OVERVIEW
The heating and ventilation system controls the temperature and flow of air supplied to the vehicle interior. The system consists of
- An air inlet duct.
- A heater.
- A rear blower.
- Two ventilation outlets.
Fresh or recirculated air flows into the heater from the inlet duct. The blower, and ram effect when the vehicle is moving, forces the air through the heater. Air from the cabin exhausts through the ventilation outlets.
Some vehicles may be fitted with a 4 zone climate control system. Refer to Auxiliary Climate Control .
Scheme 78
| Item Number | Description |
|---|---|
| 1 | Air outlet to heater assembly |
| 2 | Fixing lug |
| 3 | Door catch |
| 4 | Door |
| 5 | Particle or particle/odor filter |
| 6 | Inlet grille |
| 7 | Seal |
The air inlet duct directs fresh air from above the hood into the heater. The air inlet duct is centrally mounted on the engine bulkhead, below a ventilation grill in the hood, and secured to the bulkhead closing panels.
The cabin air filter is installed in the air inlet duct behind a hinged door. Refer to Air Distribution and Filtering .
