Power Windows: Other Lexus ES XV30

Windows 3 illustrations ~3294 words

POWER WINDOW CONTROL SYSTEM

  1. Check the basic function of the manual operation function: Turn the ignition switch ON. Check that the door glass moves up when each window switch of the driver side regulator master switch assembly is turned to UP and moves down when each window is turned to DOWN. Check that the door glass moves up when each window switch of the passenger side regulator switch assembly is turned to UP and moves down when each window is turned to DOWN. Check that the other doors glass, besides the driver's, will not operate when locking the window locking switch.
  2. Check the automatic operation function: Turn the ignition switch ON. Check that the AUTO UP operates and the door glass is fully closed when each window switch of the driver side regulator master switch assembly is turned UP by double-shift. Check that the AUTO DOWN operates and the door glass is fully opened when each window switch of the driver side regulator master switch assembly is turned DOWN by double-shift. Check that the AUTO UP operates and the door glass is fully closed when the window switch of each passenger side regulator switch assembly is turned UP by double-shift. Check that the AUTO DOWN operates and the door glass is fully opened when the window switch of each passenger regulator switch assembly is turned DOWN by double-shift. Check that the door glass stops when the applicable switch is turned UP during the AUTO DOWN operation. However, if the switch is kept in the UP position, it will transfer to the manual operation. Check that the door glass stops when the applicable switch is turned DOWN during the AUTO UP operation. However, if the switch is kept in the DOWN position, it will transfer to the manual operation.
  3. Check the wireless operation. With all of the doors closed, have no key inserted in the ignition key cylinder. Check that each door glass moves down when the UNLOCK switch of the transmitter is kept pressing for 2.5 seconds or more. Also, check that the door glass stops when the UNLOCK switch is turned off.
  4. Check the operation function by operating the driver's door key operation (operation interlocked with key). Check that each door glass moves down when the door lock cylinder is held in the UNLOCK position for 2.5 seconds or more by the key operation. Also, check that the door glass stops when the door lock cylinder is turned back to the neutral position.
  5. Check the jam protection function. Jam protection function only works during the AUTO UP operation. Open the door glass fully. Hold the handle of the hammer near the fully-closed position. When fully closing the door glass with the AUTO UP, check that it moves down without the hammer handle getting caught and will go down by about 7.87 in. (200 mm) and stop there. The window goes down by about 1.97 in. (50 mm) or for about 1 second. In case of that the opening value is below 7.87 in. (200 mm), the window goes down by 7.87 in. (200 mm) or keeps going down for 5 seconds and stops then. During the lowering operation, check that it will not move up when the driver side window regulator master switch is operated to the UP side.

PRE-CHECK

Note. P/W refers to power window.

  1. Check the power window operation mode. (Scheme 19)
  2. Check the power window fail-safe function. When an abnormality is detected in the limit switch and the pulse sensor for operating the jam protection function (DTCs: B1231, B1232, B1233, B1234), the following power windows will be prohibited for fail-safe. (Scheme 20) In case of the normal limit switch, prohibition (fail-safe function) will be cancelled by fully opening the door glass from fully closed by manual operation then AUTO operation will be possible.
  3. Retrieve DTCs. See «RETRIEVING DIAGNOSTIC TROUBLE CODES»(ref-152599-S42515259192003021400000).
  4. Clear DTCs. See «CLEARING DIAGNOSTIC TROUBLE CODES»(ref-152599-S27937069792003021400000).
  5. According to the DATA LIST displayed on the OBD II scan tool or hand-held tester, you can read the value of the switch, sensor, actuator and so on without parts removal. Connect the OBD II scan tool or hand-held tester to the DLC3. Turn the ignition switch ON. According to the display on the tester, read the DATA LIST: Body ECU (data monitor of switch signal by DTC check). DTC B1221 and B1223 are the codes to inform of each switch condition and will be output when the switch is ON. These codes are displayed when operating the switch. If the codes are displayed even when not operating the switch, there may be trouble in the switch circuit. See «INSPECTING BODY ECU DATA LIST»(ref-152599-S39762260492003021400000) table. INSPECTING BODY ECU DATA LIST Item Measurement Item/Range (DTC) Normal Condition Power Window Switch Circuit On Driver Door P/W Master Switch Signal (Except Window Lock Switch)/B1221 B1221: Operating (ON) Either Switch Of The Master Switch, No Output Of B1221: No Operation Of Any Switch (OFF) Power Window Switch Circuit On Passenger Door P/W Master Switch Signal (Except Window Lock Switch)/B1223 B1223: Passenger's Door P/W Switch Or Manual Door Lock Switch Is On, No Operation Of Any Switch (OFF) Driver Door ECU. See «INSPECTING DRIVER'S DOOR ECU DATA LIST»(ref-152599-S09879483772003021400000) table. INSPECTING DRIVER'S DOOR ECU DATA LIST Item Measurement Item/Display (Range) Normal Condition D P/W AUTO Switch, P P/W AUTO Switch, RR P/W AUTO Switch & RL P/W AUTO Switch P/W Auto Switch Signal/ ON Or OFF ON: P/W Auto UP/DOWN Switch Is ON, OFF: P/W Auto UP/DOWN Switch Is OFF LIMIT Switch Jam Protection Limit Switch/ON Or OFF ON: Window Is Almost Fully Open, OFF: Window Is Open (1) (1) With the jam protection limit switch ON, the function of the jam protection will stop. If the switch does not come ON at the position where the windows are almost fully open, the windows will not fully close as the jam protection operates at the upper portion during the automatic UP performance. Passenger Door ECU. See «INSPECTING PASSENGER'S DOOR ECU DATA LIST»(ref-152599-S25787361122003021400000) table. INSPECTING PASSENGER'S DOOR ECU DATA LIST Item Measurement Item/Display (Range) Normal Condition P P/W AUTO Switch P/W Auto Switch Signal/ ON Or OFF ON: P/W Auto UP/DOWN Switch Is ON, OFF: P/W Auto UP/DOWN Switch Is OFF LIMIT Switch Jam Protection Limit Switch/ON Or OFF ON: Window Is Almost Fully Open, OFF: Window Is Open (1) (1) With the jam protection limit switch ON, the function of the jam protection will stop. If the switch does not come ON at the position where the windows are almost fully open, the windows will not fully close as the jam protection operates at the upper portion during the automatic UP performance. Driver's Door/Passenger's Door ECU. The next data monitor is possible when the power window operated with Manual UP during the Active Test. See «INSPECTING DRIVER'S DOOR/PASSENGER'S DOOR ECU DATA LIST»(ref-152599-S36603139182003021400000) table. INSPECTING DRIVER'S DOOR/PASSENGER'S DOOR ECU DATA LIST Item Measurement Item/Display (Range) Normal Condition GRASS POS-1/4 To Monitor The Detection Of Something Caught In The P/W / OK Or CAUTION (Displayed During Active Test) OK: Nothing Caught In The Range Between Fully Open & 1/4 Open (1) GRASS POS-2/4 To Monitor The Detection Of Something Caught In The P/W / OK Or CAUTION (Displayed During Active Test) OK: Nothing Caught In The Range Between Fully 1/4 Open & 2/4 Open (1) GRASS POS-3/4 To Monitor The Detection Of Something Caught In The P/W / OK Or CAUTION (Displayed During Active Test) OK: Nothing Caught In The Range Between Fully 2/4 Open & 3/4 Open (1) GRASS POS-OPEN To Monitor The Detection Of Something Caught In The P/W / OK Or CAUTION (Displayed During Active Test) OK: Nothing Caught In The Range Between Fully 3/4 Open & Open (1) (1) In case that the CAUTION is displayed even without applying resistance in each range, there must be something caught somewhere in that range.
  6. Perform the ACTIVE TEST. Connect the OBD II scan tool or the hand-held tester to the DLC3. Turn the ignition switch ON. According to the display on the tester, perform the ACTIVE TEST: Driver's Door/Passenger's Door ECU. See «INSPECTING DRIVER'S DOOR/PASSENGER'S DOOR ECU ACTIVE TEST»(ref-152599-S29374281222003021400000) table. INSPECTING DRIVER'S DOOR/PASSENGER'S DOOR ECU ACTIVE TEST Item Test Details Diagnostic Note P/W UP/DOWN Drive The P/W Motor UP/DOWN During This ACTIVE TEST, Jam Protection/Something Caught Detection Can Be Monitored (1) (1) For details, refer to «INSPECTING DRIVER'S DOOR/PASSENGER'S DOOR ECU DATA LIST»(ref-152599-S36603139182003021400000) table. Rear Left Hand Door/Rear right hand Door Body ECU. See «INSPECTING REAR LH DOOR/REAR RH DOOR ECU ACTIVE TEST»(ref-152599-S36848021552003021400000) table. INSPECTING REAR LH DOOR/REAR RH DOOR ECU ACTIVE TEST Item Test Details RL P/W Drive The RL P/W Motor UP/DOWN RR P/W Drive The RR P/W Motor UP/DOWN

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Using Hand-Held Tester

  1. Hook up the hand-held tester to the DLC3. (Scheme 21)
  2. Monitor the ECU data by following the prompts on the tester screen. The hand-held tester has a Snapshot function which records the monitored data. Please refer to the hand-held tester operator's manual for further details.

Scheme 21

Scheme 21
Scheme 21

SYSTEM TESTS

SymptomPerform Test
Power Window Cannot Be Operated By Operation Interlocked With Key (Only Driver's Door)A

SYMPTOM INDEX

TERMINALS OF ECU

Note. Perform tests in the order listed.

Driver Door ECU (Power Window Regulator Master Switch)

  1. Disconnect the connector. See «CONNECTOR IDENTIFICATION»(ref-152599-S42233421132003021400000) .
  2. Inspect the voltage and continuity of each terminal of the vehicle's side connector. See «INSPECTING DRIVER DOOR ECU VOLTAGE & CONTINUITY»(ref-152599-S32006894532003021400000) table. If the value is not as specified, there may be a malfunction in the vehicle's side. INSPECTING DRIVER DOOR ECU VOLTAGE & CONTINUITY Tester Connection Wiring Color Condition (Specified Condition) 2 (E) - Body Ground White/Black - Body Ground Constant (Continuity) 10 (BDR) - 2 (E) Blue/White - White/Black Constant (10-14 Volts) 9 (CPUB) - 2 (E) White/Red - White/Black Constant (10-14 Volts) 20 (SIG) - 2 (E) Black/Red - White/Black Ignition Switch OFF To ON (0 Volt - 10-14 Volts) 11 (MDN) - 1 (MUP) Red - Green Constant (Continuity) 5 (LMT) - 13 (SGND) Light Green/Black - White/Black Driver's Side Door Glass Fully Closed (No Continuity) 5 (LMT) - 13 (SGND) Light Green/Black - White/Black Driver's Side Door Glass Opened By .157 in. (4 mm) (Continuity
  3. Connect the connector and inspect the voltage between each terminal of the connector. See «INSPECTING DRIVER DOOR ECU VOLTAGE»(ref-152599-S41099055102003021400000) table. If the value is not as specified, replace the master switch. See «POWER WINDOW MASTER SWITCH»(ref-152599-S22926261652003021800000) under REMOVAL & INSTALLATION. INSPECTING DRIVER DOOR ECU VOLTAGE Tester Connection, Wiring Color Condition (Specified Condition) 1 (MUP) - 2 (E), Green - White/Black Ignition Switch ON, Master Switch Driver's Side Switch OFF To UP/Manual Operation (0 Volt - 10-14 Volts) 1 (MUP) - 2 (E), Green - White/Black Ignition Switch ON, Driver's Side Door Glass Fully Opened, Master Switch Driver's Side Switch UP (Auto Operation) To Door Fully Closed (0 Volt - 10-14 Volts - 0 Volt) 11 (MDN) - 2 (E), Red - White/Black Ignition Switch ON, Master Switch ON, Master Switch Driver's Side Switch OFF To DOWN/Manual Operation (0 Volt - 10-14 Volts) 11 (MDN) - 2 (E), Red - White/Black Ignition Switch ON, Driver's Side Door Glass Fully Closed, Master Switch Driver's Side Switch OFF To DOWN (Auto Operation) To Door Glass Fully Opened (0 Volt - 10-14 Volts - 0 Volt) 6 (WLSW) - 2 (E), Gray - White/Black Ignition Switch ON, Window Lock Switch LOCK To NORMAL (0 Volt - 10-14 Volts)

Passenger Door ECU (Power Window Regulator Switch)

  1. Disconnect the connector. See «CONNECTOR IDENTIFICATION»(ref-152599-S42233421132003021400000) .
  2. Inspect the voltage and continuity of each terminal of the vehicle's side connector. See «INSPECTING PASSENGER DOOR ECU VOLTAGE & CONTINUITY»(ref-152599-S21524747752003021400000) table. If the value is not as specified, there may be a malfunction in the vehicle's side. INSPECTING PASSENGER DOOR ECU VOLTAGE & CONTINUITY Tester Connection Wiring Color Condition (Specified Condition) 2 (E) - Body Ground White/Black - Body Ground Constant (Continuity) 10 (BDR) - 2 (E) Blue/Orange - White/Black Constant (10-14 Volts) 9 (CPUB) - 2 (E) White/Red - White/Black Constant (10-14 Volts) 11 (MDN) - 1 (MUP) Red - Green Constant (Continuity) 5 (LMT) - 13 (SGND) Light Green/Black - White/Black Passenger's Side Door Glass Fully Closed (No Continuity) 5 (LMT) - 13 (SGND) Light Green/Black - White/Black Passenger's Side Door Glass Opened By .157 in. (4 mm) (Continuity)
  3. Connect the connector and inspect the voltage between each terminal of the connector. See «INSPECTING PASSENGER DOOR ECU VOLTAGE»(ref-152599-S14710642712003021400000) table. If the value is not as specified, replace the regulator switch. See «POWER WINDOW MASTER SWITCH»(ref-152599-S22926261652003021800000) under REMOVAL & INSTALLATION. INSPECTING PASSENGER DOOR ECU VOLTAGE Tester Connection, Wiring Color Condition (Specified Condition) 1 (MUP) - 2 (E), Green - White/Black Ignition Switch ON, Regulator Switch Passenger's Side Switch OFF To UP/Manual Operation (0 Volt - 10-14 Volts) 1 (MUP) - 2 (E), Green - White/Black Ignition Switch ON, Passenger's Side Door Glass Fully Opened, Regulator Switch Passenger's Side Switch UP (Auto Operation) To Door Fully Closed (0 Volt - 10-14 Volts - 0 Volt) 11 (MDN) - 2 (E), Red - White/Black Ignition Switch ON, Master Switch Driver's Side Switch OFF To DOWN/Manual Operation (0 Volt - 10-14 Volts) 11 (MDN) - 2 (E), Red - White/Black Ignition Switch ON, Passenger's Side Door Glass Fully Closed, Regulator Switch Passenger's Side Switch OFF To DOWN (Auto Operation) To Door Glass Fully Opened (0 Volt - 10-14 Volts - 0 Volt) 6 (PCT) - 2 (E), Gray - White/Black Ignition Switch ON, Window Lock Switch LOCK To NORMAL (0 Volt - 10-14 Volts)

Left Hand Rear Power Window Regulator Switch

  1. Disconnect the connector. See «CONNECTOR IDENTIFICATION»(ref-152599-S42233421132003021400000) .
  2. Inspect the voltage and continuity of each terminal of the vehicle's side connector. See «INSPECTING LH REAR POWER WINDOW REGULATOR SWITCH VOLTAGE & CONTINUITY»(ref-152599-S02392256312003021400000) table. If the value is not as specified, there may be a malfunction in the vehicle's side. INSPECTING LH REAR POWER WINDOW REGULATOR SWITCH VOLTAGE & CONTINUITY Tester Connection Wiring Color Condition (Specified Condition) 7 (GND) - Body Ground White/Black - Body Ground Constant (Continuity) 12 (BDR) - 7 (GND) White/Blue - White/Black Constant (10-14 Volts) 1 (MDN) - 6 (MUP) Green/Red - Red Constant (Continuity) 10 (E) - 7 (GND) White/Black - White/Black Constant (Continuity) 3 (LMT) - 7 (GND) Light Green - Green/Yellow Rear Left Hand Side Door Glass Fully Closed (No Continuity) 3 (LMT) - 7 (GND) Light Green - Green/Yellow Rear Left Hand Side Door Glass Opened By .157 in. (4 mm) (Continuity)
  3. Connect the connector and inspect the voltage between each terminal of the connector. See «INSPECTING LH REAR POWER WINDOW REGULATOR SWITCH VOLTAGE»(ref-152599-S06449922322003021700000) table. If the value is not as specified, replace the regulator switch. See step 1) of «POWER WINDOW REGULATOR MOTOR (REAR DOOR)»(ref-152599-S09204373842003021800000) under REMOVAL & INSTALLATION. INSPECTING LH REAR POWER WINDOW REGULATOR SWITCH VOLTAGE Tester Connection, Wiring Color Condition (Specified Condition) 6 (MUP) - 7 (GND), Green - White/Black Ignition Switch ON, Left Hand Side Regulator Switch OFF - UP/Manual Operation (0 Volt - 10-14 Volts) 6 (MUP) - 7 (GND), Green - White/Black Ignition Switch ON, Rear Left Hand Side Door Glass Fully Opened, Left Hand Side Rear Regulator Switch UP (Auto Operation) - Door Glass Fully Closed (0 Volt - 10-14 Volts - 0 Volt) 1 (MDN) - 7 (GND), Red - White/Black Ignition Switch ON, Left Hand Side Rear Regulator Switch OFF - DOWN/Manual Operation (0 Volt - 10-14 Volts) 1 (MDN) - 7 (GND), Red - White/Black Ignition Switch ON, Rear Left Hand Side Door Glass Fully Closed, Left Hand Side Rear Regulator Switch OFF - DOWN (Auto Operation) - Door Glass Fully Opened (0 Volt - 10-14 Volts - 0 Volt) 11 (PCT) - 7 (GND), Gray - White/Black Ignition Switch ON, Window Lock Switch LOCK - NORMAL (0 Volt - 10-14 Volts)

Right Hand Rear Power Window Regulator Switch

  1. Disconnect the connector. See «CONNECTOR IDENTIFICATION»(ref-152599-S42233421132003021400000) .
  2. Inspect the voltage and continuity of each terminal of the vehicle's side connector. See «INSPECTING RH REAR POWER WINDOW REGULATOR SWITCH VOLTAGE & CONTINUITY»(ref-152599-S40529624802003021700000) table. If the value is not as specified, there may be a malfunction in the vehicle's side. INSPECTING RH REAR POWER WINDOW REGULATOR SWITCH VOLTAGE & CONTINUITY Tester Connection Wiring Color Condition (Specified Condition) 7 (GND) - Body Ground White/Black - Body Ground Constant (Continuity) 12 (BDR) - 7 (GND) Blue/White - White/Black Constant (10-14 Volts) 1 (MDN) - 6 (MUP) Red - Green Constant (Continuity) 3 (LMT) - 7 (GND) Light Green/Black - White/Black Rear Right Hand Side Door Glass Fully Closed (No Continuity) 3 (LMT) - 7 (GND) Light Green/Black - White/Black Rear Right Hand Side Door Glass Opened By .157 in. (4 mm) (Continuity)
  3. Connect the connector and inspect the voltage between each terminal of the connector. See «INSPECTING RH REAR POWER WINDOW REGULATOR SWITCH VOLTAGE»(ref-152599-S12535670192003021700000) table. If the value is not as specified, replace the regulator switch. See step 1) of «POWER WINDOW REGULATOR MOTOR (REAR DOOR)»(ref-152599-S09204373842003021800000) under REMOVAL & INSTALLATION. INSPECTING RH REAR POWER WINDOW REGULATOR SWITCH VOLTAGE Tester Connection, Wiring Color Condition (Specified Condition) 6 (MUP) - 7 (GND), Green - White/Black Ignition Switch ON, Right Hand Side Regulator Switch OFF - UP/Manual Operation (0 Volt - 10-14 Volts) 6 (MUP) - 7 (GND), Green - White/Black Ignition Switch ON, Rear Right Hand Side Door Glass Fully Opened, Right Hand Side Rear Regulator Switch UP (Auto Operation) - Door Glass Fully Closed (0 Volt - 10-14 Volts - 0 Volt) 1 (MDN) - 7 (GND), Red - White/Black Ignition Switch ON, Right Hand Side Rear Regulator Switch OFF - DOWN/Manual Operation (0 Volt - 10-14 Volts) 1 (MDN) - 7 (GND), Red - White/Black Ignition Switch ON, Rear Right Hand Side Door Glass Fully Closed, Right Hand Side Rear Regulator Switch OFF - DOWN (Auto Operation) - Door Glass Fully Opened (0 Volt - 10-14 Volts - 0 Volt) 11 (PCT) - 7 (GND), Gray - White/Black Ignition Switch ON, Window Lock Switch LOCK - NORMAL (0 Volt - 10-14 Volts)

Driver Side Junction Block

  1. Disconnect the body ECU connectors 2A, 2B, 2D, 2G and 2K. See «CONNECTOR IDENTIFICATION»(ref-152599-S42233421132003021400000) .
  2. Inspect the voltage and continuity of each terminal of the vehicle's side connector. See «INSPECTING DRIVER SIDE JUNCTION BLOCK VOLTAGE & CONTINUITY»(ref-152599-S26396207232003021700000) table. If the value is not as specified, there may be a malfunction in the vehicle's side. INSPECTING DRIVER SIDE JUNCTION BLOCK VOLTAGE & CONTINUITY Tester Connection Wiring Color Condition (Specified Condition) 2K-11 (B) - 2D-3 (GND) White/Red - White/Black Constant (10-14 Volts) 2H-6 (ACC) - 2D-3 (GND) Blue/Red - White/Black Constant (10-14 Volts) 2G-14 (BDR1) - 2D-3 (GND) Blue/White - White/Black Constant (10-14 Volts) 2H-2 (BDR2) - 2D-3 (GND) White/Black - White/Black Constant (10-14 Volts) 2B-11 (SGND) - Body Ground White/Black - Body Ground Constant (0 Volt - 10-14 Volts) 2A-11 (SGND) - 2D-3 Body Ground White/Black - Body Ground Constant (Continuity) 2D-3 (GND) - Body Ground White/Black - Body Ground Constant (Continuity)

Multiplex Network Body ECU

  1. Disconnect the body ECU connector B4. See «CONNECTOR IDENTIFICATION»(ref-152599-S42233421132003021400000) . See «INSPECTING MULTIPLEX NETWORK BODY ECU CONTINUITY»(ref-152599-S10404446342003021700000) table. If the value is not as specified, there may be a malfunction in the vehicle's side. INSPECTING MULTIPLEX NETWORK BODY ECU CONTINUITY Tester Connection Wiring Color Condition (Specified Condition) B4-19 (KSW) - Body Ground Blue - Body Ground No Key In The Ignition Key Cylinder - With Key (No Continuity - Continuity)
  2. Connect the body ECU connector B4. See «INSPECTING MULTIPLEX NETWORK BODY ECU VOLTAGE»(ref-152599-S39238647062003021700000) table. If the value is not as specified, replace the regulator switch. See «POWER WINDOW MASTER SWITCH»(ref-152599-S22926261652003021800000) under REMOVAL & INSTALLATION. INSPECTING MULTIPLEX NETWORK BODY ECU VOLTAGE Tester Connection Wiring Color Condition (Specified Condition) B6-1 (DCTY) - Body Ground Red/Green - Body Ground Driver's Door CLOSED - OPEN (10-14 Volts - Below 0 Volt)

POWER WINDOW MASTER SWITCH

Note. Passenger door power window switch removal and installation is the same as the driver door power window master switch.
