COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Body ECU (Driver Side Junction Block) | (1) |
| DOOR 1 Fuse | (2) |
| DOOR 2 Fuse | (3) |
| Driver Door ECU (Power Window Regulator Master Switch) | (1) (4) |
| ECU-IG Fuse | (3) |
| Window Regulator (Front Door) | (4) |
| Window Regulator (Rear Door) | (5) |
| Passenger Door ECU (Power Window Regulator Switch) | (1) |
| Power Window Regulator Motors | (1) (4) (5) |
| Power Window Regulator Switch (Rear Door) | (5) |
| (1) (Scheme 16) (2) Located in the engine room junction block in the left engine compartment. (3) Located in the driver side junction block in the lower finish panel. (4) (Scheme 17) (5) (Scheme 18) | |
| (1) | (Scheme 16) |
| (2) | Located in the engine room junction block in the left engine compartment. |
| (3) | Located in the driver side junction block in the lower finish panel. |
| (4) | (Scheme 17) |
| (5) | (Scheme 18) |
