SPECIFICATION
| Description | Nm |
|---|---|
| Heater core inlet and outlet pipe retaining screws | 10 |
| Heater core and evaporator core housing retaining nuts | 8 |
| In-vehicle crossbeam to bulkhead retaining nuts | 25 |
| In-vehicle crossbeam to bulkhead retaining bolts | 25 |
| Heater core and evaporator core housing to bulkhead retaining nuts | 10 |
TORQUE SPECIFICATIONS
Scheme 77
| Item Number | Description |
|---|---|
| 1 | Forced ventilation outlet |
| 2 | Windshield duct |
| 3 | Face level duct |
| 4 | Front footwell duct |
| 5 | Heater assembly |
| 6 | Rear footwell duct |
| 7 | Rear face duct |
| 8 | Rear blower |
