Auxiliary Climate Control: Specifications Land Rover Range Rover III facelift

Automatic HVAC System 1 illustration

SPECIFICATION

DescriptionNm
Auxiliary climate control assembly bolts4
Auxiliary climate control sealing plate bolts4
Air conditioning (A/C) pipe bolts9

Scheme 54

Scheme 54: COMPONENT LOCATION
Scheme 54: COMPONENT LOCATION
Item NumberDescription
1Rear climate control module
2Evaporator
3Refrigerant lines
4Rear climate control panel
5Magnetic valve
