-28 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher A60-35 (CA2H) - A60-15 (BS) GR - Y HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A60-34 (CA2L) - A60-15 (BS) W - Y LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
12. AIRBAG SENSOR ASSEMBLY Disconnect the center airbag sensor assembly connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Airbag Sensor Assembly) *2 DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F34-13 (CANH) - F34-22 (CANL) V - B HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F34-13 (CANH) - F34-25 (E1) V - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F34-22 (CANL) - F34-25 (E1) B - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F34-13 (CANH) - F11-16 (BAT) V - Y CAN communication line H - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F34-22 (CANL) - F11-16 (BAT) B - Y CAN communication line L - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
13. MULTIPLEX NETWORK BODY ECU (MAIN BODY ECU) Disconnect the multiplex network body ECU (main body ECU) connectors. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Multiplex Network Body ECU) *2 DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance CAN NO. 1 BUS BRANCH WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F9-14 (CANH) - F9-13 (CANL) P - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F9-14 (CANH) - F11-4 (CG) P - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F9-13 (CANL) - F11-4 (CG) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F9-14 (CANH) - F11-16 (BAT) P - Y HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F9-13 (CANL) - F11-16 (BAT) W - Y LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher CAN MS BUS MAIN WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F7-9 (CANP) - F7-10 (CANN) G - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 108 to 132 ohms F7-9 (CANP) - F11-4 (CG) G - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F7-10 (CANN) - F11-4 (CG) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F7-9 (CANP) - F11-16 (BAT) G - Y HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F7-10 (CANN) - F11-16 (BAT) W - Y LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
14. SMART KEY ECU (CERTIFICATION ECU) Disconnect the smart key ECU (certification ECU) connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Certification ECU) - - Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F50-9 (CANH) - F50-10 (CANL) V - B HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F50-9 (CANH) - F50-15 (E) V - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F50-10 (CANL) - F50-15 (E) B - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F50-9 (CANH) - F50-1 (+B) V - R HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F50-10 (CANL) - F50-1 (+B) B - R LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
15. COMBINATION METER Disconnect the combination meter connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Combination Meter) - - Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F4-32 (CANH) - F4-31 (CANL) G - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 108 to 132 ohms F4-32 (CANH) - F4-33 (EP) G - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F4-31 (CANL) - F4-33 (EP) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F4-32 (CANH) - F4-22 (B) G - V HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F4-31 (CANL) - F4-22 (B) W - V LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
16. DISPLAY AND NAVIGATION MODULE DISPLAY (NAVIGATION ECU) (w/ Navigation System) Disconnect the display and navigation module display (navigation ECU) connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Display and Navigation Module Display) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F30-21 (CANH) - F30-22 (CANL) V - B HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F30-21 (CANH) - F30-10 (GND1) V - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F30-22 (CANL) - F30-10 (GND1) B - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F30-21 (CANH) - F30-1 (+B1) V - R HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F30-22 (CANL) - F30-1 (+B1) B - R LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
17. HEADLIGHT SWIVEL ECU (AFS ECU) (w/ AFS) Disconnect the headlight swivel ECU (AFS ECU) connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Headlight Swivel ECU) *2 DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A61-12 (CANH) - A61-13 (CANL) B - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms A61-12 (CANH) - A61-22 (E1) B - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher A61-13 (CANL) - A61-22 (E1) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher A61-12 (CANH) - F11-16 (BAT) B - Y CAN communication line H - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A61-13(CANL) - F11-16 (BAT) W - Y CAN communication line L - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
18. DRIVING SUPPORT ECU (w/ Dynamic Radar Cruise Control System) Disconnect the driving support ECU connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Driving Support ECU) Measure the resistance according to the value(s) in the table below. Standard Resistance CAN NO. 1 BUS BRANCH WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F102-39 (CA1H) - F102-17 (CA1L) G - B HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F102-39 (CA1H) - F102-25 (GND) G - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F102-17 (CA1L) - F102-25 (GND) B - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F102-39 (CA1H) - F102-30 (B) G - V HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F102-17 (CA1L) - F102-30 (B) B - V LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher Standard Resistance DRIVING SUPPORT BUS MAIN WIRE Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F102-40 (CA1P) - F102-18 (CA1N) B - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 108 to 132 ohms F102-40 (CA1P) - F102-25 (GND) B - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F102-18 (CA1N) - F102-25 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F102-40 (CA1P) - F102-30 (B) B - V HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F102-18 (CA1N) - F102-30 (B) W - V LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
19. SEAT BELT CONTROL ECU (w/ Pre-collision System) Disconnect the seat belt control ECU connectors. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Seat Belt Control ECU) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F108-1 (CANH) - F108-2 (CANL) G - B HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F108-1 (CANH) - F107-8 (PGND) G - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F108-2 (CANL) - F107-8 (PGND) B - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F108-1 (CANH) - F107-7 (+B) G - Y HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F108-2 (CANL) - F107-7 (+B) B - Y LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
20. POWER STEERING ECU Disconnect the power steering ECU connectors. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Power Steering ECU) - - Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F53-1 (CANH) - F53-7 (CANL) L - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F53-1 (CANH) - A34-2 (PGND) L - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F53-7 (CANL) - A34-2 (PGND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F53-1 (CANH) - A34-1 (PIG) L - R HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F53-7 (CANL) - A34-1 (PIG) W - R LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
21. SPIRAL CABLE WITH SENSOR (STEERING ANGLE SENSOR) Disconnect the spiral cable with sensor (steering angle sensor) connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Spiral Cable with Sensor) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F5-4 (CANH) - F5-3 (CANL) R - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F5-4 (CANH) - F5-2 (ESS) R - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F5-3 (CANL) - F5-2 (ESS) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F5-4 (CANH) - F5-6 (BAT) R - GR HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F5-3 (CANL) - F5-6 (BAT) W - GR LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
22. YAW RATE SENSOR Disconnect the yaw rate sensor connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Yaw Rate Sensor) *2 DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F3-3 (CANH) - F3-2 (CANL) R - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F3-3 (CANH) - F3-1 (GND) R - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F3-2 (CANL) - F3-1 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F3-3 (CANH) - F11-16 (BAT) R - Y HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F3-2 (CANL) - F11-16 (BAT) W - Y LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
23. PARKING ASSIST ECU (w/ Wide View Front Monitor System) Disconnect the parking assist ECU connector. TEXT IN ILLUSTRATION *1 Front view of wire harness (to Parking Assist ECU) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F106-22 (CANH) - F106-21 (CANL) R - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F106-22 (CANH) - F106-3 (GND1) R - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F106-21 (CANL) - F106-3 (GND1) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F106-22 (CANH) - F106-1 (+B) R - V HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F106-21 (CANL) - F106-1 (+B) W - V LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
24. CLEARANCE WARNING ECU (w/ Intuitive Parking Assist System Disconnect the clearance warning ECU connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Clearance Warning ECU) *2 DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A31-19 (R1) - A31-20 (R2) L - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms A31-19 (R1) - A31-21 (E) L - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher A31-20 (R2) - A31-21 (E) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher A31-19 (R1) - F11-16 (BAT) L - Y CAN communication line H - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A31-20 (R2) - F11-16 (BAT) W - Y CAN communication line L - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
25. AIR CONDITIONING AMPLIFIER Disconnect the air conditioning amplifier connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Air Conditioning Amplifier) - - Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F47-11 (CANH) - F47-12 (CANL) B - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F47-11 (CANH) - F47-14 (GND) B - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F47-12 (CANL) - F47-14 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F47-11 (CANH) - F47-21 (B) B - GR HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F47-12 (CANL) - F47-21 (B) W - GR LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
26. TIRE PRESSURE MONITOR ECU Disconnect the tire pressure monitor ECU connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Tire Pressure Monitor ECU) *2 DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F61-6 (CANP) - F61-12 (CANN) V - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F61-6 (CANP) - F61-7 (GND) V - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F61-12 (CANN) - F61-7 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F61-6 (CANP) - F11-16 (BAT) V - Y CAN communication line H - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F61-12 (CANN) - F11-16 (BAT) W - Y CAN communication line L - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
27. FRONT POWER SEAT SWITCH LH (w/ Seat Position Memory) Disconnect the connectors of the front power seat switch LH. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Front Power Seat Switch LH) - - Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition T10-8 (CANP) - T10-7 (CANN) R - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms T10-8 (CANP) - T9-1 (GND) R - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher T10-7 (CANN) - T9-1 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher T10-8 (CANP) - T9-6 (+B) R - V HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher T10-7 (CANN) - T9-6 (+B) W - V LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
28. MULTIPLEX TILT AND TELESCOPIC ECU (w/ Seat Position Memory) Disconnect the multiplex tilt and telescopic ECU connector. TEXT IN ILLUSTRATION *1 Rear view of wire harness (to Multiplex Tilt and Telescopic ECU) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F109-5 (CANP) - F109-14 (CANN) L - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F109-5 (CANP) - F109-11 (GND) L - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F109-14 (CANN) - F109-11 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F109-5 (CANP) - F109-2 (+B) L - P HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F109-14 (CANN) - F109-2 (+B) W - P LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
29. OUTER MIRROR CONTROL ECU LH (w/ Seat Position Memory) Disconnect the outer mirror control ECU LH connector. TEXT IN ILLUSTRATION *1 Front view of wire harness (to Outer Mirror Control ECU LH) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition I8-9 (CANP) - I8-8 (CANN) B - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms I8-9 (CANP) - I8-7 (GND) B - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher I8-8 (CANN) - I8-7 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher I8-9 (CANP) - I8-6 (CPUB) B - LG HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher I8-8 (CANN) - I8-6 (CPUB) W - LG LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
30. OUTER MIRROR CONTROL ECU RH (w/ Seat Position Memory) Disconnect the outer mirror control ECU RH connector. TEXT IN ILLUSTRATION *1 Front view of wire harness (to Outer Mirror Control ECU RH) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition H8-9 (CANP) - H8-8 (CANN) Y - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms H8-9 (CANP) - H8-7 (GND) Y - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher H8-8 (CANN) - H8-7 (GND) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher H8-9 (CANP) - H8-6 (CPUB) Y - LG HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher H8-8 (CANN) - H8-6 (CPUB) W - LG LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
31. MILLIMETER WAVE RADAR SENSOR (w/ Dynamic Radar Cruise Control System) Disconnect the millimeter wave radar sensor connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Millimeter Wave Radar Sensor) *2 DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A2-4 (CA1P) - A2-3 (CA1N) Y - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 108 to 132 ohms A2-4 (CA1P) - F11-4 (CG) Y - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher A2-3 (CA1N) - F11-4 (CG) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher A2-4 (CA1P) - F11-16 (BAT) Y - Y HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A2-3 (CA1N) - F11-16 (BAT) W - Y LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
32. LANE RECOGNITION CAMERA SENSOR (w/ Lane-keeping Assist System) Disconnect the lane recognition camera sensor connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Lane Recognition Camera Sensor) *2 DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition P8-1 (CA1P) - P8-2 (CA1N) R - W HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms P8-1 (CA1P) - F11-4 (CG) R - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher P8-2 (CA1N) - F11-4 (CG) W - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher P8-1 (CA1P) - F11-16 (BAT) R - Y HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher P8-2 (CA1N) - F11-16 (BAT) W - Y LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
33. DRIVER MONITOR ECU (w/ Driver Monitor System) Disconnect the driver monitor ECU connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Driver Monitor ECU) *2 DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition F111-9 (CANH) - F111-24 (CANL) G - V HIGH-level CAN bus line - LOW-level CAN bus line Power switch off 54 to 69 ohms F111-9 (CANH) - F111-11 (GND) G - W-B HIGH-level CAN bus line - Ground Power switch off 200 ohms or higher F111-24 (CANL) - F111-11 (GND) V - W-B LOW-level CAN bus line - Ground Power switch off 200 ohms or higher F111-9 (CANH) - F11-16 (BAT) G - Y CAN communication line H - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher F111-24 (CANL) - F11-16 (BAT) V - Y CAN communication line L - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher

FAIL-SAFE CHART

1. FAIL-SAFE FUNCTION When communication fails in any of the CAN bus wires (communication wires), a fail-safe function(s) will operate. The fail-safe function that is specified for each system operates to prevent those systems from malfunctioning. The following table shows the effects on each system when communication is impossible. (For further details, see the informations for each system.) Function (Function Description) Control Master System Related Fail-safe Operation DTC (Driver Detectable) Power switch (Power source control) Power management control ECU Hybrid vehicle control ECU Transmission control ECU Skid control ECU Main body ECU Combination meter Power switch does not change to on (READY) even when power switch is pressed with the brake pedal depressed Power switch off is prohibited U0073 U0129 U0293 U1133 (Warning and indicator lights come on) Hybrid driving control Hybrid vehicle control ECU (HV) Hybrid vehicle control ECU (Engine) Only motor operation is used (Engine is not used) U0100 U0293 (Warning and indicator lights come on) Shift position indicator display Combination meter Hybrid vehicle control ECU Transmission control ECU Main body ECU Shift position indicator is not displayed U0100 U0142 U0155 (Warning and indicator lights come on) Regenerative braking control Skid control ECU Power management control ECU Regenerative braking will stop (ABS/VSC control gradually stops) U0073 U0129 U0293 (Warning and indicator lights come on) ABS/TRAC/VSC control (Controls driving force while ABS/TRAC/VSC operating) Skid control ECU Hybrid vehicle control ECU Yaw rate sensor Steering angle sensor ABS/VSC control is inoperative (ABS/VSC control gradually stops) U0073 U0123 U0124 U0126 U0293 (Warning and indicator lights come on) Electric power steering control (Speed of vehicle induction type torque control) Power steering ECU Hybrid vehicle control ECU Skid control ECU Depression of EPS assist (Deterioration of steering assist) U0129 U0293 (Warning light comes on) Air conditioning control (Air conditioning control is in cabin) Air conditioning amplifier Hybrid vehicle control ECU Combination meter Main body ECU Air conditioning function and PTC heater function stop U0100 U0142 U0155 U0293 (Air conditioning is inoperative) Entry function/Power door lock control Certification ECU Main Body ECU Combination meter Unlock permitted U0142 U0155 U0327 (Wireless door lock cannot operate) Headlight swivel/leveling control (Head light control) AFS ECU Hybrid vehicle control ECU Skid control ECU Steering angle sensor Main body ECU Swivel and/or leveling control is prohibited U0073 U0126 U0129 U0142 U0182 U0293 (Indicator light comes on) Vehicle-to-vehicle distance control Driving support ECU Hybrid vehicle control ECU Skid control ECU Steering angle sensor Yaw rate sensor Main body ECU Combination meter Vehicle-to-vehicle distance control does not operate U0122 U0123 U0126 U0293 U1104 (Warning and indicator lights come on) Lane keeping assist system Driving support ECU Main body ECU Skid control ECU Yaw rate sensor EPS ECU Lane-keeping assist is inoperative U0122 U0123 U0131 U1104 (Warning and indicator lights come on) Pre-collision system Driving support ECU Power management control ECU Skid control ECU ECM Steering angle sensor Yaw rate sensor Seat belt control ECU Pre-collision control is inoperative U0122 U0123 U0126 U0293 U1104 U1100 (Warning and indicator lights come on) Seat belt control ECU Skid control ECU Driving support ECU Center airbag sensor Main body ECU Pre-collision control is inoperative U0122 U0140 U0151 U1104 (Warning and indicator lights come on) Power tilt and power telescopic steering column control Tilt and telescopic ECU Main body ECU Front power seat switch Combination meter Driving position memory function is prohibited Auto away/return function is prohibited U1115 Seat position memory Front power seat switch Main body ECU Tilt and telescopic ECU Combination meter Auto memory recall is prohibited Memory is prohibited U0142 U0208 Outer mirror control Outer mirror control ECU Main body ECU Operation of outer mirrors is prohibited U0146 U0199 U0200
