DTCs P0300-P0306 Detection Logic

On DTCs P0300-P0306, MIL is set in 2 stages. If ECM detects misfiring strong enough to cause catalytic converter overheating for any 200 revolutions of engine, MIL will blink, but will not stay illuminated. If ECM detects misfiring strong enough to cause deterioration of catalytic converter during 2 consecutive drive cycles, for any 1000 revolutions of engine, MIL will illuminate.

Note. When road testing vehicle in CHECK mode (Lexus scan tool only), Two Trip Detection Logic will not function. Also, MIL will illuminate first time a malfunction is detected.

OBD-II regulations (SAE J-1850) standardizes Data Link Connector (DLC) configurations. On all models, DLC No. 3 connector is located under left side of instrument panel. (Scheme 32)

FREEZE-FRAME DATA

The ECM records engine operating condition when a misfire, fuel trim (mixture) malfunction or other malfunction (fuel system, calculated load, coolant temperature, fuel trim (mixture), engine speed, vehicle speed, etc.) exists. If more than one fault is detected, only data from first malfunction is recorded. Recorded data is useful for determining conditions in which malfunction occurs.

NORMAL Mode Code Retrieval

  1. Connect scan tool to Data Link Connector (DLC) No. 3. (Scheme 32) DLC No. 3 is located under left side of instrument panel. Turn ignition on with engine off. Turn scan tool on. Using scan tool manufacturer's instructions, check for DTCs and freeze-frame data.
  2. If scan tool displays UNABLE TO CONNECT TO VEHICLE, DLC No. 3 must be checked. See «DLC NO. 3 INSPECTION»(ref-134937-S23182733902002022100000) under SCAN TOOL PROBLEMS. If scan tool does not display UNABLE TO CONNECT TO VEHICLE, go to next step.
  3. Record any DTCs and freeze-frame data displayed for system diagnosis. If driveability problem exists and no DTCs are present, go to «TROUBLE SHOOTING - NO CODES»(ref-134942) article for diagnosis by symptom.
  4. If any DTCs are present, perform appropriate diagnostic test in «DIAGNOSTIC TESTS»(ref-134937-S42715088952002022100000). See «DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION»(ref-134937-S15736860702002022100000) table. For more information on freeze-frame data, see «FREEZE-FRAME DATA»(ref-134937-S19223826512002022100000) under INTRODUCTION. For information on 2-trip detection logic codes, see «TWO-TRIP DETECTION LOGIC»(ref-134937-S26170631292002022100000) under INTRODUCTION.
  5. After repairs for DTC have been completed, DTCs must be cleared from ECM memory. See «CLEARING DIAGNOSTIC TROUBLE CODES»(ref-134937-S11701235242002022100000).

Scheme 32

Scheme 32
DTC (1)Description
P0100Mass Airflow (MAF) Sensor Circuit
P0101Mass Airflow (MAF) Sensor Circuit Range/Performance Fault
P0110Intake Air Temperature (IAT) Sensor Circuit
P0115Engine Coolant Temperature (ECT) Circuit
P0116Engine Coolant Temperature (ECT) Circuit Range/Performance Fault
P0120Throttle (TP)/Pedal Position Sensor Circuit Malfunction
P0121Throttle (TP)/Pedal Position Sensor Circuit Range/Performance Fault
P0125Insufficient Coolant Temperature For Closed Loop Fuel Control
P0128Thermostat Malfunction
P0130/P0150Heated Oxygen Sensor Circuit Malfunction
P0133/P0153Heated Oxygen Sensor Circuit Slow Response
P0135/P0155Heated Oxygen Sensor Heater Circuit
P0136/P0156Heated Oxygen Sensor Circuit Malfunction
P0141/P0161Heated Oxygen Sensor Heater Circuit
P0171/P0172System Too Lean/Rich (Bank No. 1)
P0174/P0175System Too Lean/Rich (Bank No. 2)
P0300Random Multiple Cylinder Misfire Detected
P0301-P0306Cylinders No. 1-6 Misfire Detected
P0325/P0330Knock Sensor Circuit Malfunction
P0335Crankshaft Position (CKP) Sensor "A" Circuit Malfunction
P0340Camshaft Position (CMP) Sensor Circuit Malfunction
P0420/P0430Catalyst System Efficiency Below Threshold
P0440EVAP System Malfunction
P0441Incorrect EVAP System Purge Flow
P0450EVAP System Pressure Sensor Malfunction
P0451EVAP System Pressure Sensor Range/Performance Fault
P0500Vehicle Speed Sensor (VSS) Malfunction
P0505Idle Control System Malfunction
P0550P/S Pressure Sensor Malfunction
P0710 (2)Transmission Fluid Temperature Sensor Fault
P0711 (2)Transmission Fluid Temperature Sensor Circuit Range/Performance Fault
P0715 (2)Turbine Speed Sensor Fault
P0750 (2)Shift Solenoid Valve No. 1 Fault
P0753 (2)Shift Solenoid Valve No. 1 Electrical Fault
P0755 (2)Shift Solenoid Valve No. 2 Fault
P0758 (2)Shift Solenoid Valve No. 2 Electrical Fault
P0760 (2)Shift Solenoid Valve No. 3 Fault
P0763 (2)Shift Solenoid Valve No. 3 Electrical Fault
P0768 (2)Shift Solenoid Valve No. 4 Electrical Fault
P0770 (2)Lock-Up Solenoid Fault
P1120Accelerator Pedal Position Sensor Circuit Malfunction
P1121Accelerator Pedal Position Sensor Circuit Malfunction
P1125Throttle Control Motor Circuit Malfunction
P1126Magnetic Clutch Circuit Malfunction
P1127Electronic Throttle Control System (ETCS) Actuator Power Source Circuit Malfunction
P1128Throttle Control Motor Lock Malfunction
P1129Electronic Throttle Control System (ETCS) Malfunction
P1300Ignitor Circuit Malfunction
P1335Crankshaft Position (CKP) Sensor
P1346Variable Valve Timing (VVT) Circuit Range/Performance Fault
P1349Variable Valve Timing (VVT) System Malfunction
P1520Stoplight Switch Signal Malfunction
P1600ECM Batt Malfunction
P1633Electronic Throttle Control System (ETCS) Circuit ECM Malfunction
P1645Body ECU Malfunction
P1656Oil Control Valve (OCV) Circuit Malfunction
P1755 (2)Shift Solenoid Valve SLU Fault
P1760 (2)Shift Solenoid Valve SLT Fault
P1765 (2)Shift Solenoid Valve SLN Fault
P1780Park/Neutral Position Switch Malfunction
B2795 (3)Unmatched Key Code
B2796 (3)No Communication In Immobilizer System
B2797 (3)Communication Malfunction No. 1
B2798 (3)Communication Malfunction No. 2
(1) Some codes are two-trip detection logic code(s). For more information, see DETECTION LOGIC under INTRODUCTION. (2) These codes only apply to electronically controlled transmissions. For testing procedures, see appropriate ELECTRONIC CONTROLS article in AUTOMATIC TRANSMISSIONS. (3) MIL will not illuminate. For testing procedures, see ENGINE IMMOBILIZER SYSTEMS - GS300 & GS430 article in ACCESSORIES & EQUIPMENT.
(1)Some codes are two-trip detection logic code(s). For more information, see DETECTION LOGIC under INTRODUCTION.
(2)These codes only apply to electronically controlled transmissions. For testing procedures, see appropriate ELECTRONIC CONTROLS article in AUTOMATIC TRANSMISSIONS.
(3)MIL will not illuminate. For testing procedures, see ENGINE IMMOBILIZER SYSTEMS - GS300 & GS430 article in ACCESSORIES & EQUIPMENT.

DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION

SUMMARY

If no diagnostic trouble codes are present, driveability symptoms exist or intermittents exist, proceed to TROUBLE SHOOTING - NO CODES article for diagnosis by symptom (i.e., ROUGH IDLE, NO START, etc.) or intermittent procedures.
